Revo AC-SSW200 User manual

AC-SSW200
AC-SSB200
Wired/
Bluetooth
Selfie
Stick
for Smartphones

Thank you for choosing Revo.
The Revo Bluetooth and Wired Selfie
Sticks are designed to add up to 28″of
reach for anyone taking pictures with
their smartphone. It connects with
your iPhone or Android phone via an
integrated cable (AC-SSW200) or
Bluetooth (AC-SSB200) and allows
you to control the camera while
experimenting with creative angles.
The shutter button on the handle
triggers the camera so you can
experiment with high- or low-angle
shooting. These selfie sticks feature a
rubber-coated, spring-loaded clip that
securely grips your phone and allows
for adjustable camera angles. The
padded, rubber-coated handle is easy
to hold, and the stick conveniently
folds down to a compact 7″length for
easy transport. A USB cable is
included (AC-SSB200 only) and
connects to any powered USB port for
swift recharging.
Specifications
Weight: 4.8 oz. (136 g)
Folded length: 7ʺ(17.8 cm)
Extended length: 28ʺ(71.1 cm)
Camera clip maximum width: 3ʺ(7.6 cm)
Compatibility: iOS 5.0 or later, Android
4.2.2 or later
Connector: 1/8ʺ(3.5 mm) mini plug
(AC-SSW200 only)
USB cable connectors: USB Standard-A to
Micro-B (AC-SSB200 only)
Precautions
•Please read and follow these instructions,
and keep this manual in a safe place.
•Clean the unit with only a soft, dry cloth.
•Make sure the item is intact and that
there are no missing parts.
•All images are for illustrative purposes only.

Components
Wrist strap
Telescoping
shaft
Locking knob
Camera clip
Clip tab
Shutter button
LED - Bluetooth/battery
indicator (AC-SSB200 only)
USB cable
(AC-SSB200 only)
Mini plug & cable
(AC-SSW200 only)
Micro USB port
(AC-SSB200 only)

Inserting Your Phone
1. Place the phone so that one side
rests on the bottom of the clip.
2. Pull the clip tab to widen the
opening until the phone fits into the
clip, and release the tab.
Important! Make sure that the clip is
not making contact with any of the
control buttons on the side of the
phone.
Attaching the Wrist Strap
1. Thread the end of the strap through
the strap hole, located at the base
of the handle.
2. Pull the other end of the strap
through the loop of the threaded
end.

Pairing via Bluetooth (AC-SSB200 only)
To connect your smartphone to the
AC-SSB200 via Bluetooth, follow
these steps:
1. Press the shutter button for
approximately three seconds. The
blue LED in the button will blink to
indicate that it is in Bluetooth
pairing mode.
2. Open the settings on your phone
and turn Bluetooth on. Your phone
will enter discover mode. In a few
seconds, you will see Revo
AC-SSB200 appear in the device list.
3. Select Revo AC-SSB200 in the
device list. Your phone will indicate
when it is paired, and the LED in
the button will glow a steady blue to
indicate that the AC-SSB200 is
paired.
To disconnect your phone, press and
hold the shutter button for three
seconds. The LED will turn off, and
your phone will indicate that it is not
connected.
Connecting via Cable (AC-SSW200 only)
1. Mount the phone into the clip (see
instructions for Inserting Your Phone.)
2. Connect the mini plug to the
headphone jack on your phone.

Taking pictures
Once your smartphone has been
paired via Bluetooth or plugged into
the Selfie Stick, you’re ready to start
taking pictures.
1. Open the camera app on your phone.
2. Press the shutter button on the handle
of the Selfie Stick to take a picture.
Charging the battery (AC-SSB200 only)
A USB cable is included to recharge
the battery in your Selfie Stick.
1. Plug the Micro USB connector into
the Micro USB port on the base of
the handle.
2. Plug the USB Standard-A
connector into a powered USB port
on a computer or USB charger. The
LED indicator next to the Micro USB
port will glow while the battery is
recharging.
3. The LED will turn off when the
battery is fully charged.
Note: The battery will operate for approximately
20 hours when fully charged. If you plan to use
your Selfie Stick for an extended period of time,
fully charge the battery before use.
Adjusting the Selfie Stick
1. Loosen the locking knob, adjust the
phone to the desired angle, and
tighten the knob.
2. Hold the handle firmly and pull the
camera and clip to extend the stick
to the desired length.

One-Year Limited Warranty
This Revo product is warranted to the
original purchaser to be free from defects in
materials and workmanship under normal
consumer use for a period of one (1) year
from the original purchase date or thirty
(30) days after replacement, whichever
occurs later. The warranty provider’s
responsibility with respect to this limited
warranty shall be limited solely to repair or
replacement, at the provider’s discretion, of
any product that fails during normal use of
this product in its intended manner and in
its intended environment. Inoperability of
the product or part(s) shall be determined
by the warranty provider. If the product has
been discontinued, the warranty provider
reserves the right to replace it with a model
of equivalent quality and function.
This warranty does not cover damage or
defect caused by misuse, neglect, accident,
alteration, abuse, improper installation or
maintenance. EXCEPT AS PROVIDED
HEREIN, THE WARRANTY PROVIDER
MAKES NEITHER ANY EXPRESS
WARRANTIES NOR ANY IMPLIED
WARRANTIES, INCLUDING BUT NOT
LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. This warranty
provides you with specific legal rights, and
you may also have additional rights that
vary from state to state.
To obtain warranty coverage, contact the
Revo Customer Service Department to
obtain a return merchandise authorization
(“RMA”) number, and return the defective
product to Revo along with the RMA
number and proof of purchase. Shipment of
the defective product is at the purchaser’s
own risk and expense.
For more information or to arrange service,
visit www.revocinegear.com or call
Customer Service at 212-594-2353.
