Reyee RG-EW Series User manual

Reyee RG-EW Series Routers
Web-Based Configuration Guide

Copyright Statement
Reyee Networks©2021
Reyee Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification,
transmission, translation or commercial use of this document or any portion of this document, in any form or by any means,
without the prior written consent of Reyee Networks is prohibited.
Exemption Statement
This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain
the latest information through the Reyee Networks website. Reyee Networks endeavors to ensure content accuracy and
will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

Preface
Thank you for using our products.
Audience
This manual is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Obtaining Technical
Assistance
Reyee Networks Website: https://www.ireyee.com/
Technical Support Email: [e-mail]
Related Documents
Documents Description
Command Reference Describes the related configuration commands, including command modes,
parameter descriptions, usage guides, and related examples.
Hardware Installation and Reference
Guide
Describes the functional and physical features and provides the device
installation steps, hardware troubleshooting, module technical specifications,
and specifications and usage guidelines for cables and connectors.
Conventions
This manual uses the following conventions:
Convention Description
boldface font Commands, command options, and keywords are in boldface.
italic font Arguments for which you supply values are in italics.
[ ] Elements in square brackets are optional.

{ x | y | z } Alternative keywords are grouped in braces and separated by vertical bars.
[ x | y | z ] Optional alternative keywords are grouped in brackets and separated by
vertical bars.

Configuration Guide Overview
1 Overview
eWeb is a Web-based network management system that manages or configures devices. You can access eWeb via
browsers such as Google Chrome.
Web-based management involves a Web server and a Web client. The Web server is integrated in a device, and is used to
receive and process requests from the client, and return processing results to the client. The Web client usually refers to a
browser, such as Google Chrome IE, or Firefox.
1.1 Conventions
In this document, texts in bold are names of buttons (for example, OK) or other graphical user interface (GUI) elements (for
example, ARP List).
1

Configuration Guide Configuration Guide
2 Configuration Guide
2.1 Preparation
Scenario
As shown in the figure below, an administrator can access the device from a browser and configure the device through the
eWeb management system.
Figure 2-1-1 Data Exchange Principle
Deliver or request
commands
through AJAX.
Administrator Return data
Web
service
Device
Remarks The eWeb management system combines various device commands and then delivers them to the device
through AJAX requests. The device then returns data based on the commands. A Web service is available on the
device to process basic HTTP protocol requests.
Deployment
Configuration Environment Requirements
Client requirements:
An administrator can log into the eWeb management system from a Web browser to manage devices. The client refers
to a PC or some other mobile endpoints such as laptops or tablets.
Google Chrome, Firefox, IE10.0 and later versions, and some Chromium-based browsers (such as 360 Extreme
Explorer) are supported. Exceptions such as garble or format error may occur if an unsupported browser is used.
1024 x 768 or a higher resolution is recommended. If other resolutions are used, the page fonts and formats may not be
aligned and the GUI is less artistic, or other exceptions may occur.
The client IP address is set in the same LAN network as the device IP address, such as 192.168.110.X. The subnet
mask is 255.255.255.0. Alternatively, you can set the IP assignment mode to Obtain an IP address automatically or
enter ruiyi.cn into the address bar of the browser to access eWeb. The default gateway is device management address
192.168.110.1.
Server requirements:
The device is enabled with Web service (enabled by default).
2

Configuration Guide Configuration Guide
The device is configured with a management IP address (Default: 192.168.110.1). You can enter http://192.168.110.1
to access the eWeb management system.
To log into the eWeb management system, open the Google Chrome browser, and enter http://192.168.110.1 into the
address bar, and press Enter.
Figure 2-1-2 Login Page
Enter the password and click Login.
2.2 Wizard
You will enter the Wizard page without login at initial setup.
2.2.1 Welcome Page
The welcome page will appear when you configure the device for the first time.
3

Configuration Guide Configuration Guide
Figure 2-2-1 Welcome Page
The image shown here is for indicative purpose only. The actual product may differ.
The network status will be displayed when you configure the device for the second time.
Figure 2-2-2 Wizard Page
4

Configuration Guide Configuration Guide
If the network are configured with repeaters, their number is displayed. (In the above figure, X32G-PRO is the primary
router.)
2.2.2 Network Settings
When the device is not connected via network cables, the following page is displayed.
Figure 2-2-3 Network Settings
5

Configuration Guide Configuration Guide
2.2.2.1 Mesh Networking
The Mesh Networking function is enabled only when the device is new. Click Mesh Networking.to enable device
automatically connect to the primary router via a seamless roaming network.
Press Mesh Networking.
Figure 2-2-4 Mesh Networking 1
6

Configuration Guide Configuration Guide
Click Next.
Figure 2-2-5 Mesh Networking 2
7

Configuration Guide Configuration Guide
The result of mesh networking is displayed.
Figure 2-2-6 Result of Mesh Networking
8

Configuration Guide Configuration Guide
2.2.2.2 Wireless Repeating
To scan nearby Wi-Fi, click Wireless Repeating.
Figure 2-2-7 Wi-Fi List
9

Configuration Guide Configuration Guide
Select a Wi-Fi to be repeated.
Figure 2-2-8 Wireless Repeating 1
10

Configuration Guide Configuration Guide
Enter the Wi-Fi password of the primary router (This item will not be displayed if the primary router Wi-Fi is open).
Click Next to set the wireless information and management password of the device (This configuration applies to only new
devices).
Figure 2-2-9 Wireless Repeating 2
11

Configuration Guide Configuration Guide
Click Next to complete the configuration.
Figure 2-2-10 Completing Wireless Repeating Configuration
12

Configuration Guide Configuration Guide
2.2.2.3 Wired Repeating
When the device is connected via network cables, the wired repeater can be configured. (This option is ready for new
devices only).
Figure 2-2-11 Wired Repeating
13

Configuration Guide Configuration Guide
Click Check, and enter the local router SSID, password and management password.
Click Save to complete the configuration.
Figure 2-2-12 Wired Repeater Page
14

Configuration Guide Configuration Guide
Figure 2-2-13 Completing Configuration
15

Configuration Guide Configuration Guide
2.2.2.4 Internet
When the device is not configured with the repeating configuration, you can access the Internet through the following means:
If the device fails to access the Internet, the system will check IP assignment automatically. It is recommended to select
DHCP.
Figure 2-2-14 Normal Connection
16
