RF-Link WAVECOM Sr User manual

WAVECOMTM Sr. owner’s manual I
To the Users of WAVECOMTM Sr.
Important safety precautions
wTo prevent fire or shock hazard, do not expose this product to rain or moisture. Do not use near a
bath tub, wash bowl, sink, or laundry tub; do not use in a wet basement or in or around a swimming
pool.
wTo avoid electrical shock, do not open the case of this product.
wOperate this product using only the power supply included with it or provided as an accessory.
wDo not overload electrical outlets or extension cords as this can result in fire or electric shock.
wRefer servicing to qualified personnel only.
Caution: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Warranty Information
RF-Link Systems, Inc., referred to as “RF-Link” hereafter, warrants this product against any defects in
material or workmanship for a period of 90 days from the date of original purchase. This Limited
Warranty shall not apply if the product has been damaged due to abuse, misuse, misapplication, accident,
or as a result of service or modifications not approved by RF-Link. Should the product become
defective within the warranty period, RF-Link may choose to replace or repair the product, provided that
it is shipped prepaid to RF-Link.
There are no express warranties other than those described above. No warranties whether expressed or
implied, including but not limited to, any implied warranties of merchantability or fitness for a particular
purpose, shall extend beyond the time period listed above. Some states do not allow limitations on
how long an implied warranty may last, so the above limitations may not apply to all users. This
warranty gives specific legal rights; users may also have other rights which vary from state to state.
Disclaimer
This product is designed for lawful use as a wireless audio and video sender from one location in the
home or office to another location. RF-Link Systems Inc. hereby advises the consumer to consult with
local officials and other legal authorities regarding the proper use and application of this product in
compliance with all applicable state and federal laws. RF-Link Technology Inc. shall not be
responsible for any misuse or unlawful application of this product by any individual or entity under any
circumstances.

WAVECOMTM Sr. owner’s manualII
Table of Contents
CHAPTER 1. INTRODUCING...........................................................................1
PRODUCT OVERVIEW .............................................................................................1
LIST OF PACKAGED CONTENTS...............................................................................2
CONTROLS ANDFEATURES.....................................................................................3
CONTROLS ANDFEATURES.....................................................................................4
CHAPTER 2. SETTING UP UNITS...................................................................5
REQUIREMENTS .....................................................................................................5
CONNECTING THETRANSMITTER............................................................................6
How to transmit audio/video from your VCR.....................................................6
How to transmit audio/video from your cable TV hookup..................................7
How to transmit audio/video from your satellite receiver or laser disc player.....8
Howto transmit audio/video from your camcorder...........................................9
How to transmit audio/video from a miniature CCD camera...........................11
How to transmit audio/video from an audio/video (A/V) receiver ....................12
How to transmit audio from your stereo receiver.............................................13
How to transmit audio from your CD player or cassette deck..........................14
How to transmit audio/video from your computer...........................................15
CONNECTING THERECEIVER................................................................................16
How to receive wireless audio/video on your TV..............................................16
Connecting Receiver to Remote TV through VCR.............................................18
How to receive audio on your remote powered speakers..................................19
How to receive audio on any remote speakers.................................................20
How to receive audio/video from your computer.............................................21
ORIENTING UNITS FOR OPTIMAL PERFORMANCE ...................................................22
Orienting the audio/video antennas................................................................22
Orienting the Remote Control Antennas..........................................................24
CHAPTER 3. TROUBLESHOOTING............................................................25
PROBLEMS AND SOLUTIONS.................................................................................27
CARE ANDMAINTENANCE ...................................................................................27
SPECIFICATIONS ............................................................................................28
EC DECLARATION OF CONFORMITY..............................................................29
OTHER PRODUCTS BY RF-LINK................................................................30

WAVECOMTM Sr. owner’s manual 1
Chapter 1. Introducing
Product Overview
WAVECOMTM Sr.uses the latest in wireless communication technology to deliver
consistently sharp stereo audio and color video images up to 300 feet (FCC
approved version) and 750 feet (BZT approved version) away. By transmitting
at a very high frequency (2.4 GHz or 2.4 billion cycles per second), the
WAVECOMTM Sr. avoid the crowded 900 MHz band used by many cordless
telephones and other wireless audio/video transmitters. Its superior quality is
due to FM rather than AM signal modulation. In addition, the use of
state-of-the-art circular polarized directional transmitting and receiving antennas
maximizes the signal range and minimizes interference from unwanted signals.
With four independent channels, you can transmit up to four different audio/video
sources simultaneously using multiple pairs.
WAVECOMTM Sr. offer you greater convenience and security in many ways:
Convenience:
wWatch the movie you rent on any TV in your home or backyard without
running messy cable, moving your VCR/laser disc player or buying a second
unit.
wWatch cable or satellite programming on any TV in your home
wListen to stereo-quality music on any powered speakers inside or outside the
home
wReceive computer images and sound on a remote TV (additional equipment
required)
Safety & Security:
wMonitor your sleeping baby, children at play, the elderly, or the infirm on
your TV using your existing camcorder or miniature CCD camera (available
from RF-Link -see “Accessories” section)
wSee outside your door on your TV using a camcorder or miniature CCD camera
wFire, police, and security personnel can send real-time images of dangerous
situations back to a mobile base station or back-up partner through a miniature
CCD camera (portable battery also available)
wAnd many more uses!

WAVECOMTM Sr. owner’s manual2
List of Packaged Contents
The following elements should be included in the box. Please check that you have
them all before installation.
1. One transmitter (Transmitter)
Transmits 2.4 GHz wireless audio/video and
receives UHF remote control signal from
the receiver.
2. One receiver (Receiver)
Receives 2.4GHz wireless audio/video and
transmits UHF remote control signal back
to the transmitter.
3. Two audio/video (A/V) cables
Connect transmitter and receiver
to your audio/video components.
*For NTSC model, you can find
two RCA to RCA cables in this
box. For PAL model, you can
find two RCA to SCART cables in
this box.
4. Two power adapters
Provide +12 VDC power to units
5. Infrared extender mouse
Emits infrared remote control
signals towards your source
components.

WAVECOMTM Sr. owner’s manual 3
Controls and Features
Transmitter
Front View
Rear View
Remote control antenna
Receives UHF remote
control signals.
Indicator light
The indicator light should
be lit when the On/Off
switch is at On position.
Directional 2.4 GHz
antenna
Transmits and receives
audio and video signals.
Caution: Do not rotate
this antenna 360 degrees
or permanent damage to
both antenna and
mechanical stopper will
occur.
Remote control window
Infrared passes through this
to remotely control
audio/video signal source.
On/Off switch
12V DC OUT
12V power output jack
for approved accessory.
Channel selection switch
Use to find optimal
reception. Must select
same channel on both
transmitter and receiver.
IR mouse jack
Left audio jack (white)
Right audio jack (red)
Videojack(yellow)
12V DC IN
12V power adapter plug

WAVECOMTM Sr. owner’s manual4
Controls and Features
Transmitter
Front View
Rear View
Directional 2.4GHz
antenna
Transmits and receives
audio and video signals.
Caution: Do not ratate
this antenna 360 degrees
or permanent damage to
both antenna and
mechanical stopper will
occur.
Indicator light
The indicator light
should be lit when the
ON/OFF switch is at
ON position.
Remote control window
Transmits UHF remote
control signals.
Channel selection switch
Use to find optimal
reception. Must select
same channel on both
transmitter and receiver.
ON/OFF switch
Video jack (yellow)
Audio right jack (red)
Audio left jack (white)
5V DC OUT
For external channel 3/4
modulator. (Not included)
12V DC OUT
12V power output jack for
approved accessory.
12V DC IN
12V power adapter plug

WAVECOMTM Sr. owner’s manual 5
Chapter 2. Setting Up Units
Requirements
Using absolutely no wires, WAVECOMTM Sr. can send audio or video signals
from virtually any sound or picture source to any TV, video monitor or powered
speakers using the same connectors as your other electronics components.
To enjoy wireless video and audio, just connect the transmitter to whatever
picture or sound source you want to view or hear at another location, and then
connect the receiver to the TV, computer, or powered speakers in that other
location. Then turn on the power switch on both the transmitter and receiver and
you are ready to go wireless.
Send from any of the following sources:
Video Audio
wVCR wCompact Disc Player or Changer
wSatellite Receiver wStereo Receiver
wCable TV wCassette Deck
wLaser Disc Player
wDigital Video Disc
wWireless Cable
wCamcorder
wSecurity Camera (CCD)
wComputer
The following pages first show you how to connect the WAVECOMTM Sr.
transmitter to any of these source components and then demonstrate how and
where to connect and position the WAVECOMTM Sr. receiver.

WAVECOMTM Sr. owner’s manual6
Connecting the Transmitter
How to transmit audio/video from your VCR
Step 1. Make sure the WAVECOMTM Sr. ON/OFF switch is in the OFF position.
Connect one set of audio/video (A/V) cables to the A/V jacks of the
transmitter and to the A/V jacks on the back of your VCR labeled LINE
OUT. Be sure the yellow, red and white plugs match the yellow, red and
white jacks on both the VCR and the transmitter. If the VCR has only one
output for audio (mono sound only), connect the white plug to that single
audio output and to the transmitter’s AUDIO LEFT jack.
Step 2. Plug one end of the provided power adapter into the back of the
WAVECOMTM Sr. transmitter and the other end into any 120-volt wall
outlet. Turn the ON/OFF switch to on position and indicator light should
go on.
Step 3. If your VCR has only one set of A/V output jacks and you want to use it
with a nearby TV, connect coaxial cable from the single OUT port on your
VCR to the VHF/UHF IN port on your TV. (Note: In order to also view
cable transmission on that TV, connect your incoming cable TV source to
the single IN port of the VCR.)
Step 4. Locate and orient the transmitter according to the chapter of this manual
titled “Orienting Units for Optimal Performance.”

WAVECOMTM Sr. owner’s manual 7
How to transmit audio/video from your cable TV
hookup
To transmit your cable TV channels, you must have either a VCR or a cable converter
box. If you use a VCR, follow the instructions on the previous page for transmitting
from your VCR. To use your cable converter box, follow the instruction below.
Step 1. Make sure the WAVECOMTM Sr. ON/OFF switch is in the OFF position.
Connect one set of audio/video (A/V) cables to the A/V jacks of the
transmitter and to the A/V jacks on the back of your cable converter box.
Be sure the yellow, red and white plugs match the yellow, red and white
jacks on both the converter box and the transmitter. If the converter box
has only one output for audio (mono sound only), connect one white plug
to that single audio output and the other to transmitter’s AUDIO LEFT
jack.
Step 2. Plug one end of the provided power adapter into the back of the
WAVECOMTM Sr. transmitter and the other end into any 120-volt wall
outlet. Turn the ON/OFF switch to ON position and indicator light should
go on.
Step 3. To view your cable signal on a nearby TV, connect coaxial cable from the
single OUT port on the cable converter box to the VHF/UHF IN port on
your TV.
Step 4. Locate and orient the transmitter according to the chapter of this manual
titled “Orienting Units for Optimal Performance.”

WAVECOMTM Sr. owner’s manual8
How to transmit audio/video from your satellite
receiver or laser disc player
You can transmit audio/video either directly from your satellite receiver or laser disc
player, or by connecting them to your VCR. To transmit directly from your satellite
receiver or laser disc player, follow the instructions below.
Step 1. Make sure the WAVECOMTM Sr. ON/OFF switch is in the OFF position.
Connect one set of audio/video (A/V) cables to the A/V jacks of the
transmitter and to the AUDIO/VIDEO OUT jacks of the satellite receiver
or laser disc player. Be sure the yellow, red and white plugs match the
yellow, red and white jacks on both the satellite receiver/laser disc player
and the transmitter.
Step 2. Plug one end of the provided power adapter into the back of the
WAVECOMTM Sr. transmitter and the other end into any 120-volt wall
outlet. Turn the ON/OFF switch to ON position and indicator light should
go on.
Step 3. If your satellite receiver or laser disc player has only one set of A/V output
jacks, and you had to disconnect your TV from those jacks to connect
WAVECOMTM Sr., reconnect the TV by connecting coaxial cable from the
single VHF/UHF OUT port on the satellite receiver or laser disc player to
the VHF/UHF IN port on your TV.
Step 4. Locate and orient the transmitter according to the chapter of this manual
titled “Orienting Units for Optimal Performance.”

WAVECOMTM Sr. owner’s manual 9
How to transmit audio/video from your camcorder
In conjunction with a camcorder, WAVECOMTM Sr. becomes a portable wireless
security system. First, position the camcorder so that it views the scene you
wish to monitor, such as a sleeping baby, children at play, the elderly, or the
infirm. Then, follow the instructions below.
Step 1. Make sure the WAVECOMTM Sr. ON/OFF switch is in the OFF
position. Connect one set of audio/video (A/V) cables to the A/V jacks
of the transmitter and to the AUDIO/VIDEO jacks of the camcorder.
Be sure the yellow, red and white plugs match the yellow, red and white
jacks on both the camcorder and the transmitter. If the camcorder has
only one output for audio (mono sound only), connect the white plug to
that single audio output and to transmitter’s AUDIO LEFT jack.
(Note: with some camcorders, you may need to use an adapter patch
cord that comes with the camera.)
Step 2. Plug one end of the provided power adapter into the back of the
WAVECOMTM Sr. transmitter and the other end into any 120-volt wall
outlet. Turn the ON/OFF switch to ON position and indicator light
should go on.
Step 3. Locate and orient the transmitter according to the chapter of this manual
titled “Orienting Units for Optimal Performance.”

WAVECOMTM Sr. owner’s manual10

WAVECOMTM Sr. owner’s manual 11
How to transmit audio/video from a miniature CCD
camera
In conjunction with a miniature CCD camera (sold separately -see accessories),
WAVECOMTM Sr. becomes a portable wireless security system. First, fasten the CCD
camera to any object using its clip adapter so that it views the scene you wish to
monitor, such as a sleeping baby, children at play, the elderly, or the infirm. Then,
follow the instructions below.
Step 1. Plug the single end of the special plug adapter that comes with the
miniature CCD camera into the bottom of the camera.
Step 2. Make sure the WAVECOMTM Sr. ON/OFF switch is in the OFF position.
Insert the two A/V plugs on the other end of the plug adapter into the
transmitter’s jacks -the black one into the video jack and the red one into
the AUDIO LEFT jack.
Step 3. Insert the power plug from the special plug adapter into the 12V DC OUT
jack on the side of the transmitter. This provides power to the CCD
camera.
Step 4. Plug one end of the provided power adapter into the back of the
WAVECOMTM Sr. transmitter and the other end into any 120-volt wall
outlet. Turn the ON/OFF switch to ON position and indicator light should
go on.
Step 5. Locate and orient the transmitter according to the chapter of this manual
titled “Orienting Units for Optimal Performance.”

WAVECOMTM Sr. owner’s manual12
How to transmit audio/video from an audio/video
(A/V) receiver
Since most audio/video (A/V) receivers have multiple input and output ports, you can
easily transmit signals from several audio/video or audio-only components to a
remote location using WAVECOMTM Sr.. To transmit from your A/V receiver,
follow the instructions below.
Step 1. Use audio/video (A/V) cables to connect the LINE OUT ports on any of
the components you wish to enjoy in another location to the AUDIO IN
and VIDEO IN ports on the back of your A/V receiver.
Step 2. Make sure the WAVECOMTM Sr. ON/OFF switch is in the OFF position.
Connect one set of audio/video (A/V) cables to the A/V jacks of the
transmitter and to the AUDIO/VIDEO OUT jacks of the A/V receiver, Be
sure the yellow, red and white plugs match the yellow, red and white jacks
on both the A/V receiver and the transmitter.
Step 3. Plug one end of the provided power adapter into the back of the
WAVECOMTM Sr. transmitter and the other end into any 120-volt wall
outlet. Turn the ON/OFF switch to ON position and indicator light should
be go on.
Step 4. Locate and orient the transmitter according to the chapter of this manual
titled “Orienting Units for Optimal Performance.”
Step 5. To transmit audio/video from a particular component connected to the A/V
receiver, select that component to be the output from the A/V receiver.
Consult the owner’s manual of your A/V receiver for further instructions.

WAVECOMTM Sr. owner’s manual 13
How to transmit audio from your stereo receiver
To enjoy sound from your CD player, cassette deck or radio on speakers in another
room, you can connect WAVECOMTM Sr. to your stereo receiver. To use this
feature, you must connect either powered speakers or another amplifier to the
WAVECOMTM Sr. receiver at the remote site (see “Connecting the Receiver”).
Step 1. Make sure the WAVECOMTM Sr. ON/OFF switch is in the OFF position.
Connect one set of audio/video (A/V) cables to the two audio jacks (red and
white) of the transmitter and to the audio jacks on the back of your stereo
receiver labeled TAPE OUT. Be sure the red and white plugs match the
red and white jacks on both the stereo receiver and the transmitter. The
yellow video plug is not used.
Step 2. Plug on end of the provided power adapter into the back of the
WAVECOMTM Sr. transmitter and the other end into any 120-volt wall
outlet. Turn the ON/OFF switch to ON position and indicator light should
go on.
Step 3. Locate and orient the transmitter according to the chapter of this manual
titled “Orienting Units for Optimal Performance.”

WAVECOMTM Sr. owner’s manual14
How to transmit audio from your CD player or
cassette deck
Your can transmit audio either directly from your CD player or cassette deck, or you
can connect them to your stereo receiver. For either scenario, to enjoy audio on
remote speakers, you must connect either powered speakers or an amplifier to the
WAVECOMTM Sr. receiver at the remote site (see “Connecting the Receiver”).
Step 1. Make sure the WAVECOMTM Sr. ON/OFF switch is in the OFF position.
Connect one set of audio/video (A/V) cables to the two audio jacks (red and
white) of the transmitter and to the LINE OUT jacks of the CD player or
cassette player. Be sure the red and white plugs match the red and white
jacks on both the transmitter and the CD/cassette player. The yellow
video plug is not used.
Step 2. Plug one end of the provided power adapter into the back of the
WAVECOMTM Sr. transmitter and the other end into any 120-volt wall
outlet. Turn the ON/OFF switch to ON position and indicator light should
go on.
Step 3. Locate and orient the transmitter according to the chapter of this manual
titled “Orienting Units for Optimal Performance.”

WAVECOMTM Sr. owner’s manual 15
How to transmit audio/video from your computer
WAVECOMTM Sr. can send computer images and sounds to any TV in the home or
office using a sound card and a VGA-to-TV Converter (purchase both at your local
computer store). You also need a mini stereo phono plug-to-stereo RCA adapter
(purchase at your local electronics store). This feature allows you to send
presentations from your desktop or laptop computer to a large TV screen without
running wires between the two. First, insert the sound card into one of your
computer’s open slots. Then, follow the instructions below.
Step 1. Connect the monitor cable attached to your computer screen to the VGA
OUT plug on the VGA-to-TV Converter.
Step 2. Connect a VGA extension cable (comes with converter) to the VGA port
on the back of your CPU unit and to the VGA IN plug on the VGA-to-TV
Converter.
Step 3. Make sure the WAVECOMTM Sr. ON/OFF switch is in the OFF position.
Connect one yellow video plug of the audio/video (A/V) cables to the
VIDEO jack on the back of the VGA-to-TV Converter and to the VIDEO

WAVECOMTM Sr. owner’s manual16
jack on the back of the transmitter. The red and white audio plugs are not
used.
Step 4. Plug the mini stereo plug of the RCA adapter into your the card, and the
red and white A/V plugs into the AUDIO LEFT and AUDIO RIGHT jacks
on the back of the transmitter.
Step 5. Plug one end of the provided power adapter into the back of the
WAVECOMTM Sr. transmitter and the other end into any 120-volt wall
outlet. Turn the ON/OFF switch to ON position and indicator light should
go on.
Step 6. Locate and orient the transmitter according to the chapter of this manual
titled “Orienting Units for Optimal Performance.”
Connecting the Receiver
How to receive wireless audio/video on your TV
There are two ways to receive wireless audio/video signals on your remote TV
(TV in another location):
wConnect the receiver directly to the remote TV.
wConnect the receiver to a VCR, which is then connected to the TV.
If your TV has picture-in-picture capability, you can view any image transmitted
by WAVECOMTM Sr., such as your sleeping baby, on an inset picture while
enjoying other programming on the rest of the screen. Consult the owner’s manual
of your TV for instructions on using this capability.
Step 1. Make sure the WAVECOMTM Sr. ON/OFF switch is in the OFF

WAVECOMTM Sr. owner’s manual 17
position. If your TV has A/V jacks, connect one set of A/V cables to
the TV’s A/V jacks and to the A/V jacks on the receiver. Be sure the
yellow, red and white plugs match the yellow, red and white jacks on
both the TV and the receiver. If the TV has only a single jack for audio
input, connect the white plug to that jack.
Step 2. Follow Steps 4 and 5 on the following page.

WAVECOMTM Sr. owner’s manual18
Connecting Receiver to Remote TV through VCR
This setup enables you to record transmitted audio and video on your remote
VCR and also enjoy the picture and sound on a remote TV.
Step 1. Make sure the WAVECOMTM Sr. ON/OFF switch is in the OFF position.
Connect one set of audio/video (A/V) cables to the A/V jacks of the
receiver and to the jacks on your VCR labeled LINE IN. Be sure the
yellow, red and white plugs match the yellow, red and white jacks on both
the WAVECOMTM Sr. receiver and the VCR. If the VCR has only a single
jack for audio input, connect the white plug to it.
Step 2. If your TV has A/V input jacks, connect another set of A/V cables to the
TV’s A/V jacks and to the jacks on your VCR labeled LINE OUT.
Step 3. If your TV has only a single coaxial input port, connect a length of coaxial
cable from the TV’s VHF/UHF IN coaxial connector to the OUT coaxial
connector on your VCR. To watch cable channels on the TV, connect
your cable TV hookup to the IN coaxial connector on your VCR.
Step 4. Plug one end of the provided power adapter into the back of the
WAVECOMTM Sr. receiver and the other end into any 120-volt wall outlet.
Turn the ON/OFF switch to ON position and indicator light should go on.
Step 5. Locate and orient the WAVECOMTM Sr. receiver according to the chapter
of this manual titled “Orienting Units for Optimal Performance.”
