RGBlink RGB3X-EPTZ-BK User manual

EPTZ Educational Tracking Camera
RGB3X-EPTZ-BK
User Manual

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
1
Content
Declarations................................................................................................................................................................ 3
FCC/Warranty........................................................................................................................................................... 3
Operators Safety Summary....................................................................................................................................3
Installation Safety Summary.................................................................................................................................. 4
Chapter 1 Your Product............................................................................................................................................6
1.1 Product Overview.............................................................................................................................................. 6
1.2 Product Features............................................................................................................................................... 6
1.3 Interface.............................................................................................................................................................. 7
1.4 Dimension...........................................................................................................................................................8
Chapter 2 Install Your Product...............................................................................................................................9
2.1 System Connection........................................................................................................................................... 9
Chapter 3 Use Your Product................................................................................................................................. 11
3.1 Browser Login and Track Setup Process.................................................................................................... 11
3.1.1 Connecting Mode..................................................................................................................................... 11
3.2 Browser Login.................................................................................................................................................. 12
3.3 Browser Preview............................................................................................................................................. 12
3.4 Browser Configuration....................................................................................................................................13
3.4.1 Audio Configuration................................................................................................................................. 13
3.4.2 Video Configuration................................................................................................................................. 13
3.4.3 Network Configuration............................................................................................................................ 16
3.4.4 System Configuration..............................................................................................................................17
3.5 Logout............................................................................................................................................................... 18
3.6 Configure Tracking Parameter......................................................................................................................18
3.6.1 Teacher Tracking Configuration............................................................................................................ 18
3.7 Description of Recording and Broadcasting Host..................................................................................... 23
3.7.1 Auto Tracking Control..............................................................................................................................23
3.7.2 Action Code Docking...............................................................................................................................23
Chapter 4 Ordering Code...................................................................................................................................... 25
4.1 Product..............................................................................................................................................................25
Chapter 5 Support................................................................................................................................................... 26
5.1 Contact us........................................................................................................................................................ 26
Chapter 5 Appendix................................................................................................................................................ 27
6.1 Specification.....................................................................................................................................................27
6.2 VISCA Protocol List........................................................................................................................................ 28
6.2.1 Camera Return Command..................................................................................................................... 28
6.2.2 Camera Control Command.................................................................................................................... 28
6.2.3 Inquiry Command.................................................................................................................................... 31
6.3 Pelco-D Protocol Command List.................................................................................................................. 33

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
2
6.4 Pelco-P Protocol Command List...................................................................................................................33
6.5 Terms & Definitions......................................................................................................................................... 34
6.6 Revision History...............................................................................................................................................39

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
3
Thank you for choosing our product!
This User Manual is designed to show you how to use this camera quickly and make use of all the features.
Please read all directions and instructions carefully before using this product.
Declarations
FCC/Warranty
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area may cause
harmful interference, in which case the user will be responsible for correcting any interference.
Guarantee and Compensation
RGBlink provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of
guarantee. On receipt, the purchaser must immediately inspect all delivered goods for damage incurred
during transport, as well as for material and manufacturing faults. RGBlink must be informed immediately in
writing of any complains.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on
the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of compliant,
RGBlink can repair the fault or provide a replacement at its own discretion within an appropriate period. If this
measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the purchase price or
cancellation of the contract. All other claims, in particular those relating to compensation for direct or indirect
damage, and also damage attributed to the operation of software as well as to other service provided by RGBlink,
being a component of the system or independent service, will be deemed invalid provided the damage is not
proven to be attributed to the absence of properties guaranteed in writing or due to the intent or gross negligence
or part of RGBlink.
If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink, or if the
goods are handled incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the
transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the
purchaser will be rendered invalid. Not included in the guarantee coverage are system failures which are
attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as
well as normal maintenance are not subject to the guarantee provided by RGBlink either.
The environmental conditions as well as the servicing and maintenance regulations specified in this manual
must be complied with by the customer.
Operators Safety Summary
The general safety information in this summary is for operating personnel.
Do Not Remove Covers or Panels
There are no user-serviceable parts within the unit. Removal of the top cover will expose dangerous voltages.

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
4
To avoid personal injury, do not remove the top cover. Do not operate the unit without the cover installed.
Power Source
This product is intended to operate from a power source that will not apply more than 230 volts rms between
the supply conductors or between both supply conductor and ground. A protective ground connection by way of
grounding conductor in the power cord is essential for safe operation.
Grounding the Product
This product is grounded through the grounding conductor of the power cord. To avoid electrical shock, plug
the power cord into a properly wired receptacle before connecting to the product input or output terminals. A
protective-ground connection by way of the grounding conductor in the power cord is essential for safe operation.
Use the Proper Power Cord
Use only the power cord and connector specified for your product. Use only a power cord that is in good
condition. Refer cord and connector changes to qualified service personnel.
Use the Proper Fuse
To avoid fire hazard, use only the fuse having identical type, voltage rating, and current rating characteristics.
Refer fuse replacement to qualified service personnel.
Do Not Operate in Explosive Atmospheres
To avoid explosion, do not operate this product in an explosive atmosphere.
Installation Safety Summary
Safety Precautions
For all camera installation procedures, please observe the following important safety and handling rules to
avoid damage to yourself and the equipment.
To protect users from electric shock, ensure that the chassis connects to earth via the ground wire provided
in the AC power Cord.
The AC Socket-outlet should be installed near the equipment and be easily accessible.
Unpacking and Inspection
Before opening shipping box, inspect it for damage. If you find any damage, notify the shipping carrier
immediately for all claims adjustments. As you open the box, compare its contents against the packing slip. If you
find any shortages, contact your sales representative.
Once you have removed all the components from their packaging and checked that all the listed components
are present, visually inspect the system to ensure there was no damage during shipping. If there is damage, notify
the shipping carrier immediately for all claims adjustments.
Site Preparation
The environment in which you install your camera should be clean, properly lit, free from static, and have

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
5
adequate power, ventilation, and space for all components.
Electric Safety
Installation and operation must accord with electric safety standard
Polarity of power supply
The power supply of the product is DC12V, the max electrical current is 2A .Polarity of the power
supply as the following drawing.
Careful of installation
Never move the camera by seizing the camera head. Don’t rotate camera head by hand; otherwise,
mechanical trouble will occur.
This series item must be put on the smooth desk or platform, and it can not be installed slant ways;
If the camera is installed on TV or computer, the base can be fixed by four double-sided adhesive trays.
Don’t apply in corrosive liquid, as or solid environment to avoid the cover which is made up of organic
material.
To make sure no obstacle in rotation range.
Never power on before installation is completed.
Don’t disassemble discretionarily.
There are no parts that users can repair by themselves on this product. We are not responsible for any
unauthorized modification or dismantling.
Avoid Magnetic Interference
Magnetic field under specific frequency may affect this product image; this is Class A product. Application in
domestic environment may cause radio interference. Therefore, user should take corresponding measures.
Caution
If the power cord need to be extended, must only extend the cord connect to outlet 220V/110V. Do not
extend the DC 12V power cord, otherwise malfunction could be caused.

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
6
Chapter 1 Your Product
1.1 Product Overview
Educational tracking camera integrates with industry leading 4K ultra-definition imaging technology, image
encoding and decoding technology, video analysis technology and electronic PTZ control technology, and realizes a
single camera to output close-ups main stream, close-up sub-stream, panoramic main stream, panoramic
sub-stream and blackboard stream at the same time. Built-in high-speed processor and advanced image
processing and analysis algorithm, the camera can track and detect accurately and quickly, and fully meet the
requirements of various scenes of teaching recording and remote interactive teaching.
1.2 Product Features
●Intelligent lecturer tracking: Built-in leading image recognition and tracking algorithm, without any auxiliary
positioning camera or tracking host, it can also track the target stably, accurately and quickly.
●Strong anti-interference ability: Once the tracking target is locked, it will be free of disturbances of other
moving objects or projectors etc.
●Smooth tracking: The sensitivity of action can be adjusted and it will not be affected by target’s unobvious
movement or gestures.
●Strong environmental adaptability: The tracking performance is not affected by classroom’s size, shape or
seats layout.
●Intelligent director: Built-in intelligent director switching strategy;
●Multiple tracking modes: Support multiple tracking modes, including tracking mode, movie mode and area
tracking mode.
●Ultra HD: 1/2.8 inch high quality 4K CMOS sensor; support 1080P@30fps/25fps image output.
●Wide view angle and distortion-free lens: Using ultra wide-angle, distortion-free camera; supports 3X digital
zoom and EPTZ control at the same time;
●Low noise and high SNR: Low Noise CMOS effectively ensure high SNR of camera video. Advanced 2D/3D
noise reduction technology is used to further reduce the noise, while ensuring image sharpness.
●Multiple video compression: H.265, H.264, MJPEG;
●Multiple video outputs: Support SDI, USB3.0 and LAN (Gigabit);
●Multiple streams: Support five streams, simultaneously output close-up main stream, close-up sub-stream,
panoramic stream, panoramic sub-stream and blackboard writing stream;
●POE support: A single network cable can support power, control, and video output simultaneously, thus
simplifying wiring installation.
●Multiple installation: Wall mount and in-ceiling mount for options.
●Networking control interface: Controlling via Network can meet different deployment of various scenarios.
●Wide application: Lecturer capture, remote interactive teaching etc.

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
7
1.3 Interface
1. Camera Lens
5.SDI Interface
9. RS232/ RS485
2. Tripod Screw Hole
6. LAN Interface
10. Power Interface
3. Tripod Screw Hole
4. USB3.0 Interface
7. Reset button
8. A-IN
11. Power Indicator

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
8
1.4 Dimension

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
9
Chapter 2 Install Your Product
2.1 System Connection
Installation Layout
Teacher tracking camera is installed at place 1.6-2.1m from ground (distance from panoramic lens to ground), and
the distance from the blackboard is 5-9m. Teacher tracking camera should be installed near central axis of the
classroom as much as possible to get the best result of tracking camera shooting. (Support ceiling mounting)
System Wiring
The teaching tracking camera products provide a smart camera solution for education information field, and
customers can select all or some products as needed. Different combinations of products meet the demands of
customers’ in various scenarios.

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
10

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
11
Chapter 3 Use Your Product
3.1 Browser Login and Track Setup Process
3.1.1 Connecting Mode
Direct connection: Connect the camera via network cable to external Internet access of the PC
Internet connection mode: Connect the camera to Internet by Router or Switch and user can log in the device by
browser.
Note: Please do not put the power and network cable in places where can be easily touched to prevent video quality
lowered by unstable signal transmission due to poor contact of cables.
The computer must have the network segment where the camera IP address belong to. The device will not be
accessible if without the segment. I.E. The camera default IP address is 192.168.5.163, then segment 5 must be
added in the computer.
Specific steps are as below:
Firstly open the window of Local Area Connection Properties on computer, select the “Internet protocol version
4(TCP/IPv4)” as shown by picture on the left. Double click or click the property “Internet” protocol version 4
(TCP/IPv4)to enter into the Internet Protocol Version 4(TCP/IPv4) Properties window, select “Advanced” to enter
into the Advanced TCP/IP Setting and add IP and subnet mask in the IP browser as picture shown below. Click the
“Confirm” to finish the adding of IP segment. User can add the corresponding network segment according to the
revised IP address of the camera.
Note: The IP address to be added cannot be same with that of other computers or devices. The existence of this IP
address needs to be verified before adding.
To verify whether the network segment has been successfully added, click the “Start” and select “Operation” to
input cmd, then click OK and open DOS command window, type ping 192.168.5.26, press Enter key to display
information shown below, which means network segment adding is succeeded.
User can also to verify network connection as steps above mentioned after the finish of camera self-check. If IP is
default, open DOS command window and input 192.168.5.163, then press Enter key, It will show the message as
below, which means network connection is normal.

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
12
3.2 Browser Login
1) Web Client Login
Input the IP address 192.168.5.163 of the device in the address filed of browser and click Enter button to enter
into Web Client login page as below picture. User can login as administrator and normal user. If login as
administrator (Default User name/Password: admin), users can preview, playback, configuration and cancel in the
Web Client; If login in as normal user (Default User name/Password: user1 or user2), users can only preview,
playback and logout, no option for configuration.
Note: Web access support browsers: IE, 360 browsers, and other conventional browsers.
2) Language Selection
click Chinese/English in the upper right corner of the login page to select the language type of the web interface.
3.3 Browser Preview
After successful login into the management interface, it enter the video preview interface. In the preview screen,
users can control PTZ, zoom, focus, video capture, sound, focus, full screen and set the preset position, run, delete
and other operations.
1) Login as administrator
User name, password the default admin
PTZ control can be carried out, zoom, focus, video capture, sound, zoom, full screen and set the preset position,
run, and delete; you can preview, playback, configuration, logoff.
2) Login as normal user
Default User name/password: user1 or user2
PTZ control can be carried out, zoom, focus, video capture, sound, zoom, full screen and set the preset position,
run, and delete; you can preview, playback and logout.
Note: There are no configuration rights for normal user login.

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
13
3.4 Browser Configuration
Click Configuration to enter into the device parameters setting page
There are the following options: audio configuration, video configuration, network configuration and system
configuration, detailed description see the following table.
Menu
Explanation
Audio
configure
Including audio compressing format, sampling frequency, sampling precision,
compressing code rate settings etc.
Video
configure
Including video encoding, stream release, RTP broadcasting ,video parameters,
character-overlapping, character size, video output setting etc.
Network
configure
Including basic parameters, Ethernet, DNS, GB28181, wireless network setting etc.
System
configure
Including equipment property, system time, user management, version update,
reset, reboot device settings etc.
3.4.1 Audio Configuration
Switch: Choose to enable the audio or not. (default: off)
Compressing Format: Set audio compressing format and the device will reboot automatically after change (default
MP3, AAC, G.711A optional)
Sampling Frequency: Set sampling frequency and the device will reboot automatically after change (default 44100,
8000, 16000, 32000 and 48000 optional)
Sampling Precision: Set sampling precision (default 16bits)
Compressing Code Rate: Set audio compressing code rate (default 64bits, 32, 48, 96, 128bits optional)
Channel type: Set channel type (default mono, stereo optional)
Input Volume: Set the input volume (default 2, 1-10 optional)
Click “Save”, it will remind ”Enable has changed. Restart the device to take effect after the success of the save.”,
then please reboot the camera to make new setting effect.
3.4.2 Video Configuration
1) Video Encoding
Code stream: Different video output mode setting, use different streams. (close-up main stream, close-up
sub-stream, panoramic main stream, panoramic sub-stream, and broadcast code stream)
Compression Format: Set the video compression format, save and reboot to take it effect (main / secondary
stream default: H.264, H.265 optional)
Profile: Set Profile mode (default HP, BP, MP optional）
Video Size: Set video image resolution, save and reboot to take it effect (close-up main stream default 1920*1080,
1280*720, 640*480 optional; close-up sub-stream default 320*180，320*240,640*360, 640*480, 1280*720
optional; panoramic main stream default 1920*1080，1280*720,640*480 optional; panoramic sub-stream default
320*180，320*240,640*360,640*480,1280*720 optional; broadcast code stream 1920*1080，1280*720,640*480
optional)
Stream Rate control: Set rate control mode, save and reboot to take it effect (close-up main stream, close-up
sub-stream, panoramic main stream, panoramic sub-stream and blackboard code stream default variable bit rate,
fixed rate is for option).
Image Quality: Set the image quality, image quality can be changed only when rate control is variable bit
rate,(main stream defaulted is best, secondary stream default is better, there are best, better, good, bad, worse,
worst for options).
Rate (Kb/s): Set the video bit rate (close-up main stream default 4096Kb/s, 64-40960Kb/s optional; close-up
sub-stream default 512Kb/s, 64-40960Kb/s optional; panoramic main stream default 4096Kb/s, 64-40960Kb/s

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
14
optional; panoramic sub-stream default 512Kb/s, 64-40960Kb/s optional; and broadcast code stream default
4096Kb/s, 64-40960Kb/s optional).
Frame rate (F/S): Set the video frame rate (close-up main stream, close-up sub-stream, panoramic main stream,
panoramic sub-stream, and broadcast code stream default 25F/S, main stream 5-30F/S optional).
Key frame interval: Set the key frame interval (close-up main stream, close-up sub-stream, panoramic main
stream, panoramic sub-stream, and broadcast code stream default 100F, main stream 1-150F optional).
Key frame minimum QP: Set the key frame minimum QP (default 20, 10-51 optional)
Stream Name: When streaming via rtsp or rtmp, user can modify stream name. close-up main stream(default
live/av0), close-up sub-stream(default live/av1), panoramic main stream(default live/av2), panoramic
sub-stream(default live/av3), and broadcast code stream(default live/av4).
Click the "Save" button to display the "saved successfully" message, then settings take effect.
2) Stream Release
Switch: To turn on/off close-up main stream, close-up sub-stream, panoramic main stream, panoramic sub-stream
and blackboard code stream.
Protocol: primary / secondary stream applies RTMP protocol.
Host Port: server port number (default 1935, 0-65535 optional)
Host Address: server IP addresses (default 192.168.5.11)
Stream Name: choose a different stream name (live / av0, live / av1, live/av2,live/av3,live/av4 optional).
User: Set the user name.
Password: Set the password.
Click on the "Save" button to display the "Save successful" message, then settings take effect.
3) RTP Broadcasting
Switch: To turn on/off close-up main stream, close-up sub-stream, panoramic main stream, panoramic sub-stream
and blackboard code stream.
Protocol: RTP or TS
Address: Default 224.1.2.3. It can be edited.
Port: Main Stream Default Port: close-up main stream default 4000， close-up sub-stream default 4002， panoramic
main stream default 4004，panoramic sub-stream default 4006，broadcast code stream default 4008.
Visit: Address comes up after setting. Eg ; rtp: //224.1.2.3:4000; udp: //@224.1.2.3:4000
4)Video Parameters
a. Exposure: Exposure mode, exposure compensation, back light compensation, anti-flicker, gain limit, wide
dynamic, shutter speed, aperture value and brightness can be set.
Exposure Mode: Set the exposure mode (the default automatic, manual, shutter priority, aperture priority,
Brightness priority optional)
Exposure compensation: Exposure compensation setting is active when it is auto status (default is off).
Exposure compensation value: Set the exposure compensation value, valid when it is set for auto (default 0, -7
to 7 optional).
BLC: Set back light compensation, valid when it is auto status (default is off).
Anti-flicker: Set up anti-flicker mode, valid when status of automatic, aperture or brightness priority (default
50Hz, closed, 60Hz optional).
Gain limit: set the gain limits, only valid when exposure mode is automatic, aperture/brightness
priority.(default 4, 0-15 optional).
Dynamic range: Set the dynamic range (default 4, 1-8 optional).
Shutter speed: Active when it is status of manual or shutter-priority (default 1/100，
1/25,1/30,1/50,1/60,1/90,1/100,1/120,1/180,1/250,1/350,1/500,1/1000,1/2000,1/3000,1/4000,1/6000,1/100
00 optional).
Aperture value: Set the aperture value, active when it is status of manual or aperture-priority (default close,
F1.8, F11, F9.6, F8.0, F6.8, F5.6, F4.8, F4.0, F3.4, F2.8, F2.4, F2.0 optional).
Brightness: Set the brightness value, active when it is a state of brightness priority (default 7, 0-23 optional).
b. Color: White balance, saturation, color, white balance, sensitivity, color temperature, gain red and blue gain
can be set.

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
15
White balance modes: Set the white balance mode (the default automatic, 2400K-7100K, manual, One-push
optional).
Note: Click the “Correction” button when selected the One-push white balance mode.
Red fine-tuning: default0, -10~10 (only available in automatic mode)
Blue fine-tunable: default 0, -10~10 (only available in automatic mode)
Saturation: Set the saturation (default 60%, 70%, 80%, 90%, 100%, 110%, 120%, 130%, 140%, 150%, 160%,
170%, 180%, 190%, 200% optional).
Chroma: Set the chroma (default 7, 0-14 optional).
White balance sensitivity: Set the white balance sensitivity (default is high, medium, low for options)
Red Gain: Set the red gain, effective when it is manual (default 108, 0-255 optional).
Blue Gain: Sets the Blue gain, effective when it is manual (default 71, 0-255 optional).
c. Image: Brightness, contrast, sharpness, black and white mode, the gamma curve, Horizontal Flip and Vertical
Flip can be set.
Brightness: Set the brightness (default 7, 0-14 optional).
Contrast: set the contrast (default 7, 0-14 optional).
Sharpness: Set the sharpness value (default 4, 0-15 optional).
Black and white mode: Set black and white mode (default color, black/white optional ).
Gamma: Gamma value setting (default, 0.45, 0.50, 0.55, 0.63 optional).
Dynamic Contrast: set the dynamic contrast (default off, 1～8 optional)
Ultra-low illumination: default off
d. Noise Reduction: 2D noise reduction, 3D noise reduction and dynamic dead pixel correction available.
2D Noise Reduction: Set 2D noise reduction level (default 2, Auto, 1-7 and Off optional).
3D Noise Reduction: Set 3D noise reduction level (default 5, 1-8 and Off optional).
Dynamic dead pixel correction: Set Dynamic dead pixel correction (default Off, 1-5 optional).
e. Style: select the picture style (default, standard, clear, bright, soft optional)
Note: Click “Refresh” to make revision of any video parameters of a, b, c, d, e effective.
5) Character-Overlapping
Display date and time: Set whether to display the time and date (default display).
Display Title: Set whether to display the title (default display).
Font Color of Time: Set font color of time and date (default white, black, yellow, red, and blue optional).
Font Color of Title: Set font color of title (default white, black, yellow, red, and blue optional).
Moving characters: Set the display position of moving date, time and title, click on the "up, down, left, right"
buttons to move the corresponding character position.
Title Content: Set title content (default CAMERA1).
Time Content: Set time content (default 1970/01/10 05:36:00)
Click on the "Save" button and display the "Save successful" message, then valid
6) Character Size
Main stream character size: Set the character size of the display, the device will restart
Automatically after changed and saved (default 48, 28-200 optional)
Secondary stream character size: Set the character size of the display, the device will restart automatically after
changed and saved (default 48, 28-200 optional)
Click on the "Save" button to display "Parameter saved successfully" message, set to take effect.
7) Video output
Output format can be checked by on/off (default off)
Output format: 1080P30, 1080P25, 1080I60, 1080I50, 720P60, 720P50
Click on the "Save" button, it will be valid when display "Save successful".

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
16
3.4.3 Network Configuration
1) Network port
Data port: set the data port, the device will restart automatically after changed (default 3000, 0-65535 optional)
Web Port: Set Web port, the device will restart automatically after changed (default is 80, 0-65535 is optional)
Onvif Port: Set Onvif port, the device will restart automatically after changed (default 2000, 0-65535 optional)
Soap Port: Set Soap port (default 1936, 0-65535 optional)
RTMP Port: Set RTMP port (default 1935, 0-65535 optional)
RTSP Port: Set RTSP port, the device will restart automatically after changed (default 554, 0-65535 optional).
Visca Port: Set Visca port, the device will restart automatically after changed (default 1259,0-65535 optional).
Click on the "Save" button, it will be valid when display "Save successful".
RTSP Obtaining method: rtsp: // device IP address: 554 / live / av0 (av0 close-up main stream, av1 close-up
sub-stream, av2 panoramic main stream, av3 panoramic sub-stream, av4 broadcast code stream.)
RTMP Obtaining method: rtmp: // device IP address:1935/live/ av0 (av0 close-up main stream, av1 close-up
sub-stream, av2 panoramic main stream, av3 panoramic sub-stream, av4 broadcast code stream.)
2) Ethernet parameters
DHCP: Enable or disable obtain IP automatically can be set. Save changes and reboot the device to takes effect
(default: OFF)
IP Address: Set the IP address, save changes and reboot the device to takes effect (default 192.168.5.163). Note:
This IP address is the same with the one used to login Web page.
Subnet Mask: Set the subnet mask (default 255.255.255.0).
Default Gateway: Set the default gateway (default 0.0.0.0).
Physical Address: Set the physical address (the parameter is read-only but can not be modified).
Click on the "Save" button, it will be valid when display "Save successful". (Note: To prevent IP conflicts When
modify)
3) DNS parameters
Preferred DNS server: set the preferred DNS server. (Default 0.0.0.0).
Alternate DNS server: Alternate DNS server settings. (Default 0.0.0.0).
Click on the "Save" button, it will be valid when display "Save successful".
4) GB28181
Switch: set whether open GB28181, can check
Time Synchronization: whether synchronization time is set, you can check
Stream Type: stream type setting (the default main stream, secondary stream optional)
Sign effective time (in seconds): 3600 Range 5-65535
Heartbeat time (seconds): 60 Range 1-65535
Register ID: 34020000001320000001
Register User name: IPC
Register Password: 12345678
Equipment ownership: Users can add their own
Administrative regions: Users can add their own
Alarm Zone: Users can add their own
Equipment installation address: Users can add their own
Local SIP Port: 5060 Range 0-65535
GB28181 Server Address: IP address of the computer
Server SIP Port: 5060 Range 0-65535
Server ID: 34020000002000000001
Click on the "Save" button, it will be valid when display "Save successful".

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
17
3.4.4 System Configuration
1) Device Properties
Device Name: Set the device name (the default Camera1, user can add their own).
Device ID: Set the device ID (default 1, Read-Only).
System Language: Set the system language (default Simplified Chinese, English optional).Need to re-login after
modify and save the setting.
Click on the "Save" button, it will be valid when display "Save successful".
2) System Time
Date Format: Set the date format (YYYY-MM-DD default That year - month - day, MM-DD-YYYY namely Month -
Day - Year, DD-MM-YYYY date - month - year Optional).
Date separator: set the date separator (default '/','.','-' Optional).
Time Zone: Set the time zone (default East eight districts, other time zones optional).
Time Type: Set the time types (default 24 hours, optional 12 hours).
Time setting: Set time mode (to choose the computer time synchronization, NTP server time synchronization, or
set manually).
Computer Time: Set the computer synchronization valid.
Update interval: Set the NTP server automatic updated time interval. Valid after setting NTP server
synchronization (default one day, 2-10 days Optional).
NTP server address or domain name: Set NTP server address or domain name (default time.nits.gov). Valid after
setting NTP server synchronization.
NTP Server Port: Sets the NTP server port (default 123).Valid after setting NTP server synchronization.
Set the time manually, Effective when set manually.
Click on the "Save" button, it will be valid when display "Save successful".
3) User Management
Select users: Set the user type (the default administrator, Common User 1, Common User 2 optional)
User name: set the user name (Select User Administrator default admin; select a common user1 default user1; to
select a common user 2 default user2; user can modify their own)
Password: Set a password (Select User Administrator default admin; select a common user1 default user1; to
select a common user 2 default user2; user can modify their own).
Password confirmation: Confirm the input passwords are the same or not.
Click on the "Save" button to display the "Save successfully" message, then the set is to take effect.
Please note the case-sensitivity of the user name and password.
Note: If login page by a common user’s name and password, one does not have configuration privileges but can only
operate to preview, playback, logout.
4) Version upgrade
Users only read the version information above which is consistent with the menu version but can not modify.
Different types of the machine has different information.
Update file: Click "Browse ..." installation, to select the upgrade file in the pop-up window.
Click on the "Upgrade" button, the upgrade dialog will appear, the device will reboot automatically after update
successfully.
(Note: Make sure the power and network is keeping connected during the process, or the upgrade will fail)
Note: After the version upgrade is complete, you need to restore factory defaults; a. through web to restore the
factory default configuration; b. through the recovery menu; c. remote control shortcut * # 6;
Choose one of the above three ways. The IP account and password of mode a are also restored to default.
5) Restore factory setting
Click on pop-up "Restore Factory Defaults" button and choose “yes” or “no”, then the device will restart

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
18
automatically and restore factory setting.
6) Reboot
Click on the pop-up "Reboot" button and choose “yes” or “no”, then the device will restart automatically.
3.5 Logout
Point "Logout" pop-up "Confirmation" dialog; select "Yes" or "No", choose “Yes” to exit the current page and
return to the user login interface again.
3.6 Configure Tracking Parameter
Setup Process
The setup process of teacher tracking The setup process of student tracking
Set the platform and
panoramic preset
Start tracking
Set space for
platform and shield
Set tracking
parameters
Stop tracking
Set panoramic
presets
Start tracking
Set shield area
Set tracking
parameters
Stop tracking
3.6.1 Teacher Tracking Configuration
The following instructions are given in accordance with the setup flowchart. The main interface of teacher tracking
configuration is shown in Figure below.

厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601
网址：www.rgblink.com 电话：[phone] 传真：[phone]
19
1. Click stop tracking
2. Preset setting of the platform
The operation interface for setting the preset position is shown in Figure below. By controlling the position and
ZOOM value of the PTZ, the camera Angle and position are adjusted to the preset position and saved. The
description of the preset position of the podium is as follows.
