Rheem RJNA Series User manual

FORM NO. P11-763 REV. 1
Supersedes Form No. P11-763
PACKAGE HEAT PUMP UNITS
RJNA- HIGH EFFICIENCY SERIES
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
*Unit shown with
optional louver
panels installed.
“CERTIFIED UNDER THE
A.R.I. CERTIFICATION
PROGRAM—A.R.I.
STANDARD 240”
ISO 9001:2000

2
TABLE OF CONTENTS
Introduction ..................................................................................................3-4
Model Identification Options............................................................................5-6
General Data
RJNA- Series ..........................................................................................7-13
General Data Notes ........................................................................................14
Performance Data
RJNA- Series ........................................................................................15-18
Airflow Performance
RJNA- Series ........................................................................................19-21
Electrical Data
RJNA- Series ........................................................................................22-23
Units with Heater Kits
RJNA- Series ........................................................................................24-30
Dimensional Data ......................................................................................31-33
Accessories ..............................................................................................34-41
Mechanical Specifications ..............................................................................42
Typical Wiring ............................................................................................43-49
Limited Warranty ............................................................................................50

3
INTRODUCTION
These quality features are included in the Rheem
Outdoor Package Heat Pumps
Evaporator Coil/Filter Access
Optional Electric Heater Kit
Compressor Access
Control Box Access
Blower Access

4
INTRODUCTIONINTRODUCTION
ENGINEERING FEATURES
RJNA- Series Package Heat Pumps
1. All models feature Copeland®Scroll®compressors offering maximum reliability, efficiency, and quiet
operation.
2. One-piece top over the indoor section with drip lip, drawn painted base pan, and 1" [25.4 mm] raised flanges
for supply/return air connections provides superior water management.
3. Convertible horizontal and vertical airflow design allows maximum field flexibility and minimizes inventory
requirements.
4. Standard full perimeter forkable baserail with lifting holes for easier maneuvering and installations.
5. Factory installed one-inch [25.4 mm] throw away filter with provisions for two-inch [50.8 mm] filter.
6. Direct or belt drive options to accommodate a wide range of design conditions as high as 1.5 inches
[37 kPa] of external static pressure.
7. Easily removable filter, blower, electric heat, and compressor/control access panels permits prompt service.
8. Number and color coded wiring helps facilitate service and maintenance.
9. Common cabinet and components allows for installation flexibility and fewer parts to inventory.
10. Standard high pressure control on all models.
11. Externally mounted refrigerant gauge ports for easy service diagnostics.
12. Side and base electric power entry helps minimize roof penetrations.
13. Quick assembly common roof curbs helps save field labor and maximize size flexibility.
14. Factory or field installed electric heat kits available up to 24 KW.
15. Easy to install plug-in, slip-in economizers; 100% fully modulating, single enthalpy.
16. Quality powder paint finish offers long lasting protection against extreme weather conditions and is able to
withstand 1000 HR salt spray test.
[ ] Designates Metric Conversions

5
MODEL IDENTIFICATION—RJNA- SERIES
RJNA—A036JK000
Electric Heat
000 = No Resistance Heat
010 = 10 kW Resistance Heat
015 = 15 kW Resistance Heat
020 = 20 kW Resistance Heat
Drive Package
K = Direct Drive
L = Belt Drive
M = Belt Drive—High Static
Electrical Designation
J = 208-230 V, 1 PH, 60 Hz
C = 208-230 V, 3 PH, 60 Hz
D = 460 V, 3 PH, 60 Hz
Nominal Cooling Capacity
(BTUH) [kW]
036 = 36,000 [10.55]
042 = 42,000 [12.31]
048 = 48,000 [14.07]
060 = 60,000 [17.58]
Future Technical Variations
Design Series
A=1stDesign
Efficiency Designation
N=13SEER
Product Classification
J = Package Heat Pump—
Light Commercial
Trad ebra nd
R = Rheem
[ ] Designates Metric Conversions

6
OPTIONS—RJNA- SERIES
Option Code
Low Ambient Reduced Height
Baserails
AA
Side Flow
AD
AF x
AK x
Hail Guard
x
xBD x
xCK x x
xBX x
AL x
No Options
Freeze Stat
Time Delay
xBS x
FACTORY INSTALLED OPTION CODES FOR RJNA (3-5 Ton) [10.6-17.6 kW]
(A036, A042, A048, A060)
Example: RJNA-A060CK000XXX (where XX is factory installed option)
Example: No Options
RJNA-A060CK000
Example: No Options with Factory Installed Economizer
RJNA-A060CK000AAB
Example: Options with Hail Guard, Low Ambient, Time Delay and Freeze Stat with No Factory Installed Economizer
RJNA-A060CK000BDA
Example: Options same as above with Factory Installed Economizer
RJNA-A060CK000BDB
No Economizer Single Enthalpy Economizer
With Barometric Relief
A x
B x
ECONOMIZER SELECTION FOR RJNA-
“x” indicates factory installed option.
[ ] Designates Metric Conversions

7
GENERAL DATA—RJNA- SERIES
Model RJNA- Series A036CK A036CL A036CM A036DK
Cooling Performance1
Gross Cooling Capacity Btu [kW] 37,600 [11] 37,600 [11] 37,600 [11] 37,600 [11]
EER/SEER211.6/13 11.6/13 11.6/13 11.6/13
Nominal CFM/ARI Rated CFM [L/s] 1200/1200 [566/566] 1200/1200 [566/566] 1200/1200 [566/566] 1200/1200 [566/566]
ARI Net Cooling Capacity Btu [kW] 36,000 [10.5] 36,000 [10.5] 36,000 [10.5] 36,000 [10.5]
Net Sensible Capacity Btu [kW] 26,823 [7.9] 26,823 [7.9] 26,823 [7.9] 26,823 [7.9]
Net System Power kW 3.1 3.1 3.1 3.1
Heating Performance (Heat Pumps)
Heating Temp. Btuh [kW] Rating 35,600 [10.4] 35,600 [10.4] 35,600 [10.4] 35,600 [10.4]
System Power KW/COP 3.2/3.3 3.2/3.3 3.2/3.3 3.2/3.3
Low Temp. Btuh [kW] Rating 21,200 [6.2] 21,200 [6.2] 21,200 [6.2] 21,200 [6.2]
Net Weight lbs. [kg] 517 [235] 517 [235] 517 [235] 517 [235]
System Power KW/COP 3/2.08 3/2.08 3/2.08 3/2.08
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
HSPF (Btu/Watts-hr) 7.7 7.7 7.7 7.7
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)383 83 83 83
Outdoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54]
Rows / FPI [FPcm] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9]
Net Latent Capacity Btu [kW] 9177 [2.7] 9177 [2.7] 9177 [2.7] 9177 [2.7]
Indoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48]
Rows / FPI [FPcm] 3 / 13 [5] 3 / 13 [5] 3 / 13 [5] 3 / 13 [5]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4]
Outdoor Fan—Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 4000 [1888] 4000 [1888] 4000 [1888] 4000 [1888]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan—Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254]
Drive Type/No. Speeds Direct/3 Belt/Variable Belt/Variable Direct/3
No. Motors 1 1 1 1
Motor HP 1/2 1/2 3/4 1/2
Motor RPM 1075 1725 1725 1075
Motor Frame Size 48 56 56 48
Filter—Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(No.) Size Recommended in. [mm] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406]
Refrigerant Charge Oz. [g] 182 [5160] 182 [5160] 182 [5160] 182 [5160]
Weights
Ship Weight lbs. [kg] 532 [241] 532 [241] 532 [241] 532 [241]
CONTINUED
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
See Page 14 for Notes.
[ ] Designates Metric Conversions

8
GENERAL DATA—RJNA- SERIES
Model RJNA- Series A036DL A036DM A036JK A042CK
Cooling Performance1
Gross Cooling Capacity Btu [kW] 37,600 [11] 37,600 [11] 37,600 [11] 42,500 [12.5]
EER/SEER211.6/13 11.6/13 11.6/13 11.8/13
Nominal CFM/ARI Rated CFM [L/s] 1200/1200 [566/566] 1200/1200 [566/566] 1200/1200 [566/566] 1400/1400 [661/661]
ARI Net Cooling Capacity Btu [kW] 36,000 [10.5] 36,000 [10.5] 36,000 [10.5] 40,500 [11.9]
Net Sensible Capacity Btu [kW] 26,823 [7.9] 26,823 [7.9] 26,823 [7.9] 30,124 [8.8]
Net System Power kW 3.1 3.1 3.1 3.4
Heating Performance (Heat Pumps)
Heating Temp. Btuh [kW] Rating 35,600 [10.4] 35,600 [10.4] 35,600 [10.4] 40,000 [11.7]
System Power KW/COP 3.2/3.3 3.2/3.3 3.2/3.3 3.6/3.28
Low Temp. Btuh [kW] Rating 21,200 [6.2] 21,200 [6.2] 21,200 [6.2] 23,200 [6.8]
Net Weight lbs. [kg] 517 [235] 517 [235] 517 [235] 521 [236]
System Power KW/COP 3/2.08 3/2.08 3/2.08 3.3/2.06
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
HSPF (Btu/Watts-hr) 7.7 7.7 7.7 7.7
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)383 83 83 83
Outdoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54]
Rows / FPI [FPcm] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9]
Net Latent Capacity Btu [kW] 9177 [2.7] 9177 [2.7] 9177 [2.7] 10,376 [3]
Indoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48]
Rows / FPI [FPcm] 3 / 13 [5] 3 / 13 [5] 3 / 13 [5] 3 / 13 [5]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4]
Outdoor Fan—Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 4000 [1888] 4000 [1888] 4000 [1888] 4000 [1888]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan—Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254]
Drive Type/No. Speeds Belt/Variable Belt/Variable Direct/3 Direct/3
No. Motors 1 1 1 1
Motor HP 1/2 3/4 1/2 1/2
Motor RPM 1725 1725 1075 1075
Motor Frame Size 56 56 48 48
Filter—Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(No.) Size Recommended in. [mm] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406]
Refrigerant Charge Oz. [g] 182 [5160] 182 [5160] 182 [5160] 177 [5018]
Weights
Ship Weight lbs. [kg] 532 [241] 532 [241] 532 [241] 536 [243]
CONTINUED
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
See Page 14 for Notes.
[ ] Designates Metric Conversions

9
GENERAL DATA—RJNA- SERIES
Model RJNA- Series A042CL A042CM A042DK A042DL
Cooling Performance1
Gross Cooling Capacity Btu [kW] 42,500 [12.5] 42,500 [12.5] 42,500 [12.5] 42,500 [12.5]
EER/SEER211.8/13 11.8/13 11.8/13 11.8/13
Nominal CFM/ARI Rated CFM [L/s] 1400/1400 [661/661] 1400/1400 [661/661] 1400/1400 [661/661] 1400/1400 [661/661]
ARI Net Cooling Capacity Btu [kW] 40,500 [11.9] 40,500 [11.9] 40,500 [11.9] 40,500 [11.9]
Net Sensible Capacity Btu [kW] 30,124 [8.8] 30,124 [8.8] 30,124 [8.8] 30,124 [8.8]
Net System Power kW 3.4 3.4 3.4 3.4
Heating Performance (Heat Pumps)
Heating Temp. Btuh [kW] Rating 40,000 [11.7] 40,000 [11.7] 40,000 [11.7] 40,000 [11.7]
System Power KW/COP 3.6/3.28 3.6/3.28 3.6/3.28 3.6/3.28
Low Temp. Btuh [kW] Rating 23,200 [6.8] 23,200 [6.8] 23,200 [6.8] 23,200 [6.8]
Net Weight lbs. [kg] 521 [236] 521 [236] 521 [236] 521 [236]
System Power KW/COP 3.3/2.06 3.3/2.06 3.3/2.06 3.3/2.06
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
HSPF (Btu/Watts-hr) 7.7 7.7 7.7 7.7
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)383 83 83 83
Outdoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54]
Rows / FPI [FPcm] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9]
Net Latent Capacity Btu [kW] 10,376 [3] 10,376 [3] 10,376 [3] 10,376 [3]
Indoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48]
Rows / FPI [FPcm] 3 / 13 [5] 3 / 13 [5] 3 / 13 [5] 3 / 13 [5]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4]
Outdoor Fan—Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 4000 [1888] 4000 [1888] 4000 [1888] 4000 [1888]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan—Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254]
Drive Type/No. Speeds Belt/Variable Belt/Variable Direct/3 Belt/Variable
No. Motors 1 1 1 1
Motor HP 1/2 3/4 1/2 1/2
Motor RPM 1725 1725 1075 1725
Motor Frame Size 56 56 48 56
Filter—Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(No.) Size Recommended in. [mm] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406]
Refrigerant Charge Oz. [g] 177 [5018] 177 [5018] 177 [5018] 177 [5018]
Weights
Ship Weight lbs. [kg] 536 [243] 536 [243] 536 [243] 536 [243]
CONTINUED
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
See Page 14 for Notes.
[ ] Designates Metric Conversions

10
GENERAL DATA—RJNA- SERIES
Model RJNA- Series A042DM A042JK A048CK A048CL
Cooling Performance1
Gross Cooling Capacity Btu [kW] 42,500 [12.5] 42,500 [12.5] 49,500 [14.5] 49,500 [14.5]
EER/SEER211.8/13 11.8/13 11.65/13 11.65/13
Nominal CFM/ARI Rated CFM [L/s] 1400/1400 [661/661] 1400/1400 [661/661] 1600/1600 [755/755] 1600/1600 [755/755]
ARI Net Cooling Capacity Btu [kW] 40,500 [11.9] 40,500 [11.9] 47,000 [13.8] 47,000 [13.8]
Net Sensible Capacity Btu [kW] 30,124 [8.8] 30,124 [8.8] 34,700 [10.2] 34,700 [10.2]
Net System Power kW 3.4 3.4 4 4
Heating Performance (Heat Pumps)
Heating Temp. Btuh [kW] Rating 40,000 [11.7] 40,000 [11.7] 46,500 [13.6] 46,500 [13.6]
System Power KW/COP 3.6/3.28 3.6/3.28 3.9/3.5 3.9/3.5
Low Temp. Btuh [kW] Rating 23,200 [6.8] 23,200 [6.8] 27,800 [8.1] 27,800 [8.1]
Net Weight lbs. [kg] 521 [236] 521 [236] 535 [243] 535 [243]
System Power KW/COP 3.3/2.06 3.3/2.06 3.7/2.22 3.7/2.22
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
HSPF (Btu/Watts-hr) 7.7 7.7 7.7 7.7
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)383 83 83 83
Outdoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54]
Rows / FPI [FPcm] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9]
Net Latent Capacity Btu [kW] 10,376 [3] 10,376 [3] 12,300 [3.6] 12,300 [3.6]
Indoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48]
Rows / FPI [FPcm] 3 / 13 [5] 3 / 13 [5] 4 / 13 [5] 4 / 13 [5]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4]
Outdoor Fan—Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 4000 [1888] 4000 [1888] 4000 [1888] 4000 [1888]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan—Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254]
Drive Type/No. Speeds Belt/Variable Direct/3 Direct/3 Belt/Variable
No. Motors 1 1 1 1
Motor HP 3/4 1/2 1/2 1/2
Motor RPM 1725 1075 1075 1725
Motor Frame Size 56 48 48 56
Filter—Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(No.) Size Recommended in. [mm] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406]
Refrigerant Charge Oz. [g] 177 [5018] 177 [5018] 206 [5840] 206 [5840]
Weights
Ship Weight lbs. [kg] 536 [243] 536 [243] 550 [249] 550 [249]
CONTINUED
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
See Page 14 for Notes.
[ ] Designates Metric Conversions

11
GENERAL DATA—RJNA- SERIES
Model RJNA- Series A048CM A048DK A048DL A048DM
Cooling Performance1
Gross Cooling Capacity Btu [kW] 49,500 [14.5] 49,500 [14.5] 49,500 [14.5] 49,500 [14.5]
EER/SEER211.65/13 11.65/13 11.65/13 11.65/13
Nominal CFM/ARI Rated CFM [L/s] 1600/1600 [755/755] 1600/1600 [755/755] 1600/1600 [755/755] 1600/1600 [755/755]
ARI Net Cooling Capacity Btu [kW] 47,000 [13.8] 47,000 [13.8] 47,000 [13.8] 47,000 [13.8]
Net Sensible Capacity Btu [kW] 34,700 [10.2] 34,700 [10.2] 34,700 [10.2] 34,700 [10.2]
Net System Power kW 4 4 4 4
Heating Performance (Heat Pumps)
Heating Temp. Btuh [kW] Rating 46,500 [13.6] 46,500 [13.6] 46,500 [13.6] 46,500 [13.6]
System Power KW/COP 3.9/3.5 3.9/3.5 3.9/3.5 3.9/3.5
Low Temp. Btuh [kW] Rating 27,800 [8.1] 27,800 [8.1] 27,800 [8.1] 27,800 [8.1]
Net Weight lbs. [kg] 535 [243] 535 [243] 535 [243] 535 [243]
System Power KW/COP 3.7/2.22 3.7/2.22 3.7/2.22 3.7/2.22
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
HSPF (Btu/Watts-hr) 7.7 7.7 7.7 7.7
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)383 83 83 83
Outdoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54]
Rows / FPI [FPcm] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9]
Net Latent Capacity Btu [kW] 12,300 [3.6] 12,300 [3.6] 12,300 [3.6] 12,300 [3.6]
Indoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48]
Rows / FPI [FPcm] 4 / 13 [5] 4 / 13 [5] 4 / 13 [5] 4 / 13 [5]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4]
Outdoor Fan—Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 4000 [1888] 4000 [1888] 4000 [1888] 4000 [1888]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan—Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254] 1/10x10 [254x254]
Drive Type/No. Speeds Belt/Variable Direct/3 Belt/Variable Belt/Variable
No. Motors 1 1 1 1
Motor HP 3/4 1/2 1/2 3/4
Motor RPM 1725 1075 1725 1725
Motor Frame Size 56 48 56 56
Filter—Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(No.) Size Recommended in. [mm] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406]
Refrigerant Charge Oz. [g] 206 [5840] 206 [5840] 206 [5840] 206 [5840]
Weights
Ship Weight lbs. [kg] 550 [249] 550 [249] 550 [249] 550 [249]
CONTINUED
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
See Page 14 for Notes.
[ ] Designates Metric Conversions

12
GENERAL DATA—RJNA- SERIES
Model RJNA- Series A048JK A060CK A060CL A060CM
Cooling Performance1
Gross Cooling Capacity Btu [kW] 49,500 [14.5] 63,500 [18.6] 64,000 [18.8] 64,000 [18.8]
EER/SEER211.65/13 11.55/13 11.55/13 11.55/13
Nominal CFM/ARI Rated CFM [L/s] 1600/1600 [755/755] 2000/2000 [944/944] 2000/2000 [944/944] 2000/2000 [944/944]
ARI Net Cooling Capacity Btu [kW] 47,000 [13.8] 61,500 [18] 61,500 [18] 61,500 [18]
Net Sensible Capacity Btu [kW] 34,700 [10.2] 43,800 [12.8] 43,800 [12.8] 43,800 [12.8]
Net System Power kW 4 5.3 5.3 5.3
Heating Performance (Heat Pumps)
Heating Temp. Btuh [kW] Rating 46,500 [13.6] 60,500 [17.7] 60,500 [17.7] 60,500 [17.7]
System Power KW/COP 3.9/3.5 5/3.5 5/3.5 5/3.5
Low Temp. Btuh [kW] Rating 27,800 [8.1] 36,000 [10.5] 36,000 [10.5] 36,000 [10.5]
Net Weight lbs. [kg] 535 [243] 565 [256] 565 [256] 565 [256]
System Power KW/COP 3.7/2.22 4.4/2.3 4.4/2.3 4.4/2.3
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
HSPF (Btu/Watts-hr) 7.7 7.7 7.7 7.7
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)383 83 83 83
Outdoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54]
Rows / FPI [FPcm] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9]
Net Latent Capacity Btu [kW] 12,300 [3.6] 17,700 [5.2] 17,700 [5.2] 17,700 [5.2]
Indoor Coil—Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48]
Rows / FPI [FPcm] 4 / 13 [5] 4 / 13 [5] 4 / 13 [5] 4 / 13 [5]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4]
Outdoor Fan—Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 4000 [1888] 4000 [1888] 4000 [1888] 4000 [1888]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan—Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x10 [254x254] 1/11x9 [279.4x228.6] 1/10x10 [254x254] 1/10x10 [254x254]
Drive Type/No. Speeds Direct/3 Direct/2 Belt/Variable Belt/Variable
No. Motors 1 1 1 1
Motor HP 1/2 13/4 1
Motor RPM 1075 1100 1725 1725
Motor Frame Size 48 48 56 56
Filter—Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(No.) Size Recommended in. [mm] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406]
Refrigerant Charge Oz. [g] 206 [5840] 184 [5216] 184 [5216] 184 [5216]
Weights
Ship Weight lbs. [kg] 550 [249] 580 [263] 580 [263] 580 [263]
CONTINUED
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
See Page 14 for Notes.
[ ] Designates Metric Conversions

13
GENERAL DATA—RJNA- SERIES
Model RJNA- Series A060DL A060DM A060JK
Cooling Performance1
Gross Cooling Capacity Btu [kW] 64,000 [18.8] 64,000 [18.8] 63,500 [18.6]
EER/SEER211.55/13 11.55/13 11.55/13
Nominal CFM/ARI Rated CFM [L/s] 2000/2000 [944/944] 2000/2000 [944/944] 2000/2000 [944/944]
ARI Net Cooling Capacity Btu [kW] 61,500 [18] 61,500 [18] 61,500 [18]
Net Sensible Capacity Btu [kW] 43,800 [12.8] 43,800 [12.8] 43,800 [12.8]
Net System Power kW 5.3 5.3 5.3
Heating Performance (Heat Pumps)
Heating Temp. Btuh [kW] Rating 60,500 [17.7] 60,500 [17.7] 60,500 [17.7]
System Power KW/COP 5/3.5 5/3.5 5/3.5
Low Temp. Btuh [kW] Rating 36,000 [10.5] 36,000 [10.5] 36,000 [10.5]
Net Weight lbs. [kg] 565 [256] 565 [256] 565 [256]
System Power KW/COP 4.4/2.3 4.4/2.3 4.4/2.3
Refrigerant Control TX Valves TX Valves TX Valves
HSPF (Btu/Watts-hr) 7.7 7.7 7.7
Compressor
No./Type 1/Copeland Scroll 1/Copeland Scroll 1/Copeland Scroll
Outdoor Sound Rating (dB)383 83 83
Outdoor Coil—Fin Type Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled
Tube Size in. [mm] OD 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 16.56 [1.54] 16.56 [1.54] 16.56 [1.54]
Rows / FPI [FPcm] 2 / 22 [9] 2 / 22 [9] 2 / 22 [9]
Net Latent Capacity Btu [kW] 17,700 [5.2] 17,700 [5.2] 17,700 [5.2]
Indoor Coil—Fin Type Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 5.16 [0.48] 5.16 [0.48] 5.16 [0.48]
Rows / FPI [FPcm] 4 / 13 [5] 4 / 13 [5] 4 / 13 [5]
Refrigerant Control TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4]
Outdoor Fan—Type Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1
CFM [L/s] 4000 [1888] 4000 [1888] 4000 [1888]
No. Motors/HP 1 at 1/3 HP 1 at 1/3 HP 1 at 1/3 HP
Motor RPM 1075 1075 1075
Indoor Fan—Type FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/10x10 [254x254] 1/10x10 [254x254] 1/11x9 [279.4x228.6]
Drive Type/No. Speeds Belt/Variable Belt/Variable Direct/2
No. Motors 1 1 1
Motor HP 3/4 1 1
Motor RPM 1725 1725 1100
Motor Frame Size 56 56 48
Filter—Type Disposable Disposable Disposable
Furnished Yes Yes Yes
(No.) Size Recommended in. [mm] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406] (2)1x25x16 [25x635x406]
Refrigerant Charge Oz. [g] 184 [5216] 184 [5216] 184 [5216]
Weights
Ship Weight lbs. [kg] 580 [263] 580 [263] 580 [263]
NOMINAL SIZES 3-5 TONS [10.6-17.6 kW]
See Page 14 for Notes.
[ ] Designates Metric Conversions

14
GENERAL DATA—RJNA- SERIES
NOTES:
1. Cooling Performance is rated at 95° F ambient, 80° F entering dry bulb, 67° F entering wet bulb. Gross capacity does not
include the effect of fan motor heat. ARI capacity is net and includes the effect of fan motor heat. Units are suitable for
operation to 20% of nominal cfm. Units are certified in accordance with the Unitary Air Conditioner Equipment
certification program, which is based on ARI Standard 210/240 or 360.
2. EER and/or SEER are rated at ARI conditions and in accordance with DOE test procedures.
3. Outdoor Sound Rating shown is tested in accordance with ARI Standard 270.
[ ] Designates Metric Conversions

COOLING PERFORMANCE DATA—RJNA-A036
HEATING PERFORMANCE DATA—RJNA-A036
DR —Depression ratio
dbE —Entering air dry bulb
wbE—Entering air wet bulb
Total —Total capacity x 1000 BTUH
Sens —Sensible capacity x 1000 BTUH
Power—KW input
NOTES:
➀When the entering air dry bulb is other than 80°F [27°C], adjust the sensible
capacity from the table by adding [1.10 x CFM x (1 – DR) x (dbE – 80)].
IDB—Indoor air dry bulb [ ] Designates Metric Conversions
ENTERING INDOOR AIR @ 80°F [26.7°C] dbE ➀
wbE 71°F [21.7°C] 67°F [19.4°C] 63°F [17.2°C]
CFM [L/s] 1440 [680] 1200 [566] 960 [453] 1440 [680] 1200 [566] 960 [453] 1440 [680] 1200 [566] 960 [453]
DR ➀.16 .13 .08 .16 .13 .08 .16 .13 .08
O
U
T
D
O
O
R
D
R
Y
B
U
L
B
T
E
M
P
E
R
A
T
U
R
E
°F
[°C]
75
[23.9]
Total BTUH [kW]
Sens BTUH [kW]
Power
46.4 [13.60]
27.9 [8.18]
2.2
44.8 [13.13]
25.5 [7.47]
2.2
43.1 [12.63]
23.1 [6.77]
2.2
43.4 [12.72]
33.5 [9.82]
2.2
41.9 [12.28]
30.6 [8.97]
2.2
40.4 [11.84]
27.7 [8.12]
2.1
41.1 [12.05]
34.8 [10.20]
2.2
39.7 [11.63]
31.8 [9.32]
2.2
38.2 [11.20]
28.8 [8.44]
2.1
80
[26.7]
Total BTUH [kW]
Sens BTUH [kW]
Power
45.5 [13.33]
27.3 [8.00]
2.3
43.9 [12.87]
25.0 [7.33]
2.3
42.3 [12.40]
22.6 [6.62]
2.3
42.6 [12.48]
32.9 [9.64]
2.3
41.1 [12.05]
30.0 [8.79]
2.3
39.6 [11.61]
27.2 [7.97]
2.3
40.2 [11.78]
34.2 [10.02]
2.3
38.8 [11.37]
31.3 [9.17]
2.3
37.4 [10.96]
28.3 [8.29]
2.3
85
[29.4]
Total BTUH [kW]
Sens BTUH [kW]
Power
44.5 [13.04]
26.7 [7.83]
2.5
42.9 [12.57]
24.4 [7.15]
2.4
41.3 [12.10]
22.1 [6.48]
2.4
41.5 [12.16]
32.3 [9.47]
2.4
40.0 [11.72]
29.5 [8.65]
2.4
38.6 [11.31]
26.8 [7.85]
2.4
39.2 [11.49]
33.6 [9.85]
2.4
37.8 [11.08]
30.7 [9.00]
2.4
36.4 [10.67]
27.9 [8.18]
2.4
90
[32.2]
Total BTUH [kW]
Sens BTUH [kW]
Power
43.3 [12.69]
26.1 [7.65]
2.6
41.7 [12.22]
23.9 [7.00]
2.5
40.2 [11.78]
21.7 [6.36]
2.5
40.3 [11.81]
31.7 [9.29]
2.6
38.9 [11.40]
29.0 [8.50]
2.5
37.5 [10.99]
26.3 [7.71]
2.5
38.0 [11.14]
33.0 [9.67]
2.6
36.6 [10.73]
30.2 [8.85]
2.5
35.3 [10.35]
27.4 [8.03]
2.5
95
[35]
Total BTUH [kW]
Sens BTUH [kW]
Power
42.0 [12.31]
25.6 [7.50]
2.7
40.5 [11.87]
23.4 [6.86]
2.6
39.0 [11.43]
21.2 [6.21]
2.6
39.0 [11.43]
31.1 [9.11]
2.7
37.6 [11.02]
28.5 [8.35]
2.6
36.3 [10.64]
25.8 [7.56]
2.6
36.7 [10.76]
32.4 [9.50]
2.7
35.4 [10.37]
29.7 [8.70]
2.6
34.1 [9.99]
26.9 [7.88]
2.6
100
[37.8]
Total BTUH [kW]
Sens BTUH [kW]
Power
40.7 [11.93]
25.0 [7.33]
2.8
39.3 [11.52]
22.8 [6.68]
2.8
37.8 [11.08]
20.7 [6.07]
2.7
37.7 [11.05]
30.5 [8.94]
2.8
36.4 [10.67]
27.9 [8.18]
2.7
35.1 [10.29]
25.3 [7.41]
2.7
35.4 [10.37]
31.9 [9.35]
2.8
34.2 [10.02]
29.1 [8.53]
2.7
32.9 [9.64]
26.4 [7.74]
2.7
105
[40.6]
Total BTUH [kW]
Sens BTUH [kW]
Power
39.5 [11.58]
24.4 [7.15]
2.9
38.1 [11.17]
22.3 [6.54]
2.9
36.7 [10.76]
20.2 [5.92]
2.8
36.5 [10.70]
30.0 [8.79]
2.9
35.2 [10.32]
27.4 [8.03]
2.9
33.9 [9.94]
24.8 [7.27]
2.8
34.2 [10.02]
31.3 [9.17]
2.9
33.0 [9.67]
28.6 [8.38]
2.9
31.8 [9.32]
25.9 [7.59]
2.8
110
[43.3]
Total BTUH [kW]
Sens BTUH [kW]
Power
38.4 [11.25]
23.8 [6.98]
3.0
37.0 [10.84]
21.8 [6.39]
3.0
35.7 [10.46]
19.7 [5.77]
2.9
35.4 [10.37]
29.3 [8.59]
3.0
34.2 [10.02]
26.8 [7.85]
3.0
32.9 [9.64]
24.3 [7.12]
2.9
33.1 [9.70]
30.7 [9.00]
3.0
31.9 [9.35]
28.0 [8.21]
3.0
30.8 [9.03]
25.4 [7.44]
2.9
115
[46.1]
Total BTUH [kW]
Sens BTUH [kW]
Power
37.5 [10.99]
23.2 [6.80]
3.1
36.1 [10.58]
21.2 [6.21]
3.1
34.8 [10.20]
19.2 [5.63]
3.0
34.5 [10.11]
28.7 [8.41]
3.1
33.3 [9.76]
26.3 [7.71]
3.1
32.1 [9.41]
23.8 [6.98]
3.0
32.2 [9.44]
30.0 [8.79]
3.1
31.0 [9.09]
27.5 [8.06]
3.1
29.9 [8.76]
24.9 [7.30]
3.0
45
[46.1]
Total BTUH [kW]
Power
35.4 [10.37]
2.4
34.9 [10.23]
2.5
34.4 [10.08]
2.6
33.6 [9.85]
2.7
33.1 [9.70]
2.7
32.6 [9.55]
2.8
31.9 [9.35]
2.9
IDB
31.4 [9.20]
3.0
31.0 [9.09]
3.1
60°F [15.5°C]
50
[10]
70°F [21.1°C]
Total BTUH [kW]
Power
37.6 [11.02]
2.5
80°F [26.7°C]
37.1 [10.87]
2.5
36.6 [10.73]
2.6
CFM [L/s]
35.8 [10.49]
2.7
35.3 [10.35]
2.8
1440 [680] 1200 [566] 960 [453] 1440 [680] 1200 [566] 960 [453] 1440 [680] 1200 [566] 960 [453]
34.8 [10.20]
2.8
34.1 [9.99]
2.9
33.6 [9.85]
3.0
33.1 [9.70]
3.1
O
U
T
D
O
O
R
D
R
Y
B
U
L
B
T
E
M
P
E
R
A
T
U
R
E
°F
[°C]
0
[-17.8]
Total BTUH [kW]
Power
8.9 [2.61]
2.1
8.7 [2.55]
2.1
8.6 [2.52]
2.2
7.0 [2.05]
2.3
6.9 [2.02]
2.4
6.8 [1.99]
2.4
5.3 [1.55]
2.6
5.2 [1.52]
2.6
5.1 [1.49]
2.7
5
[26.7]
Total BTUH [kW]
Power
12.2 [3.58]
2.1
12.0 [3.52]
2.2
11.9 [3.49]
2.2
10.4 [3.05]
2.4
10.2 [2.99]
2.4
10.1 [2.96]
2.5
8.6 [2.52]
2.6
8.5 [2.49]
2.7
8.4 [2.46]
2.7
10
[-12.2]
Total BTUH [kW]
Power
15.5 [4.54]
2.2
15.3 [4.48]
2.2
15.1 [4.43]
2.3
13.6 [3.99]
2.4
13.5 [3.96]
2.5
13.3 [3.90]
2.5
11.9 [3.49]
2.6
11.8 [3.46]
2.7
11.6 [3.40]
2.8
15
[32.2]
Total BTUH [kW]
Power
18.7 [5.48]
2.2
18.5 [5.42]
2.3
18.2 [5.33]
2.3
16.9 [4.95]
2.4
16.6 [4.86]
2.5
16.4 [4.81]
2.6
15.1 [4.43]
2.7
14.9 [4.37]
2.8
14.7 [4.31]
2.8
20
[-6.6]
Total BTUH [kW]
Power
21.8 [6.39]
2.2
21.5 [6.30]
2.3
21.2 [6.21]
2.4
20.0 [5.86]
2.5
19.7 [5.77]
2.5
19.4 [5.69]
2.6
18.3 [5.36]
2.7
18.0 [5.28]
2.8
17.7 [5.19]
2.9
25
[37.8]
Total BTUH [kW]
Power
24.8 [7.27]
2.3
24.5 [7.18]
2.3
24.1 [7.06]
2.4
23.0 [6.74]
2.5
22.7 [6.65]
2.6
22.3 [6.54]
2.6
21.3 [6.24]
2.8
21.0 [6.15]
2.8
20.7 [6.07]
2.9
30
[-1.1]
Total BTUH [kW]
Power
27.7 [8.12]
2.3
27.3 [8.00]
2.4
26.9 [7.88]
2.4
25.9 [7.59]
2.5
25.5 [7.47]
2.6
25.1 [7.36]
2.7
24.1 [7.06]
2.8
23.8 [6.98]
2.9
23.5 [6.89]
2.9
35
[43.3]
Total BTUH [kW]
Power
30.5 [8.94]
2.4
30.0 [8.79]
2.4
29.6 [8.67]
2.5
28.6 [8.38]
2.6
28.2 [8.26]
2.6
27.8 [8.15]
2.7
26.9 [7.88]
2.8
26.5 [7.77]
2.9
26.1 [7.65]
3.0
40
[4.4]
Total BTUH [kW]
Power
33.0 [9.67]
2.4
32.6 [9.55]
2.5
32.1 [9.41]
2.5
31.2 [9.14]
2.6
30.7 [9.00]
2.7
30.3 [8.88]
2.7
29.5 [8.65]
2.9
29.0 [8.50]
2.9
28.6 [8.38]
3.0
15
SYSTEMS PERFORMANCE—RJNA- SERIES

COOLING PERFORMANCE DATA—RJNA-A042
HEATING PERFORMANCE DATA—RJNA-A042
DR —Depression ratio
dbE —Entering air dry bulb
wbE—Entering air wet bulb
Total —Total capacity x 1000 BTUH
Sens —Sensible capacity x 1000 BTUH
Power—KW input
NOTES:
➀When the entering air dry bulb is other than 80°F [27°C], adjust the sensible
capacity from the table by adding [1.10 x CFM x (1 – DR) x (dbE – 80)].
IDB—Indoor air dry bulb [ ] Designates Metric Conversions
ENTERING INDOOR AIR @ 80°F [26.7°C] dbE ➀
wbE 71°F [21.7°C] 67°F [19.4°C] 63°F [17.2°C]
CFM [L/s] 1680 [793] 1400 [661] 1120 [529] 1680 [793] 1400 [661] 1120 [529] 1680 [793] 1400 [661] 1120 [529]
DR ➀.18 .15 .11 .18 .15 .11 .18 .15 .11
O
U
T
D
O
O
R
D
R
Y
B
U
L
B
T
E
M
P
E
R
A
T
U
R
E
°F
[°C]
75
[23.9]
Total BTUH [kW]
Sens BTUH [kW]
Power
50.3 [14.74]
30.8 [9.03]
2.3
48.5 [14.21]
28.2 [8.26]
2.3
46.8 [13.72]
25.6 [7.50]
2.2
47.6 [13.95]
37.2 [10.90]
2.3
46.0 [13.48]
34.0 [9.96]
2.3
44.3 [12.98]
30.8 [9.03]
2.2
45.0 [13.19]
38.6 [11.31]
2.3
43.4 [12.72]
35.3 [10.35]
2.3
41.9 [12.28]
32.0 [9.38]
2.2
80
[26.7]
Total BTUH [kW]
Sens BTUH [kW]
Power
50.3 [14.74]
30.8 [9.03]
2.4
48.5 [14.21]
28.1 [8.24]
2.4
46.8 [13.72]
25.5 [7.47]
2.4
47.7 [13.98]
37.1 [10.87]
2.4
46.0 [13.48]
33.9 [9.94]
2.4
44.3 [12.98]
30.8 [9.03]
2.4
45.1 [13.22]
38.5 [11.28]
2.4
43.5 [12.75]
35.2 [10.32]
2.4
41.9 [12.28]
31.9 [9.35]
2.4
85
[29.4]
Total BTUH [kW]
Sens BTUH [kW]
Power
49.6 [14.54]
30.3 [8.88]
2.6
47.8 [14.01]
27.7 [8.12]
2.5
46.1 [13.51]
25.1 [7.36]
2.5
46.9 [13.75]
36.6 [10.73]
2.6
45.3 [13.28]
33.5 [9.82]
2.5
43.6 [12.78]
30.4 [8.91]
2.5
44.3 [12.98]
38.1 [11.17]
2.6
42.8 [12.54]
34.8 [10.20]
2.5
41.2 [12.07]
31.6 [9.26]
2.5
90
[32.2]
Total BTUH [kW]
Sens BTUH [kW]
Power
48.3 [14.16]
29.6 [8.67]
2.7
46.6 [13.66]
27.1 [7.94]
2.7
44.9 [13.16]
24.5 [7.18]
2.6
45.6 [13.36]
35.9 [10.52]
2.7
44.0 [12.90]
32.9 [9.64]
2.7
42.4 [12.43]
29.8 [8.73]
2.6
43.0 [12.60]
37.4 [10.96]
2.7
41.5 [12.16]
34.2 [10.02]
2.7
40.0 [11.72]
31.0 [9.09]
2.6
95
[35]
Total BTUH [kW]
Sens BTUH [kW]
Power
46.7 [13.69]
28.8 [8.44]
2.9
45.0 [13.19]
26.3 [7.71]
2.8
43.4 [12.72]
23.9 [7.00]
2.8
44.0 [12.90]
35.1 [10.29]
2.9
42.5 [12.46]
32.1 [9.41]
2.8
40.9 [11.99]
29.1 [8.53]
2.8
41.4 [12.13]
36.5 [10.70]
2.9
40.0 [11.72]
33.4 [9.79]
2.8
38.5 [11.28]
30.3 [8.88]
2.8
100
[37.8]
Total BTUH [kW]
Sens BTUH [kW]
Power
45.0 [13.19]
27.9 [8.18]
3.0
43.4 [12.72]
25.5 [7.47]
3.0
41.8 [12.25]
23.1 [6.77]
2.9
42.4 [12.43]
34.3 [10.05]
3.0
40.9 [11.99]
31.3 [9.17]
3.0
39.4 [11.55]
28.4 [8.32]
2.9
39.8 [11.66]
35.7 [10.46]
3.0
38.4 [11.25]
32.6 [9.55]
3.0
37.0 [10.84]
29.6 [8.67]
2.9
105
[40.6]
Total BTUH [kW]
Sens BTUH [kW]
Power
43.5 [12.75]
27.2 [7.97]
3.1
42.0 [12.31]
24.9 [7.30]
3.1
40.4 [11.84]
22.5 [6.59]
3.0
40.8 [11.96]
33.5 [9.82]
3.1
39.4 [11.55]
30.7 [9.00]
3.1
38.0 [11.14]
27.8 [8.15]
3.0
38.2 [11.20]
34.9 [10.23]
3.1
36.9 [10.81]
32.0 [9.38]
3.1
35.6 [10.43]
29.0 [8.50]
3.0
110
[43.3]
Total BTUH [kW]
Sens BTUH [kW]
Power
42.4 [12.43]
26.7 [7.83]
3.3
40.9 [11.99]
24.4 [7.15]
3.2
39.4 [11.55]
22.1 [6.48]
3.2
39.7 [11.63]
33.0 [9.67]
3.3
38.3 [11.22]
30.2 [8.85]
3.2
36.9 [10.81]
27.4 [8.03]
3.2
37.1 [10.87]
34.4 [10.08]
3.3
35.8 [10.49]
31.5 [9.23]
3.2
34.5 [10.11]
28.6 [8.38]
3.2
115
[46.1]
Total BTUH [kW]
Sens BTUH [kW]
Power
41.9 [12.28]
26.5 [7.77]
3.4
40.4 [11.84]
24.3 [7.12]
3.4
39.0 [11.43]
22.0 [6.45]
3.3
39.3 [11.52]
32.9 [9.64]
3.4
37.9 [11.11]
30.1 [8.82]
3.4
36.5 [10.70]
27.3 [8.00]
3.3
36.7 [10.76]
34.3 [10.05]
3.4
35.4 [10.37]
31.4 [9.20]
3.4
34.1 [9.99]
28.4 [8.32]
3.3
45
[46.1]
Total BTUH [kW]
Power
36.9 [10.81]
2.6
36.4 [10.67]
2.7
35.9 [10.52]
2.7
36.1 [10.58]
2.9
35.6 [10.43]
3.0
35.1 [10.29]
3.1
34.6 [10.14]
3.2
IDB
34.1 [9.99]
3.3
33.6 [9.85]
3.4
60°F [15.5°C]
50
[10]
70°F [21.1°C]
Total BTUH [kW]
Power
43.7 [12.81]
2.7
80°F [26.7°C]
43.1 [12.63]
2.7
42.5 [12.46]
2.8
CFM [L/s]
42.9 [12.57]
3.0
42.3 [12.40]
3.1
1680 [793] 1400 [661] 1120 [529] 1680 [793] 1400 [661] 1120 [529] 1680 [793] 1400 [661] 1120 [529]
41.7 [12.22]
3.1
41.3 [12.10]
3.3
40.8 [11.96]
3.3
40.2 [11.78]
3.4
O
U
T
D
O
O
R
D
R
Y
B
U
L
B
T
E
M
P
E
R
A
T
U
R
E
°F
[°C]
0
[-17.8]
Total BTUH [kW]
Power
9.5 [2.78]
2.0
9.4 [2.75]
2.1
9.3 [2.73]
2.1
8.7 [2.55]
2.3
8.6 [2.52]
2.4
8.5 [2.49]
2.5
7.1 [2.08]
2.6
7.0 [2.05]
2.7
6.9 [2.02]
2.7
5
[26.7]
Total BTUH [kW]
Power
13.9 [4.07]
2.1
13.7 [4.02]
2.1
13.5 [3.96]
2.2
13.1 [3.84]
2.4
12.9 [3.78]
2.5
12.7 [3.72]
2.5
11.5 [3.37]
2.7
11.4 [3.34]
2.7
11.2 [3.28]
2.8
10
[-12.2]
Total BTUH [kW]
Power
17.1 [5.01]
2.2
16.9 [4.95]
2.2
16.7 [4.89]
2.3
16.3 [4.78]
2.5
16.1 [4.72]
2.5
15.9 [4.66]
2.6
14.8 [4.34]
2.7
14.6 [4.28]
2.8
14.3 [4.19]
2.9
15
[32.2]
Total BTUH [kW]
Power
19.5 [5.71]
2.2
19.3 [5.66]
2.3
19.0 [5.57]
2.3
18.7 [5.48]
2.5
18.4 [5.39]
2.6
18.2 [5.33]
2.7
17.2 [5.04]
2.8
16.9 [4.95]
2.9
16.7 [4.89]
2.9
20
[-6.6]
Total BTUH [kW]
Power
21.5 [6.30]
2.3
21.2 [6.21]
2.3
20.9 [6.13]
2.4
20.6 [6.04]
2.6
20.4 [5.98]
2.7
20.1 [5.89]
2.7
19.1 [5.60]
2.9
18.8 [5.51]
2.9
18.6 [5.45]
3.0
25
[37.8]
Total BTUH [kW]
Power
23.3 [6.83]
2.3
23.0 [6.74]
2.4
22.7 [6.65]
2.5
22.5 [6.59]
2.7
22.2 [6.51]
2.7
21.8 [6.39]
2.8
20.9 [6.13]
2.9
20.6 [6.04]
3.0
20.3 [5.95]
3.1
30
[-1.1]
Total BTUH [kW]
Power
25.4 [7.44]
2.4
25.1 [7.36]
2.5
24.7 [7.24]
2.5
24.6 [7.21]
2.7
24.2 [7.09]
2.8
23.9 [7.00]
2.9
23.0 [6.74]
3.0
22.7 [6.65]
3.1
22.4 [6.56]
3.2
35
[43.3]
Total BTUH [kW]
Power
28.1 [8.24]
2.5
27.8 [8.15]
2.5
27.4 [8.03]
2.6
27.3 [8.00]
2.8
26.9 [7.88]
2.9
26.5 [7.77]
2.9
25.8 [7.56]
3.1
25.4 [7.44]
3.1
25.0 [7.33]
3.2
40
[4.4]
Total BTUH [kW]
Power
31.9 [9.35]
2.5
31.4 [9.20]
2.6
31.0 [9.09]
2.7
31.0 [9.09]
2.9
30.6 [8.97]
2.9
30.2 [8.85]
3.0
29.5 [8.65]
3.1
29.1 [8.53]
3.2
28.7 [8.41]
3.3
16
SYSTEMS PERFORMANCE—RJNA- SERIES

COOLING PERFORMANCE DATA—RJNA-A048
DR —Depression ratio
dbE —Entering air dry bulb
wbE—Entering air wet bulb
Total —Total capacity x 1000 BTUH
Sens —Sensible capacity x 1000 BTUH
Power—KW input
NOTES:
➀When the entering air dry bulb is other than 80°F [27°C], adjust the sensible
capacity from the table by adding [1.10 x CFM x (1 – DR) x (dbE – 80)].
HEATING PERFORMANCE DATA—RJNA-A048
IDB—Indoor air dry bulb [ ] Designates Metric Conversions
ENTERING INDOOR AIR @ 80°F [26.7°C] dbE ➀
wbE 71°F [21.7°C] 67°F [19.4°C] 63°F [17.2°C]
CFM [L/s] 1920 [906] 1600 [755] 1280 [604] 1920 [906] 1600 [755] 1280 [604] 1920 [906] 1600 [755] 1280 [604]
DR ➀.18 .15 .11 .18 .15 .11 .18 .15 .11
O
U
T
D
O
O
R
D
R
Y
B
U
L
B
T
E
M
P
E
R
A
T
U
R
E
°F
[°C]
75
[23.9]
Total BTUH [kW]
Sens BTUH [kW]
Power
59.9 [17.55]
35.6 [10.43]
2.7
57.8 [16.94]
32.6 [9.55]
2.6
55.7 [16.32]
29.5 [8.65]
2.6
56.2 [16.47]
43.0 [12.60]
2.7
54.3 [15.91]
39.3 [11.52]
2.7
52.3 [15.33]
35.6 [10.43]
2.6
53.5 [15.68]
46.0 [13.48]
2.7
51.7 [15.15]
42.0 [12.31]
2.6
49.8 [14.59]
38.1 [11.17]
2.6
80
[26.7]
Total BTUH [kW]
Sens BTUH [kW]
Power
58.7 [17.20]
35.1 [10.29]
2.9
56.6 [16.59]
32.1 [9.41]
2.8
54.5 [15.97]
29.1 [8.53]
2.8
55.0 [16.12]
42.5 [12.46]
2.9
53.1 [15.56]
38.8 [11.37]
2.8
51.2 [15.01]
35.2 [10.32]
2.8
52.3 [15.33]
45.5 [13.33]
2.9
50.5 [14.80]
41.6 [12.19]
2.8
48.7 [14.27]
37.7 [11.05]
2.8
85
[29.4]
Total BTUH [kW]
Sens BTUH [kW]
Power
57.4 [16.82]
34.6 [10.14]
3.0
55.4 [16.24]
31.6 [9.26]
3.0
53.4 [15.65]
28.7 [8.41]
3.0
53.8 [15.77]
41.9 [12.28]
3.1
51.9 [15.21]
38.3 [11.22]
3.0
50.0 [14.65]
34.7 [10.17]
3.0
51.1 [14.98]
44.9 [13.16]
3.0
49.3 [14.45]
41.1 [12.05]
3.0
47.5 [13.92]
37.2 [10.90]
2.9
90
[32.2]
Total BTUH [kW]
Sens BTUH [kW]
Power
56.1 [16.44]
33.9 [9.94]
3.2
54.1 [15.86]
31.0 [9.09]
3.2
52.1 [15.27]
28.1 [8.24]
3.1
52.5 [15.39]
41.2 [12.07]
3.2
50.6 [14.83]
37.7 [11.05]
3.2
48.8 [14.30]
34.2 [10.02]
3.1
49.8 [14.59]
44.2 [12.95]
3.2
48.0 [14.07]
40.4 [11.84]
3.2
46.3 [13.57]
36.7 [10.76]
3.1
95
[35]
Total BTUH [kW]
Sens BTUH [kW]
Power
54.7 [16.03]
33.1 [9.70]
3.4
52.8 [15.47]
30.3 [8.88]
3.4
50.9 [14.92]
27.5 [8.06]
3.3
51.1 [14.98]
40.4 [11.84]
3.4
49.3 [14.45]
37.0 [10.84]
3.4
47.5 [13.92]
33.5 [9.82]
3.3
48.4 [14.18]
43.5 [12.75]
3.4
46.7 [13.69]
39.7 [11.63]
3.3
45.0 [13.19]
36.0 [10.55]
3.3
100
[37.8]
Total BTUH [kW]
Sens BTUH [kW]
Power
53.3 [15.62]
32.3 [9.47]
3.6
51.4 [15.06]
29.6 [8.67]
3.5
49.5 [14.51]
26.8 [7.85]
3.5
49.6 [14.54]
39.6 [11.61]
3.6
47.9 [14.04]
36.3 [10.64]
3.5
46.2 [13.54]
32.9 [9.64]
3.5
46.9 [13.75]
42.7 [12.51]
3.6
45.3 [13.28]
39.0 [11.43]
3.5
43.6 [12.78]
35.4 [10.37]
3.5
105
[40.6]
Total BTUH [kW]
Sens BTUH [kW]
Power
51.7 [15.15]
31.5 [9.23]
3.8
49.9 [14.62]
28.8 [8.44]
3.7
48.1 [14.10]
26.1 [7.65]
3.6
48.1 [14.10]
38.8 [11.37]
3.8
46.4 [13.60]
35.5 [10.40]
3.7
44.7 [13.10]
32.2 [9.44]
3.7
45.4 [13.31]
41.9 [12.28]
3.7
43.8 [12.84]
38.3 [11.22]
3.7
42.2 [12.37]
34.7 [10.17]
3.6
110
[43.3]
Total BTUH [kW]
Sens BTUH [kW]
Power
50.2 [14.71]
30.7 [9.00]
3.9
48.4 [14.18]
28.1 [8.24]
3.9
46.6 [13.66]
25.5 [7.47]
3.8
46.5 [13.63]
38.0 [11.14]
4.0
44.9 [13.16]
34.8 [10.20]
3.9
43.3 [12.69]
31.5 [9.23]
3.8
43.8 [12.84]
41.0 [12.02]
3.9
42.3 [12.40]
37.5 [10.99]
3.9
40.8 [11.96]
34.0 [9.96]
3.8
115
[46.1]
Total BTUH [kW]
Sens BTUH [kW]
Power
48.5 [14.21]
29.9 [8.76]
4.1
46.8 [13.72]
27.4 [8.03]
4.0
45.1 [13.22]
24.8 [7.27]
4.0
44.9 [13.16]
37.2 [10.90]
4.1
43.3 [12.69]
34.1 [9.99]
4.1
41.7 [12.22]
30.9 [9.06]
4.0
42.2 [12.37]
40.3 [11.81]
4.1
40.7 [11.93]
36.8 [10.79]
4.0
39.2 [11.49]
33.4 [9.79]
4.0
45
[46.1]
Total BTUH [kW]
Power
44.2 [12.95]
2.8
43.6 [12.78]
2.9
43.0 [12.60]
2.9
43.7 [12.81]
3.1
43.1 [12.63]
3.2
42.5 [12.46]
3.3
42.7 [12.51]
3.5
IDB
42.1 [12.34]
3.6
41.5 [12.16]
3.7
60°F [15.5°C]
50
[10]
70°F [21.1°C]
Total BTUH [kW]
Power
47.2 [13.83]
2.8
80°F [26.7°C]
46.5 [13.63]
2.9
45.8 [13.42]
3.0
CFM [L/s]
46.6 [13.66]
3.2
46.0 [13.48]
3.3
1440 [680] 1200 [566] 960 [453] 1440 [680] 1200 [566] 960 [453] 1440 [680] 1200 [566] 960 [453]
45.3 [13.28]
3.3
45.6 [13.36]
3.5
45.0 [13.19]
3.6
44.3 [12.98]
3.7
O
U
T
D
O
O
R
D
R
Y
B
U
L
B
T
E
M
P
E
R
A
T
U
R
E
°F
[°C]
0
[-17.8]
Total BTUH [kW]
Power
13.5 [3.96]
2.4
13.3 [3.90]
2.4
13.1 [3.84]
2.5
13.0 [3.81]
2.7
12.8 [3.75]
2.8
12.6 [3.69]
2.8
12.0 [3.52]
3.1
11.8 [3.46]
3.1
11.6 [3.40]
3.2
5
[26.7]
Total BTUH [kW]
Power
17.3 [5.07]
2.4
17.1 [5.01]
2.5
16.8 [4.92]
2.6
16.8 [4.92]
2.8
16.5 [4.84]
2.8
16.3 [4.78]
2.9
15.8 [4.63]
3.1
15.5 [4.54]
3.2
15.3 [4.48]
3.3
10
[-12.2]
Total BTUH [kW]
Power
21.0 [6.15]
2.5
20.7 [6.07]
2.5
20.4 [5.98]
2.6
20.5 [6.01]
2.8
20.2 [5.92]
2.9
19.9 [5.83]
2.9
19.5 [5.71]
3.2
19.2 [5.63]
3.2
18.9 [5.54]
3.3
15
[32.2]
Total BTUH [kW]
Power
24.6 [7.21]
2.5
24.3 [7.12]
2.6
23.9 [7.00]
2.6
24.1 [7.06]
2.8
23.7 [6.95]
2.9
23.4 [6.86]
3.0
23.1 [6.77]
3.2
22.7 [6.65]
3.3
22.4 [6.56]
3.4
20
[-6.6]
Total BTUH [kW]
Power
28.1 [8.24]
2.6
27.7 [8.12]
2.6
27.3 [8.00]
2.7
27.6 [8.09]
2.9
27.2 [7.97]
3.0
26.8 [7.85]
3.0
26.6 [7.80]
3.3
26.2 [7.68]
3.3
25.8 [7.56]
3.4
25
[37.8]
Total BTUH [kW]
Power
31.5 [9.23]
2.6
31.1 [9.11]
2.7
30.6 [8.97]
2.7
31.0 [9.09]
2.9
30.6 [8.97]
3.0
30.1 [8.82]
3.1
30.0 [8.79]
3.3
29.6 [8.67]
3.4
29.1 [8.53]
3.5
30
[-1.1]
Total BTUH [kW]
Power
34.8 [10.20]
2.7
34.3 [10.05]
2.7
33.9 [9.94]
2.8
34.3 [10.05]
3.0
33.8 [9.91]
3.1
33.3 [9.76]
3.1
33.3 [9.76]
3.3
32.8 [9.61]
3.4
32.4 [9.50]
3.5
35
[43.3]
Total BTUH [kW]
Power
38.1 [11.17]
2.7
37.5 [10.99]
2.8
37.0 [10.84]
2.8
37.5 [10.99]
3.0
37.0 [10.84]
3.1
36.5 [10.70]
3.2
36.5 [10.70]
3.4
36.0 [10.55]
3.5
35.5 [10.40]
3.6
40
[4.4]
Total BTUH [kW]
Power
41.2 [12.07]
2.8
40.6 [11.90]
2.8
40.0 [11.72]
2.9
40.7 [11.93]
3.1
40.1 [11.75]
3.2
39.5 [11.58]
3.2
39.7 [11.63]
3.4
39.1 [11.46]
3.5
38.5 [11.28]
3.6
17
SYSTEMS PERFORMANCE—RJNA- SERIES

COOLING PERFORMANCE DATA—RJNA-A060
HEATING PERFORMANCE DATA—RJNA-A060
DR —Depression ratio
dbE —Entering air dry bulb
wbE—Entering air wet bulb
Total —Total capacity x 1000 BTUH
Sens —Sensible capacity x 1000 BTUH
Power—KW input
NOTES:
➀When the entering air dry bulb is other than 80°F [27°C], adjust the sensible
capacity from the table by adding [1.10 x CFM x (1 – DR) x (dbE – 80)].
IDB—Indoor air dry bulb [ ] Designates Metric Conversions
ENTERING INDOOR AIR @ 80°F [26.7°C] dbE ➀
wbE 71°F [21.7°C] 67°F [19.4°C] 63°F [17.2°C]
CFM [L/s] 2500 [1180] 2000 [944] 1500 [708] 2500 [1180] 2000 [944] 1500 [708] 2500 [1180] 2000 [944] 1500 [708]
DR ➀.22 .19 .15 .22 .19 .15 .22 .19 .15
O
U
T
D
O
O
R
D
R
Y
B
U
L
B
T
E
M
P
E
R
A
T
U
R
E
°F
[°C]
75
[23.9]
Total BTUH [kW]
Sens BTUH [kW]
Power
74.9 [21.95]
44.2 [12.95]
4.0
71.6 [20.98]
39.6 [11.61]
3.9
68.4 [20.05]
35.0 [10.26]
3.8
71.3 [20.90]
53.4 [15.65]
3.9
68.2 [19.99]
47.8 [14.01]
3.9
65.1 [19.08]
42.3 [12.40]
3.8
67.6 [19.81]
57.5 [16.85]
3.9
64.6 [18.93]
51.5 [15.09]
3.8
61.7 [18.08]
45.5 [13.33]
3.8
80
[26.7]
Total BTUH [kW]
Sens BTUH [kW]
Power
74.4 [21.80]
44.3 [12.98]
4.2
71.2 [20.87]
39.7 [11.63]
4.1
67.9 [19.90]
35.0 [10.26]
4.1
70.8 [20.75]
53.5 [15.68]
4.2
67.7 [19.84]
47.9 [14.04]
4.1
64.6 [18.93]
42.3 [12.40]
4.0
67.1 [19.67]
57.6 [16.88]
4.1
64.2 [18.82]
51.5 [15.09]
4.1
61.2 [17.94]
45.5 [13.33]
4.0
85
[29.4]
Total BTUH [kW]
Sens BTUH [kW]
Power
73.3 [21.48]
43.8 [12.84]
4.5
70.2 [20.57]
39.2 [11.49]
4.4
67.0 [19.64]
34.7 [10.17]
4.3
69.7 [20.43]
53.0 [15.53]
4.4
66.7 [19.55]
47.5 [13.92]
4.3
63.6 [18.64]
41.9 [12.28]
4.2
66.0 [19.34]
57.1 [16.73]
4.4
63.1 [18.49]
51.1 [14.98]
4.3
60.3 [17.67]
45.2 [13.25]
4.2
90
[32.2]
Total BTUH [kW]
Sens BTUH [kW]
Power
71.8 [21.04]
43.0 [12.60]
4.7
68.7 [20.13]
38.5 [11.28]
4.6
65.6 [19.23]
34.0 [9.96]
4.5
68.2 [19.99]
52.2 [15.30]
4.6
65.2 [19.11]
46.7 [13.69]
4.5
62.3 [18.26]
41.3 [12.10]
4.4
64.5 [18.90]
56.3 [16.50]
4.6
61.7 [18.08]
50.4 [14.77]
4.5
58.9 [17.26]
44.5 [13.04]
4.4
95
[35]
Total BTUH [kW]
Sens BTUH [kW]
Power
70.0 [20.51]
41.9 [12.28]
4.9
67.0 [19.64]
37.5 [10.99]
4.8
63.9 [18.73]
33.2 [9.73]
4.7
66.4 [19.46]
51.1 [14.98]
4.8
63.5 [18.61]
45.8 [13.42]
4.7
60.6 [17.76]
40.4 [11.84]
4.6
62.7 [18.38]
55.2 [16.18]
4.8
60.0 [17.58]
49.4 [14.48]
4.7
57.2 [16.76]
43.7 [12.81]
4.6
100
[37.8]
Total BTUH [kW]
Sens BTUH [kW]
Power
68.0 [19.93]
40.7 [11.93]
5.1
65.1 [19.08]
36.5 [10.70]
5.0
62.1 [18.20]
32.2 [9.44]
4.9
64.4 [18.87]
49.9 [14.62]
5.1
61.6 [18.05]
44.7 [13.10]
5.0
58.8 [17.23]
39.5 [11.58]
4.9
60.7 [17.79]
54.0 [15.83]
5.0
58.1 [17.03]
48.4 [14.18]
4.9
55.4 [16.24]
42.7 [12.51]
4.8
105
[40.6]
Total BTUH [kW]
Sens BTUH [kW]
Power
66.0 [19.34]
39.6 [11.61]
5.4
63.1 [18.49]
35.4 [10.37]
5.3
60.3 [17.67]
31.3 [9.17]
5.1
62.4 [18.29]
48.8 [14.30]
5.3
59.7 [17.50]
43.7 [12.81]
5.2
56.9 [16.68]
38.6 [11.31]
5.1
58.7 [17.20]
52.8 [15.47]
5.3
56.1 [16.44]
47.3 [13.86]
5.2
53.6 [15.71]
41.8 [12.25]
5.1
110
[43.3]
Total BTUH [kW]
Sens BTUH [kW]
Power
64.1 [18.79]
38.5 [11.28]
5.6
61.3 [17.97]
34.5 [10.11]
5.5
58.5 [17.14]
30.5 [8.94]
5.4
60.5 [17.73]
47.7 [13.98]
5.5
57.8 [16.94]
42.7 [12.51]
5.4
55.2 [16.18]
37.8 [11.08]
5.3
56.8 [16.65]
51.8 [15.18]
5.5
54.3 [15.91]
46.4 [13.60]
5.4
51.8 [15.18]
41.0 [12.02]
5.3
115
[46.1]
Total BTUH [kW]
Sens BTUH [kW]
Power
62.4 [18.29]
37.8 [11.08]
5.8
59.7 [17.50]
33.8 [9.91]
5.7
57.0 [16.71]
29.9 [8.76]
5.6
58.8 [17.23]
47.0 [13.77]
5.7
56.2 [16.47]
42.1 [12.34]
5.6
53.7 [15.74]
37.2 [10.90]
5.5
55.1 [16.15]
51.1 [14.98]
5.7
52.7 [15.44]
45.7 [13.39]
5.6
50.3 [14.74]
40.4 [11.84]
5.5
45
[46.1]
Total BTUH [kW]
Power
59.9 [17.55]
3.8
58.9 [17.26]
3.9
57.8 [16.94]
4.1
58.3 [17.09]
4.2
57.3 [16.79]
4.4
56.3 [16.50]
4.5
58.2 [17.06]
4.7
IDB
57.2 [16.76]
4.9
56.2 [16.47]
5.0
60°F [15.5°C]
50
[10]
70°F [21.1°C]
Total BTUH [kW]
Power
63.1 [18.49]
3.9
80°F [26.7°C]
62.0 [18.17]
4.0
60.9 [17.85]
4.1
CFM [L/s]
61.5 [18.02]
4.3
60.4 [17.70]
4.5
2500 [1180] 2000 [944] 1500 [708] 2500 [1180] 2000 [944] 1500 [708] 2500 [1180] 2000 [944] 1500 [708]
59.3 [17.38]
4.6
61.4 [17.99]
4.8
60.4 [17.70]
5.0
59.3 [17.38]
5.1
O
U
T
D
O
O
R
D
R
Y
B
U
L
B
T
E
M
P
E
R
A
T
U
R
E
°F
[°C]
0
[-17.8]
Total BTUH [kW]
Power
16.6 [4.86]
3.0
16.3 [4.78]
3.1
16.0 [4.69]
3.2
15.0 [4.40]
3.4
14.7 [4.31]
3.5
14.4 [4.22]
3.7
14.9 [4.37]
3.9
14.6 [4.28]
4.1
14.4 [4.22]
4.2
5
[26.7]
Total BTUH [kW]
Power
22.7 [6.65]
3.1
22.3 [6.54]
3.2
21.9 [6.42]
3.3
21.1 [6.18]
3.5
20.7 [6.07]
3.6
20.3 [5.95]
3.7
21.0 [6.15]
4.0
20.6 [6.04]
4.2
20.3 [5.95]
4.3
10
[-12.2]
Total BTUH [kW]
Power
28.5 [8.35]
3.2
28.0 [8.21]
3.3
27.5 [8.06]
3.4
26.9 [7.88]
3.6
26.4 [7.74]
3.7
25.9 [7.59]
3.8
26.8 [7.85]
4.1
26.3 [7.71]
4.2
25.9 [7.59]
4.4
15
[32.2]
Total BTUH [kW]
Power
34.0 [9.96]
3.3
33.4 [9.79]
3.4
32.8 [9.61]
3.5
32.3 [9.47]
3.7
31.8 [9.32]
3.8
31.2 [9.14]
3.9
32.3 [9.47]
4.2
31.7 [9.29]
4.3
31.1 [9.11]
4.5
20
[-6.6]
Total BTUH [kW]
Power
39.1 [11.46]
3.4
38.4 [11.25]
3.5
37.7 [11.05]
3.6
37.5 [10.99]
3.8
36.8 [10.79]
3.9
36.2 [10.61]
4.0
37.4 [10.96]
4.3
36.8 [10.79]
4.4
36.1 [10.58]
4.6
25
[37.8]
Total BTUH [kW]
Power
43.9 [12.87]
3.5
43.2 [12.66]
3.6
42.4 [12.43]
3.7
42.3 [12.40]
3.9
41.5 [12.16]
4.0
40.8 [11.96]
4.1
42.2 [12.37]
4.4
41.5 [12.16]
4.5
40.7 [11.93]
4.7
30
[-1.1]
Total BTUH [kW]
Power
48.4 [14.18]
3.5
47.6 [13.95]
3.7
46.7 [13.69]
3.8
46.8 [13.72]
4.0
46.0 [13.48]
4.1
45.1 [13.22]
4.2
46.7 [13.69]
4.5
45.9 [13.45]
4.6
45.1 [13.22]
4.8
35
[43.3]
Total BTUH [kW]
Power
52.6 [15.42]
3.6
51.7 [15.15]
3.7
50.7 [14.86]
3.9
50.9 [14.92]
4.0
50.1 [14.68]
4.2
49.2 [14.42]
4.3
50.9 [14.92]
4.6
50.0 [14.65]
4.7
49.1 [14.39]
4.8
40
[4.4]
Total BTUH [kW]
Power
56.4 [16.53]
3.7
55.4 [16.24]
3.8
54.5 [15.97]
4.0
54.8 [16.06]
4.1
53.8 [15.77]
4.3
52.9 [15.50]
4.4
54.7 [16.03]
4.6
53.8 [15.77]
4.8
52.8 [15.47]
4.9
18
SYSTEMS PERFORMANCE—RJNA- SERIES

External Static Pressure—Inches W.C. [kPa]
CFM [L/s] Air Delivery/RPM/Watts—208 Volts Side Discharge—Wet Coil
4.0
[14.07] Low
Blower Size/
Motor
HP [w] &
# of Speeds
Nominal
Cooling
Capacity
Tons [kW]
3.5
[12.30]
Factory
Motor
Speed
1400/1800
Manufacturer
Recommended
Air-Flow Range
(Min/Max) CFM
Motor
Speed
10x10
1/2 HP [373]
3 Speed Motor
High
CFM
Low
1766 [833] 1719 [811] 1671 [789] 1617 [763]
1225/1575
10x10
1/2 HP [373]
3 Speed Motor
1550 [732] 1465 [691]
10x10
1/2 HP [373]
3 Speed Motor
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17]
Watts 735 719 697 671 639 603 Watts 493 481 468 452 431 402
Med
CFM 1397 [659] 1344 [634] 1319 [622] 1297 [612] 1249 [589] 1147 [541]
3.0
[10.55] Low 1050/1350 Low
CFM 1275 [602] 1235 [583] 1210 [571] 1181 [557] 1132 [534] 1045 [493]
Watts 561 537 522 508 488 454
0.8 [.20] 0.9 [.22] 1.0 [.25]
5.0
[17.6]
High
CFM
Low
2185 [1031] 2148 [1014] 2112 [997] 2076 [980]
1750/2250
11x9
1 HP [746]
2 Speed
Motor 2040 [963] 2005 [946] 1970 [930]
780
1935 [913]
Watts 675 685 700 720 735 750 770 805
1900 [897]
Low
CFM 1974 [932] 1935 [913] 1897 [895] 1860 [878] 1823 [860] 1788 [844] 1753 [827]
605
1719 [811]
Watts 490 505 510 545 555 575 600 625
1686 [796]
DIRECT-DRIVE BLOWER 208 AIRFLOW PERFORMANCE
External Static Pressure—Inches W.C. [kPa]
CFM [L/s] Air Delivery/RPM/Watts—230/460 Volts Side Discharge—Wet Coil
4.0
[14.07] High
Blower Size/
Motor
HP [w] &
# of Speeds
Nominal
Cooling
Capacity
Tons [kW]
3.5
[12.30]
Factory
Motor
Speed
1400/1800
Manufacturer
Recommended
Air-Flow Range
(Min/Max) CFM
Motor
Speed
10x10
1/2 HP [373]
3 Speed
Motor
Med
CFM
Med.
1964 [927] 1902 [898] 1839 [868] 1771 [836]
1225/1575
10x10
1/2 HP [373]
3 Speed
Motor
1693 [799] 1602 [756]
10x10
1/2 HP [373]
3 Speed
Motor
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17]
Watts 847 811 780 751 721 688
*5.0*
[17.6]
High
CFM
Low
2185 [1031] 2148 [1014] 2112 [997] 2076 [980]
1750/2250
11x9
1 HP [746]
2 Speed
Motor 2040 [963] 2005 [946] 1970 [930]
780
1935 [913]
Watts 675 685 700 720 735 750 770 805
1900 [897]
Low
CFM 1974 [932] 1935 [913] 1897 [895] 1860 [878] 1823 [860] 1788 [844] 1753 [827]
605
1719 [811]
Watts 490 505 510 Watts 578 565 549 528 502 472
545 555
Med
CFM 1601 [756] 1561 [737] 1517 [716] 1466 [692] 1401 [661] 1317 [622]
3.0
[10.55] Low 1050/1350 Low
CFM 1455 [687] 1423 [672] 1388 [655] 1345 [635] 1289 [608]
575
1214 [573]
Watts 659 636 613 589 562 529
600 625
1686 [796]
0.8 [.20] 0.9 [.22] 1.0 [.25]
DIRECT-DRIVE BLOWER 230/460 AIRFLOW PERFORMANCE
19
AIRFLOW PERFORMANCE—RJNA- SERIES
*There is not a 5-ton 460 Volt Direct Drive. [ ] Designates Metric Conversions

20
AIRFLOW PERFORMANCE—RJNA- SERIES
825
Models RJNA-A036 [10.55 kW] & A042 [12.31 kW]—Heat Pump (13 SEER)
External Static Pressure—Inches of Water [kPa]
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17] 0.8 [.20] 0.9 [.22] 1.0 [.25] 1.1 [.27] 1.2 [.30] 1.3 [.32] 1.4 [.35] 1.5 [.37]
RPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM W
900 [425] — — — — 665 290 730 300 780 315 830 330 875 360 920 375 960 390 990 410 1040 445 1080 470 1140 510 1190 540 1235 590
1000 [472] — — 625 275 680 295 750 310 805 325 850 345 895 375 935 390 970 410 1015 435 1065 465 1100 500 1160 530 1210 560 1255 610 1100 [519] — — 640 300 710 315 780 325 830 340 875 365 915 390 955 405 990 430 1040 450 1080 485 1115 540 1180 540 1230 600 1270 630 1200 [566] — — 670 315 735 330 800 345 850 365 890 385 935 410 975 430 1010 450 1060 475 1100 520 1145 560 1200 600 1250 630 1285 660 1300 [614] 625 315 700 330 770 350 830 370 875 400 915 415 955 440 990 450 1040 495 1085 530 1125 565 1165 590 1220 645 1260 675 1305 710 1400 [661] 655 340 730 365 795 385 850 400 890 430 935 445 975 470 1010 500 1070 540 1110 575 1150 615 1195 645 1230 685 1280 725 1325 760 1500 [708] 685 380 755 390 415 870 435 915 450 955 480 990 505 1040 545 1090 590 1135 630 1180 660 1220 720 1255 740 1295 785 1350 820 1600 [755] 730 420 790 435 850 455 890 490 935 505 970 525 1005 550 1075 605 1110 640 1160 680 1200 730 1245 780 1280 800 1325 840 1365 885 1700 [802] 755 465 825 475 875 505 915 535 955 550 985 570 1040 630 1100 685 1135 710 1185 750 1225 800 1265 830 1295 875 1350 910 — — 1800 [850] 790 500 850 530 890 550 935 570 975 600 1020 650 1080 690 1125 740 1165 770 1210 830 1245 870 1290 910 1310 930 — — — —
Voltage 208/230-460—3 Phase
Air
Flow
CFM [L/s]
Drive Package L M N (Field-Supplied)
Motor H.P. [w] 1/2 [373] (3/4 [559] - 575V) 3/4 [559] 3/4 [559]
Blower Sheave 6.9 Pitch Diameter 6.4 Pitch Diameter 6.4 Pitch Diameter
Motor Sheave Adjustable 2.4-3.4 Pitch Diameter Adjustable 3.4-4.4 Pitch Diameter Adjustable 4.0-5.0 Pitch Diameter
Turns Open 0 1 23 4 5 6 0 1 2 3 45 6
RPM 935 875 830 780 730 680 625 1295 1230 1185 1135 1085 1000 955 RPM Range 1090-1365
Factory sheave settings are shown in bold print. BELT-DRIVE AIRFLOW PERFORMANCE NOTE: Bold lines separate L, M and N drives respectively.
1160 1275
895
Models RJNA-A048 [14.06 kW]—Heat Pump (13 SEER)
RPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM WRPM W
1200 [566] — — — — 745 340 810 375 390 900 400 945 420 1000 440 1040 460 1075 490 1115 540 1170 580 1215 620 1260 650 1300 685 1300 [614] — — 695 330 770 365 835 395 880 415 920 435 975 455 1010 470 1060 490 1100 530 1140 570 1190 600 1235 640 1270 685 1315 740 1400 [661] — — 725 350 795 395 855 420 895 435 945 455 995 470 1030 500 1070 520 1115 560 600 1205 640 1250 685 1290 745 1335 810 1500 [708] 690 360 750 390 820 425 875 450 920 465 970 480 1010 500 1055 560 1100 580 1140 630 1180 660 1230 700 1270 760 1315 815 1350 865 1600 [755] 720 390 780 430 850 460 895 480 945 500 990 530 1035 565 1075 590 1115 635 1160 680 1205 725 1250 770 1290 830 1335 890 1365 935 1700 [802] 750 430 810 465 870 485 920 500 970 530 1015 570 1055 600 1090 645 1140 695 1180 735 1225 790 1270 845 1315 910 1350 960 — — 1800 [850] 780 475 840 515 540 945 555 990 600 1035 625 1080 660 1115 710 1155 740 1205 800 1250 860 1295 930 1340 995 1365 1030 — — 1900 [897] 820 520 870 560 925 580 970 600 1015 640 1060 690 1115 750 1145 790 1185 835 1225 880 900 1315 1010 1355 1060 — — — — 2000 [944] 850 585 900 610 950 630 1000 665 1045 715 1090 760 1130 810 1170 865 1205 900 1255 965 1300 1050 1340 1100 1365 1140 — — — —
865
External Static Pressure—Inches of Water [kPa]
Air
Flow
CFM [L/s]
Voltage 208/230-460—3 Phase
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17] 0.8 [.20] 0.9 [.22] 1.0 [.25] 1.1 [.27] 1.2 [.30] 1.3 [.32] 1.4 [.35] 1.5 [.37]
Factory sheave settings are shown in bold print. Note: See component air resistance table in this manual. [ ] Designates Metric Conversions NOTE: Bold lines separate L, M and N drives respectively.
Drive Package L M N (Field-Supplied)
Motor H.P. [w] 1/2 [373] (3/4 [559] - 575V) 3/4 [559] 3/4 [559]
Blower Sheave 6.9 Pitch Diameter 6.4 Pitch Diameter 6.4 Pitch Diameter
Motor Sheave Adjustable 2.8-3.8 Pitch Diameter Adjustable 3.4-4.4 Pitch Diameter Adjustable 4.0-5.0 Pitch Diameter
Turns Open 012 3 4 5 6 0 1 23 4 5 6
RPM 990 945 895 850 800 750 695 1270 1225 1170 1115 1065 1015 965 RPM Range 1090-1365
BELT-DRIVE AIRFLOW PERFORMANCE
