LFL-C30-CS2 LED Floodlight Installation Manual
LFL-C30-CS2
1.1 Installation & Dimensions(Unit: mm)
Size diagram (Figure A)
RoHS 35,000h Outdoor
LNGND
Brown - L
Blue --- N
G/Y --- GND
Caution:
vertical installation is
absolutely not permitted
Caution:
vertical installation is
absolutely not permitted
Notes before installation:
Please read LED Flood light use manual carefully before installation and follow the instructions.
To avoid accidents like damage, dropping, electric shock, fire, please don't arbitrarily retrofit or change any lamp fittings. Clean
lamps with a soft wrung-out soapy cloth, and then wipe it with a dry cloth. Please don't wipe the lamps with gasoline or other
volatiles. Please don't spray insecticides on the lamps. Otherwise, it may cause discoloration or damage. Please do not open the
lamp without permission.
Please turn off the power when in installation or maintenance.
Please installation follow below way:
1. Mount the LFL-C30-CS2 Flood light onto a surface, wall or ceiling by adjusting the attached U-Shape bracket (0 ~ 180°).
2. Rotate the flood light (0 ~ 340°) in the direction most suitable for the lighting installation. Do not mount the flood light vertically up or
vertically down (refer to Figure B).
3. Connect the power cable to a 100~240VAC power supply.
4. Ambient Sensor: Turn the dial +/- to adjust the lux level sensitivity from 2 ~2000lx (refer to Figure C).
5. PIR Sensor: turn the dial +/- to adjust the passive infrared sensitivity from 2 ~6m radius (refer to Figure C).
6. On-time delay: turn the dial +/- to adjust the time the light stays on from 5s ~ 5mins before switching off (refer to Figure C).
Mounting diagram (Figure B)
the motion sensor can be adjusted 340° from left to right;
available for any kind of installation method
Lux: Set the lux of sensor light
Time: Set the Lighting Time
Sens: Set the sensitivity of sensor light
1.5s~5min adjustable time settings
2.Sensor head easy to adjustable angle
(Pan:150° / +75° ,-75°; Tilt: 180° / +90°,-90°)
PIR
angle adjustable from upside to
downside 0°/-90° 0°/-90°
the motion sensor can be adjusted up
and down over 90°
PIR Motion Sensor (Figure C)
Installation Instructions
30W

1.2Motion Sensor Diagram
1.5Attention
Since the PIR sensor can sense surrounding changes of brightness and temperature,like in places below,it may cause mis-operation or non-operation.
1. Install by qualified electricians only.
2. Make sure that the supply voltage is disconnected before installation.
3. Make sure the voltage is suitable with the lamps, And L/N/G connect properly.
4. All the lights during installation or using should not be leds’s cover vertical upside or Vertical down.
5. Don’t open the lamps without Manufacturer’s Authorization.
1.No close to plants or curtains
that sway because of wind.
2.No close to air-conditioners,
or in draft.
3.No close to marble floor or
stuff that releases intnense
radiation.
4.No close to glasses or
partition walls.
6.No facing to road on which
cars go through.
7.No being installed in places
that release strong radio waves. .8.No being installed at the height over 5M.
5.No close to places that can
easily vibrate.
When installation,
please put this side
downwards.
PIR Motion Sensor Rotation (Figure D)
