RhinoVac RH35LW User manual

RH35LW
Shop Vacuum
USER GUIDE

User guide
RH35LW
2
RH35LW
User Guide
Table of contents:
1- Machine Components ................................................3
2- Before Assembly and Starting Operation ...................4
3- Technical Data ............................................................5
4- Overview of Nozzles ...................................................5
5- Assembly ................................................................... 6
6- Wet Vacuum Cleaning.................................................7
7- Dry Vacuum Cleaning..................................................8
8- Blowing .......................................................................9
9- Maintenance Cleaning ................................................9
Read all safety rules carefully before attempting
to operate. Retain for future reference.

User guide RH35LW
3
1. Machine Components
1- Handle
2- ON/ OFF switch
3- Top section
4- Latch
5- Vacuum hose connector
6- Tank
7- Accessories holder
8- Pedestal
9- Wheel
10- Cloth bag
11- Safety float valve
12- Filter basket
13- Sponge filter
14- Plastic tube
15- Hose
16- Paper dust bag
17- Floor brush
18- Crevice tool
1
2
5
7
8
9
3
4
6

User guide
RH35LW
4
2. Before Assembly and Starting Operation
ATTENTION:
If the supply cord is damaged, it must be replaced by the manufacturer or it’s
service agent to a similarly qualified person in order to avoid hazards.
Before cleaning or maintaining the appliance, the power plug must be removed
from the socket.
Check the entire accessory before connect and use them to make sure they are
in correct position and there’s not any defect.
• Read the operating instructions carefully
• Check that the mains voltage corresponds to the details on the type plate
• Only connect to a proper 120volt, 60Hz socket
• Pull the mains plug out of the socket when the unit is not in use, before opening the unit,
before cleaning and maintenance
• Never clean with solvents
• Do not use the cable to pull the plug out of the socket
• ●When unit is ready for use, do not leave unattended
• Safeguard from children
• Care must be taken that the main connection lead is not damaged by being driven over,
crushed, stretched, etc.
• The unit must not be operated if the mains connection lead is not in perfect condition
• Replacement mains connection leads must not differ from the versions indicated by the
manufacturer
• On no account vacuum: burning matches, glowing ashes and cigarette ends, inflammable,
corrosive, fire hazard or explosive substances, vapours and liquids
• This unit is not suitable for vacuuming dust which is damaging to health
• Store the unit in a dry place
• Do not operate a defection unit
• Servicing only by an authorized after-sales service point
• Use only for operations for which the unit is intended
• Take great care when cleaning stairs
• Use only manufacturer attachments and spare parts

User guide RH35LW
5
3. Technical Data
Rated voltage:................ 120 V
Normal frequency:......... 60 Hz
Rated power: ................ 1000 W
Capacity:........................ 35 L
4. Overview of Nozzles

User guide
RH35LW
6
1. When you assemble products, don’t plug into electricity
2. Loosen the locking hooks
3. Remove the suction group
4. Remove the contents of the tank
5. Assemble the wheels on the bottom of the tank
6a. Pull the supplied sponge filter over the filter basket for wet vacuum cleaning
6b Slip the paper dustbag onto the suction mouth for dry vacuum cleaning
7. Put the top cover on the tank
8. Make the clips locking on the cover
9. Insert the suction hose in the hole on the side of the tank,turn the hose
connector and it is ready to work
10. Slide the brush at the end of the wand
5. Assembly
1

User guide RH35LW
7
1. When you assemble products,please don’t plug into electricity
2. Loosen the locking hooks, pull the supplied sponge filter over the filter basket for wet vacuum
cleaning,then make the clips locking on the cover
3. Insert the suction hose in the hole on the side of the tank, turn the hose connector
4. Then Insert the plug into the socket
5. Press the switch and the machine begins to work
6. After working or when the bin is full, what significantly decreases the suction power,remove
the plug from the electrical socket and clean the drum
7. To do this,unhook the two locks and remove the suction unit and filter
6. Wet Vacuum Cleaning
1
4
3

User guide
RH35LW
8
1. When you assemble products,please don’t plug into electricity
2. Loosen the locking hooks, slip the paper dust bag onto the suction mouth for dry vacuum
3. Cleaning, then make the clips locking on the cover
4. Insert the suction hose in the hole on the side of the tank turn the hose connector
5. Insert the plug into the socket
6. Press the switch and the machine begins to work
7. After working or when the bin is full,what significantly decreases the suction power,remove
the plug from the electrical socket and clean the drum.To do this,unhook the two locks and
remove the suction unit and filter.Usually,when the paper dustbag to be full, throw it into the
ash bin
7. Dry Vacuum Cleaning
1
5

User guide RH35LW
9
8. Blowing
9. Maintenance Cleaning
1. Insert one side of hose in the air outlet mouth on the top cover
2. Then, insert the plug into the socket
3. Press the switch and the machine begins to work
4. You can blow the ash
1. After working or when the bin is full,what significantly decreases the suction power
2. Remove the plug from the electrical socket and clean the drum
3. To do this, unhook the two locks and remove the suction unit and filter.
4. Clean the drum
5 Wash the sponge filter with clean water and soft soap. Rinse well
1
2
ATTENTION
When you use the blower function, always be careful and were safety glasses.

FOR
PARTS, ACCESSORIES &
VACUUM BAGS
VISIT OUR WEBSITE AT
www.rhino-vac.com
RH35LW - EN - User Guide
