Richmond K302-1 User manual

Model K302-1
Photographs are notto scale.
Specifications subjectto change
without prior notice. 0359
WARNING
• For outdoor use only. Notforcommercial use.
• Use only Propaneregulator37mbar.
• Read instructionsbeforeusingtheappliance.Failuretofollowinstructionscould
resultindeath,serious bodily injury, and/orproperty loss.
• Warning: accessibleparts may be very hot. Keep young childrenaway.
• Do not movetheapplianceduring use.
• Turn off the gas supply atthegasbottle afteruse.
• Any modification oftheappliance,misuse, orfailure tofollowthe instructions may
be dangerousandwillinvalidate yourwarranty.This does notaffect your statutory
rights.
• Retain theseinstructionsforfuturereference.
• Leak testyour barbecue annually. Check thehoseconnections are tightandleak
testthem each time you reconnectthe gas bottle.
FOR YOUR SAFETY
Ifyou smell gas:
1. Shut offgastotheappliance.
2. Extinguishany openflame.
3. Openbarbecuelid orhood.
4. Ifodourcontinues, discontinue use and
contact yourlocaldealer.
FOR YOUR SAFETY
1. Do notstoreorusepetrol or otherflammable
vapoursorliquidsinthe vicinity ofthisorany
otherappliance.
2. A gas bottlenot connected foruseshall not be
stored in thevicinity ofthis or any other
appliance.
Assembly and Operating Instructions for
Richmond3 Burner Gas BBQ
PDF created with pdfFactory trial version www.pdffactory.com

2
A. Parts List
Quantities varyaccording to model purchased. Specifications subject to change without priornotice. For more details on
hardware, please see the corresponding Hardware Reference Diagramforyour barbecue model.
Code. Part Qty
Lid Assembly
A1 Lid left side plate 1
A2 Lid 1
A3 Temperature gauge 1
A4 Lid right side plate 1
A5 Lid handle 1
Grill Assembly
B1 Warming rack 1
B2 Grill back plate 1
B3 Heat tent 3
B4 Burner 3
B5 Cookinggrill 2
B6 Fuze 2
B7 Controlpanel 1
B8 Controlknob 3
B9 Heat insulationplate 1
B10 Body assembly 1
B11 Grease tray 1
B12 HVR (Hose, Valve &
Regulator) 1
Sideshelf Assembly
C1 Sideshelfhandle 2
C2 Sideshelf 6
C3 Endcapof side shelf tube 8
C4 Sideshelffrontsupport 2
C5 Sideshelfback support 2
Trolley Assembly
D1 Leftfront leg 1
D2 Left rear leg 1
D3 Right front leg 1
D4 Right rear leg 1
D5 Wheel 2
D6 Wheel cap 2
D7 Bottom shelf assembly 1
Hardware
E1 M6*35 bolt 4
E2 M6*12 bolt 12
E3 M5*40 bolt 8
E4 Axle 2
E5 R pin 2
PDF created with pdfFactory trial version www.pdffactory.com

3
B1. Parts Diagram
Quantities varyaccording to model purchased. Specifications subject to change without priornotice. For more details on
hardware, please see the corresponding Hardware Reference Diagramforyour barbecue mode
PDF created with pdfFactory trial version www.pdffactory.com

4
B2. Hardware ReferenceDiagram
Specifications subject to change without priornotice.
K302-1
PDF created with pdfFactory trial version www.pdffactory.com

5
C. Assembly
TOOLS NEEDED FOR ASSEMBLY:
Medium size flat blade or Philips/cross-point screwdriver, adjustable spanner or metricspanner set
This barbecue requires two people for assembly.Please removeallpackaging materials from allindividualparts before
assembling.Please lay outallnuts and bolts and check lengths before assembling.Whilst everycareis takenduringthe
manufacture of this product, care must be taken during the assembly in case sharp edges are present.
1
Fig 1a Fig 1b
Put theLeft Front Leg (D1), Left Rear Leg (D2), RightFront Leg(D3) andRight Rear Leg(D4) on the Lid and
Grill Assembly using M6*12 bolts (E2) as fig 1aandfig1b. Fix the bolts tightly by the screwdriver.
2
Fig 2a Fig 2b
Put theLeft Front Leg (D1), Left Rear Leg (D2), RightFront Leg(D3) andRight Rear Leg(D4) on the Bottom
Shelf Assembly (D7) using M5*40bolts(E3) as fig 2aand fig2b. Fix thebolts tightlyby the screwdriver.
D7 E3
E3 D4
D3
D2
D1
PDF created with pdfFactory trial version www.pdffactory.com

6
3
Fig 3a Fig 3b
Insert theWheels (D5) to the Left FrontLeg (D1) and LeftRear Leg (D2) usingthe Axel (E4). Then fix the
Axel (E4) bythe R Pins(E5) and cover theWheels (D5) by theWheel Caps(D6) as fig3a and fig 3b.
4
Fig 4
Fix theSide ShelfAssembly on theLeft Legs andRight Legs using M6*35bolts (E1) and M6*12bolts (E2)
as fig4.
D1
D5
D6
E4
E5
D2
PDF created with pdfFactory trial version www.pdffactory.com

7
B5
B3
5
Fig 5
6
Put theGreaseTray (B11) on the Grill as Fig5.
Fig 6
Put the HeatTent (B3) andCookingGrill (B5) onthe Grill as fig 6.
B11
PDF created with pdfFactory trial version www.pdffactory.com

8
7
Fig 7
Put theWarming Rack (B1) on the Grill and completetheassembly as fig7.
B1
PDF created with pdfFactory trial version www.pdffactory.com

9
D. Important Information
Please read these instructions carefully before
assembly anduse.
• Retain these instructions for future reference.
• For outdoors use only do not use indoors. Do
not use below ground level.
• For use with LPG bottled gas only.Aregulator of
37mbar must be used for propane.
• Do not use within 1mofany flammable structure
or surface.
• LP gas cylinders should notbeplaceddirectly
underneath the barbecue.
• LP gas cylinders must not bestored or used in the
horizontal position. Aleak would be very serious
and liquid could enter the gas line.
• When igniting barbecue open its hood before
lighting.
• Do not movethe barbecue while alight.
• This barbecue must not be leftunattended when
lit.
• The hood handle can become veryhot.Grip only
the centre ofthe handle. Use ofa cooking gloveis
advised.
• Use caution when opening the hood, as hot
steam inside is released upon opening.
• Parts of this barbecue become very hot care
must be taken when children,elderly people,and
animals are present.
• Always turn off the gas bottle when the barbecue
is not in use.
• Never cover abarbecue until ithas completely
cooled.
• Never use thebarbecue with theside shelfinthe
down position.
• Leak test annually, and whenever the gas bottle is
removed orreplaced.
• Do not store flammable materials near this
barbecue.
• Do not use aerosols near this barbecue.
• Failure to follow the manual’sinstructions could
result inserious injuryor damage.
• Ifyou have any queries regarding these
instructions, contact yourlocal dealer.
E.Gas andRegulator
This barbecue can useonly propane LPG bottled
gas. Propane bottles willsupply gas allyear round,
even on cold winter days. A spanner maybe required
to change gas bottles. The bottle should never be
stood on the trolley base and placeddirectlyunder
the barbecue. Gas bottles should never be stored or
used laid on theirside. Neverstore gas bottles
indoors.
YOU MUSTHAVE THE PROPER REGULATOR
AND BOTTLEINORDER FOR THEBARBECUETO
OPERATE SAFELY ANDEFFICIENTLY.USEOF
AN INCORRECTOR FAULTY REGULATOR IS
DANGEROUSAND WILL INVALIDATE ANY
WARRANTY. Please consult your localgas dealer
forthe most suitable gas bottles.
F.Installation
F1. Selecting aLocation
This barbecue is foroutdoor use only and should be
placed in awell-ventilated area. Take care to ensure
that itis not placed UNDERanycombustiblesurface.
The sides of the barbecue should NEVER be closer
than 1metre from any combustiblesurface.Keep
this barbecue away from any flammable materials!
F2. Precautions
Do not obstructanyventilationopenings inthe
barbecue body. Secure the gas bottle on the cylinder
holder and always tighten it with the black strap
provided. Should youneed tochange thegas bottle,
confirm that the barbecue is switched off,and that
there are no sources of ignition (cigarettes, open
flame,sparks, etc.)near beforeproceeding.Inspect
the gas hose to ensure it is free of any twisting or
tension. Thehose should hang freelywith nobends,
folds, or kinks that could obstruct free flow of gas.
Apart from theconnectionpoint,no partof the hose
should touch any hotbarbecue parts. Always inspect
the hose forcuts, cracks, or excessivewear before
use. If the hose is damaged, it must be replaced with
hose suitable foruse with LPGand meetthenational
standardsfor the country of use. The length of the
hose shallnot exceed 1.5m. N.B.-Thedate onU.K.
hose is the date of manufacture, notthe expirydate.
F3. Fixing the Regulator to the Gas Bottle
Confirmallbarbecue control knobs are in the off
position.Connect the regulator to the gas bottle
according toyour regulator and bottledealer’s
instructions.
F4. Leak Testing(Tobe performedinawell-
ventilated area.)
Confirm all control knobs are in the off position. Open
the gas controlvalveonthe bottle orregulator.
Check for leaks by brushing asolution of ½water
and ½soap overallgas systemjoints,including all
valveconnections, hose connections and regulator
connections. NEVER USE AN OPEN FLAME to test
forleaks at anytime.If bubbles form over anyof the
joints, thereis aleak.Turn off the gas supply and
retighten all joints. Repeat test. If bubbles form again,
do not use the barbecue. Please contact your local
dealer forassistance. Leak test your barbecue
annually.Check the hose connections are tightand
leak test themeach timeyou reconnect the gas
bottle.
PDF created with pdfFactory trial version www.pdffactory.com

10
G.Operation
G1. Warning
• Beforeproceeding,makecertainthatyou
understand the IMPORTANT INFORMATION
section ofthis manual.
G2. Preparation Before Cooking
To preventfoods from stickingtothecooking grill,
please use along handled brush to apply alight coat
of cooking or vegetable oil before each barbecuing
session. (Note: When cooking forthefirst time,
paintcolours may change slightlyas aresult.
This is normal and shouldbe expected.)
G3. Lightingthe Barbecue
• Open the barbecue hood.
• Ensure all knobs are in the off position. Open the
gas control valveon the gas bottle orregulator.
• Fromthe “OFF”position,push in and turn middle
control knob anti-clockwise until you feel
resistance pause 4seconds. Then continue
turning the controlknob untilaclick is heard and
the burner is lit.Then push inand turn leftknob
and right knob.
• Ifthe burner fails to ignite after above procedure,
turn all the knobs to the off position and close the
gas valve on thegas bottle.Wait5minutes and
then repeat the above steps. If thebarbecue still
fails to light, please refer to the manual ignition
instructioninthe section below.
• After ignition, the burner should be burned at the
high position for 3-5 minutes in order to preheat
the barbecue.This process should be done
before every cooking session. The hood (where
applicable) should be open during preheating.
• After completion of preheating, the burner should
normallybe turned down to alower position for
best cooking results.
G4. Manual IgnitionInstruction
• Insert lit match through the match-lighting hole at
the left orright side of the barbecue body.
• Push in and turn thecontrolknob anti-clockwise
to the max position, the leftmost burner should
ignite.
• Aftertheleftmostburner is lit,push and turnthe
second leftcontrol knob to maxposition,the
second burner should igniteautomatically.
• Repeat same procedure to light the third and
rightmost burner.
• If burner fails toignite,contactyour local dealer
forassistance.
• After ignition, the burner should be burned at the
maxposition for 3-5 minutes in order to preheat
the barbecue.This process should be done
before every cooking session. The hood (where
applicable) should be open during preheating.
• After completion of preheating, the burner should
normallybe turned down to alower position for
best cooking results.
G5. Roasting Hood Cooking
Barbecues equipped with aroasting hood give the
option ofcooking with hood closed to form an ‘oven’
forroasting food, such as joints of meat,whole
chickens, etc.
Whenroasting,turntheburner under the foodtothe
OFFposition.Close the hood and turn theother
burner down to alower setting i.e.low to mediumto
achievethetemperaturerequired.DONOT ALLOW
YOUR BARBECUETOOVERHEAT. Avoid lifting the
hood unnecessarily as heat is lost each timethe
hood is opened.
G6. Endof Cooking Session
Aftereach cooking session, turnthe barbecue burner
to the “max”positionand burn for 5minutes. This
procedure willburn off cooking residue, thus making
cleaning easier.Make sure the hood is open during
this process.
G7. TurningOff Your Barbecue
When you havefinished using your barbecue, turn all
the controlvalves fully clockwise to the “Off”position,
then switch off thegas at the bottle.Waituntil the
barbecue is sufficiently cool before closing its hood.
H. CARE AND MAINTENANCE
Regularlyclean your barbecue between uses and
especially after extended periods ofstorage. Ensure
the barbecue and its components are sufficiently cool
beforecleaning. Donotleave the barbecue exposed
to outside weather conditions or stored indamp,
moist areas.
• Never douse the barbecue with water when its
surfaces are hot.
• Never handlehot parts with unprotected hands.
H1. CookingGrill
Clean with hot soapy water. To removeany food
residue, use amild creamcleaner on anon-abrasive
pad. Rinse well and dry thoroughly.
PDF created with pdfFactory trial version www.pdffactory.com

11
H2. Burner Maintenance
Your burner has been preset foroptimalflame
performance. You willnormallysee a blue flame,
possibly with asmallyellow tip when the burner is
alight.If the flamepattern is significantlyyellow, this
could be a problem caused by grease from cooking
blockingthe burner or spiders or other insects in the
burner venturi.This can result in the flow ofthe gas
and air mixture being restricted orblocked which may
result ina fire behind the controlpanel causing
serious damage to your barbecue.If thishappens,
the gasshouldbe immediately turnedoff at the
bottle. Burners should be inspected and cleaned on
a regular basis in addition to the following conditions:
1) Bringingthe barbecue out of storage.
2) One or moreofthe burners do not ignite.
3) The burner flame pattern is significantly yellow.
4) The gas ignites behind the control panel.
To clean a burner, remove it from the barbecue. The
outside ofthe burner canbe cleaned with a wire
brush. Clean the portholes with a pipe cleaner or
piece of wire. Take care notto enlarge the portholes.
Clean the insect screen on the end ofthe venturi
tube with a bristle brush (i.e. anold toothbrush).
Clean the venturitube with a pipe cleaner or piece of
wire. You may need a torch to see into the venturi
tube to makesure itis clear. ”Turn the burner up on
end and lightlytap against apiece of wood to
dislodge any debris from inside.”
H3. Barbecue Body
Regularly removeexcess grease or fat from the
barbecue body with asoft plasticor wooden scraper.
Itis notnecessary to remove all thegrease from the
body. If you need to clean fully, use hot soapy water
and acloth, or nylon-bristled brush only. Remove
cooking surfaces and burners before fullcleaning. Do
not immerse the gas controls or manifold in water.
Check burner operation after carefully refitting into
body.
H4. Fixings
Allscrews and bolts, etc.should be checked and
tightened on a regular basis.
H5. Storage
Store your barbecue in a cool dryplace. Itmust be
inspected on a regular basis as damp or
condensation can form which mayresult in damage
to the barbecue. It may be necessary to dry the
barbecue and the inside ofthe cover if used. Mould
can grow under these conditions and should be
cleaned and treated if required.Any rust that is found
that does not come into contact with the food should
be treated with a rust inhibitor and paintedwith
barbecue paint or a heatresistant paint. Chrome
plated warming racks and grills should be coated
with cooking oil.Wrap the burners in aluminiumfoil to
help preventinsects or other debris from obstructing
the burners.
The gas bottlemust bealways be disconnected from
the barbecue and stored in awell ventilated area at
least 1 metreaway from any fixedignitionsource. Do
not store inside residential accommodation. Never
store cylinders below ground level(e.g.cellars). Do
not let children tamper withbottles.
I. Technical Specifications
This barbecue grill ismanufacturedby:
Donguang KingsunEnterprises Co.Ltd.
Address: Xicheng Area 2, ShiyongVillage, Hengli
Town, DongguanCity,GuangdongProvince,
China
Model Number K302-1
Gas Category I3P (37)
Type ofGas Propane
Gas Pressure 37 mbar
Pin Number 359/BU/1016
InjectorSize 0.89mm
3 Burner Heat Input9.7 kW
Gas Consumption 693 g/h
Country of Destination GB and IE
PDF created with pdfFactory trial version www.pdffactory.com

14
L. Troubleshooting
Problem Possible Cause Solution
Burner will not light using the
ignition system
LP gas cylinder is empty Replace with full cylinder
Faulty regulator Have regulator checked or replace
Obstructions in burner Clean burner
Obstructions in gas jets or gas hose Clean jets and gas hose
Electrode wire is loose or disconnected on
electrode or ignition unit.
Reconnect wire
Electrode or wire is damaged Change electrode and wire
Faulty pushbutton ignitor Change ignitor
Burner will not light with a match LP gas cylinder is empty Replace with full cylinder
Faulty regulator Have regulator checked or replace
Obstructions in burner Clean burner
Obstructions in gas jets or gas hose Clean jets and gas hose
Low flame or flashback (fire in
burner tube— a hissing or
roaring noise may be heard)
LP gas cylinder too small Use larger cylinder.
Obstructions in burner Clean burner
Obstructions in gas jets or gas hose Clean jets and gas hose
Windy conditions. Use BBQ in a more sheltered position
Gas valve knob difficult to turn Gas valve jammed Replace gas valve
G
Argos Limited, MK9 2NW
