Brinkmann 855-3303-S User manual

GUARDE ESTE MANUAL PARA REFERENCIA FUTURA
NOTICE TO INSTALLER:
LEAVE THESE INSTRUCTIONS WITH
THE GRILL OWNER FOR FUTURE
REFERENCE.
OWNER’S MANUAL
ASSEMBLY AND OPERATING INSTRUCTIONS
WARNING
READ AND FOLLOW ALL WARNINGS AND
INSTRUCTIONS IN THIS MANUAL TO AVOID
PERSONAL INJURY OR PROPERTY DAMAGE.
MANUAL DEL PROPIETARIO
INSTRUCCIONES DE ARMADO Y OPERACIÓN
SAVE THIS MANUAL FOR FUTURE REFERENCE
ADVERTENCIA
LEA Y SIGA TODAS LAS ADVERTENCIAS E
INSTRUCCIONES EN ESTE MANUAL PARA
EVITAR LESIONES PERSONALES O DAÑOS
MATERIALES.
AVISO PARA EL INSTALADOR:
ENTREGUE ESTAS INSTRUCCIONES AL
PROPIETARIO DE LA PARRILLA PARA
REFERENCIA FUTURA.
Heavy-Gauge Charcoal Drum
Tambor de Grueso Calibre para Carbón

WARNING
• Only use this grill on a hard, level, non-combustible, stable surface (concrete, ground, etc.) capable of supporting the weight
of the grill. Never use on wooden or other surfaces that could burn.
• DO NOT use grill without charcoal grates in place. DO NOT attempt to remove charcoal grates while tray contains hot coal.
• Proper clearance of 10 feet between the grill and combustible material (bushes, trees, wooden decks, fences, buildings,
etc.) or construction should be maintained at all times when grill is in use. Do not place grill under a roof overhang or other
enclosed area.
• For outdoor use only. Do not operate grill indoors or in an enclosed area.
• For household use only. Do not use this grill for other than its intended purpose.
• We recommend the use of a Charcoal Chimney Starter to avoid the dangers associated with charcoal lighting fluid. If you
choose to use charcoal lighting fluid, only use lighting fluid approved for lighting charcoal. Carefully read manufacturer’s
warnings and instructions on the charcoal lighting fluid and charcoal prior to the use of their product. Store charcoal lighting
fluid safely away from grill.
• When using charcoal lighting fluid, allow charcoal to burn with grill lid open until covered with a light ash (approximately 20
minutes). This will allow charcoal lighting fluid to burn off. Failure to do this could trap fumes from charcoal lighting fluid in
grill and may result in a flash fire or explosion when lid is opened.
• Do not use gasoline, kerosene or alcohol for lighting charcoal. Use of any of these or similar products could cause an
explosion possibly leading to severe bodily injury.
• Never add charcoal lighting fluid to hot or even warm coals as flashback may occur causing severe burns.
• Place grill in an area where children and pets cannot come into contact with unit. Close supervision is necessary when grill
is in use.
• Do not leave grill unattended when in use.
• When adding charcoal and/or wood, use extreme caution and follow instructions in “Adding Charcoal/Wood During Cooking”
section of this manual.
• Do not store or use grill near gasoline or other flammable liquids, gases or where flammable vapors may be present.
• Do not store lighter fluid or other flammable liquids or material under the grill.
Grill is hot when in use. To avoid burns:
• DO NOT attempt to move the grill.
• Brace grill so the unit does not accidentally move.
• Wear protective gloves or oven mitts.
• DO NOT touch any hot grill surfaces.
• DO NOT wear loose clothing or allow hair to come in contact with grill.
IMPORTANT SAFETY WARNINGS
WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE.
THE PURPOSE OF THIS SAFETY ALERT SYMBOL
IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL.
WHEN YOU SEE THE SAFETY ALERT SYMBOL, PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS!
READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING AND OPERATING YOUR GRILL.
1

WARNING
• Check grease level in tin can often and empty or change when 3/4 full. Use extreme caution as the smoker, tin can and its
contents will be hot.
• When grilling, grease from meat may drip into the charcoal and cause a grease fire. If this should happen close lid to
suffocate the flame. Do not use water to extinguish grease fires.
• Use caution since flames can flare-up when fresh air suddenly comes in contact with fire. When opening the lid, keep
hands, face and body a safe distance from hot steam and flame flare-ups.
• Never place more than 15 pounds on front shelf. Do not lean on the front shelf.
• Do not exceed a temperature of 400°F. Do not allow charcoal and/or wood to rest on the walls of grill. Doing so will great-
ly reduce the life of the metal and finish of your grill.
• Use caution when assembling and operating your grill to avoid scrapes or cuts from sharp edges of metal parts. Use
caution when reaching into or under grill.
• When opening lid, make sure it is pushed all the way open. If lid is not fully open, it could fall back to a closed position
and cause bodily injury.
• In windy weather, place grill in an outdoor area that is protected from the wind.
• Close lid, air shutter and smoke stack to suffocate flame.
• Never leave coals and ashes in grill unattended. Before grill can be left unattended, remaining coals and ashes must be
removed from grill. Use caution to protect yourself and property. Carefully place remaining coals and ashes in a non-
combustible metal container and saturate completely with water. Allow coals and water to remain in metal container 24
hours prior to disposing.
• Extinguished coals and ashes should be placed a safe distance from all structures and combustible materials.
• With a garden hose, completely wet the surface beneath and around grill to extinguish any ashes, coals or embers which
may have fallen during the cooking or cleaning process.
• After each use, clean the grill thoroughly and apply a light coat of vegetable oil to interior to prevent rusting. Cover the
grill to protect it from excessive rusting.
• Use caution when lifting or moving grill to prevent strains and back injuries.
• We advise that a fire extinguisher be on hand. Refer to your local authority to determine proper size and type of fire
extinguisher.
• Accessory attachments not manufactured by The Brinkmann Corporation for this particular product are not recommended
and may lead to personal injury or property damage.
• Store the grill out of reach of children and in a dry location when not in use.
• Do not attempt to service grill other than normal maintenance as explained in “After-Use Safety” and “Proper Care &
Maintenance” sections of this manual.
• Remove all stickers and labels before first use.
• Properly dispose of all packaging material.
USE CAUTION AND COMMON SENSE WHEN OPERATING YOUR GRILL.
FAILURE TO ADHERE TO SAFETY WARNING AND GUIDELINES IN THIS MANUAL COULD RESULT
IN BODILY INJURY OR PROPERTY DAMAGE.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
2

PARTS LIST - Charcoal Drum:
13 Cooking Grills
22 Charcoal Grate
31 Grill Body Assembly
41 Smokestack Damper
51 Smokestack Damper Assembly
61 Front Shelf
71 Side Handle
81 Wheels Axle with Washers and Nuts
91 Left Rear Leg (with Axle Holes)
10 1 Left Front Leg (with Axle Holes)
11 1 Right Rear Leg (with Axle Holes)
12 1 Right Front Leg (with Axle Holes)
13 1 Bottom Shelf
14 2 Wheels
15 1 Door
16 1 Air Shutter
17 1 Latch
ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 800-527-0717.
Inspect contents of the box to ensure all parts are included and undamaged.
We recommend two people work together when assembling this unit.
The following tools are required to assemble this Charcoal Drum:
• Pliers
• Phillips & Flathead Screwdrivers
• Adjustable Wrench
CALIFORNIA PROPOSITION 65 WARNING
This product contains chemicals, including lead in the brass of certain component parts, that are known to the State of
California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling. When used,
this product emits fuel combustion chemicals that are known to the State of California to cause cancer,
and birth defects or other reproductive harm.
Follow all instructions in this manual and use only in well ventilated, outdoor area.
3
1
2
4
3
5
6
7
8
12
13
11
9
14
10
15
16
17

Parts Bag Contents
25 M6 X 12 mm Bolts
2 M12 Nuts
1 M6 Cap Nut
1 M5 X 14 mm Shoulder Bolt
1 M6 X 14 mm Shoulder Bolt
16 Flat Washers
25 M5 Nuts
1 M6 Spring
M6 X 12 mm Bolts
M5 X 14 mm Shoulder Bolt
M6 X 14 mm Shoulder Bolt
Flat Washers
M5 Nuts
M6 Spring
M6 Cap Nut
M12 Nuts
4

5
Right Rear Leg
(without Axle Holes)
Bottom Shelf
Grill Body
Assembly
M6 Flat Washers
Top View
Clear an assembly area and get a friend
to help you put your smoker together. Lay
cardboard down to protect smoker finish and
assembly area.
Step 1
Place the grill body assembly on its end
with the lid open. Make sure that another
person is holding the grill body assembly
steady. The opening to the smoke stack
should be facing up as illustrated.
Step 2
With the grill body assembly standing on
its side as in Step 1, attach the right rear
leg (without axle holes) to the grill body
assembly. Align the bolts of leg with the
pre-drilled holes in the grill body assembly
as illustrated. Attach using four
M6 X12 mm bolts, M6 flat washers
and M6 nuts. Hand tighten only. Do not
attach the right front leg yet.
Step 3
Insert the bottom shelf (curved end pointed
down) into the mounted right rear leg.
Insert bottom shelf into right front leg.
Attach right front leg onto grill body
assembly using the same technique
described in Step 2.
Smoke Stack
Opening
Right Front Leg
(without Axle Holes)
Grill Body
Assembly
M6 Nuts
M6 X 12 mm
Bolts

6
Wheel
Wheel Axle
M12 Nut
Step 4
Attach the left front and rear legs (with
wheel axle holes) to the grill body
assembly. First, insert the bottom shelf
into the left rear leg, then move bolted
end of leg until bolts align with holes
in the grill body assembly. Attach using
four M6 X12 mm bolts, M6 flat washers
and M6 nuts. Hand tighten only. Repeat
this step for left front leg. Tighten all
bolts and nuts for each leg attached to
the grill body assembly.
Step 5
Insert wheel axle through left front
and rear legs and attach wheels using
two M12 nuts as illustrated. Tighten
securely.
Note: With the help of a friend, lift
the grill body assembly to an
upright position. Try to minimize
the stress to the legs.
CAUTION: Keep lid closed when
setting unit upright to
prevent bodily injury.
Grill Body
Assembly
Bottom View
Bottom Shelf
Left Rear Leg
(with Axle Holes)
Left Front Leg
(with Axle Holes)
M6 Flat
Washers
M6 Nuts
Grill Body
Assembly
M6 X12 mm
Bolts

7
Step 6
Attach the air shutter door and air shutter
to the left side of grill body assembly using
M5 shoulder bolt as illustrated. Then
attach M6 shoulder for door latch.
Step 7
Attach smoke stack assembly and side
handle to right side of grill body assembly
using eight M6 X 12 mm bolts
and M6 nuts.
Air Vent
Smoke Stack
Side Handle
Air Vent
Door
M5 Shoulder
Bolt
M6 Shoulder
Bolt

8
Step 8
Place smoke stack damper and M6 spring
onto pre-attached bolt on smoke stack as
illustrated. Then screw on M6 cap nut to
secure.
Step 9
Open lid. Place heat distribution plate on
top of fire pot down inside grill body as-
sembly.
Step 10
Place charcoal grates on support ribs.
Step 11
Place cooking grills on support ribs directly
above charcoal grates.
Step 12
Insert front shelf in holes on grill body
assembly as illustrated.
Smoke Stack
Damper
M6 Spring
M6 Cap Nut
Smoke Stack
Cooking Grills
Charcoal Grates
Front Shelf
Grill Body
Assembly

9
Heavy-Gauge Charcoal Drum
(Assembled)
