RIDGE RYDER RR0056 User manual

OWNERS MANUAL
1
24 lItrE
INSTRUCTIONS

RIDGE
ADVENTURE
GEAR
2
CONTENTS
General Safety...................................................3
Performance & Function ...................................4
Assembly & Parts ..............................................4
Operating Instructions ......................................5
Maintenance & Troubleshooting.......................6
Specications ...................................................7.
Warranty ............................................................7

RIDGE
ADVENTURE
GEAR
OWNERS MANUAL
3
IMPORTANT: It is important that you read these instructions carefully and understand
the operation and safety features of this appliance
GENERAL SAFETY
• Connect the device only as follows:
- When connecting the power cables supplied with the appliance for connection to 12V DC or 240V AC
power source
• The appliance shall not be exposed to rain
• When removing the plug from the socket, do not pull on the power cable
• If the 12V DC or 240V AC cable is damaged it must be replaced with the same type & rated cable in
order to avoid operating problems
• If the device shows visible damage, do not use
• Repairs on this device may only be executed by an approved repair agent
• In the case of required repairs or warranty please contact the Customer Service line PH: 1300 555 197
• Disconnect the supply cable after each use and before cleaning and servicing
• Make sure the ventilation slots are not covered or obstructed at any time during operation
• Check that the voltage indicated on the type plate corresponds to that of the energy supply
• The appliance is not suitable for the transport of corrosive or solvent based substances!
• Food may only be stored in its original packaging or in suitable containers
SAFETY WHEN OPERATING THE APPLIANCE
• Before use ensure the power cords are serviceable & dry
• Do not place the appliance in the proximity of open ames or other heat sources
(heaters, strong solar rays, gas ovens etc.)
• Do not ll any liquids or ice into the interior of the appliance
• Protect the appliance and cables against heat and moisture
• Ensure your hands are dry before handling the plug or switching on the appliance
• Super Retail Group or Supercheap Auto are not liable for damages which are caused by
non-intended use or incorrect operation
• This product is suitable for camping use
• The appliance shall not be exposed to rain
• This appliance is not intended to be used in household and similar applications such as
- staff kitchen areas in shops, ofces and other working environments;
- farm houses and by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
• Do not store explosive substances such as aerosol cans with a ammable propellant in
this appliance
ELECTRICAL DEVICES ARE NOT TOYS!
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience or
knowledge, unless they have been given supervision or instruction concerning
the use of this appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the appliance.

RIDGE
ADVENTURE
GEAR
4
Large easy to read
digital control panel
Easy to clean liner
Easy to access
power socket
PERFORMANCE & FUNCTION
The Ridge Ryder thermocooler is suitable for mobile use; it is not intended to be used as a fridge/
freezer. It can cool goods down to max 25°C below ambient temperature or warm up to a max of 65°C.
The performance may differ depending on conditions such as voltage input, thermal load, ventilation,
number of times the cabinet is opened and closed, temperature of goods inside unit etc.
Note: Minimum temperature is dependent on the surrounding ambient/external temperature.
For example if it is 30°C outside the cooler’s minimum temperature will be approximately 5°C
The thermocooler is equipped with an automatic voltage change over function that will select 240V
power over 12V power; if 240V power is not available then the 12V power is automatically selected.
ASSEMBLY AND PARTS
Large fans for
efficient performance
12V and 240V
cables included

RIDGE
ADVENTURE
GEAR
OWNERS MANUAL
5
ADJUSTING TO HEAT OR COOL
Step 1:
- Use the up/down buttons to select desired
temperature
- A fan sound will occur when
heat or cool mode activated.
PLEASE NOTE: ONCE DESIRED TEMPERATURE
SET, DISPLAY WILL REVERT SHOWING
CURRENT TEMPERATURE OF CABINET.
OPERATING INSTRUCTIONS
Step 1: Select the required Power Cable
and connect to the appliance and suitable
power source
Step 2: Power On
- Press power button on display
- Press the temp set button display will ash
- Use the up/down buttons to select desired
temperature
- A green light will illuminate on display for cooling
& red light for warming modes
TURN OFF
Step 1:
- Press power button to turn unit off
NOTE: Fans may run for up to 30 seconds after turning off.
HINTS & TIPS
- Place the appliance on stable ground when
in use
- Ensure the appliance is located in a shady spot
for effective cooling
- For effective use it is best to cool the unit
overnight with nothing inside of it
- Let warm foods cool down rst before placing
them in the appliance
- If using the appliance to store medicine,
please check if the cooling capacity of the
device corresponds to the requirements of the
respective medication

RIDGE
ADVENTURE
GEAR
6
FAU LT POSSIBLE CAUSE SUGGESTION
The appliance does not appear to
function and the internal fan cannot
be heard
Check that the display is on
Check the input power source
• Check all cable connections repair or
replace as required
• Check the fuse located in the
cigarette lighter tip is operational
and not damaged Glass Fuse 5mm x
20mm F10A/250V
On DC/12V:
• Check that the ignition switch is
turned on allowing power to the 12V
accessory socket. Many accessory
sockets require the engine to be
running
• Check the 12V socket fuse in the
vehicle or on your power supply is not
damaged.
• Try any alternative 12V power supply.
ON AC/240V:
• Check that the lead is connected
correctly
• Check that the power is turned on
The appliance does not appear to
be operating however the display is
illuminated and the internal fan can be
heard
The ambient temperature is above the
maximum level of 35°C degrees
• Check the temperature and
move to a cooler location
• Ensure that the vents are not
blocked or obstructed
• Remove some of the produce to
reduce the thermal mass
The appliance does not appear to be
operating & the internal fan cannot be
heard
The Thermo-Electric system is defective Call Customer Service on 1300 555 197
for assistance
The Integrated Electrical System is
defective
The appliance is not reaching set
temperature
Appliance only capable of cooling 25°C
degrees below ambient temperature or
warm up to a max of 65°C degrees
Move appliance to cooler area or
change temperature setting
CLEANING
Disconnect the power cable from the power source before cleaning
Using warm soapy water and mild detergents wipe down all internal and external surfaces of the
appliance taking care that water does not enter any vents or electrical connections.
DO NOT submerge or rinse the appliance under water, in a bowl or sink
DO NOT use abrasive cleaners or bleach
DISPOSAL
Place the packaging material in the appropriate recycling waste bins wherever possible.
If you wish to dispose of the appliance, ask your local recycling centre or specialist dealer for details
about how to do this in accordance with the applicable disposal regulations.
MAINTENANCE AND TROUBLESHOOTINGMAINTENANCE AND TROUBLESHOOTING
CAUTION!
TROUBLE SHOOTING

RIDGE
ADVENTURE
GEAR
OWNERS MANUAL
7
SPECIFICATIONS
Model RR0056 Thermo-Cooler 24L
Capacity - Gross 24 L
Rated Voltage Mode Rating
Input DC 12V Cool 70W ± 10%
Heat 60W ± 10%
Input AC 220-240V
50-60Hz
Cool 55W ± 10%
Heat 63W ± 10%
Climate Category T
WARRANTY
This product is guaranteed against defects for a period of 12 months from date of purchase.
This warranty is provided by Supercheap Auto Pty Ltd ACN 085 395 124 (Supercheap Auto) of 6 Coulthards Ave, Strathpine,
QLD 4500. PO Box 344 Strathpine, QLD 4500. Phone: [phone], Fax: + 61 (0)7 3205 8522. The warranty is not
transferable to a subsequent customer if the product is sold by the original customer during the warranty period. If a defect
appears in the manufacture or assembly of the product before the end of the warranty period and Supercheap Auto nd the
product to be defective in materials or workmanship than Supercheap Auto will, in its sole discretion either;
a) Replace or repair the product or defective part of the product free of charge; or
b) Have the product or defective part of the product replaced or repaired by a qualied repairer free of charge
Supercheap Auto reserves the right to replace a defective part of the product with parts and components of similar quality,
grade and composition where an identical part is not available. Refurbished parts may be used to repair the product
WARRANTY CLAIMS
1. To claim under this warranty, take this product to the Front Service Desk of your nearest Supercheap Auto store. For store
locations, visit www.supercheapauto.com.au (AUS) or www.supercheapauto.co.nz (NZ)
2. Any warranty claim must be accompanied by proof of purchase; additional information may be requested of you to process
your claim. Should you not be able to provide proof of purchase with a receipt or bank statement, identication showing your
name, address and signature may be required to process your claim
3. The product may need to be sent for testing to assess the defect before determining any claim. Faults or defects cause by
product modication, misuse and abuse, normal wear and tear or failure to follow user instructions are not covered under
this warranty
CONSUMER RIGHTS
• Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
• You are entitled to have the goods replaced if the goods fail to be of an acceptable quality and the failure does not amount to
major failure.
• Any expenses incurred relating to the return of this product to store will normally have to be paid by you. For more
information contact your nearest Supercheap Auto store.
• The benets to the consumer given in this warranty are in addition to other rights and remedies of the Australian Consumer
Law in relation to the goods and services to which this warranty relates.

201906
PLU: 577077
CODE: RR0057
Manufactured and packaged for
SRGS PTY LTD
ABN 23 113 230 050
6 Coulthards Ave, Strathpine
Queensland 4500, Australia
PO Box 344 Strathpine,Queensland 4500
Phone: [phone]
Fax: [phone]
MADE IN CHINA
