R5013 1/2 in. HAMMER DRILL
REPAIR SHEET
RIDGID
PERCEUSE À PERCUSSION DE 13 mm
(1/2 po) R5013
FEUILLE DE RÉPARATION
RIDGID
R5013 TALADRO DE PERCUSIÓN
DE 13 mm (1/2 pulg.)
LISTAS DE PIEZAS DE REPUESTO

R5013
WARNING: The assembly shown represents an important part of
the Double Insulated System. To avoid the possibility of alteration or
damage to the System, service should be performed by your nearest
authorized service center.
AVERTISSEMENT : L'ensemble illustré représente une partie
importante du système à isolation double. Afin d'éviter la possibilité
de modification ou de dommage au système, la réparation ne doit être
effectuée que par votre centre de réparation centre de réparations
agréé le plus proche.
ADVERTENCIA: El conjunto que se ilustra representa una parte
importante del Sistema de doble aislamiento. Para evitar la posibilidad
de alteración o daño del sistema, la reparación debe ser efectuada en
su centro de servicio autorizado.
1
56
57
58
59
60
55
2
3
459
14 13
8
10
11
12
17
17
19
18
21
20
22
23
49
24
25
26
27
28
15
7
6
16
29
30
31
32 33
34
34
35
35
36
36
37
38
40
41
42
39
44
45
46
48
47
47
62
63
50
18
18
53
52
54
51
24
61
43

R5013
KEY P/N DESCRIPTION QTY KEY P/N DESCRIPTION QTY KEY P/N DESCRIPTION QTY
* Standard Hardware Item – May Be Purchased Locally
1 6613402 SCREW (M6 X 27 mm) ................................1
2 672380001 CHUCK .......................................................1
3 671025001 RETAINING RING (32 mm) ..........................1
4 901002003 OIL SEAL .....................................................1
5 660024019 * SCREW (M4 X 34 mm) ................................3
6 670030002 SPRING WASHER .......................................3
7 300308033 GEAR BOX ASSEMBLY ...............................1
8 513922001 ANTI-SKID PAD (RIGHT) .............................1
9 570598001 SEAL RING ..................................................1
10 513642001 IMPACT BUTTON .......................................1
11 901241001 SPONGE SEAL ............................................1
12 631486001 CATCH RING ...............................................1
13 301603001 CAP ASSEMBLY .........................................1
14 631485001 IMPACT KEY ...............................................1
15 513641001 IMPACT HOUSING ......................................1
16 570603001 SEAL RING ..................................................1
17 681012001 TRUST BEARING ........................................2
18 631504001 WASHER .....................................................4
19 671871001 SPRING .......................................................1
20 631483001 WASHER .....................................................1
21 671401002 BALL ........................................................1
22 631500001 PIN ........................................................1
23 301957001 GEAR BOX COVER ASSEMBLY
(INCL. KEY NOS. 24, 50, AND 51) ..............1
24 560712001 RUBBER KNOCK ........................................3
25 513698001 FAN CASE ...................................................1
26 680141014 BALL BEARING (608 LLU) ..........................1
27 200216021 ARMATURE ASSEMBLY
(INCL. KEY NOS. 26 AND 28) .....................1
28 6972701 BALL BEARING (626Z) ................................1
29 290102006 WIRE ASSEMBLY (90 mm) .........................1
30 290102007 WIRE ASSEMBLY (55 mm) .........................1
31 740940001 FIELD ASSEMBLY .......................................1
32 200058009 MOTOR HOUSING ASSEMBLY ..................1
33 940045024 DATA LABEL ................................................1
34 660203046 * SCREW (M3 X 6 mm) ..................................2
35 513689001 PRESSURE PLATE ......................................2
36 290069080 BRUSH ASSEMBLY ....................................2
37 941304001 AC PLUG ICON LABEL ...............................2
38 730401010 POWER CORD ............................................1
39 940299942 CORD TAG ..................................................1
40 290102005 WIRE ASSEMBLY (95 mm) ..........................1
41 940114139 LOGO LABEL ..............................................1
42 660024007 * SCREW (M4 X 16 mm) ................................7
43 300904001 CORD WRAP ASSEMBLY ...........................1
44 560801001 BEND RELIEF ..............................................1
45 6627201 * SCREW (M4 X 14 mm) ................................2
46 5950101 CORD CLAMP .............................................1
47 300160013 HANDLE ASSEMBLY ..................................1
48 760406003 SWITCH .......................................................1
49 570593001 SEAL RING ..................................................1
50 672026001 ARMATURE SHAFT SUPPORT ...................1
51 660320004 * SCREW (M3.5 X 10 mm) .............................2
52 631813001 WASHER .....................................................1
53 300022010 GEAR SHAFT ASSEMBLY ...........................1
54 513923001 ANTI-SKID PAD (LEFT) ................................1
55 620448001 DEPTH STOP ROD .....................................1
56 620451001 SPRING PLATE ...........................................1
57 660169228 * SCREW (M8 X 62 mm) ...............................1
58 301459004 CARRIER ASSEMBLY .................................1
59 513694001 AUXILIARY HANDLE CAP ...........................1
60 301374002 AUXILIARY HANDLE ...................................1
61 301374003 AUXILIARY HANDLE ASSEMBLY
(INCL. KEY NOS. 55-60) .............................1
62 560989001 CHUCK KEY STRAP ...................................1
63 690176004 CHUCK KEY ................................................1
901054003 CANVAS BAG (NOT SHOWN) .....................1
987000060 OPERATOR’S MANUAL (NOT SHOWN) .....1
02-12-07
(REV:00)

R5013
1 6613402 VIS (M6 X 27 mm) ........................................1
2 672380001 MANDRIN ...................................................1
3 671025001 BAGUE D’RETENIR (32 mm) .......................1
4 901002003 JOINT PETROLE .........................................1
5 660024019 * VIS (M4 X 34 mm) ........................................3
6 670030002 RONDELLE ÉLASTIQUE .............................3
7 300308033 COUVERCLE DE D’ENGRENAGES ...........1
8 513922001 PATIN ANTIDÉRAPANT (DROIT) ..................1
9 570598001 BAGUE D’ÉTANCHÉITÉ ..............................1
10 513642001 BOUTON À IMPACT ....................................1
11 901241001 JOINT ÉPONGE ..........................................1
12 631486001 BAGUE DE PRISE .......................................1
13 301603001 BOUCHON ..................................................1
14 631485001 CLÉ À IMPACT ............................................1
15 513641001 BOÎTIER À IMPACT .....................................1
16 570603001 BAGUE D’ÉTANCHÉITÉ ..............................1
17 681012001 CONFIANCE ROULEMENT .........................2
18 631504001 RONDELLE ..................................................4
19 671871001 RESSORT ....................................................1
20 631483001 RONDELLE ..................................................1
21 671401002 BILLE ........................................................1
22 631500001 BROCHE .....................................................1
23 301957001 COUVERCLE DE CARTER D’ENGRENAGES
(INCL. PIÈCES NO. 24, 50, ET 51) .............1
24 560712001 COUP DE CAOUTCHOUC ..........................3
25 513698001 CARTER DE VENTILATEUR ........................1
26 680141014 ROULEMENT (608 LLU) ..............................1
27 200216021 INDUIT (INCL. PIÈCES NO. 26 ET 28) .........1
28 6972701 ROULEMENT (626Z) ...................................1
29 290102006 FIL DE CONNEXION (90 mm) ....................1
30 290102007 FIL DE CONNEXION (55 mm) ....................1
31 740940001 FIL DE CHAMP ............................................1
32 200058009 CARTER MOTEUR ......................................1
33 940045024 PLAQUETTE SIGNALÉTIQUE .....................1
34 660203046 * VIS (M3 X 6 mm) ..........................................2
35 513689001 PLAQUE DE PRESSION ..............................2
36 290069080 BALAI ........................................................2
37 941304001 AUTOCOLLANT DE BOUCHON .................2
38 730401010 CORDON D’ALIMENTATION .......................1
39 940299942 ÉTIQUETTE DU CORDON ...........................1
40 290102005 FIL DE CONNEXION (95 mm) .....................1
41 940114139 AUTOCOLLANT DE LOGO .........................1
42 660024007 * VIS (M4 X 16 mm) ........................................7
43 300904001 ENROULEMENT DE CORDON ...................1
44 560801001 TUBE DE SÉCURITÉ ...................................1
45 6627201 * VIS (M4 X 14 mm) ........................................2
46 5950101 RETENUE DE CORDON ..............................1
47 300160013 POIGNÉE .....................................................1
48 760406003 INTERRUPTEUR .........................................1
49 570593001 BAGUE D’ÉTANCHÉITÉ ..............................1
50 672026001 ARBRE DE INDUIT SUPPORT ....................1
51 660320004 * VIS (M3.5 X 10 mm) .....................................2
52 631813001 WASHER .....................................................1
53 300022010 ARBRE D’ENGRENAGES ............................1
54 513923001 PATIN ANTIDÉRAPANT (GAUCHE) .............1
55 620448001 TIGE DE BUTÉE DE PROFONDEUR ...........1
56 620451001 PLAQUE À RESSORT .................................1
57 660169228 * VIS (M8 X 62 mm) .......................................1
58 301459004 SUPPORT ....................................................1
59 513694001 BOUCHON DE POIGNÉE AUXILIAIRE ........1
60 301374002 POIGNÉE AUXILIAIRE .................................1
61 301374003 FIL DE POIGNÉE AUXILIAIRE
(INCL. PIÈCES NO. 55-60) ..........................1
62 560989001 ATTACHE DE CLÉ DE MANDRIN ................1
63 690176004 CLÉ À MANDRIN .........................................1
901054003 SACOCHE (NON ILLUSTRÉE) ....................1
987000060 MANUEL D’UTILISATION
(NON ILLUSTRÉ) .........................................1
PIÈCE RÉF. DESCRIPTION QTÉ PIÈCE RÉF. DESCRIPTION QTÉ PIÈCE RÉF. DESCRIPTION QTÉ
* Article de boulonnerie standard – En vente dans les magasins locaux

R5013
1 6613402 TORNILLO (M6 X 27 mm) ............................1
2 672380001 PORTABROCAS .........................................1
3 671025001 ANILLO DE RETENER (32 mm) ...................1
4 901002003 ANILLO DE ACEITE .....................................1
5 660024019 * TORNILLO (M4 X 34 mm) ............................3
6 670030002 ARANDELA ELÁSTICA ................................3
7 300308033 CONJUNTO DE LA CAJA
DE ENGRANAJES .......................................1
8 513922001 ALMOHADILLA ANTIDESLIZANTE
(DERECHA) ..................................................1
9 570598001 ANILLO DE SELLADO .................................1
10 513642001 BOTÓN DEL IMPACTO ...............................1
11 901241001 ANILLO DE ESPONJA .................................1
12 631486001 ANILLO DE CIERRE ....................................1
13 301603001 CONJUNTO DEL TAPA ...............................1
14 631485001 LLAVE DEL IMPACTO .................................1
15 513641001 ALOJAMIENTO DEL IMPACTO ................... 1
16 570603001 ANILLO DE SELLADO .................................1
17 681012001 COJINETE DE CONFIANZA ........................2
18 631504001 ARANDELA ..................................................4
19 671871001 RESORTE ....................................................1
20 631483001 ARANDELA ..................................................1
21 671401002 BOLA ........................................................1
22 631500001 PASADOR ....................................................1
23 301957001 CONJUNTO DE LA TAPA DE LA CAJA
DE ENGRANAJES
(INCL. PZAS. NÚMS. REF. 24, 50, Y 51) .....1
24 560712001 GOLPE DE CAUCHO ..................................3
25 513698001 ESTUCHE DEL VENTILADOR .....................1
26 680141014 COJINETE DE BOLAS (608 LLU) ................ 1
27 200216021 CONJUNTO DEL INDUCIDO
(INCL. PZAS. NÚMS. REF. 26 Y 28) ............1
28 6972701 COJINETE DE BOLAS (626Z) ......................1
29 290102006 CONJUNTO DEL CABLE (90 mm) .............1
30 290102007 CONJUNTO DEL CABLE (55 mm) .............1
31 740940001 CONJUNTO DEL CAMPO ...........................1
32 200058009 CONJUNTO DEL ALOJAMIENTO
DEL MOTOR ................................................1
33 940045024 ETIQUETA DE DATOS .................................1
34 660203046 * TORNILLO (M3 X 6 mm) ..............................2
35 513689001 ESCOBILLA A PRESIÓN .............................2
36 290069080 ESCOBILLA .................................................2
37 941304001 ETIQUETA TAPÓN .......................................2
38 730401010 CORDÓN DE CORRIENTE ..........................1
39 940299942 ETIQUETA DEL CORDÓN ...........................1
40 290102005 CONJUNTO DEL CABLE (95 mm) ..............1
41 940114139 ETIQUETA LOGOTIPO ................................1
42 660024007 *TORNILLO (M4 X 16 mm) ............................7
43 300904001 CONJUNTO DE SOPORTE PARA
ENROLLAR EL CORDÓN ............................1
44 560801001 PROTECTOR DEL CORDÓN ......................1
45 6627201 * TORNILLO (M4 X 14 mm) ............................2
46 5950101 ABRAZADERA DEL CORDÓN ....................1
47 300160013 CONJUNTO DEL MANGO ..........................1
48 760406003 INTERRUPTOR ...........................................1
49 570593001 ANILLO DE SELLADO .................................1
50 672026001 SOPORTE DE EJE DE INDUCIDO ..............1
51 660320004 * TORNILLO (M3.5 X 10 mm) .........................2
52 631813001 ARANDELA ..................................................1
53 300022010 CONJUNTO DEL EJE DEL ENGRANAJE ....1
54 513923001 ALMOHADILLA ANTIDESLIZANTE
(IZQUIERDA) ...............................................1
55 620448001 CALIBRADOR DE PROFUNDIDAD .............1
56 620451001 PLACA DE RESORTE ..................................1
57 660169228 * TORNILLO (M8 X 62 mm) ...........................1
58 301459004 CONJUNTO DEL PORTADOR .....................1
59 513694001 TAPA DEL MANGO AUXILIAR .....................1
60 301374002 MANGO AUXILIAR ......................................1
61 301374003 CONJUNTO DEL MANGO AUXILIAR
(INCL. PZAS. NÚMS. REF. 55-60) ...............1
62 560989001 CORREA DE LALLAVE
DEL PORTABROCAS ..................................1
63 690176004 LLAVE DEL PORTABROCAS .......................1
901054003 BOLSA (NO SE ILUSTRA) ...........................1
987000060 MANUAL DEL OPERADOR
(NO SE ILUSTRA) ........................................1
REF. N/P DESCRIPCIÓN CANT. REF. N/P DESCRIPCIÓN CANT. REF. N/P DESCRIPCIÓN CANT.
* Artículo estándar de ferretería – Puede adquirirse en la localidad
