RIGGING INNOVATIONS Telesis 2 User manual

RI-1313-(2) Revision 1.0
5/3/2001
page i
RIGGING INNOVATIONS, INC.
OWNER'S MANUAL
AND PACKING INSTRUCTIONS
$8.00

RI-1313-(2) Revision 1.0
5/3/2001
page ii
WARNING !
1. Training and/or experience are required to lower the risk
of serious bodily injury or death.
NEVER use this equipment unless you have:
A. Read the warning label and completed a “controlled
program of instruction” in the use of this parachute
assembly.
-OR-
B. Read the warning label and all appropriate owners /
flight manuals, packing instructions and completed
at least 100 ram-air parachute jumps.
2. Lower the risk of death, serious injury, canopy damage
and hard openings by never exceeding the limits shown
on the warning label.
Warning labels may be found in the following
locations:
Ram-Air parachute -center cell top skin at trailing edge.
Harness/Container System -backpad.

RI-1313-(2) Revision 1.0
5/3/2001
page iii
DISCLAIMER -NO WARRANTY
Because of the unavoidable danger associated with the use of the Telesis 2
parachute system, the manufacturer makes NO WARRANTY, either expressed or implied.
The system is sold with all faults and without any warranty of fitness for any purpose.
Manufacturer also disclaims any liability in tort of damages, direct or consequential,
including personal injuries resulting from a defect in design, material or workmanship or
manufacturing whether caused by negligence on the part of the manufacturer or otherwise.
By using this system, or allowing it to be used by others, the buyer WAIVES any liability
of or the manufacturer for personal injuries or other damages arising from such use.
If the buyer declines to waive liability on the part of the manufacturer, buyer may
obtain a full refund of the purchase price by returning the system, before it is used,to the
manufacturer within 15 days of the date of the original purchase with a letter stating why
it was returned.
!!! WARNING !!!
You can substantially reduce risk by assuring that each component of the system
has been assembled and packed in strict compliance with the manufacturer's instructions,
by obtaining proper instruction in the use of this system, and by operating each component
of the system in strict compliance with owner's manual. However, parachute systems
sometimes fail to operate properly even when correctly assembled, packed and operated
so that you risk serious injury or death each time you use the system.
DANGER
Each time you use this parachute system you
risk serious bodily injury or death. DANGER

RI-1313-(2) Revision 1.0
5/3/2001
page iv
Telesis 2 P/N 6113-(2) S/N __________________________
DATE OF MANUFACTURE: _____________________________
Manufactured by
Rigging Innovations, Inc.
4900 N. Tumbleweed Rd. Bldg 1,
Eloy, AZ 85231, USA
Telephone: [phone]
FAX: [phone]
E-mail: [email protected]
© All Material is Copyright 1998 by Rigging Innovations Inc. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
this manual designed and produced by
RIGGING INNOVATIONS, INC.

RI-1313-(2) Revision 1.0
5/3/2001
page v
TABLE OF CONTENTS
WARNING ..........................................................................................................ii
DISCLAIMER .................................................................................................... iii
SERIAL NUMBER AND DATE OF MANUFACTURE RECORD ................ iv
Section 1 -General Information ........................................................1
1.1 Telesis 2 TSO Certification
1.2 Rigger Qualifications
1.3 “Am I Qualified to Jump This Equipment?”
1.4Customer Service
1.5 Table I -Parts List
Section 2 -Component Compatibility ................................................7
2.1 Canopy Compatibility
2.2 Reserve Compatibility
2.3 Volume
2.4 Deployment Bag
2.5 Deployment Type
2.6 Orange Warning Label Placard Data
Section 3 -User Information ..............................................................10
3.1 Main Container Packing Instructions
3.2 3-Ring Release System
S.O.S. Single Operation System
3.3 Reserve Static Line Lanyard System
3.4 Harness Adjustments and Fitting
3.5 Maintenance Procedures
3.6 Cleaning -Table III -Cordura® -Recommended Stain Removal Methods
Section 4 Rigger Information ........................................................... 24
4.1 Orange Warning Label Placard Data
4.2 Parachute Assembly Inspection Form
4.3 Ram-Air Reserve Packing Instructions
4.3.1 Assembling Reserve Parachute
4.3.2 Closing Loop Lengths
4.3.3 Installing Cypres AAD
4.3.4 Recommended Tools List
4.3.5 Canopy Folding Instructions
4.3.6 Closing Reserve Container

RI-1313-(2) Revision 1.0
5/3/2001
page 1
Section 1.0
General
Information

RI-1313-(2) Revision 1.0
5/3/2001
page 2
1.1 Telesis 2 Certification
Several different levels of TSO certification are in use today. Older parachute systems are built under TSO C23b in the
Low Speed Category. Newer systems are built under TSO C-23c in either Category A, B, or C depending upon weight and speed
limits. The Telesis 2 is built to standards prescribed under TSO C-23c Category B.
The Telesis 2 harness and container systems are approved under FAA TSO-C23c, Category B: and limited to use by
persons up to 116 kg (254 lb.) fully equipped, and up to 130 knots.
NORTHWEST MOUNTAIN REGION
TRANSPORT AIRPLANE DIRECTORATE
AIRCRAFT CERTIFICATION SERVICE
LOS ANGELES AIRCRAFT CERTIFICATION OFFICE
3229 E SPRING ST.
LONG BEACH, CA 90806-2425
AUG. 7, 1989
Rigging Innovations Inc.
Mr. Sandy R. Reid, President
236-A E. Third St.
Perris, CA 92370
Gentlemen: Rigging Innovations Inc., Telesis Dual Parachute Harness & Container Assembly,
Part Number 6113-( ); Series; Technical Standard Order C23c
Your application of June 14, 1989, requesting the issuance of a Technical Standard Order (TSO) authorization in accordance
with the procedural requirements of Federal Aviation Regulation (FAR) Part 21, Subpart O, has been reviewed. Based upon your
data and statement of conformance certifying your article has met the requirements of FAR Part 21, Subpart O, and the minimum
performance standards of TSO-C23c (Ref. FAR 21.305(b)) authorization is hereby granted.
The following technical data are considered to fulfill the requirements for TSO authorization and are being retained in our files:
1. Qualification Test Report SAE8015A -Test Summary Per AS8015A
2. Marking Requirements dated May, 1989
3. Owners Manual P/N 6113-( ) dated May, 1989
The quality control procedures contained in your quality control manual currently on file at the Manufacturing Inspection
District Office and your statement that those procedures will be applied to the manufacture of subject articles at the above
address, are considered adequate in accordance with FAR 21.143.
Effective this date you are authorized to use TSO procedures is extended to include the subject Telesis Dual Parachute Harness
and Container Assembly and you may identify this article with the applicable TSO markings as required by TSO-C23c.
In accordance with the provisions of FAR 21.3, you are required to report to the FAA any failure, malfunction, of defect related
to your TSO. authorization. As required by 21.613(b), you must also notify the FAA when you no longer manufacture a TSO
approved article.
This authorization pertains only to manufacturing operations at the above address and this office must be notified in advance of
any proposed relocation to preclude interruption while awaiting quality control approval of your new facility
Sincerely,

RI-1313-(2) Revision 1.0
5/3/2001
page 3
1.2 Rigger Qualifications
To pack and maintain this parachute system, the FAA Senior or Master Rigger -or foreign equivalent -
must possess a BACK rating endorsement to his or her certificate. Since these systems are certified only
with square reserve parachutes the rigger should be appropriately trained to pack ram-air parachutes
prior to certifying the Telesis 2 system for emergency use.
FAR Part 65.127( )No certificated parachute rigger may -
(e) Pack, maintain, or alter a parachute in any manner that deviates from the procedures
approved by the administrator OR the manufacturer of the parachute; or
(f) Exercise the privileges of his certificate and type rating unless he understands the
current manufacturer's instructions for the operation involved.
ANYONE who circumvents Rigging Innovations, Inc. instructions is in violation of FAR Part 65.127 and
is, therefore, performing an illegal procedure.

RI-1313-(2) Revision 1.0
5/3/2001
page 4
1.3 "Am I Qualified to Use this Equipment?"
As the new owner of a Rigging Innovations, Inc. Telesis 2 parachute system, before you use it, it is
very important that you can answer yes to several questions. Only by doing so can you be assured that you
have the necessary training and/or experience to safely utilize modern parachute equipment of this type.
Question 1: Does my experience level and/or training qualify me for using this equipment?
Advanced equipment such as the Telesis 2 have features requiring a certain level of
experience and training in order to be used safely.
Question 2: Have I been briefed or trained in the operation of this equipment by qualified personnel
such as an Instructor or licensed Rigger?
If you have progressed to the level where you are qualified to jump advanced equipment, or
if you have been trained on other types, there may be certain features of this system that you
are unfamiliar with. Make sure that you have received a thorough briefing from a certified
Instructor or Rigger for the type of equipment you are about to jump.
Question 3: Does the equipment fit properly?
Can you see and/or reach the main deployment handle, 3-ring release handle, reserve
ripcord and RSL? This equipment is built in a variety of container sizes, lengths, and
widths, and an adjustable harness. These configurations along with options such as BOC
main deployment, make compatible sizing to the individual extremely important to the safe
operation of the system. If the system does not fit properly, the handles may be inaccessible
or may move during the jump thereby causing problems in the air.
The above questions have dealt with your ability to safely jump this RIGGING INNOVATIONS
product only. If you have answered "Yes" to all the questions, you should feel comfortable using our
equipment. However, there are additional factors that may influence your decision and ability that do not
relate to our product. If you have any questions or feel uneasy about using this harness and container
system, do not hesitate to ask a qualified Parachute Instructor, FAA Certified Parachute Rigger, or contact
Rigging Innovations at 520-466-2655 for any further information or training you feel necessary.

RI-1313-(2) Revision 1.0
5/3/2001
page 5
1.4
RIGGING INNOVATIONS INC.
Customer Service Policy and Limits
Harness and Containers
RI will provide no charge repair service for repairs that RIGGING INNOVATIONS INC. has determined
to result from defects in material or workmanship for a period of six months from the date of purchase.
Date of purchase and proof of purchase must be supplied to RI by the customer with the item in order to
be repaired free of charge.
Safety
RI will perform all Mandatory Service Bulletins repairs or modifications due to SAFETY concerns free of
charge.
Unauthorized Modifications/Alterations
RI will charge for repair service when the damage is caused by unauthorized modification or alteration of
the product. RI reserves the right to refuse to repair any product so modified or altered.
Improper Use
RI will charge for repairs that results from improper use, or from abuse such as exposure to chemicals,
saltwater, improper washing, improper packing, excessive exposure to sunlight, or negligence of the part
of the user (i.e. jumping already damaged equipment).
Limits
RI reserves the right to refuse service on equipment for which materials and/or manufacturing patterns and
specifications no longer exist.
Configuration
Articles sent in for repair should be sent in with all parts. RI may request and require additional information
pertaining to the product.
Accessory Part -Replacement
RI will recommend replacement of component parts based on inspection when safety is a factor due to
normal wear and tear or maintenance of the product.
Product Improvement
Product improvements will be available as an option to customers.
January 1998

RI-1313-(2) Revision 1.0
5/3/2001
page 6
1.5
Table I -Parts List
QUANTITY
DESCRIPTION Part Number
1HARNESS/CONTAINER ASSEMBLY 6113-(2)
1STEALTH RESERVE PILOT CHUTE 2237-( )
1SQUARE RESERVE FREEBAG AND BRIDLE 2114-( )
1RESERVE RIPCORD 2511-(5)
1S.O.S. RESERVE RIPCORD 2513-(3)
2RESERVE STEERING TOGGLES 2611-(1)
1RESERVE CLOSING LOOP 2913-(4)
1SAFETY STOW LOOP 2911-(2)
2MAIN RISERS TY-82431-(2)
2MAIN TOGGLES 2621-(1)
13-RING RELEASE HANDLE 2521-(2)
1MAIN DEPLOYMENT BAG 2124-( )
1MAIN STATIC LINE 2821-(1)
1MAIN RIPCORD -PINLESS 2531-(1)
1MAIN RIPCORD -FXC 2532-(2)
1MANUAL OVERRIDE DEPLOYMENT (MOD) HANDLE 2532-(4)
1MAIN PILOT CHUTE
357L
T.O.P. -36”
2239-(2)
2241-(2)
1MAIN BRIDLE
RIPCORD
T.O.P. / ROL
T.O.P. / BOC
2321-(3)
2321-(13)
2321-(14)
1RSL LANYARD -TAS 2811-(4)a
1RSL LANYARD -SOS 2811-(9)
1OWNER'S MANUAL AND REGISTRATION CARD 1313-(2)
NO SUBSTITUTION OF COMPONENT PARTS IS AUTHORIZED !

RI-1313-(2) Revision 1.0
5/3/2001
page 7
Section 2.0
Component
Compatibility
2.1 Canopy Compatibility
IMPORTANT It is imperative that that the rigger and the owner understand what canopies are
compatible with a particular model of Rigging Innovations, Inc. harness/container assembly. IF
INCOMPATIBLE CANOPIES ARE USED WITH THIS Telesis 2 SYSTEM, IT COULD FAIL TO
OPERATE AS DESIGNED RESULTING IN SERIOUS INJURY OR EVEN DEATH TO THE USER..
2.2 Reserve Compatibility
To determine whether a particular reserve canopy is compatible with a Telesis 2 harness/container assembly,
there are several requirements that must be met. They are pack volume, deployment type, TSO
certification, and placard limitations.
2.3 Volume
The pack volume of a canopy is determined by using the standard Parachute Industry Association
(PIA) volume measurement as determined by PIA Technical Standard TS-104 in its most current edition.
By cross referencing this measurement to the Rigging Innovations, Inc. Main/Reserve Container
Volume, Table II, the volume compatibility may be determined.
IMPORTANT NOTES ON VOLUME REFERENCES
Rigging Innovations maintains the PIA canopy volume measurement study. If R.I. has not tested a
particular make and model canopy in our volume chamber we cannot be responsible for its fit in a given
size container. We will accept orders for specific size rigs if no reference to canopy make or model is
made. However, if canopy sizes are stated on an order form then R.I. will determine what is the best
container size for those canopies.
Proper container sizing is one of the more difficult processes in determining the correct size of main
to reserve canopy compatibility. Volume testing by the Parachute Industry Association has shown a
volume variable of up to 20% for a given canopy model.

RI-1313-(2) Revision 1.0
5/3/2001
page 8
The PIA canopy volume may be based on a single sample and should serve only as a rough guide in
selecting the correct size of container to canopy. Factors such as temperature, humidity, age, number of
jumps and packing technique affect the volume of a given canopy.
Reserve canopy technology has not progressed at the same pace as main canopies. Often, the
reserve canopy volume determines the container size. Today’s high performance main canopies allow
jumpers to fly much smaller volume canopies than an appropriate size reserve canopy for the individual’s
weight and experience.
R.I. generally takes a conservative approach when selecting the appropriate container size for a
given canopy combination. R.I. sizes containers a little on the loose side to ease packing, while making the
Telesis 2 more comfortable and durable.
The customer should tell the dealer the type of packing and fit that suits their experience and
requirements. i.e. firm, ideal or soft pack. Write the customers’ preference on the order to assist R.I. in
meeting the customer’s expectations.
RI will not assume responsibility for fit if a customer or dealer specifies a particular container size
that may be marginal for the canopy combination.
2.4 Reserve Deployment Bag and Bridle
Only a Rigging Innovations deployment bag and bridle assembly of the correct size and properly
labeled with P/N 2114-( ) is compatible with the Telesis 2. No other deployment bag is approved for
use with the Telesis 2 system.
Table II. Telesis 2 Main/Reserve Container Volumes
All numbers refer to the cubic inch volume of the containers.
Container size Volume
TS1 Reserve/Main 400/500
TS2 Reserve/Main 500/600
TS3 Reserve/Main 550/700
TS4 Reserve/Main 600/750
TS5 Reserve/main 650/850

RI-1313-(2) Revision 1.0
5/3/2001
page 9
2.5 Deployment Type
There are 5 different canopy deployment methods in common use. Of these, only TYPE 5 (free
bag) is approved for use in the Rigging Innovations, Inc. Telesis 2 harness/container assembly. The
description and example is as follows:
Type 5: Free Bag: Canopy stowed in bag and lines stowed on/in bag.
Examples: Ram air reserve canopies.
2.6 Orange Warning Label Placard Data
As Part of the manufacturers requirements, the ORANGE WARNING LABEL located on the
back pad must be filled in by the Rigger assembling and packing the Telesis 2. FAILURE TO COMPLETE
THE ORANGE WARNING LABEL WILL RESULT IN THE TSO BEING NULL AND VOID!
The data required for the warning label is obtained from the canopy manufacturer and should be
found on the canopy warning label or data panel.
Please note that there may be instances where one model canopy may have TWO DIFFERENT
placard limitations; one as a reserve and one as a main. An example of this is the Precision Super Raven 4
canopy. As a reserve it is limited to 254 lb. maximum gross weight. However, as a main it is placarded at
288 lb. Make sure that your Rigger marks the correct space with the right category information.

RI-1313-(2) Revision 1.0
5/3/2001
page 10
Section 3.0
User
Information
3.1 Main Container Packing Instructions
Assembly
Step 1 Lay out main parachute, flake canopy, and check lines for
straightness and continuity.
Step 2 With line check complete, attach connector links to main
risers (nose of canopy on front riser, tail on rear riser). Note that
risers are marked on back with an L or R to designate left and right.
Double check that you have the proper riser on the appropriate side of
canopy.
Step 3 Route steering lines through guide rings on rear risers.
Step 4 Route steering line through toggle grommet from Velcro side
and align mark on line with the grommet. Pass line around either side
of toggle and through grommet two more times in same direction.
(Figure 1) Secure with a Figure 8 knot locked with an overhand knot.
Double check that toggle is secure and knot will not slip.
It is also acceptable to make a finger-trapped loop 1 inch long (Figure
3) and install as shown. (Figure 4) The finger-trap must be locked
with a zigzag or bartack stitch.
Step 5 Attach risers to harness making sure you have left on left and
right on right.
Figure 1
Figure 2
Figure 3
Figure 4

RI-1313-(2) Revision 1.0
5/3/2001
page 11
Step 6 Attach main deployment bag to canopy as follows:
a. Install the RED canopy attachment loop to the top of the
main canopy by looping the large end through the ring or loop on the
top of the canopy. (Figure 5)
b. Take the small end and place it through the grommet in the
top of the main bag. (Figure 6)
c. Attach main pilotchute bridle, either T.O.P. or ripcord to
the canopy attachment loop with the #5 Rapide link provided.
(Figure 6)Trap the Ty-8 webbing yoke at the top of the bag inside
the Rapide link. Note that the canopy attachment loop and the main
bridle are the same color (normally red) while the yoke is yellow. By
using color coordination, it reduces the possibility of assembling the
system incorrectly. ALWAYS MATE COLOR TO COLOR.
Step 7 Set brakes by pulling steering lines down until locking loops
are just below guide rings on main risers. Insert main toggle upper
end into brake set loop on steering line. Align and press toggle onto
riser Velcro. Stow excess lower control line in Velcro keeper.
(Figure 7)
Step 8 Install rubber bands provided onto the bag. The main
parachute is now ready to pack according to canopy manufacturer’s
instructions.
Packing
When packing the main canopy, dress it approximately 4” wider
than bag (2” each side) to fill out sides and not concentrate bulk in the
center. For best appearance, bulk must be distributed evenly in the bag.
Route lines out the center and lock the two center locking stows. Lock
two outer locking stows and finish stowing lines to within 18” of
connector links.
Work air out of the bag at this time to flatten the bag prior to
placing it in container. Pick up bag and place it at bottom of the main
container. Route main risers over shoulders and deep into riser cover
channels on either side. Main toggles face inboard.
Place bag into main container with lines to the bottom of
container. (Figure 8) FAILURE TO PLACE LINES TO THE
BOTTOM OF CONTAINER COULD RESULT IN A
PILOTCHUTE IN TOW. Kneeling on bag, push it into corners of
container while pulling up on the side flaps.
Figure 6
Figure 5
Figure 8
Figure 7

RI-1313-(2) Revision 1.0
5/3/2001
page 12
Main Container Closing -
-Ripcord and M.O.D. Handles
Step 1 “S” fold the main bridle and place on top of the main bag and
place the base of the spring pilotchute on top of the bridle.
Step 2 Collapse the pilotchute while stuffing the material in between
the coils. (Figure 9) The arrow on pilot chute cap should point toward
top of rig. Arrow indicates metal swage on pilotchute spring. Correct
orientation prevents unsightly wear on container flaps.
Step 3 Close the container in the numbered sequence. #1 -Bottom; #2 -
Top ; #3 -Right side ; #4 -Left side. Insert black plastic coated ripcord
cable through M.O.D. ring, if so equipped, (Figure 10) then through the
main closing loop. Stow the excess cable just under the top edge of the
left main flap. (Figure 11)
Note: If the Telesis 2 is set up for operation with an FXC AAD on the
main, the closing sequence for the last two flaps will be reversed. That
is, the right flap will close last.
-Throw-Out (T.O.P.)
Step 4 Route main bridle across top of bag and out upper right corner
of container See page 11 (Figure 8).
Step 5 Close main flaps in the order stamped on each flap. #1 -Top;
#2 -Bottom; #3 -Right side; #4 -Left side. Pull flaps into place and
lock with the curved pin. Mate Velcro slack-tab and lay flat toward
top. (Figure 12)
Figure 9
Figure 10
Figure 11
Figure 12

RI-1313-(2) Revision 1.0
5/3/2001
page 13
FOLDING THROW-OUT PILOTCHUTE (T.O.P.)
Step 1 Place pilotchute on a flat surface with the handle down and
spread to its full size. (Figure 13)
Step 2 Fold pilotchute in half and stow excess bridle near the outer
edge of pilotchute. (Figure 14)
Step 3 Fold outside edge toward handle keeping bridle inside.
(Figure 15)
Step 4 Fold pilotchute into thirds as shown. (Figure 16)
Step 5 Fold pilotchute into thirds again so the result is a flat package
about the same length and width as spandex pocket. (Figure 17)
Step 6 Slide pilotchute into spandex pocket so that only handle
protrudes. ( Figure 18) Stow excess bridle under right side main flap.
Figure 14
Figure 15
Figure 17
Figure 16
Figure 13
Figure 18

RI-1313-(2) Revision 1.0
5/3/2001
page 14
MANUAL OVERRIDE DEPLOYMENT (MOD) HANDLE
The Telesis 2 AFF M.O.D. or Manual Over-ride Deployment handle
was first introduced on the Telesis system. The MOD is a backup
main ripcord mounted on the lower left corner of the main container.
This allows the reserve side jumpmaster on an AFF jump to easily
deploy the main parachute. Because the AFF/M.O.D. handle is a
completely separate component, it may be left off the assembly when
the Telesis 2 is used in a normal freefall or static line mode.
To install the handle:
Step 1 Mate the ring end of the handle lanyard with the small piece of
Velcro located just below the grommet on the left main flap.
(Figure 19)
Step 2 Make a full twist in the lanyard between the two sections of
Velcro and mate the long piece of hook to the corresponding piece of
loop Velcro on the underside edge of the left main flap. (Figure 20)
Step 3 Reach into the pocket on the left corner of the main container
and pull out the handle mounting flap with the hook Velcro on it.
(Figure 21) Mate the handle to the mounting flap and then tuck the
handle into the pocket so it is held securely. (Figure 22)
Step 4 Close the container in the numbered sequence. #1 -Bottom;
#2 -Top; #3 -Right side; #4 -Left side. Insert black coated ripcord
cable through M.O.D. ring, if so equipped, then through the main
closing loop. Tuck the excess cable under the left side container flap.
Figure 19
Figure 20
Figure 21
Figure 22

RI-1313-(2) Revision 1.0
5/3/2001
page 15
MAIN STATIC LINE INSTALLATION
The Telesis 2 main static line activates a direct bag system. With
ram-air canopies, the canopy is free stowed in the bag. That is, there is
no assist device or connection between the canopy and the bag.
Regulations requiring canopy assists are intended for round
parachutes.
The Telesis 2 is designed to be easily converted from freefall to
static line and back without having to unpack the canopy. We do this
by using a canopy attachment loop you installed as in Figure 5 on
page 11. Whenever you pack the canopy, you always pack it with the
canopy attachment loop exposed through the grommet at the top of
the bag. In freefall mode, you attach the pilotchute and bridle to the
canopy attachment loop. For static line, the static line is looped
directly to the yoke on the top of the bag. To make it even simpler, we
color coded the canopy attachment loop and the freefall pilotchute
bridle the same color (normally RED). We made the mating loops the
same size so that they can be attached with a #5 Rapide link. These
loops for the Rapide link are too small for the static line to be
inadvertently attached to the canopy. The static line and the yoke on
the bag are also color coded (yellow) for proper mating.
To convert from freefall to static line:
Step 1 Disconnect the freefall pilotchute and bridle from the canopy
attachment loop.
Step 2 Loop the end of the Main Static Line over the yoke on the top
of the main bag and tighten securely. (Figure 23)
Step 3 Place the main bag in the main container with the static line
exiting the upper left (or right) hand corner of the container. (Figure
24)
Step 4 Close the container in the numbered sequence. #1 -Bottom;
#2 -Top; #3 -Right side; #4 -Left side. Insert the static line
Flexpin through the main closing loop.
Step 5 Fold the static line above the Flexpin attachment point and
double stow it in a rubber band on the static line stow loop on the left
or right side main flap. This is for shortest routing to the aircraft door
and so that the Flexpin is not accidentally dislodged by the drag of the
static line during use. (Figure 25)
Step 6 Close the main protector flap and finish stowing the static line
left to right in rubber bands attached to stow loops. (Figure 26)
Figure 23
Figure 24
Figure 25
Figure 26
