Rini ComfortMove User manual

User Manual
Special- and Saddle chairs
ComfortMove, RiFlex, Dynamic, RiRest,
Amazone, Jumper, Classic, SwingFit and
more…
2011-0153 v1
Tel
+46-

Rini Special- and Saddle chairs
2
Table of content
1. Special and Saddle chairs................................................................ 3
2. Important - Before use...................................................................... 3
2.1 Unpacking and installation............................................................. 3
2.2 Intended areas of use ....................................................................3
3. Basic adjustment of the chairs........................................................ 4
3.1 Wheels and Trumpet gliders.......................................................... 4
4. Tips for comfortable position .......................................................... 5
5. Saddle chairs..................................................................................... 5
5.1 Adjusting the correct seating position ............................................ 5
5.2 Tilt angle and width adjustment...................................................... 6
6. Adjusting the foot control ................................................................ 6
7. Replacing the gas spring ................................................................. 7
8. Disinfection, cleaning & repairs....................................................... 8
9. Safety................................................................................................. 9
9.1 CE Declaration of conformance..................................................... 9
10. Disposal and recycling..................................................................... 9
11. Warranty ............................................................................................ 9

Rini Special- and Saddle chairs
1. Special and Saddle chairs
Thank you for choosing a Rini Chair!
Rini’s Special- and Saddle chairs offer excellent comfort with its
ergonomic design, enabling high efficiency in daily patient work for
surgeons, assistants and other medical professionals.
Even the feel and look can be important so many of the chairs can
therefore be ordered in different colours and different materials. The
chairs are popular in many health care areas, see full range of chairs in
our product catalogue.
Rini is constantly improving existing products and developing new ones.
Consequently, we value the professional user’s point of view; so don’t
hesitate to let us know your opinion about any of our product lines.
2. Important - Before use
To ensure safety and the lifespan of the product, it is important to
observe the following instructions before use. Please read this
manual carefully and understand how to use the product before you
start.
2.1 Unpacking and installation
Before the product is unpacked make sure that the packaging has not
been damaged during transport. If so, document these with a picture and
report this to the transport company and your local Rini representative.
The chair is normally delivered in parts to save shipping space and is
assembled by the following steps.
Put the wheelbase on the floor and if not already mounted, the gas
spring in the cone which is in the base.
2.2 Intended areas of use
The chairs are developed for different types of work in a professional
medical environment where the operator needs a stable and ergonomic
seated work position.
Intended uses include: Neurosurgery, Eye surgery, Ear, Nose and Throat
surgery, Facial Plastic surgery, Robotic surgery, Dental surgery and
similar examination or treatment areas.
The chair may only be used for the purposes specified in this
manual. Any other use may pose a risk to the user. The chair should
not be used by operators that weigh more than 120kg.

Rini Special- and Saddle chairs
4
3. Basic adjustment of the chairs
The picture shows as an example a foot controlled RiRest chair with
backrest but all Rini chairs have similar adjustment possibilities.
1. Adjustment of height of backrest
2. Adjustment of seat and backrest angle
3. Hand adjustment of height
4. Foot adjustment of height (option and replace the hand control)
3.1 Wheels and Trumpet gliders
The chair can be equipped with various types of wheels and also trumpet
gliders, each with different functions.
Wheel low friction
These wheels have low friction and rolls easily with and without load, for
great mobility.
Wheel high friction
These wheels have high friction and rolls slowly with and without load.
Wheel, brake when loaded
These wheels are easy rolling when not loaded. They lock automatically
when the seat is loaded, for example when one sits down.
Trumpet glider
This glider replaces the wheels and provides high stability.
1
4
3
2

Rini Special- and Saddle chairs
5
4. Tips for comfortable position
To achieve the best level of comfort please try the following steps.
a) Whilst seated in the chair, adjust the height of the chair to achieve
a 90oangle of the legs. The feet shall have the whole sole against
the ground during the adjustment.
b) Adjust the seat and backrest to a comfortable position.
c) If necessary, fine-tune the height of the seat.
5. Saddle chairs
To sit on a saddle chair is different from sitting on a regular chair. Place
yourself beside the chair. Lift the leg closest to the chair over the seat
and sit down.
Be careful when lifting the leg over the seat, the chair can be
pushed away. Attempt to be seated traditionally, which is from the
front, may result in the chair rolling away and causing personal
injury.
A saddle chair should not be moved with the front forward. Instead, the
chair is suitable to be moved sideways or backwards.
5.1 Adjusting the correct seating position
The seat is adjustable in height with hand or foot control. Some chairs
also have the option to have the seat tilted.
When an optimal ergonomic position appears shall the chair feel
comfortable and a 135oangle is created between the thighs and upper
body.
The legs should be relaxed, and the feet shall rest steady on the floor,
not hanging in the air. Normally is the height of the seat changed
250-400mm upwards compared to a regular office chair.
135o

Rini Special- and Saddle chairs
6
To achieve optimal seating position:
a) Raise the chair so the feet are hanging in the air
b) Let your leg and pelvis relax and stretch for some minute, which
the gravity takes care of automatically
c) Lower the chair until the heels touch the floor
5.2 Tilt angle and width adjustment
Some chairs are equipped with tilt and width adjustement function. Under
the seat there is a lever for the tilt function. Push the lever up towards the
seat and choose suitable angle of the seat.
The width of a chair with this function can be adjusted by a lever which
unlocks the halves.
Viewed from behind, push the lever to the right to unlock the halves.
Adjust and lock by pushing the lever back to its original position.
6. Adjusting the foot control
If the foot control does not work satisfactorily, it may need to be adjusted.
The two most common causes and actions are:
a) If the chair cannot be adjusted in height with the foot control at all
then adjust the screw clockwise until function is restored, see picture
below.
Lever for adjustment
of the gap

Rini Special- and Saddle chairs
7
b) If the chair collapse under load, even if the foot control is not being
used, then adjust the screw counter clockwise until function is
restored, see picture below.
7. Replacing the gas spring
All Rini chairs can normally be equipped with gas springs with different
height span; low, medium and high. To change the gas spring a rubber
or plastic hammer is needed. If the gas spring is stuck there are some
special tool that can be ordered from Rini, see picture below.
First turn the chair upside down and hold it slightly above the ground.
Lift the chair in the gas spring and hit lightly with the hammer against the
metal chassis under the seat.
Loosen with a
10mm wrench
and adjust with
hex wrench.
Hit with the
hammer here

Rini Special- and Saddle chairs
8
If the chair is hand controlled hit against the gas spring from underneath
the base, this makes the gas spring loosen from the base.
If the If the chair is foot controlled there are three screws that hold the
height adjustment mechanism that needs to be removed from the gas
spring.
8. Disinfection, cleaning & repairs
No part of the product is normally in contact with the patient and the
armrests are normally draped.
Disinfection
Part
Product
Other information
Upholstery and
armrests
Virkon
(including most
disinfectants
without alcohol).
1% concentration.
(Disinfectants containing alcohol
cannot be used due possible to
dehydration)
Chassis
Noedischer
Dekonta
CCOTRADE RW
1-3% concentration
0,5% concentration
Hit with the
hammer here

Rini Special- and Saddle chairs
9
Cleaning
Part
Product
Other information
Upholstery and
armrests
Water and soap
Use damp cloth
Chassis
Water and soap
Use damp cloth
Repairs
The product should only be repaired by Rini or a Rini authorised service
centre. Product to be repaired under warranty must be sent to Rini
factory or an authorised Rini service centre.
Unauthorized repairs and modifications may result in loss of
function and void warranty.
9. Safety
The product should only be used as intended otherwise it can cause
injury to persons or product. Read this manual before the product is put
into service. Necessary knowledge of the product is required before
clinical use and this manual should always be available when using the
product. No accessories other than those mentioned in this manual may
be used. Please note the warning signs on the product.
Warning signs are used when there is a risk for patients, staff or
product.
9.1 CE Declaration of conformance
Rini Special and Saddle chairs follow MDD EU
Directive 93/42 EEC for medical products.
10. Disposal and recycling
The product is mainly made from environmentally recyclable materials as
steel, stainless steel, aluminum and plastics. Rini recommends that the
material be sorted and recycled in connection with the destruction of the
product.
11. Warranty
The warranty is valid one year from the date of purchase. Please contact
Rini for further information.

Operator Chair Carl Spring and Carl Swing
10
Rini Ergoteknik AB Fågelsångsvägen 3B
SE-186 42 Vallentuna Sweden
Phone [phone]
Email [email protected] www.rini.se
