Riotoro AVIATOR CLASSIC User manual

OI!
Hej!
Cześć!
Привет!
Hi!
Hola!
Hallo!
Bonjour!
Hi!
你好!
Hi!

Congratulations you are on your way to build the
perfect gaming machine.
Welcome to RIOTORO
Thank you for purchasing the
AVIATOR CLASSIC headphones.
Immerse yourself in the game with
AVIATOR CLASSIC’s 7.1 position
surround sound and superior long-playing comfort.
Support for PC, Playstation, Xbox, Nintendo and mobile
platforms means AVIATOR CLASSIC is ready to
play wherever you roam. Noise cancelling provides
distraction-free audio for you and your team mates.

Welcome to your
AVIATOR CLASSIC headphones
This guide shows you how to use your
AVIATOR CLASSIC headphones, including
customization, buttons, and general information.
System Requirements:
- PC with available USB 2.0 or later port.
- Windows® 7 or later.
- Internet connection to download NADIX
mouse software.
What is included:
- 1x Aviator Classic Headphone
- 1x Detachable Mic
- 1x Voice/Audio Dongle
- 1x USB Dongle w/Volume Control
- Quick Start Guide

About your AVIATOR CLASSIC
headphones
AVIATOR CLASSIC’S embodies
the power of gamers in a headphone with
studio quality sound, superior noise cancelation,
multi platform capabilities, surround sound, person-
alized comfort and your own sense of style.
Features:
- Over-ear headphone
- Virtual 7.1 channel surround sound
- Flexible, detachable noise cancelling microphone
- Adjustable head beam and detachable ear pads
- Gold connectors, sleeved cables and USB adapter
- Multi-platform support for PC, Playstation, Xbox
and mobile
- Large 50mm drivers for fullersound reproduction

1. Power on your PC.
2. Connect the USB cable to your PC.
3. Check your audio settings to ensure usb
audio is enabled.
Installing AVIATOR CLASSIC
headphones

1. Connect the 3.5 mm cable to your gaming
console audio jack.
2. Connect the USB cable to your gaming console.
Installing AVIATOR CLASSIC
headphones

AVIATOR CLASSIC
Microphone
The noise canceling microphone can be removed,
just pull it gently and it will detached from
the headset.
The noise canceling microphone allows you to make
crystal clear calls calls, live streams or gaming
chats through any device.

Volume down
Mute sound
Mute microphone
Volume up
The 7.1 surround sound controller allows you to
control the volume and mute the headset or
microphone. Simply click on the specific button
once on the remote for the specific action you require.
AVIATOR CLASSIC
Remote

Installing AVIATOR CLASSIC
Cables
The braded cords are completely detachable so you
can decide which device you prefer to use.
a) 3.5 mm cable: to be
used with any device
with a 3.5 mm jack.
b) Usb cable: to be
used with any device
with a USB enabled audio.
b) Y-cable: to be used
with any device with a
audio/mic input.

Simple pull down the the ear muffs to the desired
height (from both sides) and adjustuntil it fits comfortably.
AVIATOR CLASSIC
Adjustable head beam
8.7 in /
220.0 mm
7.3 in /
185.0 mm

Rated input power:
Maximum input power:
Impedance:
Sensitivity:
Channel balance:
Phase:
Drive Unit Dimensions:
Magnet:
Drive Unit Sensitivity:
Drive Unit Frequency Response:
Plug and Pin:
Cord length:
Weight:
MIC Sensitivity:
Frequency Response:
Directivity 指向性
MIC Dimension:
Size:
MIC Impedance:
AVIATOR CLASSIC
Specifications
10mW
20mW
64 15%
103 3dB
3dB
Same phase
53 mm
(NdFeB)
110 3dB
50−20KHZ
Usb/3.5mm
2700 10%mm
348.2+/-5g
-42 3dB
100-10KHz
Omni-direction
Ø6.0×2.7MM
152x185x90mm
≤2200

LIMITED PRODUCT WARRANTY ("Limited Warranty")
Limited Warranty. RIOTORO warrants the Product to be free
from defects in materials and workmanship when used
normally in accordance with the official documentation for
the applicable Warranty Period from the date of retail
purchase.
Exclusions and Limitations. This Limited Warranty
does not cover:
-Software, including (without limitation) software added to
the RIOTORO-branded hardware products or third-party
software.
-Non-RIOTORO branded products and accessories, even if
packaged and sold with the Product.
-Problems with and/or damage to the Product caused by
using accessories, parts, or components not made by
RIOTORO;
-Damage caused by service (including upgrades and
expansions) performed by anyone who is not officially acting
as an employee, representative or sub-contractor of
RIOTORO.
-Claims arising from any unacceptable use or care of the
Product.
-Claims arising from external causes, including (without
limitation), accidents, acts of God, liquid contact, fire or
earthquake.
-Products with a serial number or date stamp that has been
altered, obliterated or removed.
-Cosmetic damage, minor cosmetic abnormalities (including
minor pixel abnormalities) and normal wear and tear,
including (without limitation) scratches, dents and chips.
For the latest and current terms of the Limited Product
Warranty, please visit www.riotoro.com/warranty.

Technical Support and
Customer Service
US & Canada
1-888- 270-7090
[email protected]
[email protected]
© Copyright 2019 RIOTORO. All rights reserved.
All trademarks are the property of
their respective owners.
Reproduction in whole or part without
written permission is prohibited.
