Iluv TrueBTAir User manual

No Wire, True Wireless Stereo In-ear
Earbuds with Charging Case
TrueBTAir
INDICE DE PROTECTION
CONTRE L'EAU ET LES CHOCS
LEVEL OF PROTECTION
FROM WATER
INTRUSION
X4
- English -
User Manual

1. Overview of the Product
2. What’s Included
S
Earbuds with ear ns
3 size ear tips
Charging storage case
Micro USB
charging cable (3 ft)
M L
2
User
Manual
1st
Setup
Ear Tip
Ear Fin
Status LED
Multifuntion
Button (L)
Multifuntion
Button (R)
Battery status LEDCharging storage case lid

3. Attention
3
IPX4 rated TrueBTAir can resist water splash and
sweat but must not merged inside water or left on
wet place long time.
TrueBTAir provides a double locking
system of angled in-ear tips and ear ns
for superior comfort and an active
lifestyle.Try dierent eartips for your
comfortable and secure t. Ultra mini
and lightweight design with the similar size of a quarter coin allows
you to wear it for a long time comfortably.
X4
Please charge the ear-buds rst and
wear TrueBTAir ear-buds since TrueBTAir
guides you with voice prompt.
4. Wear Earbuds

Pairing
successful
4
5. Power On and Pairing
1. To turn on, press multifunction buttons on BOTH earbuds
for 2 seconds
After opening a new package initially, follow these steps. Skip
step 5-1 when the earbuds are taken from the charging case.
The right earbud is assigned as the master earbud by default
and connects to left earbud (slave earbud) automatically.
2. Turn on Bluetooth on your mobile device
a. Go to settings c. Scan for and select "iLuv
TrueBTAir"
d. Voice Prompt: "Pairing
Successful" on right earbud
b. Turn on Bluetooth
iLuv TrueBTAir
1. Power on
2. Connected,
right channel
3. Please pair to your device
(On master earbud)
1. Power on
2. Connected,
left channel
...
:02
Hold
:02
Hold

5
Click
Double
Click
1. Once paired, open music app on
your mobile device
2. Click a multifunction button
on either of earbuds to play
3. Click a multifunction button
again to pause
6. Music Playback
1. When you receive an incoming call, click a multifunction
button on any earbud to answer the call. You will hear the
sound only from master earbud.
8. Answer the Call
1. Double click a multifunction
button on any earbud.
2. Siri on iPhone or Google assistant
on Android phone will be activated.
3. Ask question or command with your voice
7. Voice Command

6
Power off
:03
Hold
:01
Hold
3. Hold the multifunction
button for 1 second to
decline when you receive an
incoming call
2. Click a multifunction button again to hang up
1. Hold a multifunction on any
earbud for 3 seconds to turn
o power.
2. Hold a multifunction button on ONE of the earbuds for 5
seconds to pair. Do not release the button when you hear
"Power on" but release it after "Pairing".
9. Two Separate
Mono Earbuds
Incoming call
Click
di, di
(On master
earbud)

7
Pairing
successful
3. Turn on Bluetooth on your mobile device
a. Go to settings c. Scan for and select
"iLuv TrueBTAir"
d. Voice Prompt:
“Pairing successful”
b. Turn on Bluetooth
iLuv TrueBTAir
4. Blue light will ash every 5 seconds, indicating that the
Bluetooth is connected successfully. Play music and enjoy!
5. You can use it as a mono earbud to answer calls hands free
or listen to music, ideal while driving.
:05
Hold
Power on
...
Pairing

8
1. Power o by pressing a multifunction
button on any earbud for 3 seconds.
If you want to hear the sound of
hands free call from your ear with
better hearing, you can change
the master earbud as follow.
2. Press and hold multifunction buttons on BOTH
earbuds for 5 seconds. Both earbuds will turn on and pair
automatically each other. Do NOT release the buttons
until you hear“Pairing”
Power off
:03
Hold
10. Change the Master Earbud
6. Set up the other earbud with a dierent phone, following
above guideline. Two people can use them as two mono
earbuds.
Power on
...
Pairing
Power on
...
Pairing
:05
Hold
:05
Hold

9
3. Double click one of them to set as a“Master" earbud
which will be connected to your phone.
Pairing successful
(On master earbud)
4. Turn on Bluetooth on your mobile device
a. Go to settings c. Scan for and select
"iLuv TrueBTAir"
Voice Prompt: "Pairing
Successful" on master
earbud
b. Turn on Bluetooth
iLuv TrueBTAir
1. Searching for slave
2. Connected. left channel
3. Please pair to your device
(On master earbud)
...
1. Connected.
right channel
...
Double
Click

Charging storage case with 800 mAh not only works as a
portable case but also as a charger which can charge both
earbuds fully 5 times.
1. Insert the smaller end of the
included 3ft Micro USB charging
cable into Micro USB charging
port on the Charging Case
Red LED: Charging
LED o : Fully charged
2. Insert the other end of the
Micro USB charging cable
into a USB wall charger or a
USB port on a computer
10
3ft.
Charging Case
11. Charging
5. Blue light will ash every 5 seconds, indicating that the
Bluetooth is connected successfully. Play music and enjoy!
If you want to pair with another device
1. Unpair iLuv TrueBTAir from currently paired mobile device
2. Power o iLuvTrueBTEP by pressing a multifunction
button for 3 seconds
3. Follow the same pairing guideline above with another device
Battery status LED for
Charging Storage case

11
High capacity battery of 60 mAh on each earbud gives you
long music playing and talking time. The earbuds can be
charged while they are stored in the charging case.
1. When the batteries of the
earbuds get lower, voice prompt
will say "Battery low".
Earbuds
Battery low
L R
2. Put the earbuds in the charging
case and close the lid. The
earbuds will turn o automatically
and start charging. The cover
must be closed so that the
earbuds are connected to charg-
ing pins securely.
3. While charging, the red LED
indicators on the backside of
charging case will be on.
4. When fully charged.
LED will turn o.
5. When you take the earbuds out
of the charging case, the earbuds
will turn on automatically.
Battery status
LED for right
earbud
Battery status
LED for left
earbud

12
Power off
:03
Hold
1. Put the earbuds in the
charging case and close the
lid. The earbuds will turn o
automatically and start
charging.
2. When you take the earbuds out of the charging case, the
earbuds will turn on and connect to the previously paired
phone automatically.
1. Press multifunction button on any
earbud for 3 seconds to turn o both
earbuds.
When you use the charging Case
When you use multifunction
button
12. Power O/On
1. Power On
2. Connected, right channel
3. Pairing successful
(On master earbud)
1. Power On
2. Connected,
left channel
...

13
2. Press multifunction buttons on BOTH earbuds for 2 seconds
to turn on the earbuds. The earbuds will connect to the
previously paired phone automatically.
1. Power On
2. Connected,right channel
3. Pairing successful
(On master earbud)
:02
Hold
:02
Hold
1. Power on
2. Connected,
left channel
...

14
1. Sound comes from only one earbud when I use it for hands
free talk. As I have hard hearing on my right ear, how can I hear
the sound from left side?
Since only master earbud communicates with your phone, you
hear the sound only from one side of master earbud.
If you want to change the master earbud to left earbud, you can
assign it, referring to "10. Change the Master Earbud" section.
2. After charging earbuds from the charging case, should I
connect them to my phone via Bluetooth again?
No, you don’t need to. When you take them out of charging
case, they automatically connect to your previously connected
device.
3. Should I turn o power before charging and turn on power
after charging the earbuds?
No, you don’t. When you place the earbuds inside the charging
case and close the lid, they will be turned o automatically after
a while. Then, they will start charging.
When you take them out of the charging case, they will be
automatically turned on.
4. What is music play time?
When the earbuds are fully charged, you can play music or talk
up to 3 hours which varies depend on the music content and
volume. Standby time is up to 22 hours.
Since the charging case can charge both earbuds 5 times, you
can play music up to 15 hours with 5 times of charge.
Trouble Shooting

Véritables écouteurs stéréo sans l
intra-auriculaires avec boîtier
de charge
TrueBTAir
INDICE DE PROTECTION
CONTRE L'EAU ET LES CHOCS
LEVEL OF PROTECTION
FROM WATER
INTRUSION
X4
- French -
User Manual

1. Vue d'ensemble du produit
2. Contenu du coret
S
Écouteurs avec
ailettes auriculaires
3 tailles d'embouts auriculaires
Boîtier de charge
et de rangement
Câble de chargement
micro USB (92 cm)
M L
16
User
Manual
1st
Setup
Embout
auriculaire
Ailette auriculaire
LED d'état
Bouton
multifonction (L)
Bouton
multifonction (R)
LED d'état de la batterie
Boîtier de charge et de
rangement avec couvercle

3. Attention
17
Classés IPX4, les écouteurs TrueBTAir sont résistants à la
sueur et aux éclaboussures. Cependant, ils ne doivent
pas être plongés dans l’eau ou exposés à l’humidité
trop longtemps.
TrueBTAir ore un double système de
verrouillage sur embouts intra-
auriculaires inclinés et des ailettes pour
un confort supérieur adapté à un mode
de vie actif. Essayez les diérents types d'embouts pour un maximum
de confort et de sécurité. Très légers et aussi petits qu’une pièce de
monnaie, vous pourrez les porter longtemps sans désagrément.
X4
Veuillez d'abord charger les écouteurs puis les
placer sur vos oreilles, car TrueBTAir va vous
guider par message vocal.
4. Placez les écouteurs
sur vos oreilles

:02 :02
1. Power on
2. Connected,
right channel
3. Please pair to your device
(sur l’écouteur maître)
1. Power on
2. Connected,
left channel
...
Pairing
successful
18
5. Mise sous tension et couplage
1. Pour allumer, appuyez sur les boutons multifonction des
DEUX écouteurs pendant 2 secondes.
Après avoir ouvert le coret, suivez ces étapes. Passez l'étape
5.1 lorsque les écouteurs sont retirés du boîtier de charge.
2. Activez le Bluetooth sur votre appareil mobile.
a. Allez dans les
paramètres.
c. Recherchez et sélectionnez
« iLuv TrueBTAir ».
d. Message vocal : « Pairing
Successful » (couplage réussi)
dans l'écouteur droit.
b. Activez le Bluetooth.
iLuv TrueBTAir
MaintienMaintien

19
Pressez
Pressez
2 fois
1. Une fois le couplage eectué,
ouvrez l'application musicale sur
votre appareil mobile.
2. Pressez le bouton multifonc-
tion sur l'un des écouteurs pour
lancer la lecture.
3. Pressez à nouveau le bouton
multifonction pour mettre en
pause.
6. Lecture musicale
1. Lorsque vous recevez un appel entrant, pressez le bouton
multifonction sur n'importe quel écouteur pour prendre
l'appel. Vous n'entendrez le son que dans l'écouteur maître.
8. Répondre à un appel
1. Pressez 2 fois le bouton
multifonction sur n'importe
quel écouteur.
2. Siri sur iPhone ou l'assistant Google
sur téléphone Android s’active.
3. Posez une question ou commandez à la voix
7. Commande vocale

20
Power off
:03
:01
Maintien
Maintien
3. Maintenez le bouton
multifonction 1 seconde
pour refuser les appels
entrants.
2. Pressez à nouveau le bouton multifonction pour
raccrocher.
1. Maintenez 3 secondes le bouton
multifonction sur n'importe quel
écouteur pour éteindre l'appareil.
2. Maintenez 5 secondes le bouton multifonction sur l'UN
des écouteurs pour appairer. Ne relâchez pas le bouton
lorsque vous entendez « Power on » (mise sous tension) et
relâchez après « Pairing » (couplage).
9. Deux écouteurs
mono distincts
Incoming call
Pressez
bip, bip
(sur écouteur
maître)
