Riso Perfect Binder G10 200 User manual

User's Guide
Series 061-36009

Perfect Binder User’s Guide
Model:Perfect Binder G10 (200) / Perfect Binder G10 (120)
The user is cautioned that unauthorised changes or modifications not approved could void the user’s authority to operate
the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio / TV technician for help.
CAN ICES-3(B)/NMB-3(B)
To ensure safety precautions, be sure to read this guide before
using the product. After reading this guide, keep it in handy for
future reference.
CAUTION
Um Vorsichtsmasnahmen zu treffen, lesen Sie sich vor
Gebrauch des Produkts das Handbuch durch. Halten Sie das
Handbuch nach dem Durchlesen stets griffbereit.
VORSICHT

1
Perfect Binder User’s Guide
About This Guide
Prefaces
Thank you for purchasing the Perfect Binder.
The Perfect Binder is a device which can be connected to a RISO printer (ComColor GD Series) to perform
perfect binding. You can make booklets with the printed covers and body pages, and also make printing and
binding from Microsoft Word files or PDF files by using the dedicated software or printer driver.
Please read the related guides before using or when you have concerns while using, and make use of this
product and guide long for ever.
The following two guides are supplied with the Perfect Binder.
●User's Guide (this guide)
This guide describes specifications, operations and settings of each function.
This guide also describes how to handle or replace the consumables and the action to take when the problems
occur.
●Application Guide
This guide describes the method to create binding data by loading "cover data" and "body page data".
This guide describes required information when connecting the Perfect Binder. For settings of the printer that
are not related to the binding function, see the guides of the ComColor GD Series printer.
About This Guide
(1) This guide may not be reproduced in whole or in part without the permission of RISO KAGAKU CORPORATION.
(2) The contents of this manual may be changed without prior notice due to product improvements.
(3) RISO KAGAKU CORPORATION shall not be liable for any consequence of using this guide or the machine.
Trademark Credits
Microsoft, Windows, and Microsoft Word are either registered trademarks or trademarks of Microsoft Corporation in
the United States and/or other countries.
PostScript is either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or
other countries.
, , ComColor, and FORCEJET are trademarks or registered trademarks of RISO KAGAKU
CORPORATION in the United States and other countries.
Other corporate names and/or trademarks are either registered trademarks or trademarks of each company,
respectively.
This guide mainly describes operations using "Perfect Binding Software" which allows for easy editing of
such as impositioning. You can also send original data created with an application of your choice via a
printer driver or dedicated printer driver compatible with PostScript 3 (if the optional print controller has
been installed) for simplified binding. For more information on how to transmit binding data and the items
for configurations, see "Using the Printer Driver" (p. 1-4) or the user's guide of the print controller
(ComColor Express FS 2000C).
Acquisition of Color Universal Design Certification
The Perfect Binder (this unit) is certified for being manufactured in consideration of Color
Universal Design, which improves visibility for more people regardless of individual
differences in color perception, by the Color Universal Design Organization (CUDO).

2
Perfect Binder User’s Guide
■Symbols Used in This Guide
Indicates cautions that should be noted for safe use of this unit.
Indicates important items that should be noted or are prohibited.
Indicates useful information or additional information.
■Names of Keys and Buttons
The names of physical keys on the operation panel, buttons on the touch panel screen, and buttons/items displayed on
the computer operation screen are indicated with square brackets [ ].
■Illustrations Used in This Guide
The screenshots and illustrations contained in this guide may vary depending on the model of the printer, or the usage
environment, including the connected optional equipment.
Symbols, Notations, and Screenshots Used in This Guide
Example: Press the [Stop] key. Example: Touch [Perfect Binding].
Example: Place a check in [Perfect
Binding].
●Operation Panel ●Touch Panel Screen ●Computer Window

3
Perfect Binder User’s Guide
Contents
About This Guide ................................................................................................1
Symbols, Notations, and Screenshots Used in This Guide ........................... 2
Safety Precautions ..............................................................................................5
Warning Symbols .......................................................................................... 5
Power Plug .................................................................................................... 5
Installation Location ...................................................................................... 5
Power Connection ......................................................................................... 6
Handling ........................................................................................................ 7
Caution Label ................................................................................................ 8
Before Use ...........................................................................................................9
Installation Location ...................................................................................... 9
Power Connection ......................................................................................... 9
Required Spacing ....................................................................................... 10
Handling ...................................................................................................... 11
Consumable Storage and Handling Precautions ........................................ 11
Disposing of Used Consumables ................................................................ 12
Usable Paper .............................................................................................. 12
Handling of Bound Booklets ........................................................................ 13
Restrictions on the Printer ........................................................................... 14
Part Names and Functions ...............................................................................15
What You Can Do with the Perfect Binder ......................................................16
Perfect Binding ..................................................................................................18
Binding Method ........................................................................................... 18
Terms .......................................................................................................... 18
Paper Feed Path ......................................................................................... 20
Binding Preparations ........................................................................................21
Power Supply .............................................................................................. 21
Unit Status .................................................................................................. 22
Loading the Body Pages/Cover (Manual Binding) ...................................... 23
Chapter 1 Binding...................................................................................1-1
Basic Operations of the Perfect Binding Software .......................................1-2
Using the Printer Driver ...................................................................................1-4
Setting the Printer Configuration ................................................................ 1-4
Allocating the Original Data to the Cover Sheet and Body Pages ............. 1-4
Performing Perfect Binding ........................................................................ 1-6

4
Perfect Binder User’s Guide
[Finishing] Tab ........................................................................................... 1-6
Operations of the Binding Job ........................................................................1-8
Changing the Settings during Printing ........................................................ 1-8
Changing the Settings of a Waiting Job ..................................................... 1-8
Setting the Binding Functions .................................................................... 1-9
Admin Menu Settings ....................................................................................1-11
Perfect Binder Settings ............................................................................ 1-11
Cover Settings for the Perfect Binder ....................................................... 1-12
Chapter 2 Maintenance ..........................................................................2-1
Replacing the Consumables ...........................................................................2-2
Replacing the Glue Sheet .......................................................................... 2-2
Replacing the Filters .................................................................................. 2-4
Disposing the Cutting Trash ....................................................................... 2-5
Cleaning the Unit ..............................................................................................2-7
Troubleshooting ...............................................................................................2-8
Precautions when Removing Jammed Paper .......................................... 2-14
Chapter 3 Appendix................................................................................3-1
Specifications ...................................................................................................3-2
Consumables ....................................................................................................3-4
Types of Consumables .............................................................................. 3-4
Index ..................................................................................................................3-6
Vorsichtsmaßnahmen ......................................................................................3-8
Warnsymbole ............................................................................................. 3-8
Netzstecker ................................................................................................ 3-9
Aufstellungsort ........................................................................................... 3-9
Netzanschluss ............................................................................................ 3-9
Behandlung .............................................................................................. 3-10
Warnsymbole ........................................................................................... 3-11
Vor Inbetriebnahme .......................................................................................3-12
Aufstellungsort ......................................................................................... 3-12
Netzanschluss .......................................................................................... 3-12
Abmessungen .......................................................................................... 3-13
Behandlung .............................................................................................. 3-14
Materiallager und Schutzmaßnahmen zur sicheren Handhabung ........... 3-14
Entsorgung verbrauchten Materials ......................................................... 3-15
Verwendbares Papier .............................................................................. 3-15
Handhabung gebundener Booklets ......................................................... 3-16
Technische Daten ..........................................................................................3-17

5
Perfect Binder User’s Guide
Safety Precautions
This section describes the items that should be followed for safe use of this unit. Be sure to read this section
before using the unit.
To use the unit properly and to prevent human injury and damage to properties, the following warning
symbols are used. Read the meaning of the symbols to understand and then read this guide.
Examples of symbols
Warning Symbols
WARNING Indicates that incorrect handling by ignoring this symbol may cause death or
serious human injury.
CAUTION Indicates that incorrect handling by ignoring this symbol may cause human
injury or damage to properties.
The symbol indicates a prohibited action. A specific prohibited action is drawn inside or
next to the symbol. (The figure on the left indicates that disassembly is prohibited.)
The symbol indicates a forced action or an instruction.
A specific instruction is drawn inside the symbol. (The left figure indicates an instruction to
remove the power plug from the electrical outlet.)
■In addition to this unit, printers and optional
devices connected to the printer also have
power plugs.
CAUTION
■Place the unit on a flat or stable surface.
Otherwise, the unit may tilt or collapse and
cause human injury.
■Do not place the unit in a dusty or humid
location. Otherwise, a fire or an electric shock
might occur.
Power Plug Installation Location

6
Perfect Binder User’s Guide
WARNING
■Confirm the specification of the unit's power
source and use the power source with
sufficient margin. Otherwise, a fire or an
electric shock might occur.
■Do not connect another electric product to the
same electrical outlet.
■Connect the power cord to an electrical
socket and use this unit alone. If an
extension cord is absolutely required,
do not use longer than 5m (15ft).
Otherwise, a fire or an electric shock might
occur.
■Do not damage or rebuild the power
cord. Placing a heavy object on the cord
or pulling or forcibly bending the cord
may damage the cord, resulting in a fire or an
electric shock.
■The power cord supplied with this product can
be used only for this unit. Do not use it for
another electric product.
Otherwise, a fire or an electric shock might
occur.
■Do not plug or unplug the power cord if your
hands are wet. Otherwise, an electric shock
might occur.
CAUTION
■Connect the plug securely to the optional
connection outlet on the printer main unit to
avoid a loose connection.
■Do not pull the power cord when unplugging it.
Otherwise, it could become damaged and a fire
or an electric shock might occur. Be sure to
hold on to the plug when unplugging the power
cord.
■If the unit will not be used for a long time, such
as during a holiday, unplug the power cord
from the electrical outlet for safety.
■Remove the power plug from the electrical
socket at least once a year and clean the
prongs of the plug and their surroundings.
Dust collected on these areas can result in fire.
Power Connection

7
Safety Precautions
Perfect Binder User’s Guide
WARNING
■Do not place water containers or metallic
objects on the unit. If water drips inside the
unit or a metallic object drops inside it, a fire or
an electric shock might occur.
■Do not remove the covers. Otherwise,
you might be electrically shocked by
the high-voltage part inside.
■Do not disassemble or rebuild the unit by
yourself. Otherwise, a fire or an electric shock
might occur.
■Do not insert or drop any metallic material or
flammable substances into the unit through
any opening. Otherwise, a fire or an electric
shock might occur.
■If something falls inside the unit,
immediately hold down the [Power] key
on the operation panel, turn off the
operating power, and then turn off the main
power switch. Next, unplug all of the power
cords and contact your dealer or authorized
service representative. Continued use might
result in a fire or an electric shock.
■In the unlikely event that the unit
continues to be used while emitting
excessive heat, smoke, or a foul odor, a
fire or an electric shock might occur.
Immediately hold down the [Power] key on the
operation panel, turn off the operating power,
and then turn off the main power switch. Next,
be sure to unplug all of the power cords and
contact your dealer or authorized service
representative.
CAUTION
■Do not insert your fingers in the areas around
the body sheet stacker or booklet slot.
Failure to do so may cause injury.
■When moving the unit, contact your dealer or
authorized service representative.
Attempting to forcibly move the unit may cause
the unit to collapse and result in injury.
■Perform adequate ventilation during work with
the unit. If you feel sick, immediately move to a
place with fresh air.
■If you feel something unusual, immediately
consult a doctor.
■Around the high temperature caution label
becomes high temperature. Never touch
around the label.
Also, do not keep touching the parts which
become hot for a long time. Failure to comply
may result in a burn.
■Be careful not to stumble over the output tray.
Contact might result in a fall or an injury.
■Do not place objects on the unit. The heat from
the heater inside the unit may deform or
damage the objects.
Handling

8
Perfect Binder User’s Guide
For safety use, the caution label below is adhered to this unit. When operating or maintaining this unit, read
the instructions on the caution labels for safe use. Do not remove or dirty the label. If the label is not stuck on
the unit, turned out or unreadable, contact your dealer or authorized service representative.
■Location of the Caution Label
The locations of the caution labels (warning) are shown below.
■Label Details
The location of the label is high temperature. Body contact may result in burn.
Caution Label
Do not touch this unit with your bare hands immediately after the unit has been stopped.
• When touching the unit, wear the heatproof gloves. When you do not wear the gloves, confirm that the unit has
thoroughly cooled down.

9
Perfect Binder User’s Guide
Before Use
This section describes the precautions that must be
observed before using the unit.
Observe the following precautions.
■Your dealer will help you determine a proper
installation location for the unit upon delivery.
■When moving the unit, contact your service
representative.
■Avoid installing the unit in the following
locations. Otherwise, incorrect operation,
malfunction, or accident might occur.
•Places exposed to direct sunlight or excessive
illumination such as near a window
(If such is unavoidable, install curtains to cover the
window.)
•Places subject to sudden temperature variations
•Places excessively hot and humid or cold and dry
•Places close to fire or heat
•Places directly subject to cold air from air
conditioners or hot air from heaters, as well as
radiant heat
•Places with poor air permeability or ventilation
•Dusty places
•Places subject to excessive vibration
■Install the unit in a place whose levelness is
within the following specified range.
Installation surface level: 2 degrees or less
■Operate the unit under the following
environment conditions.
Temperature range: 15 °C - 30 °C (59 °F - 86 °F)
Humidity range: 40% - 70% RH (non-condensing)
Observe the following precautions.
■Connect the plug securely to the optional
connection outlet on the printer main unit to
avoid a loose connection.
■Install the unit near an electrical outlet.
■When the main power switch of this unit is on,
the power of the unit will turn on and off
together with the power of the printer.
Installation Location
Power Connection

10
Perfect Binder User’s Guide
■Printer and Perfect Binder
Provide sufficient space for the operations, replacing the consumables, and maintenance.
Required Spacing
• As seen from the front
Units: mm (inch)
1,260
(49 5/8") 2
2,495 (98 1/4")
2,755 (108 7/16") 1
• As seen from the side
Units: mm (inch)
1,320 (51 31/32") 3
1,635 (64 3/8")
830 (32 21/32")
100
(3 15/16")

11
Before Use
Perfect Binder User’s Guide
The size varies depending on the optional equipment used.
■Do not turn the main power switch off or unplug the unit during operation.
■Do not open any of the covers during operation.
■Do not move the unit.
■The unit contains precision components and moving parts. Therefore, do not perform operations not
described in the guides.
■Do not place heavy objects on the unit or subject the unit to strong shocks.
■Open and close the covers gently.
■When turning the main power back on after once turning the main power of this unit off, do so after
turning the [Power] key on the printer's operation panel off.
■Avoid keeping the glue sheets and filters in the following places. Store these items in an appropriate
environment.
•Places subject to direct sunlight or excessively illuminated such as next to a window (if such is unavoidable, use a
curtain at the window and store in areas between 5 °C and 35 °C (41 °F - 95 °F))
•Places subject to sudden temperature variations
•Places excessively hot and humid or cold and dry
■Keep the operation environment of the unit and storage temperature of consumable, and check the
manufacturing date to use as soon as possible after purchase.
1
Width
Printer and Perfect Binder 2,755 mm (108 7/16")
Printer, Perfect Binder and Scanner (when using special scanner stand) 2,755 mm (108 7/16")
Printer, Perfect Binder and Face Down Finisher 2,975 mm (117 1/8")
Printer, Perfect Binder and High Capacity Feeder 3,100 mm (122 1/16")
2
Height
Printer and Perfect Binder 1,160 mm (45 21/32")
Printer, Perfect Binder and Scanner (when using special scanner stand) 1,260 mm (49 5/8")
Printer, Perfect Binder and Face Down Finisher 1,345 mm (52 31/32")
3
Depth
Printer and Perfect Binder 1,240 mm (48 13/16")
Printer, Perfect Binder and Scanner (when using special scanner stand) 1,320 mm (51 31/32")
Printer, Perfect Binder and High Capacity Feeder 1,240 mm (48 13/16")
Handling
Consumable Storage and Handling Precautions

12
Perfect Binder User’s Guide
Dispose finished glue sheets (glue sheet core, film)
and filters (secondary filter, primary filter) according
to the regulations in your local community.
For details, contact your dealer or authorized
service representative.
The following paper type and size can be loaded for
the cover sheet.
■Cover sheet type and size
1If the thickness of a booklet (spine) is 20 mm (25/32")
or more, the use of paper that is 105 g/m2(28-lb blnd)
or heavier is recommended.
2The length of the cover will vary depending on the
thickness of the body pages to be bound. When
leaving the surplus part, paper of a length that will not
leave a surplus when the body pages are wrapped
cannot be used.
Disposing of Used
Consumables
Glue Sheet
Part Material
Glue sheet Plastic
Core Paper
Sheet Holder Plastic
Release Liner/Rolling
Core
Plastic/Paper
Filter
Part Material
Secondary filter/
frame
Plastic, active charcoal/
paper
Primary filter Plastic
Usable Paper
Cover Sheet
Item Plain paper, recycled paper
Weight 1Feed tray: 80 g/m2- 104 g/m2(21-lb
bond - 28-lb bond)
Standard tray / cover sheet inserter:
80 g/m2- 210 g/m2(21-lb bond -
56-lb bond)
Texture
Direction
(Paper
Texture)
Short-grained paper (parallel to the
short side)
Paper
Warpage
5 mm (7/32") or less
Cover
Sheet
Size 2
[Regular Size]
Cover sheet (When cutting off the
surplus part):
For A5 binding:
210 mm × 307 mm - 342 mm
(8 1/4" × 12 3/32" - 13 15/32")
For B5 binding:
257 mm × 374 mm - 409 mm
(10 1/8" × 14 23/32" - 16 1/8")
For A4 binding:
297 mm × 430 mm - 465 mm
(11 11/16" × 16 15/16" - 18 5/16")
For Letter-sized binding:
279.4 mm × 441.8 mm - 476.8 mm
(11" × 17 13/32" - 18 25/32")
Cover sheet (When leaving the
surplus part):
For A5 binding:
210 mm × 298.5 mm - 398 mm
(8 1/4" × 11 3/4" - 15 11/16")
For B5 binding:
257 mm × 365.5 mm - 432 mm
(10 1/8" × 14 3/8" - 17")
For A4 binding:
297 mm × 421.5 mm - 460 mm
(11 11/16" × 16 5/8" - 18 1/8")
For Letter-sized binding:
279.4 mm × 433.3 mm - 466 mm
(11" × 17 1/16" - 18 11/32")
• For more information on usable paper, see also
the guides of the ComColor GD Series printer.
OK
Cover
Body page
Cut NG

13
Before Use
Perfect Binder User’s Guide
The following paper type and size can be loaded for
the body pages.
■Body page type and size
1A5-LEF is unavailable
2A5-LEF is 64 g/m2- 128 g/m2(17-lb bond - 34-lb
bond)
3The size of the body pages is the binding size
If a booklet bound with this unit is stored in a place
exposed to direct sunlight, high temperatures, high
humidity, or a tightly sealed environment, the glue
may peel off and body pages may fall out.
Avoid locations exposed to direct sunlight, high
temperatures, and high humidity and store the
booklets in an environment that is not tightly
sealed.
Body Pages
Item Plain paper, recycled paper
Paper
Weight
Feed tray: 52 g/m2- 104 g/m2(14-lb
bond - 28-lb bond) 1
Standard tray / body sheet stacker:
52 g/m2- 128 g/m2(14-lb bond - 34-lb
bond) 2
Texture
Direction
(Paper
Texture)
Long-grained paper (parallel to the
long side)
Paper
Warpage
5 mm (7/32") or less
Size 3[Regular Size]
A5 (210 mm × 148 mm
(8 1/4" × 5 27/32"))
B5 (257 mm × 182 mm
(101/8"×73/16"))
A4 (297 mm × 210 mm
(11 11/16" × 8 1/4"))
Letter (279.4 mm × 215.9 mm
(11" × 8 1/2"))
Thickness
of a booklet
1.5 mm (1/16") - 30 mm (1 3/16")
15 - 500 sheets (15 to 300 sheets
when using plain paper and recycled
paper (85 g/m2(23-lb bond)).
However, the number of sheets that
can be bound will vary depending on
the type of paper.)
Handling of Bound
Booklets
Note regarding the size of the
cover sheet and the body pages
In this document, the size of the cover sheet
and the body pages for binding is expressed in
the form of (width) × (length) mm.
Length
Width

14
Perfect Binder User’s Guide
The original data for the cover may not be used on the printer without the feed tray. When the Perfect Binder
is connected to the printer only with the standard tray, load the printed cover into the cover sheet inserter
before binding.
Usable paper type and size vary depending on the place into which the paper is loaded. For more information,
see "Usable Paper" (p. 12).
Restrictions on the Printer
Printer Standard Tray Feed tray Cover Sheet
Inserter
Binding
size
Model with the feed tray
ComColor GD9630/
GD7330
B5/A5
A4/B5/Letter
A4/B5/A5/
Letter
A4/B5/Letter
Model without the feed
tray
ComColor GD9631
A4/B5/A5/
Letter
Body
Pages
Cover
Cover
Body
Pages
Body
Pages
Cover
Body
Pages
Cover
Body
Pages
Cover
Paper texture
There are two types of paper: long-grained paper and short-grained paper. The paper texture is the fibers'
orientation formed in the paper-forming process, which influences the finishing of the perfect binding.
When a long-grained sheet is used as the cover, the folded (spine) part is
undulated so that the booklet is not neatly binded. Also, the booklet is easily
damaged by opening and closing the booklet repeatedly. When a short-
grained sheet is used as the body page, the booklet is hard to open due to the
paper stiffness. Also, when you open the booklet, the body pages may peel
off from the spine part. Use the short-grained paper for the cover and the
long-grained paper for the body pages so that the paper texture becomes
parallel to the long side of the booklet. Cover (short-grained paper)
Body pages (long-grained paper)
Cover: short-grained paper (recommended) Body pages: long-grained paper (recommended)
The paper fibers are
parallel to the short
side of the paper
The paper fibers are
parallel to the long
side of the paper

15
Perfect Binder User’s Guide
Part Names and Functions
aCover Sheet Inserter
Set cover sheets for manual binding.
bSide Guides
Slide to suit the cover width so that the paper is neatly
aligned.
cEnd Guide
Slide to suit the cover end so that the paper is neatly
aligned.
dCover Sheet Inserter Open Lever
Use to slide the cover sheet inserter.
eBooklet Slot
Bound booklets are output.
fFront Cover
Open this cover to remove jammed paper or when
disposing the cutting trash in the cover sheet dust
box.
gCover Sheet Dust Box
Collects the cover sheet dust (cutting trash).
hBody Sheet Stacker
Load the printed body pages into this part for manual
binding.
iSecondary Filter
Absorbs vaporized matters and odors generated in
the unit when warming up the glue.
jSide Cover
Open this cover to replace the consumables.
kGlue Sheet Cover
Use to hold and supply the glue sheet.
lGlue Sheet
Load the glue sheet used for binding.
mRolling Core
Set the rolling core used to roll up the protect film of
the glue sheet.
nMain Power Switch
When the main power switch is on, the power of the
unit will turn on and off together with the power of the
printer.
oOutput Tray
Booklets are output here.
pEject Button
Press to eject the booklets.

16
Perfect Binder User’s Guide
What You Can Do with the Perfect Binder
You can perform perfect binding with the three following methods:
•Print out both the cover and body pages from original data
•Load the printed cover into the Perfect Binder, and then print out the body page's original data
•Load the printed cover and body pages into the Perfect Binder
Print out both the cover
and body pages from
original data
Print Preparations
Prepare original data of
cover and body pages, or
printouts
Creating Process of
Binding Data
Load the printed cover
into the Perfect Binder,
and then print out the
body page's original
data
Load the printed cover
and body pages into
the Perfect Binder
Preparation
Start the binding data
creating application on
your PC.
Start the binding data
creating application on
your PC.
Set up the manual
binding on the touch
panel.
Cover
Cover
Page 1
Body
page
Cover
Body
page
• It is also possible to cut the excess portion of the cover sheet upon binding. The setting for whether to cut the cover sheet
can be changed with the "Admin Menu". (p. 1-12 "Cover Settings for the Perfect Binder")
• For more information on items for configurations and how to transmit original data, created with other than the Perfect
Binding Software, via a printer driver or a dedicated printer driver compatible with PostScript 3 (if the optional print
controller has been installed), see "Using the Printer Driver" (p. 1-4) or the user's guide of the print controller (ComColor
Express FS 2000C).

17
Perfect Binder User’s Guide
There are two processes for perfect binding:
•Process of creating binding data: Create binding data using the Perfect Binding Software
•Binding process: Bind the printouts using the Perfect Binder
Binding Process
Creating Binding Data
Creating Binding Data
Load original data to set
imposition and edit data.
Load original data to set
imposition and edit data.
Load the printed cover into
the cover sheet inserter in
the Perfect Binder.
Load the printed cover into the cover sheet
inserter in the Perfect Binder.
Load body pages into the body sheet stacker.
Printing and binding the
cover and body pages
Binding the printed body
pages
Binding
Cover
Cover
Page 1
Body
page

18
Perfect Binder User’s Guide
Perfect Binding
This section describes the method, terms, and constructure of this unit.
Perfect binding does not use staples; the binder glues body pages to the cover sheet. A booklet is created by
wrapping the body pages with a single cover sheet on which the front, spine and back covers are printed.
With the Perfect Binder, you can make a booklet directly upon printing the original data with the printer. It is
also possible to make a booklet by loading the unit with a cover sheet and body pages printed in advance.
This section describes the terms of binding used in this guide.
Binding Method
Terms
Terms of the Perfect Binding
Term Description
Binding data Original data with cover data and body page data
Cover data Original data for printing on the cover
Body page data Original data for printing on the body page
Cover 1 Front side of the front cover (outer)
Cover 2 Back side of the front cover (inner)
Cover 3 Back side of the back cover (inner)
Cover 4 Front side of the back cover (outer)
Spine The part that the pages are fastened onto
Thickness of a booklet The main body's thickness (exclude the cover's thickness)
Slip sheet The sheet without printing both sides (in this guide)
AD
E
BC
F
D
CB
E
F
A
• When the binding side is [Right] • When the binding side is [Left]
aCover 1
bCover 2
cCover 3
dCover 4
eSpine
fBody pages
