Rittal CMC III User manual

CMC III Rauchmelder
CMC III smoke alarm
7030.400
Montage-, Installations- und Bedienungsanleitung
Assembly and operating instructions

Preface
EN
2Rittal CMC III smoke alarm
Preface
Dear Customer!
Thank you for choosing a CMC III smoke alarm (hereaf-
ter referred to as "smoke alarm") from Rittal.
We wish you every success.
Yours,
Rittal GmbH & Co. KG
Rittal GmbH & Co. KG
Auf dem Stützelberg
35745 Herborn
Germany
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]
www.rittal.com
www.rittal.de
We are always happy to answer any technical questions
regarding our entire range of products.

Rittal CMC III smoke alarm 3
Contents
EN
Contents
1 Notes on documentation .................. 4
1.1 CE labelling................................................... 4
1.2 Storing the documents.................................. 4
1.3 Symbols used in these operating instructions 4
1.4 Other applicable documents ......................... 4
1.5 Area of validity............................................... 4
2 Safety instructions ............................ 5
2.1 General safety instructions ............................ 5
2.2 Operating and technical staff......................... 5
3 Product description .......................... 6
3.1 Functional description and components........ 6
3.1.1 Function ............................................................... 6
3.1.2 Components ........................................................ 6
3.2 Proper use, foreseeable misuse .................... 6
3.3 Scope of supply............................................ 6
4 Transport and handling .................... 7
4.1 Transport ...................................................... 7
4.2 Unpacking .................................................... 7
5 Installation ........................................ 8
5.1 Safety instructions......................................... 8
5.2 Siting location requirements .......................... 8
5.3 Installation procedure.................................... 8
5.3.1 Notes on assembly ............................................... 8
5.3.2 Installation with the mounting plate provided ........ 8
5.4 Connecting the smoke alarm ........................ 8
6 Operation ....................................... 10
6.1 Activating the smoke alarm ......................... 10
6.2 Operating and display elements .................. 10
6.3 LED displays ............................................... 10
6.3.1 Multi-LED displays .............................................. 10
6.3.2 LED displays on the CAN bus connection ........... 10
6.4 Operation.................................................... 10
6.5 Operating via the CMC III Processing Unit
website ....................................................... 10
6.5.1 Device ................................................................ 10
6.5.2 Smoke ................................................................ 11
7 Storage and disposal ..................... 12
7.1 Storage....................................................... 12
7.2 Disposal...................................................... 12
8 Technical specifications ................. 13
9 Customer service addresses .......... 14

1 Notes on documentation
EN
4Rittal CMC III smoke alarm
1 Notes on documentation
1.1 CE labelling
Rittal GmbH & Co. KG hereby confirms that the CMC III
smoke alarm is compliant with the EC EMC Directive
2004/108/EC. An appropriate declaration of conformity
has been prepared. It can be provided on request.
1.2 Storing the documents
The assembly and operating instructions as well as all
other applicable documents are an integral part of the
product. They must be passed to those persons who
are engaged with the unit and must always be available
and on hand for the operating and maintenance person-
nel.
1.3 Symbols used in these operating in-
structions
The following symbols are used in this documentation:
 This symbol indicates an "action point" and shows that
you should perform an operation or procedure.
1.4 Other applicable documents
– Installation Guide and Short User's Guide
– CMC III Processing Unit/CMC III Processing Unit
Compact assembly and operating instructions
1.5 Area of validity
This guide applies to software version V3.15.00.
This documentation shows the English screenshots.
The descriptions of individual parameters on the
CMC III PU website likewise use English terminology.
Depending on the set language, the displays on the
CMC III PU website may be different (see assembly and
operating instructions for the CMC III processing unit).
Danger!
A hazardous situation in which failure to
comply with the instructions causes
death or severe injury.
Warning!
A hazardous situation which may lead to
death or serious injury if the instructions
are not followed.
Caution!
A hazardous situation which may lead to
(minor) injuries if the instructions are not
followed.
Note:
Identification of situations that can lead to
material damage.

Rittal CMC III smoke alarm 5
2 Safety instructions
EN
2 Safety instructions
2.1 General safety instructions
Please observe the general safety instructions below
when installing and operating the system:
– Use only original Rittal products or products recom-
mended by Rittal in conjunction with the smoke alarm.
– Please do not make any changes to the smoke alarm
that are not described in this user manual or in the as-
sociated assembly and operating instructions.
– The operational safety of the smoke alarm is only war-
ranted in case of use as intended and according to the
rules. The technical specifications and limit values
stated must not be exceeded under any circumstanc-
es. In particular, this applies to the specified ambient
temperature range and IP protection category.
– The smoke alarm housing may only be opened in or-
der to reset it by briefly disconnecting the sensor from
the base.
– Operating the system in direct contact with water, ag-
gressive materials or inflammable gases and vapours
is prohibited.
– Other than these general safety instructions, ensure
you also observe the specific safety instructions when
carrying out the tasks described in the following chap-
ters.
2.2 Operating and technical staff
– The mounting, installation, commissioning, mainte-
nance and repair of this unit must only be performed
by qualified, trained personnel.
– Only properly instructed personnel may work on the
unit while in operation.

3 Product description
EN
6Rittal CMC III smoke alarm
3 Product description
3.1 Functional description and components
3.1.1 Function
The smoke alarm is an optical smoke detector with a
measurement chamber that detects any smoke occur-
ring at the installation site and on the connected CMC III
PU. The smoke alarm has an identifier that allows it to be
detected automatically by the CMC III PU.
3.1.2 Components
The unit consists of a compact plastic housing with ven-
tilation holes.
3.2 Proper use, foreseeable misuse
The CMC III smoke alarm must only be used for detect-
ing smoke in an IT rack and sending an alarm to the con-
nected CMC III PU. It must only be used together with
the CMC III PU. Any other use is not permitted.
The unit is state of the art and built according to recog-
nised safety regulations. Nevertheless, improper use
can pose a threat to the life and limb of the user or third
parties, or result in possible damage to the system and
other property.
Consequently, the unit must only be used properly and
in a technically sound condition! Any malfunctions which
impair safety should be rectified immediately. Follow the
operating instructions!
Proper use also includes the observance of the docu-
mentation provided and compliance with the inspection
and maintenance conditions.
Rittal GmbH & Co. KG is not liable for any damage which
may result from failure to comply with the documenta-
tion provided. The same applies to failure to comply with
the valid documentation for any accessories used.
Inappropriate use may result in danger. Inappropriate
use includes:
– Use of impermissible tools.
– Improper operation.
– Improper rectification of malfunctions.
– Use of accessories not approved by Rittal GmbH &
Co. KG.
3.3 Scope of supply
– CMC III smoke alarm
– Accessories provided (fig. 1)
– Installation Guide and Short User's Guide
Fig. 1: Accessories supplied loose
Note:
In the following text, the designation
"CMC III Processing Unit" refers to both the
"CMC III Processing Unit" and also the
"CMC III Processing Unit Compact". All text
passages which only apply to one of these
two variants are labelled accordingly.

Rittal CMC III smoke alarm 7
4 Transport and handling
EN
4 Transport and handling
4.1 Transport
The unit is delivered in a cardboard box.
4.2 Unpacking
 Remove the packaging materials from the unit.
 Check the unit for any damage that may have oc-
curred during transport.
 Remove the protective film from the unit.
Note:
After unpacking, the packaging materials
must be disposed of in an environmentally
friendly way. They consist of the following
materials:
Polyethylene film (PE film), cardboard.
Note:
Damage and other faults, e.g. incomplete de-
livery, should be reported immediately, in
writing, to the shipping company and to Rittal
GmbH & Co. KG.

5 Installation
EN
8Rittal CMC III smoke alarm
5 Installation
5.1 Safety instructions
 Please observe the valid regulations for installation in
the country in which the smoke alarm is installed and
operated, and the national regulations for accident
prevention. Please also observe any internal company
regulations, such as work, operating and safety regu-
lations.
 The technical specifications and limit values stated
must not be exceeded under any circumstances. In
particular, this applies to the specified ambient tem-
perature range and IP protection category.
 If a higher IP protection category is required for a spe-
cial application, the smoke alarm must be installed in
an appropriate housing or in an appropriate enclosure
with the required IP protection category.
5.2 Siting location requirements
To ensure proper functioning of the unit, the conditions
for the installation site of the unit specified in section 8
"Technical specifications" must be observed.
Electromagnetic interference
– Interfering electrical installations (high frequency)
should be avoided.
5.3 Installation procedure
5.3.1 Notes on assembly
 It is vital to ensure that the smoke alarm is always as-
sembled with the sensor head pointing downwards.
In any other position, there is no guarantee that smoke
will be detected.
 The smoke alarm must also be positioned so that it is
ventilated with an adequate amount of air and the ven-
tilation slots are not covered.
5.3.2 Installation with the mounting plate
provided
The smoke alarm is installed using the mounting plate
provided.
 Release the smoke alarm sensor head from the base.
To do so, hold the base, twist the sensor head, and
pull it off the base in a downward direction.
Fig. 2: Installing the smoke alarm
 Attach the base to the mounting plate using the M4 x
18 screws provided.
 Replace the sensor head onto the base and secure it
by twisting until it locks home.
 Secure the mounting plate to the enclosure frame with
the sensor head pointing downwards using the M6 x
16 screws or clamps.
5.4 Connecting the smoke alarm
The CAN bus connection supplies the smoke alarm with
the necessary operating voltage. There is no need to
connect a separate power supply unit.
Fig. 3: Rear of the smoke alarm
Key
1 CAN bus connection, 24 V
2 CAN bus connection, 24 V

Use a CAN bus connection cable to connect the
smoke alarm to a CAN bus interface on the
CMC III Processing Unit or the neighbouring compo-
nent on the CAN bus (fig. 3, item 1).
The following CAN bus connection cables from the
CMC III accessories range may be used:
– 7030.090 (length 0.5 m)
– 7030.091 (length 1 m)
– 7030.092 (length 1.5 m)
– 7030.093 (length 2 m)
Note:
If the housing of the CMC III smoke alarm is
opened, please be very careful not to touch
the circuit board of the smoke alarm with
your hands, as this may damage the sensor.

Rittal CMC III smoke alarm 9
5 Installation
EN
– 7030.480 (length 3 m)
– 7030.490 (length 4 m)
– 7030.094 (length 5 m)
– 7030.095 (length 10 m)
The smoke alarm software is updated, if necessary, after
connection. The status LED of the smoke alarm glows
blue throughout and also flashes purple during the entire
update process.
In addition, the status LED of the CMC III Processing
Unit flashes white and a corresponding message ap-
pears on the website.
The smoke alarm update is complete when the following
conditions have been fulfilled:
1. The LEDs on the CAN bus connection of the smoke
alarm show green.
2. The multi-LED of the smoke alarm flashes blue and
also green or red, depending on the status of the
smoke alarm.
Further components are connected as a daisy chain.
 If necessary, connect another component (e.g. anoth-
er sensor type) to the second, free CAN bus interface
of the smoke alarm (fig. 3, item 2).
Status change display:
– The two green and the two red CAN bus LEDs on
the CAN bus connection flash.
– The multi-LED of the Processing Unit flashes contin-
ually in the sequence green – yellow – red.
– The multi-LED of the smoke alarm flashes blue con-
tinuously.
– Press the "C" key on the CMC III Processing Unit (an
initial audio signal will sound) and keep it pressed for
approx. 3 seconds until a second audio signal is
heard.
Status change display on the CAN bus LEDs
– Continuous green LEDs: CAN bus status "OK".
– Continuous red LEDs: CAN bus status defective.
Status change display on the multi-LED of the Pro-
cessing Unit
– Continuous green light: All devices connected to the
CAN bus have the status "OK".
– Continuous orange light: At least one device connect-
ed to the CAN bus has the status "Warning".
– Continuous red light: At least one device connected to
the CAN bus has the status "Alarm".
Status change display on the multi-LED of the
smoke alarm
– Continuous blue flashing: Communication via the CAN
bus.
– Green flashing: When the measured value changes, or
at least every 5 seconds.
Note:
No settings can be modified as long as the
update process is running.
Note:
See section 6.3.1 "Multi-LED displays" for a
list of all of the multi-LED displays.

6 Operation
EN
10 Rittal CMC III smoke alarm
6Operation
6.1 Activating the smoke alarm
After connecting the smoke alarm to the CMC III Pro-
cessing Unit using a CAN bus connection cable, the
smoke alarm will activate automatically (see section 5.4
"Connecting the smoke alarm"). Separate activation is
not required.
6.2 Operating and display elements
Fig. 4: Rear of the smoke alarm
Key
1 CAN bus connection, 24 V
2 CAN bus connection, 24 V
6.3 LED displays
A multi-LED for the status display is integrated into the
rear of the smoke alarm.
6.3.1 Multi-LED displays
The status of the smoke alarm can be read on the multi-
LED.
6.3.2 LED displays on the CAN bus connection
A red and a green LED are located on the CAN bus con-
nection. They display the status of the CAN bus.
6.4 Operation
Once the smoke alarm has been tripped, it will need to
be reset. This requires the following actions:
 First, allow the smoke to dissipate completely, to avoid
re-activating the smoke alarm.
 Disconnect the power supply to the sensor head by
releasing it from the base (twist and then pull off down-
wards).
 Wait for at least one second, then push the sensor
head back onto the base and lock it into position by
twisting.
6.5 Operating via the CMC III Processing
Unit website
After logging on to the CMC III Processing Unit, the web
interface for operating the device is displayed.
 First select the "CMCIII-SMK" entry in the navigation
area.
Similar to the CMC III Processing Unit, the Configuration
tab can be used to individually configure the access
rights for the smoke alarm (Device Rights button) and
the alarm messages (Alarm Configuration button).
The Observation tab is used to configure all of the set-
tings for the smoke alarm, such as the time delay for
changing the status message.
In the following sections 6.5.1 "Device" to 6.5.2
"Smoke", only those parameters which you can modify
are described. There are also display values that provide
information.
6.5.1 Device
General settings for the smoke alarm are configured at
the "Device" level.
In addition, parameters that provide detailed information
about the smoke alarm, such as the software and hard-
ware version, are also displayed. You should have such
information available, in particular to permit fast trouble-
shooting of queries with Rittal.
Colour Status
Green When the measured value changes, or at
least every 5 seconds.
Purple A smoke alarm software update is being
carried out.
Blue Communication via the CAN bus.
Red The smoke alarm has "alarm" status.
Tab. 1: Multi-LED flashing codes
Colour Status
Green
(steady light)
Communication via the CAN bus possible.
Red
(flashing)
Transmission error.
Tab. 2: LEDs on the CAN bus connection
Parameter Explanation
Description Specific description of the smoke alarm.
Location Installation location of the smoke alarm.
Tab. 3: Settings at "Device" level

Rittal CMC III smoke alarm 11
6 Operation
EN
6.5.2 Smoke
General settings for the smoke alarm are configured at
the "Smoke" level.
The following parameters are also displayed for the
smoke alarm:
Parameter Explanation
DescName Specific description of the smoke alarm.
Delay Time delay after which the status message
changes.
Tab. 4: Settings at "Smoke" level
Parameter Explanation
Value Currently measured smoke level (0 = no
smoke/OK, 1 = smoke/alarm).
Status Current status of the sensor, taking ac-
count of the time delay.
Tab. 5: Settings at "Smoke" level

7 Storage and disposal
EN
12 Rittal CMC III smoke alarm
7 Storage and disposal
7.1 Storage
If the device is not used for a long period, Rittal recom-
mends that it be disconnected from the mains power
supply and protected from damp and dust.
7.2 Disposal
Since the smoke alarm consists mainly of the "housing"
and "circuit board" parts, the device must be passed on
to the electronic waste recycling system for disposal.

Rittal CMC III smoke alarm 13
8 Technical specifications
EN
8 Technical specifications
Technical specifications CMC III smoke alarm
Model No. 7030.400
Height x diameter (mm) 50 x 100
Operating temperature range +5°C…+45°C
Storage temperature -45°C…+85°C
Operating humidity range 5%...95% relative humidity, non-condensing
Protection category IP 30 to IEC 60 529
Measurement technique Silicon PIN photodiode/GaAs infrared LED
Inputs and outputs CAN bus (RJ 45) 2 x
Operation/signals LED display OK/Alarm/CAN bus status
Tab. 6: Technical specifications

9 Customer service addresses
EN
14 Rittal CMC III smoke alarm
9 Customer service addresses
For technical queries, please contact:
Tel.: [phone]
E-mail: [e-mail]
Homepage: www.rittal.com
For complaints or service requests, please contact:
Tel.: [phone]
E-mail: [email protected]

 Enclosures
 Power Distribution
 Climate Control
 IT Infrastructure
 Software & Services
RITTAL GmbH & Co. KG
Postfach 1662 · D-35726 Herborn
Phone [phone] · Fax [phone]
E-mail: [email protected] · www.rittal.com
02.2015 / ID no. A 051029 00 IT
