RIUKOE ML-WZ007 User manual

7x40W ZOOM
ML-WZ007 LED MOVING HEAD
User Manual
KEEP THIS MANUAL FOR FUTURE NEED

2
INDEX
STATEMENT 2
ACCESSORIES 3
SAFETY INSTRUCTION 3
GENERAL GUIDELINES 4
INSTALLATION 5
TECHNICAL SPECIFICATIN 6
CONTROL SYSTEM 7
HOW TO SET THE UNIT 8
HOW TO CONTROL THE UNIT 10
CLEANING AND MAINTENANCE 15
STATEMENT
The product has well capability and intact packing when leave
factory. All of the user should comply with warning item and manual, any
misuse cause of the damages are not included in our guarantee, and
also cannot be responsible for any malfunction & problem owing to
ignore the manual.

3
ACCESSORIES
These items are packed together with the product:
Name
Quantity
Unit
Remark
DMX CABLE
1
PCS
POWER CABLE
1
PCS
SAFETY INSTRUCTION
Please keep this User Guide forfutureconsultation. If you sell the unit to another
user, be sure that they also receive this instruction booklet.

4
GENERAL GUIDELINES
NEVER OPEN THIS FIXTURE WHILE IN USE!
During the initial operation of this fixture, a light smoke or smell may emit
from the interior of the fixture. This is a normal process and is caused by
excess paint in the interior of the casing burning off from the heat
associated with the lamp and will decrease gradually over time.
This fixture is a professional lighting effect designed for INDOOR / DRY
LOCATIONS ONLY on stage, in nightclubs, theatres, etc.
Please make sure there are NO FLAMMABLE MATERIALS close to the
fixture while operating, to prevent any fire hazard.
The fixture must be installed in a location with adequate ventilation, at least
1.5 feet (.5m) from adjacent surfaces. Be sure no air ventilation slots are
blocked.
DO NOT attempt installation and/or operation without knowledge how to
do so.
DO NOT permit operation by persons who are not qualified to operate this
type of fixture. Most damages are the result of operations by
nonprofessionals. Consistent operational breaks may ensure the fixture will
function properly for many years to come.
DO NOT shake fixture, avoid brute force when installing and/or operating
fixture.
Always install the fixture with an appropriate safety cable. When installing
the fixture in a suspended environment, always use mounting hardware
that is no less than M10 x 25 mm, also be sure the hardware is insert in the
pre-arranged screw holes in the bracket of the fixture.
Use the original packaging and materials to transport the fixture in for
service.
DO NOT TOUCH the housing bare-hand during its operation. Turn OFF
the power and allow approximately 15 minutes for the fixture to cool down
before replacing or serving.

5
INSTALLATION
C A U T I O N S
For added protection, mount the fixture in areas outside walking paths,
seating areas, or in areas were unauthorized personnel might reach the
fixture.
Ambient operating temperature range for this fixture is 5° to 113°F. (-15°
to 45°C) Do not use the fixture under or above this temperature.
Before mounting the fixture to any surface, make sure the installation area
can hold a minimum point load of 10 times the weight of the fixture.
Fixture installation must always be secured with a secondary safety
attachment, such as an appropriate safety cable.
Never stand directly below the device when mounting, removing or
servicing.
The unit should be mounted via its screw holes on the bracket. Always ensure
that the unit is firmly fixed to avoid vibration and slipping while operating. And
make sure that the structure to which you are attaching the unit is secure and is
able to support a weight of 10 times of the unit’s weight. Also always use a
safety cable that can hold 12 times of the weight of the unit when installing the
fixture.
The equipment must be fixed by professionals. And it must be fixed at a place

6
where is out of the touch of people.
DMX-512 control connection:
Connect the provided XLR cable to the female 3-pin XLR output of your controller and the
other side to the male 3-pin XLR input of the moving head. You can chain multiple Moving
head together through serial linking. The cable needed should be two core, screened cable
with XLR input and output connectors. Please refer to the diagram below.
DMX-512 connection with DMX terminator:
For installations where the DMX cable has to run a long distance or is in an electrically noisy
environment, such as in a discotheque, it is recommended to use a DMX terminator. This
helps in preventing corruption of the digital control signal by electrical noise. The DMX
terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which
is then plugged into the output XLR socket of the last fixture in the chain. Please see
illustrations below.
TECHNICAL SPECIFICATIN
DMX channel：12/17ch mode
Control mode：DMX512，master-slave, auto, sound
LCD display screen
Voltage：AC100V-240V，50/60Hz

7
Power Consumption：350W
LED：7X 40W OSRAM RGBW LED
Strobe: 1-25 times/second
PAN: 540°/240° 16bit
Beam angle: 4.5°-45°
Dimmer: 0-100% linear dimming system
N.W：10 Kg
Small，Fast, Functional LED moving head wash zoom.
Please Note: Specifications and improvements in the design of this unit and this manual are subject to change
without any prior written notice
CONTROL SYSTEM
Th e D M X512 is w id ely used in intellig ent ligh ti ng con tr ol, with a DMX 512
controller. Connect several lights together dmx in and dmx out,
3 pin XLR connectors : Pin 1: G ND , Pin 2: Nega tive s ign a l (-), Pin 3: P o s itive s i gna l
(+)

8
HOW TO SET THE UNIT
MAIN FUNCTION
To select any of the given functions, press the MENU button up to where
the required function is showing on the display. Select the function by
pressing the ENTER button and the display will blink. Use the DOWN
and UP buttons to change the mode. Once the required mode has been
selected, press the ENTER button to confirm. To go back to the functions
without any changes, press the MENU button again. Press and hold the
MENU button for one second or wait for one minute to go back to the
main menu.
The main functions are as below:
DmxAddr
001 - 512
Fix Set
Ch Mode
STD/HIS
Run Mode
DMX/Host
Pan Inv
Close/Open
Tilt Inv
Close/Open
Manual
Pan
0 - 255

9
Pan Fine
0 - 255
Tilt
0 - 255
Tilt Fine
0 - 255
.
0 - 255
.
0 - 255
.
0 - 255
Fix Info
TimeInfo
Cur Time
xxxh
Show Time
xxxh
PowerCnt
xxx
SenSor
Pan
OK/NG
Tilt
OK/NG
Zoom
OK/NG
Temp
OK/NG
Fan
OK/NG
TempInfo
Temprat
xxx C
FanSpeed
xxxx RPM
Soft Ver
Panel
Vx.xxx
Motor
Vx.xxx
Home Set
Password
0 - 255
Pan
0 - 255
Tilt
0 - 255
Zoom
0 - 255
Red
0 - 255
Green
0 - 255
Blue
0 - 255
White
0 - 255

10
FixReset
Reset
Cance/Run
Factory
Cance/Run
Display
Language
EN/CH
DispFlip
Open/Close
DispMode
Show/60s
HOW TO CONTROL THE UNIT
1：address code setting
⚫Set dmx address in DMX menu
⚫Set the same address or different according to needs
A001 is default setting，press ENTER into address set，UP/DOWN to
change
code，then ENTER， press Mode/Esc back to main menu.
2：Fix setting
2.1：channel setting
2 optional channel modes，12 ch and 17 ch，to DMX512 signal
2.2：running mode
【Run】running mode，select【Master】mode and【Slave】mode and
sound control
2.3：Pan Inv
【Reverse PAN】Pan info forward and reverse settings，select【OFF]
forward，select【ON】reverse
2.4：Tilt Inv：
【Reverse Tilt 】Tilt info forward and reverse settings，select【OFF]
forward，select【ON】reverse
3：manual control
Manual control each functions on the menu,like Pan/tilt move speed,dimming,

11
strobe.
4.Fix info
Time display，sensor，temp and cur soft version
5.home setting
set the pan, tilt, zoom and R,,G,B,W
6：reset
[RESET]motor reset mode，select【ON】reset，【OFF】not reset
press【ENTER】into【Reset default】，select【default】，press
【ENTER】
press【down】【up】to choose，【ON】reset deault，【OFF】stay cur
setting，press【ENTER】confirm
7：display setting：
language：Chinese/ English
display flip
display mode setting
CHANNEL DESCRIPTION (17 CHANNEL):
CH
FUNCTION
VALUE
DESCRIPTION
1
Pan
0-255
Pan Rotation
2
Pan Fine
0-255
Pan Fine
3
Tilt
0-255
Tilt Rotation
4
Tilt Fine
0-255
Tilt Fine
5
P/T Speed
0-255
P/T Speed
6
Red
0-255
LED OFF - LED ON
7
Green
0-255
LED OFF - LED ON
8
Blue
0-255
LED OFF - LED ON
9
White
0-255
LED OFF - LED ON
10
Dimmer
0-255
NO LIGHT - FULL LIGHT

12
11
Strobe
252 - 255
OPEN
239 - 251
RANDOM FAST STROBE
226 - 238
RANDOM MEDIUM STROBE
213 - 225
RANDOM SLOW STROBE
208 - 212
OPEN
108-207
SLOW PULSATION - FAST PULSATION
104 - 107
OPEN
4-103
SLOW STROBE - FAST STROBE
0 - 3
CLOSED
12
CCT
225-255
2500 K
189-224
3200 K
145-188
4000 K
118-144
5000 K
100-117
5600 K
55-99
6000 K
11-54
7000 K
10
8000 K
0-9
UNUSED RANGE
13
Macro colour
209-255
White
208
Dirty White
207
Alice Blue
191-206
Congo Blue
184-190
Dark Steel Blue
180-183
Deep lavender
179
Lilac Tint
175-178
Daylight Blue
174
Flame Red
172-173
Bastard Amber
168-171
Deep Orange
162-167
Pale Gold
157-161
Apricot
151-156
Bright Blue

13
149-150
Primary Green
147-148
Special lavender
146
Pale Lavender
145
Deep Golden Amber
142-144
Medium Blue
138-141
Bright Pink
136-137
Mauve
134-135
Dark Green
131-133
Leaf Green
129-130
Dark Blue
128
Light Blue
127
Steel Blue
126
Med Blu Green
125
Peacock Blue
123-124
Magenta
121-122
Dark Pink
120
Middle Rose
119
Light Salmon
118
English Rose
117
Light Rose
115-116
Orange
114
Deep Amber
113
Straw
112
Light Amber
110-111
Spring Yellow
100-109
Dark yellow green
89-99
Just Blue
78-88
Sky Blue
68-77
Lavender
62-67
Light Lavender
49-61
Pink Carnation
46-48
Medium Pink

14
45
Light Pink
35-44
Sunrise Red
32-34
Dark Amber
31
Gold Amber
30
Medium Amber
29
Fire
27-28
Surprise Peach
23-26
Straw Tint
20-22
Medium Yellow
19
Black
18
White 5000 K
17
White 3700 K
16
White 7000 K
15
Magenta
14
Yellow
13
Cyan
12
Blue
11
Green
10
Red
0-9
Macro color OFF
14
Zoom
0-255
NARROW BEAM - WIDE BEAM
15
Reset
0-127
UNUSED RANGE
128-255
COMPLETE RESET
16
Control
0-255
Control
17
Effect
0
CLOSED
1-100
Wave
101-200
Dream
201-255
CLOSED
CHANNEL DESCRIPTION (12 CHANNEL):
CH
FUNCTION
VALUE
DESCRIPTION
1
Pan
0-255
Pan

15
2
Pan Fine
0-255
Pan Fine
3
Tilt
0-255
Tilt
4
Tilt Fine
0-255
Tilt Fine
5
P/T Speed
0-255
P/T Speed
6
Hue
0-255
Hue
7
Saturation
0-255
Saturation
8
Intensiyt
0-255
Intensiyt
9
Strobe
0-255
SLOW STROBE - FAST STROBE
10
Zoom
0-255
NARROW BEAM - WIDE BEAM
11
Control
0-255
Control
12
Reset
0-127
UNUSED RANGE
128-255
COMPLETE RESET
CLEANING AND MAINTENANCE
CLEANING
Frequent cleaning is recommended to insure proper function, optimized light
output, and an extended life. The frequency of cleaning depends on the
environment in which the fixture operates: damp, smoky or particularly dirty
environments can cause greater accumulation of dirt on the fixture’s optics.
•Clean the external lens surface at least every 20 days with a soft cloth
to avoid dirt/debris accumulation.
•Never use alcohol, solvents, or ammonia based cleaners.

16
MAINTENANCE
Regular inspections are recommended to insure proper function and extended
life. There are no user serviceable parts inside this fixture, please refer all
other service issues to an authorized service technician. Should you need any
spare parts, please order genuine parts from your local dealer.
Please refer to the following points during routine inspections:
•A detailed electric check by an approved electrical engineer every
three months, to make sure the circuit contacts are in good condition
and prevent overheating.
•Be sure all screws and fasteners are securely tightened at all times.
Lose screws may fall out during normal operation resulting in damage
or injury as larger parts could fall.
•Check for any deformations on the housing, color lenses, rigging
hardware and rigging points (ceiling, suspension, trussing).
Deformations in the housing could allow for dust to enter into the
fixture. Damaged rigging points or unsecured rigging could cause the
fixture to fall and seriously injure a person(s).
•Electric power supply cables must not show any damage, material
fatigue or sediments. Never remove the ground prong from the power
cable.

17
Factroy: No.31 Zhongxing Road Baiyun District Guangzhou,China
[phone]
[e-mail]
www.riukoe.com
Facebook
YouTube
