Service Manual - CD-808MPFM
Service Manual - CD-808MPFM
R
CD-808MPFM

PDF created with FinePrint pdfFactorytrial version http://www.pdffactory.com

Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 1 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2004.12.03
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
IS0-93CE6980-00-00 ISO WITHLINE WIRE A'SSY ISO (25WX4 )
OP0-00936980-00-00 ISO OUT PLUG WITHLINE KIT 1
ISO (25WX4 )
OP0-02440002-01-00 OUT PLUG WITH WITE KIT 1
16P
OS0-02440001-01-00 OUT SOCKET WITH WIRE PCS 0 1
16P
PP0-00000000-IS-00 ISO 16P PCS 0 1
ISO
PW0-10300511-00-01 TWIN WIRE AWG 20 L=5+300+5MM GREEN/ GREEN.BLACK PCS 0 1
PVC
PW0-10300519-00-01 TWIN WIRE AWG 20 L=5+300+5MM WHITE/WHITE.BLACK PCS 0 1
PVC
PW0-10300520-00-01 TWIN WIRE AWG 20 L=5+300+5MM PURPLE/PURPLE.BLACK PCS 0 1
PVC
PW0-10300531-00-01 TWIN WIRE AWG 20 L=5+300+5MM GREY/GREY BLACK PCS 0 1
PVC
PW0-20140606-00-01 PVC WIRE AWG 20 L=5+140+5MM BLUE PCS 0 1
PVC
PW0-20140700-00-00 PVC WIRE AWG 18 L=5+140+5MM BLACK PCS 0 1
PVC
PW0-20140704-00-00 PVC WIRE AWG 18 L=5+140+5MM YELLOW PCS 0 1
PVC
PW0-20300502-00-00 PVC WIRE AWG 20 L=5+300+5MM RED PCS 0 1
PVC
SK0-07031801-00-01 AUDIO SOCKET RCA JACK 180MM WITH WIRE PCS 0 1
RCA
WE0-00000000-00-00 4400RDS 16P 鐵端子 PCS 0 16
WE0-01000000-00-00 ISO OP & OS PCS 0 12
ISO
WE0-02000000-00-00 FUSE VALUE END PCS 0 6
16
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 2 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.10.03
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
JPW-957300-00-00 MC&T MCU VFD,FM
FC0-20309002-00-00 RIBBON WIRE AWG 28 3P L=3+90+3MM COLOUR PCS 1
PW0-40080000-00-00 75 OHM SINGLE SHIELD WIRE D=3.0 L=5+80+5MM BLACK PCS 1

75
PW0-40140608-00-00 SINGLE SHIELD WIRE D=1.8 L=3+140+3MM GREY PCS 1 FM OSC
3
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 3 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.10.03
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
MPA-957300-00-00 MC&T VFD MC&T FM
AS0-00000000-02-01 ANT SOCKET DUAL HOLE PCS 1
FB0-00734804-01-00 FIBRE SHEET 20X40MM PCS 1
FB0-00801050-02-00 FIBRE SHEET 15X18X0.5MM PCS 1
FB0-92CE3010-01-00 FIBER 150X33X0.5MM PCS 1
FB0-95CE3010-00-00 FIBER 173X148.5X0.5MM PCS 1
MP0-00000410-28-00 REAR BRACKET PLATE PCS 1
MP0-00733000-58-00 FUSE CLIP 5MM PCS 2
B
MP0-00733000-58-01 CLIP FOR FUSE 6MM PCS 2
A
MP0-00882000-09-00 SHORT BRACKET PCS 1
MP0-00882000-80-00 BRACKET-LOCK"L" PCS 1
MP0-00928000-27-00 KEY PCS 2
MP0-00928300-29-00 COVER BOX "A" PCS 1
EL A
MP0-00928300-30-00 COVER BOX "B" PCS 1
EL B
MP0-00958900-04-00 RIGHT CABINET PCS 1
MP0-00958900-44-03 CD BRACKET-03 PCS 1
CD 03
MP0-00958900-44-05 CD BRACKET-05 PCS 1
CD -05
MP0-00958900-82-00 SIDE SPRING PCS 2
MP0-88DV3050-92-00 DOOR COVER PCS 1
MP0-88DV3070-81-00 BRACKET-LOCK"R" PCS 1
MP0-88DV3110-38-00 CLIP FOR OUTPUT WIRES PCS 1 VFD
MP0-95CE3010-05-00 BACK BRACKET PCS 1

MP0-95CE3010-06-00 TOP CABINET PCS 1
MP0-95CE3010-07-00 BOTTOM CABINET PCS 1
MP0-95CE3010-16-00 HEAT SINK PCS 1
MP0-95CE3010-34-00 IC BRACKET PCS 1
IC (TDA7384AIC)
MP0-95CE3010-61-00 REAR DECK BRACKET PCS 1
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 4 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.10.03
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
MPA-957300-00-00 (MC&T ) VFD MC&T FM
MP0-95CE7300-01-00 FRONT CABINET PCS 1
MP0-95CE7300-39-00 BRACKET LCD PCS 1
LCD
MP0-95CE8050-03-00 LEFT CABINET PCS 1
PV0-00923030-00-02 PVC FOR LCD-02 108X23.30MM PCS 1 LCD/BM用
PVC 02
PV0-00923030-00-03 PVC FOR LCD-03 108X23.30MM PCS 0 1 LCD
PVC -03
PV0-00923030-00-04 PVC FOR LCD-04 108X23.30MM PCS 0 1 LCD
PVC -04
:32
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 5 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.10.03
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
OPC-957300-00-00 LCD H(CE7340-A1)+VFD
DR0-88DV3050-00-00 DOOR PCS 1
ER0-00000002-00-00 E RING 2.0MM PCS 2
E RING 2.0MM
HH0-00005012-06-00 SCREW 5.0X12MM HH PCS 1
HN0-00000030-00-00 HEX NUT M3.0 T=2.5MM PCS 1 L7808
MD0-00734000-00-00 MICRO DAMPER PCS 1
MP0-95CE7300-50-00 LOCK SHAFT PCS 1
PL0-00005010-00-00 PLAIN WASHER M5X10 PCS 2

SA0-00000050-00-00 SPRING WASHER D=5.0MM PCS 1
SG0-00440828-05-00 SPONGE FOR CARRY BOX 180X58X5MM PCS 2
SP0-00440491-BA-00 EJECT KNOB SPRING PCS 1
SP0-00440491-BW-00RELEASE KNOB SPRING PCS 1
SP0-00928000-01-00 SPRING-LOCKER PCS 1
SP0-00928800-01-00 SPRING-RELEASE PCS 1
SP0-95CE7300-01-00 LOCK PLATE SPRING PCS 1
SP0-95CE7300-04-00 PRESS SPRING PCS 1
SP0-95CE7300-05-00 SPRING-05 PCS 2
SR0-00001703-02-01 SCREW 1.7X3 KM BLACK PCS 1
SR0-00002003-00-01 SCREW 2X3 PM BLACK PCS 2
SR0-00002004-09-01 SCREW 2X4CM BLACK PCS 1
SR0-00002004-11-00 SCREW 2X4 TTP PCS 4 PCB
SR0-00002005-05-01 SCREW 2X5 PA BLACK PCS 4
SR0-00002006-08-01 SCREW 2X6 KA BLACK PCS 2
SR0-00002008-05-01 SCREW 2X8 PA BLACK PCS 4
SR0-00002603-11-00 SCREW 2.6X3 TTP PCS 2 2
SR0-00002604-02-00 SCREW 2.6X4 KM PCS 2 2
SR0-00002604-11-00 SCREW 2.6X4 TTP PCS 10
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 6 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.10.03
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
OPC-957300-00-00 LCD H(CE7340-A1)+VFD
SR0-00002604-23-00 SCREW 2.6X4 TKM PCS 3
SR0-00003003-26-01 SCREW 3X3 FM BLACK PCS 4
SR0-00003004-11-00 SCREW 3X4 TTP PCS 3
SR0-00003005-26-00 SCREW 3X5 FM PCS 2

SR0-00003008-00-00 SCREW 3X8 PM PCS 3 l7808
SR0-00003016-00-00 SCREW 3X16 PM PCS 2 IC
SR0-00005025-05-00 SCREW 5X25 PA PCS 1
SR1-00001703-02-01 SCREW 1.7X3.5 KM BLACK PCS 4
SU0-00009709-02-00 SPONGE FOR B 10X8X5MM PCS 1
B
SU0-00928800-01-00 REMOTE-SPONG RUBBER 4X7.5MM PCS 1
SU0-00989300-01-02 SPONGE RUBBER B 8.0X4.0X5.0MM BLACK PCS 2
SU0-72KE4900-03-00 SPONGE RUBBER-03 6X1.5MM PCS 2
-3
SU0-95CE7300-01-00 SPONGE RUBBER 116X25X1.5MM PCS 1 VFD
SU0-95CE7300-02-00 SPONGE RUBBER 100X41X1.5MM PCS 1
SU0-95CE7300-03-00 SPONGE RUBBER 7.0X6.0X1.5MM PCS 2
SU0-95CE8050-01-00 SPONGE RUBBER 15X7X6MM PCS 4
ZF0-95CE7300-01-00 FABRIC 150X7X0.3MM PCS 1
43
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 7 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.10.15
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PAK-927300-10-00 PACKING A'SSY
CT0-92CE9620-00-00 CARTON 39X26X32CM 4PCS/CTN PCS 0,25
(B)
GB0-92CE9620-00-00 GIFT BOX 240X90X280MM PCS 1
IB0-00000002-00-10 WARRANTY CARD ROADSTAR PCS 1
IB0-00009114-00-00 INSTRUCTION BOOK 7300CDHRFL1+MP3+ESP+RDS ROADSTA PCS 1
IM0-99000000-00-00 DESICCANT SILICASOL 6克PCS 1
LB0-00000203-00-00 QC PASS LABEL PCS 1
QC
LB0-00000903-00-01 FUSE LABEL 0.5A PCS 1
0.5A
LB0-00002103-00-00 LABEL FOR TOP CABINET PCS 1
LB0-00102703-00-00 LASER LABEL PCS 1

LB0-20000803-00-00 CHASSIS GROUND BATTERY BLACK LABEL PCS 1
2000/3000
LB0-23870803-05-00 LEFT SPEAKER REAR OUTPUT GREEN LABEL PCS 1
LB0-30000803-02-00 DC POWER BATTERY 12V +RED LABEL PCS 1
LB0-30000803-09-00 LEFT CH RCA OUTPUT WHITE LABEL PCS 1
RCA
LB0-30000803-14-00 "RIGHT RCA OUTPUT" RED LABEL PCS 1
RCA
LB0-80000603-01-00 CATION LABLE-01 PCS 1
LB0-80000603-02-00 CATION LABLE-02 PCS 2
LB0-80000603-03-00 CATION LABLE-03 PCS 1
LB0-96000803-04-00 BATTERY B(+) YELLOW LABEL PCS 1
LB0-96000803-06-00 AUTO ANTENNA (B+) BLUE LABEL PCS 1
LB0-96000803-07-00 RIGHT SPEAKER REAR OUTPUT PURPLE LABEL PCS 1
LB0-96000803-08-00 RIGHT SPEAKER FRONT OUTPUT GREY LABEL PCS 1
LB0-96000803-09-00 LEFT SPEAKER FRONT OUTPUT WHITE LABEL PCS 1
PA0-CE962026-86-00 PAPCR CARD TOP CABINET 268X86X60MM KIT 1
PR0-00235085-03-00 PAPER PAD 235X85X3MM PCS 1
PY0-00030090-00-00 POLY BAG 9"X3"X0.05MM PCS 1
PY0-00043100-00-00 POLY BAG 10"X4.3"X0.025MM PCS 2 1PCS
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 8 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.10.15
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PAK-927300-10-00 PACKING A'SSY
PY0-00110120-00-00 POLY BAG 12"X11"X0.05MM PCS 1
27
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 9 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.05.07
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:

PCB-92CE3030-17-01 (MC&T CE3030-A1 )15A
CC0-10474520-00-00 CERAMIC CAP 104P 50V Y5V +80/-20% PCS 2
CH0-01105000-01-00 CHOKE COIL AL1745-102K 1mH +/-10% PCS 1
CH0-14001800-00-00 TRANSFORMER AMC-18A-NDW5 0.5MH PCS 1
CR0-10252000-00-00 RESISTOR 1K OHM 1/2W +/-5% PCS 1
DI0-15401020-00-00 RECTIFIER SILICON FOR 1N5401 PCS 1
EC0-10704020-00-00 100UF 16V+/-20% -40+85 5X11MM I=0.004CV or 0.4 (uA) PCS 1
EC0-47704020-00-00 470UF 16V +/-10% -40+85 (8X14MM)I=0.004CV or 0.4 (uA) PCS 1
FS0-01000050-00-00 FUSE VALUE 0.5A (5X20)MM PCS 1
FS0-01001500-00-00 FUSE VALUE 15A (6X30)MM PCS 1
PB0-00000500-17-21 P.C.B AS-000-21 38X42MM SS HB TH=1.6MM PCS 1
:10
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 10 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2004.03.18
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PCB-92CE7300-16-01 BATTERY BOARD A'SSY VFD
CC0-10474520-00-00 CERAMIC CAP 104P 50V Y5V +80/-20% PCS 2 C1.3
CH0-14000130-01-00 TRANSFORMER EE-13-01 =0.5MM 14.5X13X14MM PCS 1
CR0-15250000-00-00 RESISTOR 1K5 OHM 1/8W +/-5% PCS 1 R5
CR0-22350000-00-00 RESISTOR 22K OHM 1/8W +/-5% PCS 1 R4
CR0-22851000-00-00 RESISTOR 2.2 OHM 1/4W +/-5% PCS 2 R8.9
CR0-27250000-00-00 RESISTOR 2K7 OHM 1/8W +/-5% PCS 1 R3
CR0-33250000-00-00 RESISTOR 3.3K OHM 1/8W +/-5% PCS 1 R2
CR0-33350000-00-00 RESISTOR 33K OHM 1/8W +/-5% PCS 1 R1
CR0-68150000-00-00 RESISTOR 680 OHM 1/8W +/-5% PCS 1 R6
CR0-82851000-00-00 RESISTOR 8.2 OHM 1/4W +/-5% PCS 1 R7
DI0-24148010-00-00 SIGNAL DIODE 1N 4148 DO-35 PCS 3 D1.2.3
DI0-30501010-00-00 ZENER SILICON 5V1 1/2W DO-35 +/-2% PCS 1 ZD1

DI0-30608010-00-00 ZENER SILICON 6V8 1/2W DO-35 +/-2% PCS 1 ZD3
DI0-31200011-00-00 ZENER SILICON 12V 1W DO-41 +/-2% PCS 1 ZD2
EC0-47604020-01-00 47UF 16V +/-20% -40+85 5X11MM I=0.004CV or 0. PCS 1 EC2
EC0-47604050-01-00 47UF 50V +/-20% 6.3X11MM -40+105 PCS 2 EC1.3
MC0-43140050-00-01 POLY CAP 430PF 50V +/-10% NP0 PCS 1 C2
PB0-CE730075-16-G2P.C.B CE7300-G2 37.5X25MM SS.HB TH=1.6MM PCS 1
PW0-60350600-00-00 THREE SHIELD WIRE D=3.0 L=3+350+3MM BLACK PCS 1
TR0-10882426-00-00 TRANSISTOR 2SD882 NPN TO-126 PCS 1
TR0-19014002-00-00 TRANSISTOR C9014C NPN TO-92 PCS 1 Q1
:21
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 11 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2006.01.04
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PCB-92CE7320-25-18 CD MP3+ESP MC&T WXX 8310IC
CC0-10215540-00-00 CHIP CAP 0603 102P NPO 50V +/-5% PCS 1 C194
CC0-10310540-00-00 CHIP CAP 0603 103P 50V X7R +/-10% PCS 10 C203,185,181,211,208,209,223,224,1 49,166
CC0-10410540-00-00 CHIP CAP 0603 104P 25V X7R +/-10% PCS 25 C202,190,189,186,184,139,154,195,1 96,139,178,152,160,177,
CC0-10510540-00-00 CHIP CAP 0603 1UF X7R 16V +/-10% PCS 2 C156,157
CC0-10650110-00-00 TANTALUM CAP 1206 (SIEZE A) 10UF 10V +/-20% PCS 4 C153,155,159,182
CC0-12210540-00-00 CHIP CAP 0603 122P X7R 50V +/-10% PCS 3 C174,173,172
CC0-15015540-00-00 CHIP CAP 0603 15P NPO 50V +/-5% PCS 3 C227,228,226
CC0-15210540-00-00 CHIP CAP 0603 152P 50V X7R +/-10% PCS 2 C151,150
CC0-15310540-00-00 CHIP CAP 0603 153P 50V X7R +/-10% PCS 1 C207
CC0-22210540-00-00 CHIP CAP 0603 222P 50V X7R +/-10% PCS 2 C187,199
CC0-30010540-00-00 CHIP CAP 0603 30P NPO 50V +/-5% PCS 2 C170,171
CC0-30810540-00-00 CHIP CAP 0603 3P NPO 50V +/-5% PCS 1 C201
CC0-33310540-00-00 CHIP CAP 0603 333P 25V X7R +/-10% PCS 1 C191
CC0-39115540-00-00 CHIP CAP 0603 391P NPO 50V +/-5% PCS 1 C188

CC0-47210540-00-00 CHIP CAP 0603 472P 50V X7R +/-10% PCS 1 C200
CC0-47410540-00-00 CHIP CAP 0603 474P 25V X7R +/-10% PCS 2 C68,148
CC0-50810540-00-00 CHIP CAP 0603 5P NPO 50V +/-5% PCS 1 C198
CC0-68310540-00-00 CHIP CAP 0603 683P 25V X7R +/-10% PCS 1 C183
CF0-11693401-00-01 X-TAL 16.9344MHZ 2LEG (立式) PCS 1 XT3
CH0-09100000-01-00 CHIP INDUCTANCE 0805 10UH+\-10% PCS 6 L4,5,9,10,6,3
CR0-10050410-00-00 CHIP RESISTOR 0603 10 OHM 1/10W 50V +/-5% PCS 3 R260.195.202
CR0-10250410-00-00 CHIP RESISTOR 0603 1K OHM 1/10W 50V +/-5% PCS 18 R179,307,235,164,180,192,191,194,1 89,188,187,234,181-185,292
CR0-10350410-00-00 CHIP RESISTOR 0603 10K OHM 1/10W 50V +/-5% PCS 8 R245,246,230,258,289,308,301,290
CR0-10450410-00-00 CHIP RESISTOR 0603 100K OHM 1/10W 50V +/-5% PCS 6 R255,271,232,233.238.253(R238, PP 330K)
CR0-10550410-00-00 CHIP RESISTOR 0603 1M OHM 1/10W 50V +/-5% PCS 2 R228,236
CR0-12250410-00-00 CHIP RESISTOR 0603 1.2K OHM 1/10W 50V +/-5% PCS 4 R240,237,242,244
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 12 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2006.01.04
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PCB-92CE7320-25-18 CD MP3+ESP MC&T WXX 8310IC
CR0-12450410-00-00 CHIP RESISTOR 0603 120K OHM 1/10W 50V +/-5% PCS 2 R250,254
CR0-15350410-00-00 CHIP RESISTOR 0603 15K OHM 1/10W 50V +/-5% PCS 1 R249
CR0-18350410-00-00 CHIP RESISTOR 0603 18K OHM 1/10W 50V +/-5% PCS 1 R291
CR0-22250410-00-00 CHIP RESISTOR 0603 2K2 OHM 1/10W 50V +/-5% PCS 13 R216,299,208,209,306,302-305,298,1 74,300,241
CR0-22350410-00-00 CHIP RESISTOR 0603 22K OHM 1/10W 50V +/-5% PCS 4 R229,214,173,168
CR0-22450410-00-00 CHIP RESISTOR 0603 220K OHM 1/10W 50V +/-5% PCS 2 R252,215
CR0-27450410-00-00 CHIP RESISTOR 0603 270K OHM 1/10W 50V +/-5% PCS 2 R262,266
CR0-30350410-00-00 CHIP RESISTOR 0603 30K OHM 1/10W 50V +/-5% PCS 1 R251
CR0-33150410-00-00 CHIP RESISTOR 0603 330 OHM 1/10W 50V +/-5% PCS 2 R162,165
CR0-39350410-00-00 CHIP RESISTOR 0603 39K OHM 1/10W 50V +/-5% PCS 1 R145
CR0-47350410-00-00 CHIP RESISTOR 0603 47K OHM 1/10W 50V +/-5% PCS 4 R256,248,169,170

CR0-47450410-00-00 CHIP RESISTOR 0603 470K OHM 1/10W 50V +/-5% PCS 2 R284.285
CR0-56250410-00-00 CHIP RESISTOR 0603 5K6 OHM 1/10W 50V +/-5% PCS 3 R231,288,259
CR0-68350410-00-00 CHIP RESISTOR 0603 68K OHM 1/10W 50V +/-5% PCS 4 R263,264,265,267
CR0-82050410-00-00 CHIP RESISTOR 0603 82 OHM 1/10W 50V +/-5% PCS 1 R1
CR0-82350410-00-00 CHIP RESISTOR 0603 82K OHM 1/10W 50V +/-5% PCS 1 R247
DI0-24148081-00-00 SIGNAL DIODE 1N4148 (0805) SMD PCS 5 D27,28,49-51
DI0-80023000-00-00 DIODE-IR EMITTING 4X4MM ST-23G PCS 2 LD1,2
(CD)
DK0-30200002-00-00 CD DECK (C20PICK UP) (WXX) PCS 1
CD
EC0-10709011-00-00 100UF 10V +/-20% -40+85 5X8MM I=0.004CV or 0.4( uA) PCS 4 C134,161,140,137
EC0-10709022-00-00 100UF 16V +/-10% 6.3X5MM -40+85 PCS 2 C143,145,
EC0-22704009-00-00 220UF 6.3V +/-10% 6X5MM -40+85 PCS 2 C179,204
EC0-47504051-00-00 4U7 50V +/-10% 4X7MM -40+85 PCS 1 C197
(4X7MM)
EC0-47604011-00-00 47UF 10V +/-20% 4X7MM -40+85 I=0.004CV or 0.4ua PCS 3 C205,175,210
(4X7MM)
IC0-11117000-00-00 IC AMS1117-3.3 SOT-223 3PIN PCS 1 IC16
IC0-11117000-00-03 IC AMS1117-1.2V SOT-223 3PIN PCS 1 IC19
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 13 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2006.01.04
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PCB-92CE7320-25-18 CD MP3+ESP MC&T WXX 8310IC
IC0-34001000-00-00 IC IP4001D SOP-28 PCS 1 IC13
IC0-38310300-00-00 IC S5L8310X 100-TQFP-1414 PCS 1 IC18
IC0-91922700-00-00 IC S1L9226 TQFP48 PCS 1 IC2
IC0-97117300-00-00 SDRAM CM71V17403CT6 3V TSOP-24 PCS 1 IC15
(16M)
PB0-CE303074-25-M1PCB CE3030ESP+MP3-M1 112X95.5MM FR4.HB TH=1.2MM PCS 1
SK0-02040020-00-02 D TYPE CONNECTOR WAFER 4PIN PH=2.0MM PCS 1 CN6
SK0-03140800-00-01 D YTPE CONNECTOR FEMALE PH=2.00MM 14P L=80+3MM PCS 2
SK0-15170001-00-00 CONNECT SOCKET 17P PH=1.0MM PCS 1 CN1

SW0-10001110-00-00 SWITCH-TACT (CHECK S/W SW-111) PCS 1 SW2
TR0-61015806-00-00 CHIP TRANSISTOR HMBT1015 SOT-23 PNP (M6) PCS 4 Q40,41,42,36
TR0-61815824-00-00 CHIP TRANSISTOR HMBT1815 SOT-23 NPN (L6) PCS 2 Q28,29
:63
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 14 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.10.15
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PCB-937300-07-01 FRONT PCB A'SSY VFD MC&T
CC0-10115500-00-00 CHIP CAP 0805 =0.8MM 101P NPO 50V +/-5% PCS 2 (C4.5 )
CC0-10415500-00-00 CHIP CAP 0805 =1.25MM 104P X7R 50V +/-10% PCS 2 C2.3
CR0-00051210-00-00 CHIP RESISTOR 0805 0 Ω1/8W 100V +/-5% PCS 3 R47.48
CR0-10050210-00-00 CHIP RESISTOR 0805 10 Ω1/8W 100V +/-5% PCS 1 R45
CR0-10250210-00-00 CHIP RESISTOR 0805 1K OHM 1/8W 100V +/-5% PCS 11 R1-5.13.24.31.36.38.32
CR0-15250210-00-00 CHIP RESISTOR 0805 1K5 OHM 1/8W 100V +/-5% PCS 2 R14.23
CR0-18150210-00-00 CHIP RESISTOR 0805 180 OHM 1/8W 100V +/-5% PCS 2 R29.8
CR0-22150210-00-00 CHIP RESISTOR 0805 220 OHM 1/8W 100V +/- 5% PCS 2 R9.28
CR0-22250210-00-00 CHIP RESISTOR 0805 2K2 OHM 1/8W 100V +/-5% PCS 2 R15.22
CR0-33150210-00-00 CHIP RESISTOR 0805 330 OHM 1/8W 100V +/-5% PCS 2 R10.27
CR0-33250210-00-00 CHIP RESISTOR 0805 3K3 OHM 1/8W 100V +/-5% PCS 2 R16.21
CR0-47150210-00-00 CHIP RESISTOR 0805 470 OHM 1/8W 100V +/-5% PCS 2 R11.26
CR0-47250210-00-00 CHIP RESISTOR 0805 4K7 OHM 1/8W 100V +/-5% PCS 3 R17.20.30
CR0-68150210-00-00 CHIP RESISTOR 0805 680 OHM 1/8W 100V +/-5% PCS 5 R12.25.33-35
CR0-68350210-00-00 CHIP RESISTOR 0805 68K OHM 1/8W 100V +/-5% PCS 1 R6
CR0-82250210-00-00 CHIP RESISTOR 0805 8K2 OHM 1/8W 100V +/-5% PCS 1 R19
DI0-24148080-00-00 SIGNAL DIODE 1N4148 (1206) SMD PCS 5 D1-5
FC0-41806041-01-00 FILEXABLE WIRE 18P 60MM PITH=1MM PCS 1
IC0-36318700-00-00 IC PT6318 QFP 52PIN PCS 1

LE0-56120620-00-00 CHIP LED (RED) 0805 SMD PCS 9 D8.10.12-17.19
LE0-70080560-00-00 CHIP ULTRA (BLUE) 0805 SMD PCS 4 D6.7.11.18
PB0-CE730074-07-D1 P.C.B CE7300-D1 164X41MM SS HB TH=1.2MM PCS 1
(VFD)
PB0-CE730074-20-K1 P.C.B CE7300-K1 34X16.5MM SS HB TH=1.2MM PCS 1
SK0-13180000-00-00 18PIN CONNECTOR MALE HFS1800/1831 2.0MM PCS 1
8603
SK0-14180000-00-01 18PIN CONNECTOR FEMALE HSF1800/1831 PCS 1
SW0-10020500-00-00 TACT SWITCH 2PIN 5MM PCS 17
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 15 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.10.15
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PCB-937300-07-01 FRONT PCB A'SSY VFD MC&T用
SW0-10040250-00-00 TACT SWITCH 4PIN 2.5MM SMD PM1157 PCS 1
VF0-1CE73000-00-00 VACUUM FLUORESCENT 29X118.2MM L=8.5MM 49PIN PCS 1
7300 VFD
VR0-80008700-00-00 ENCODER VOLUME L=8.7MM PCS 1
(5000 )
:29
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 16 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2006.02.07
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PCB-95CE8150-01-20(MC&T MP3+ESP+RDS H FM VFD
CC0-10110540-00-00 CHIP CAP 0603 100P NPO 50V +/-5% PCS 3 C82.118.130(C118.130RDS )
CC0-10215540-00-00 CHIP CAP 0603 102P NPO 50V +/-5% PCS 9 C57,58,168,8,5,15,18,71,139
CC0-10310540-00-00 CHIP CAP 0603 103P 50V X7R +/-10% PCS 8 C116,146,145,170,133,184,152,109
CC0-10410540-00-00 CHIP CAP 0603 104P 25V X7R +/-10% PCS 43 C117,172,166,56,165,75,150,188,94,7 7,74,93,4,80,76,135,181,1
CC0-10510540-00-00 CHIP CAP 0603 1UF X7R 16V +/-10% PCS 31 C67,69,83,64,84,65,110,113,137,79,4 7,88,112,90,46,81,23,10,1
CC0-15015540-00-00 CHIP CAP 0603 15P NPO 50V +/-5% PCS 1 C78
CC0-15310540-00-00 CHIP CAP 0603 153P 50V X7R +/-10% PCS 2 C140,141
CC0-22015540-00-00 CHIP CAP 0603 22P NPO 50V +/-5% PCS 2 C121.122 RDS

CC0-22210540-00-00 CHIP CAP 0603 222P 50V X7R +/-10% PCS 2 C44,45
CC0-22310540-00-00 CHIP CAP 0603 223P X7R 50V +/-10% PCS 7 C61,62,63,73,173,59,60
CC0-30010540-00-00 CHIP CAP 0603 30P NPO 50V +/-5% PCS 2 C111,114
CC0-47410540-00-00 CHIP CAP 0603 474P 25V X7R +/-10% PCS 1 C147
CC0-56110540-00-00 CHIP CAP 0603 560P X7R 50V +/-10% PCS 3 C68.174.120(C174.120RDS )
CC0-56210540-00-00 CHIP CAP 0603 562P X7R 50V +/-10% PCS 2 C143,144
CF0-14332301-00-00 CRYSTAL 4.332MHZ 2LEG HC-49/US PCS 1 XT2
CF0-19000300-00-00 CRYSTAL 49-S 9.0MHZ 2LEG 20PF PCS 1 XT1
CF0-41070400-02-01 CERAMIC FILTER 10.7MJ 3LEG PCS 2 CF1,2
CR0-00050410-00-00 CHIP RESISTOR 0603 0 OHM 1/10W 50V +/-5% PCS 8 R227,143,234,210,223(R223RDS )FMQ30E 1.245.242VFD
CR0-00051510-00-00 CHIP RESISTOR 1206 0 OHM 1/4W 200V +/-5% PCS 8 R149,221,236,237,225,222,142,L2
CR0-10051000-00-00 RESISTOR 10 OHM 1/4W +/-5% PCS 1 R155
CR0-10150410-00-00 CHIP RESISTOR 0603 100 OHM 1/10W 50V +/-5% PCS 5 R67,109,178,160,190
CR0-10250000-00-00 RESISTOR 1K OHM 1/8W +/-5% PCS 9 R238,217-220,162,235.140.141(R140. 141RDS )
CR0-10250410-00-00 CHIP RESISTOR 0603 1K OHM 1/10W 50V +/-5% PCS 15 R102,167,89,204,66,75,185,154,58,57 ,74,146,213,91,96
CR0-10250510-00-00 CHIP RESISTOR 1206 1K OHM 1/4W 200V +/-5% PCS 1 R186
CR0-10350000-00-00 RESISTOR 10K OHM 1/8W +/-5% PCS 5 R95,157,230,1,211
CR0-10350410-00-00 CHIP RESISTOR 0603 10K OHM 1/10W 50V +/-5% PCS 16 R164,226,275,277,60,110,72,86,83,9, 14-17,139.77
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 17 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2006.02.07
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PCB-95CE8150-01-20(MC&T MP3+ESP+RDS H FM VFD
CR0-10450410-00-00 CHIP RESISTOR 0603 100K OHM 1/10W 50V +/-5% PCS 5 R163,138,175,229.215
CR0-10450510-00-00 CHIP RESISTOR 1206 100K OHM 1/4W 200V +/-5% PCS 1 R94
CR0-10550000-00-00 RESISTOR 1M OHM 1/8W +/-5% PCS 1 R6
CR0-10550410-00-00 CHIP RESISTOR 0603 1M OHM 1/10W 50V +/-5% PCS 2 R7,62
CR0-12350000-00-00 RESISTOR 12K OHM 1/8W +/-5% PCS 1 R13(R13-TA8264IC)

CR0-12350410-00-00 CHIP RESISTOR 0603 12K OHM 1/10W 50V +/-5% PCS 6 R165,273,276,(R2,3,12-TA8264IC)
CR0-15250410-00-00 CHIP RESISTOR 0603 1K5 OHM 1/10W 50V +/-5% PCS 2 R92,93
CR0-15350410-00-00 CHIP RESISTOR 0603 15K OHM 1/10W 50V +/-5% PCS 3 R168,145,97,
CR0-22150410-00-00 CHIP RESISTOR 0603 220 OHM 1/10W 50V +/-5% PCS 1 R8
CR0-22250000-00-00 RESISTOR 2K2 OHM 1/8W +/-5% PCS 1 R87
CR0-22250410-00-00 CHIP RESISTOR 0603 2K2 OHM 1/10W 50V +/-5% PCS 3 R99,184,181
CR0-22350000-00-00 RESISTOR 22K OHM 1/8W +/-5% PCS 1 R81
CR0-22350410-00-00 CHIP RESISTOR 0603 22K OHM 1/10W 50V +/-5% PCS 14 R65,80,79,147,148,174,25,30,20,27,3 5,29,28,26
CR0-22450410-00-00 CHIP RESISTOR 0603 220K OHM 1/10W 50V +/-5% PCS 3 R100,101,61
CR0-33050410-00-00 CHIP RESISTOR 0603 33 OHM 1/10W 50V +/-5% PCS 3 R161,64,84
CR0-33150410-00-00 CHIP RESISTOR 0603 330 OHM 1/10W 50V +/-5% PCS 3 R70,73,76
CR0-33250410-00-00 CHIP RESISTOR 0603 3K3 OHM 1/10W 50V +/-5% PCS 5 R176,177,169,170,159
CR0-33852000-00-00 RESISTOR 3.3 OHM 1/2W +/-5% PCS 2 R54,90
CR0-47050000-00-00 RESISTOR 47 OHM 1/8W +/-5% PCS 1 R88
CR0-47050410-00-00 CHIP RESISTOR 0603 47 0HM 1/10W 50V +/-5% PCS 1 R133
CR0-47150000-00-00 RESISTOR 470 OHM 1/8W +/-5% PCS 2 R183,(R152 RDS )
CR0-47150410-00-00 CHIP RESISTOR 0603 470 OHM 1/10W 50V +/-5% PCS 1 R182
CR0-47250000-00-00 RESISTOR 4K7 OHM 1/8W +/-5% PCS 2 R228,214
CR0-47250410-00-00 CHIP RESISTOR 0603 4K7 OHM 1/10W 50V +/-5% PCS 5 R85,151,153,82,71
CR0-47350000-00-00 RESISTOR 47K OHM 1/8W +/-5% PCS 2 R268,269
CR0-47350410-00-00 CHIP RESISTOR 0603 47K OHM 1/10W 50V +/-5% PCS 15 R68,69,179,106,144,78,172,281,212,2 2,33,32,23,173,240
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 18 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2006.02.07
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PCB-95CE8150-01-20(MC&T MP3+ESP+RDS H FM VFD
CR0-47450000-00-00 RESISTOR 470K OHM 1/8W +/-5% PCS 1 R166
CR0-47550410-00-00 CHIP RESESTOR 0603 4M7 OHM 1/10W 50V +/-5% PCS 1 R180

CR0-47852000-00-00 RESISTOR 4.7 OHM 1/2W +/-5% PCS 1 R244(R244VFD )
CR0-56250410-00-00 CHIP RESISTOR 0603 5K6 OHM 1/10W 50V +/-5% PCS 10 R274,278,21,34,31,24,(R4,5,10,11-TA 8264IC)
CR0-56450410-00-00 CHIP RESESTOR 0603 560K OHM 1/10W 50V +/-5% PCS 2 R98,158
CR0-68250410-00-00 CHIP RESISTOR 0603 6K8 OHM 1/10W 50V +/-5% PCS 2 R55,56
CR0-68350410-00-00 CHIP RESISTOR 0603 68K OHM 1/10W 50V +/-5% PCS 1 R103
CR0-82250410-00-00 CHIP RESISTOR 0603 8K2 OHM 1/10W 50V +/-5% PCS 3 R18,19,59
CR0-82350410-00-00 CHIP RESISTOR 0603 82K OHM 1/10W 50V +/-5% PCS 1 R239
DI0-14001020-00-00 RECTIFIER SILICON FOR 1N4001 PCS 1 D2
DI0-24148010-00-00 SIGNAL DIODE 1N 4148 DO-35 PCS 3 D6,18.15(D15VFD )
DI0-24148080-00-00 SIGNAL DIODE 1N4148 (1206) SMD PCS 20 D4,5,21,22,16,17,7,19+11.ARZA2(AR ZA2 FM )
DI0-30501010-00-00 ZENER SILICON 5V1 1/2W DO-35 +/-2% PCS 1 D48
DI0-30602010-00-00 ZENER SILICON 6V2 1/2W DO-35 +/-2% PCS 1 D3
DI0-31005010-00-00 ZENER SILICON 10V 1/2W DO-35 +/-2% PCS 1 D8
EC0-10504051-00-00 1UF 50V +/-20% 4X7MM -40+85 PCS 1 C115
(4X7MM)
EC0-10604031-00-00 10UF 25V +/-20% 4X7MM -40+85 PCS 3 C20,97,66
(4X7MM)
EC0-10704020-00-00 100UF 16V+/-20% -40+85 5X11MM I=0.004CV or 0.4 (uA) PCS 2 C70,129
EC0-10709011-00-00 100UF 10V +/-20% -40+85 5X8MM I=0.004CV or 0.4( uA) PCS 15 C95,24,27,26,43,29,52,53,54,171,131, 72,151.124.142(C124RDS)
EC0-22504051-00-00 2.2UF 50V +/-20% 4X7MM -40+85 PCS 1 C19
(4X7MM)
EC0-22604031-00-00 22UF 25V +/-20% -40+854X7MM I=0.004CV or 0.4(uA) PCS 4 C126,1,3,33
EC0-22704010-00-00 220UF 10V +/-20% -40+85 6.3X11MM I=0.004CV or 0.4(uA) PCS 1 C134
EC0-33509051-00-00 3.3UF 50V +/-10% -40+85 4X7MM I=0.004CV or 0.4 (uA) PCS 1 C136
EC0-33809020-00-00 3300UF 16V +/-20% -40+85 13X20MM I=0.004CV or 0.4 (uA) PCS 1 C2
EC0-47604011-00-00 47UF 10V +/-20% 4X7MM -40+85 I=0.004CV or 0.4ua PCS 1 C91
(4X7MM)
FS0-01000050-00-01 FUSE VALUE 0.5A (6X30)MM PCS 1
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 19 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2006.02.07
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location

Assembly Code:
PCB-95CE8150-01-20(MC&T MP3+ESP+RDS H FM VFD
IC0-17805500-00-00 IC 78L05J TO-92 3PIN PCS 1 U8
IC0-17808801-00-00 IC KA78M08 ZIP 3PIN PCS 1 U9
IC0-30831701-02-00 IC AUTO_831RC 100PIN QFP(CPU) GREEN PCS 1 U6
(CD+ESP+MP3+RDS) 8310IC
IC0-31140800-00-00 IC LA1140 SIP16 PCS 1 U11
IC0-31923300-00-00 IC BU1923F SOP16 PCS 1 U7
IC0-32313300-00-00 IC PT2313 SOP 28PIN PCS 1 U1
IC0-33370200-00-00 IC LA3370 SIP16 = DBL1085 PCS 1 U12
IC0-34558300-00-00 IC YM4558M SO-8PIN PCS 2 U3,5
IC0-37032500-00-00 IC RESET KIA-7032P TO-92 PCS 1 U10
IC0-38264800-00-00 IC TA8264AH HZIP25-P-1.00F PCS 1 U2
IF0-13070703-08-00 IFT 0308 7X7MM FM-DET BLUE PCS 1
LE0-12035420-00-00 LED ROUND 3MM (RED) LEG.L=30MM PCS 1 D23
LP0-51440300-00-00 PIOLT LAMP 3X7MM 14V 40MA @3MM PCS 1
PB0-CE734005-01-A1 P.C.B CE7340-A1 173X148.2MM SS HB TH=1.6MM PCS 1
(MC&T) H
SK0-02140020-00-02 D TYPE CONNECTOR MALE 14P NONE WIRE PH=2.0MM PCS 2 CON6,7
SK0-15180000-00-01 CONNECT SOCKET 1.0C-NPBX(S) 18P PH=1.0MM PCS 1 CON5
18P
SW0-10040501-01-00 TACT SWITCH 4P L=5MM PCS 1 SW2
TR0-10435000-00-00 TRANSISTOR BD435 NPN TO-126ML PCS 1 Q16
TR0-20772000-00-00 TRANSISTOR KSB772-Y PNP TO-126ML PCS 2 Q18,31
TR0-61015806-00-00 CHIP TRANSISTOR HMBT1015 SOT-23 PNP (M6) PCS 3 Q10,33,36
TR0-61815824-00-00 CHIP TRANSISTOR HMBT1815 SOT-23 NPN (L6) PCS 16 Q6,8,12,13,14,32,35,34,17,19,11,3,1,4 ,2,5
TR0-69018006-00-00 CHIP TRANSISTOR ZX9018 SOT-23 NPN PCS 2 Q7,9
TU0-20002050-00-00 FM TUNER EWG-205V PCS 1
VR0-11030520-00-00 SEMI RESISTOR B10K 3LEG D=5MM PCS 1 VR3
VR0-15020820-00-00 SEMI RESISTOR B5K 3LEG D=5MM PCS 1 VR4
VR0-15030520-00-00 VARIABLE RESISTOR 50KB 3LEG D=5MM F065-B503 PCS 2 VR1,2
Autosound Electronic(H.K.) Ltd

Product Assembly Listing
Print Date: 2006.02.10 Page 20 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2006.02.07
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) 06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PCB-95CE8150-01-20(MC&T MP3+ESP+RDS H FM VFD
: 104
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 21 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.10.03
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PPA-957300-20-00 PLASTIC PARTS A'SSY (RDS+MP3+ESP)+VFD
PP0-00732380-YH-00 FUSE SLEEVE PCS 1
PP0-00733000-AH-00 TRANSFORMER BOX PCS 1
PP0-00923020-BA-01 EJ-KNOB-01 PCS 1
PP0-00928000-CR-00 TRIM-OUT PCS 1
PP0-00928000-PY-00 GEAR-B PCS 1
PP0-00928000-PZ-00 GEAR-A PCS 1
PP0-00928300-YW-00PLASTIC WIRE CLIP A PCS 1
PP0-00928300-YW-01PLASTIC WIRE CLIP C PCS 1
PP0-00928300-YX-00 PLASTIC WIRE CLIP B PCS 1
PP0-00928300-YX-01 PLASTIC WIRE CLIP D PCS 1
PP0-88DV3050-AL-00 MIDDLE UP PMMA PCS 1
PP0-88DV3080-AG-00ANTE-THEFT BOX PCS 1
PP0-95CE7300-01-00 KNOB-01 PCS 0
PP0-95CE7300-01-01 KNOB-01-01 ("SEL") PCS 1
PP0-95CE7300-02-00 KNOB-02 PCS 0
PP0-95CE7300-02-02 KNOB-02-02 ("PTY") PCS 1
PP0-95CE7300-03-00 KNOB-03 PCS 0
PP0-95CE7300-03-01 KNOB-03-01 ("●") PCS 1

PP0-95CE7300-05-00 KNOB-05 PCS 5
PP0-95CE7300-AA-00FRONT CABINET PCS 0
PP0-95CE7300-AA-01FRONT CABINET-01 ("OPEN,REL,MU") PCS 1
PP0-95CE7300-AB-00MIDDLE CABINET PCS 1
PP0-95CE7300-AC-00BOTTOM CABINET PCS 1
PP0-95CE7300-AU-00PLASTIC LOCK PCS 1
PP0-95CE7300-BW-00RELEASE KNOB PCS 1
PP0-95CE7300-CG-00ART.BRACKET PCS 1
Autosound Electronic(H.K.) Ltd
Product Assembly Listing
Print Date: 2006.02.10 Page 22 of 22
Product Number: CE730020-H0IR0F10-01 Date Def.:
2005.10.03
Product Name: CE7300HRFL1+ESP+MP3+RDS+ISO VFD ( .CE7340-A1 MC&T ) 40WX4 FM HIGH (ROADSTAR CD-808MP/FM) :06010096 F
Part Code Name/Description Unit Qty Location
Assembly Code:
PPA-957300-20-00 PLASTIC PARTS A'SSY (RDS+MP3+ESP)+VFD
PP0-95CE7300-DA-00LENS PCS 0 1
PP0-95CE7300-DA-57LENS-57 (CD+ESP+MP3+RDS )PCS 1
PP0-95CE7300-DJ-00 LOCK PLATE A PCS 1
PP0-95CE7300-DK-00LOCK PLATE B PCS 1
PP0-95CE7300-DQ-00PLASTIC BRACKET A PCS 1
PP0-95CE7300-DR-00PLASTIC BRACKET B PCS 1
PP0-95CE7300-KA-00VOLUMEE KNOB PCS 1 1
PP0-95CE7300-PF-00 ART.PRO.SHEET PCS 1
PP0-95CE7300-SW-00OPEN KNOB PCS 1
PP0-95CE7300-YP-00RIGHT CONNECT COVER PCS 1
PP0-96CE7610-CM-00PLASTIC PAT PCS 1
PPS-95CE7300-01-00 CRYSTAL KNOB-01 PCS 0
PPS-95CE7300-01-01 CRYSTAL KNOB-01-01 ("BND") PCS 1
PPS-95CE7300-01-02 CRYSTAL KNOB-01-02 (絲印電源符號) PCS 1
PPS-95CE7300-02-00 CRYSTAL KNOB-02 PCS 0
