Robe ROBIN ParFect 150 TW User manual

1
Version 1.2

2
Table of contents
1. Safety instructions ......................................................................................................... 3
2. Fixture exterior view ...................................................................................................... 5
3. Installation....................................................................................................................... 6
3.1 Connection to the mains ............................................................................................ 6
3.2 Installing barndoors and the gel frame....................................................................... 7
3.3 Installing the eggcrate ................................................................................................ 8
3.4 Installing the di󰀨user 2° (Robin Parfect 150 TW only)................................................ 9
3.5 Rigging the xture .................................................................................................... 10
3.6 DMX-512 connection................................................................................................ 12
3.7. Wireless DMX operation ......................................................................................... 13
4. Control menu map........................................................................................................ 14
5. Control menu (Standard and Easy control mode)..................................................... 16
5.1 Addressing (DMXA).................................................................................................. 16
5.2 Fixture information (Info) .......................................................................................... 17
5.3 Personality (Pers)..................................................................................................... 17
5.4 Manual Control (Manual).......................................................................................... 18
5.5 Test program (Test Prg)............................................................................................ 18
5.6 Stand-alone (St Alone) ............................................................................................. 18
5.7 Special functions (Special)....................................................................................... 19
6. RDM ............................................................................................................................... 20
7. Error and information messages ................................................................................ 20
8. Technical Specications.............................................................................................. 21
9. Maintenance and cleaning........................................................................................... 23
9.1 Replacing the fuse ................................................................................................... 23
9.2 Disposing of the product .......................................................................................... 23
ROBIN ParFect 150 TW
ROBIN ParFect 150 FW TW

3
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE POWERING OR INSTALLING YOUR ROBIN ParFect 150 TW !
Save it for future reference.
This device has left our premises in absolutely perfect condition. In order to maintain this condition and to en-
sure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes
written in this manual.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this ma-
nual or any unauthorized modication to the device.
Please consider that damages caused by manual modications to the device are not subject to warranty.
The ParFect 150 TW was designed for indoor use and it is intended for
professional application only. It is not for household use.
1. Safety instructions
DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT!
Make sure that the available voltage is not higher than stated on the rear panel of the xture.
This xture should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power supplied, consult your authorized distributor or local power company.
Always disconnect the xture from AC power before cleaning, removing or installing any part of the xture.
The power plug has to be accessible after installing the xture. Do not overload wall outlets and extension cords
as this canresult in re or electric shock.
Do not allow anything to rest on the power cord. Do not locate this xture where the cord may be damaged by
persons walking on it.
Make sure that the power cord is never crimped or damaged by sharp edges. Check the xture and the power
cord from time to time.
Refer servicing to qualied service personnel.
This xture falls under protection class I. Therefore this xture has to be connected to
a mains socket outlet with a protective earthing connection.
Do not connect this xture to a dimmer pack.
Warning!
Do not stare at exposed lamp in operation. May be harmful to the eyes.
Avoid looking directly into the light source
LED light emission. Do not view the light output with optical instruments or
any device that may conncentrate the beam.
If the xture has been exposed to drastic temperature uctuation (e.g. after transportation), do not switch it on
immediately. The arising condensation water might damage your device. Leave the device switched o󰀨 until
it has reached room temperature.

4
Avoid brute force when installing or operating the xture.
This xture was designed for indoor use only, do not expose this unit to rain or use near water.
When choosing the installation spot, please make sure that the xture is not exposed to extreme heat, moisture
or dust.
Do not block the lens array with any object when the xture is under operation.
Openings in housing of the xture should never be covered with cloth or other materials, and never must be
blocked.
This xture should not be placed in a built-in installation unless proper ventilation is provided.
Only operate the xture after having checked that the housing is rmly closed and all screws are tightly fastened.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing the xture.
To avoid damage of an internal optical system of the xture, never let the sunlight (or
other light source) lights directly to the lens array, even when the xture is not working
The xture becomes hot during operation. Allow the xture to cool approximately 15 minutes prior to manipulate
with it.
Operate the xture only after having familiarized with its functions. Do not permit operation by persons not
qualied for operating the xture. Most damages are the result of unprofessional operation!
Please use the original packaging if the xture is to be transported.
Please consider that unauthorized modications on the xture are forbidden due to safety reasons!
If this device will be operated in any way di󰀨erent to the one described in this manual, the product may su󰀨er
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
-circuit, burns, electric shock, crash etc.

5
2. Fixture exterior view
4 - Safety wire securing accessory
frame adaptor to the housing
5 - DMX OUT
6- DMX IN
7 - Fuse holder
8 - Mains IN
9 - Mains OUT
10 - Display and control buttons
11 - Safety wire attachment point
1 - Mounting yoke
2 - Tilt locks
3 - Lenses array
