Robe iSpiider User manual

1
Version 1.7
QR code for user manual

2
Table of contents
1. Safety instructions ......................................................................................................... 3
2. Operating determination................................................................................................ 4
3. Fixture exterior view ...................................................................................................... 5
4. Installation....................................................................................................................... 6
4.1 Connection to the mains ............................................................................................ 6
4.2 Rigging the xture ...................................................................................................... 7
4.3 DMX-512 connection................................................................................................ 10
4.4 Ethernet connection ................................................................................................. 11
4.5 Wireless DMX operation .......................................................................................... 13
5. Checking the IP65 integrity of the xture................................................................... 14
6 . Operating the xture at ambient temperatures below 0°C ....................................... 16
7 . Standby mode............................................................................................................... 17
8. Remotely controllable functions................................................................................. 18
9. Control menu map........................................................................................................ 20
10. Control menu ............................................................................................................. 24
10.1 Tab " Address" ........................................................................................................ 26
10.2 Tab "Information" .................................................................................................... 26
10.3 Tab "Personality" .................................................................................................... 29
10.4 Tab "Manual Control".............................................................................................. 31
10.5 Tab "Stand-alone" .................................................................................................. 31
10.6 Tab "Service" .......................................................................................................... 32
11. RDM.............................................................................................................................. 36
12. NFC .............................................................................................................................. 37
13. Error and information messages .............................................................................. 38
14. Cleaning ...................................................................................................................... 39
15. Maintenance................................................................................................................ 39
15.1 Torques for watertight covers ................................................................................ 41
15.2 Torques of Pan/Tilt motors screws ......................................................................... 45
15.3 Checking and replacing the silica gel desiccants .................................................. 46
16. Robe Ethernet Access Portal (REAP)....................................................................... 50
17. Technical Specications............................................................................................ 58
18. Photometric diagrams................................................................................................ 61
19. Appendix - DMX modes overview ............................................................................. 63
20. ChangeLog ................................................................................................................. 64
Robin iSpiider

3
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOU INITIAL START - UP
This device has left our premises in absolutely perfect condition. In order to maintain this condition and to en-
sure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warnings in
this manual.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this
manual or any unauthorized modication to the device.
Please consider that damages caused by manual modications to the device are not subject to warranty.
The Robin iSpiider was designed for outdoor use and it is intended for
professional application only. It is not for household use.
1. Safety instructions
CAUTION!
Disconnect the xture from mains before removing any cover of the xture.
With a high voltage you can suer a dangerous electric shock when touching
alive wires and electrical parts under covers!
Make sure that the available voltage is not higher than stated on the rear panel of the xture.
This xture should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power supplied, consult your authorized distributor or local power company.
Always disconnect the xture from AC power before cleaning or servicing any part of the xture.
The power plug has to be accessible after installing the xture. Do not overload wall outlets and extension cords
as this can result in re or electric shock.
Do not allow anything to rest on the power cord. Do not locate this xture where the cord may be damaged by
persons walking on it.
Make sure that the power cord is never crimped or damaged by sharp edges. Check the xture and the power
cord from time to time.
Refer servicing to qualied service personnel.
This xture falls under protection class I. Therefore this xture has to be connected to
a mains socket outlet with a protective earthing connection.
Do not connect this xture to a dimmer pack.
During the initial start-up some smoke or smell may arise. This is a normal process and does not necessarily
mean that the device is defective.
The housing of the xture becomes hot during its operation.
For replacement use fuse and battery of same type and rating only.
LED light emission. Risk of eye injury. Do not look into the beam at short distance of
the of the product. Do not view the light output with optical instruments or any device
that may concentrate the beam.
The light source contains blue LEDs.

4
2. Operating determination
WARNING! This unit does not contain an ON/OFF switch. Always disconnect the power input cable
from mains to completely remove power from unit when not in use or before cleaning or servicing the unit.
Avoid brute force when installing or operating the device.
Never lift the xture by holding it at the xture head as the mechanics may be damaged. Always hold the xture
at the transport handles.
When choosing the installation spot, please make sure that the device is not exposed to extreme heat or dust.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing the xture.
Always secure the xture with an appropriate safety wire.
Only operate the xture after having checked that the housing is rmly closed and all screws are tightly fastened.
Do not block the front cover glass with any object when the xture is under operation.
The xture becomes very hot during operation. Allow the xture to cool approximately 20 minutes prior to ma-
nipulate with it.
To avoid damage of an internal optical system of the xture, never let the sunlight (or
other light source) lights directly to the lens array, even when the xture is not working
Operate the device only after having familiarized with its functions. Do not permit operation by persons not
qualied for operating the device.
The xture housing never must be covered with cloth or other materials during its operation. Do not block fans
or fans ventilation slots with any object. Fans and ventilation slots must remain clean.
Please consider that unauthorized modications on the device are forbidden due to safety reasons!
Potential foggy front lens array does not inuence function of the xture and does not
subject to complaint.
Please use only an original ROBE packaging (paper box, loader case or foam shell) for
transporting the device, otherwise potential damage of the device during its transport
will not subject to warranty .
The xture must not come into contact with sea water (salt water).
Damages or corrosion issues resulting from salt water will void
the manufactures warranty and will not be subject to any warranty
claims or repairs.
The product (covers and cables) must not be exposed to a high frequency electromagnetic eld higher than 3V/m.
Immunity of the equipment is designed according to the standard EN 55035 Electromagnetic compatibility of
multimedia equipment - Immunity requirements
Emission of the equipment complies with the standard EN55032 Electromagnetic compatibility of multimedia
equipment – Emission Requirements according to class B.
Contains FCC ID: 2A6PL-DMXRDMRW001
Contains IC: 29573-DMXRDMRW001
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,

5
including interference that may cause undesired operation.
Changes or modications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
The [Device] wireless operation is safe and complies to RF Exposure requirements
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
o󰀨 and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit di󰀨erent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.

6
3. Fixture exterior view
The head has to be locked for transportation - the pan lock latch (5) and the tilt lock latch (6) have to be in the
locked positions. To unlock the head, move these latches to unlock positions before operating the xture.
The ENTER/DISPLAY ON button also serves for switching the display on when the xture is disconnected
from the mains.
1- Lens array
2 - Yoke
3- Handle
4- Control panel
5- Pan lock
6- Tilt lock
7- Power (Neutrik TrueOne)
8- Base
9- Cover of fuse holde
10 - Ethernet IN
11 - Ethernet OUT
12- 5-pin DMX IN
13- Gore valve
14- Cover of battery holder
15- 5-pin DMX OUT

7
4. Installation
Fixtures must be installed by a qualied electrician in accordance with all
national and local electrical and construction codes and regulations.
The Robin iSpiider´s panel connectors are dust and water protected according to IP 65
by mating with related cable connectors. They cannot stay disconnected outdoor.
All unused panel connectors have to be sealed by the rubber caps.
Visually check panel connectors on accidental water leaks before connecting related
cable connectors.
If some water will appear in panel connectors, do not connect cable connectors,
especially power!
4.1 Connection to the mains
For protection from electric shock, the xture must be earthed!
The xture has to be connected to an electric outlet which is equipped with
a residual-current device (residual-current circuit breaker)!
The Robin iSpiider is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz AC
power source from 100-240 Volts.
The IP65 rated power cable is enclosed to the xture. If you need to install a power plug on the power cable
to allow connection to power outlets, install a grounding-type (earthed) plug, following the plug manufacturer’s
instructions. If you have any doubts about proper installation, consult a qualied electrician.
The cores in the power cable are coloured according to the following table.
Core (EU) Core (US) Connection Plug Terminal Marking
Brown Black Live L
Light blue White Neutral N
Yellow/Green Green Earth
This device falls under class one and must be earthed (grounded)!
Ensure all connections and the power plug on the cable are properly sealed.
To apply power, rst check that the head pan and tilt locks are released.
The rubber caps have to be placed on unused connectors.

8
4.2 Rigging the xture
A structure intended for installation of the xture (s) must safely hold weight of the xture(s) placed on it. The
structure has to be certicated to the purpose.
The xture (xtures) must be installed in accordance with national and local electrical and construction codes
and regulations.
For overhead installation, the xture must be always secured with a safety wire.
When rigging, derigging or servicing the xture staying in the area below the installation place, on bridges,
under high working places and other endangered areas is forbidden.
Allow the xture to cool for ten minutes before handling.
Fixture should be installed in areas outside walking paths, seating areas, or away from areas were unauthorized
personnel might reach the xture by hand.
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including calculating working
load limits, installation material being used, and periodic safety inspection of all installation material and the
projector. If you lack these qualications, do not attempt the installation yourself, but use a help of professional
companies.
CAUTION: Fixtures may cause severe injuries when crashing down! If you have doubts concerning the safety
of a possible installation, do not install the xture!
The xture has to be installed out of the reach of public.
The xture must never be xed swinging freely on the truss.
Danger of re !
When installing the device, make sure there is no highly inammable
material (decoration articles, etc.) in a distance of min. 0.5 m.
CAUTION!
Use 2 appropriate clamps to rig the xture on the truss.
Follow the instructions mentioned at the bottom of the base.
Make sure that the device is xed properly! Ensure that the
structure (truss) to which you are attaching the xtures is secure.
For securing the xture to the truss, install a safety wire which can hold at least 10 times the weight of the xture.
Truss installation
1.Bolt Clamps (4) to the brackets Omega CL (1) with M12 bolts and lock nuts through the hole in the bracket
Omega CL.
2.Fasten the brackets Omega CL on the bottom of the base by means of the quick-lock fasteners (2) and tighten
them fully clockwise.
3. Install the xture on the truss.
4. Pull a safety wire (3) through the carrying handle and the truss (6) as shown on the picture below in a suitable
position so that the maximum fall of the xture will be 20 cm. Fasten a snap hook in the attachment point (5).
Use only the safety wire with a snap hooks with screw lock gates.
.

9
Available positions of Omega holders:
Allowed installation positions of the iSpiider:
1-Mounting brackets Omega CL
2-Quick-lock fasteners
3-Safety wire
4-Clamps
5-Attachment point
6-Truss

10
Note for open-air installation: if the xture stands on the ground, min. distance of 4" (10cm) between the xture
base and the ground has to be kept.
When installing xtures side-by-side,
avoid illuminating one xture with another!
DANGER TO LIFE!
Before taking into operation for the rst time,the installation has to be approved by
an expert!
In order to protect the internal parts of the head from the sun, the function
PARKING POSITION must be switched ON before switching the xture o.
The PARKING POSITION function is located on the Power/Special functions channel (120-129 DMX). If the
function is on, the xture will automatically detect via G-sensor whether the xture is on the oor or hangs on
the truss or is mounted sideways on the truss and moves the pan and tilt to the position (including movement
of zoom to the front part of the head) in which the head will always face down. Owing this position of the xture
head, there is not chance to burn internal parts of the head by the sun light.

11
4.3 DMX-512 connection
The xture is equipped with 5-pin XLR sockets for DMX input and output.
Only use a shielded twisted-pair cable designed for RS-485 and 5-pin XLR plugs and connectors in order to
connect the controller with the xture or one xture with another.
To keep declared IP rating of the XLR panel connectors, all used XLR connectors and cables have to
meet IP 65 rating.
DMX - output DMX-input
XLR sockets (rear view): XLR plugs (rear view):
Building a serial DMX chain:
Connect the DMX output of the rst xture in the DMX chain with the DMX input of the next xture. Always connect
one output with the input of the next xture until all xtures are connected. Up to 32 xtures can be connected.
Caution: At the last xture, the DMX cable has to be terminated with a terminator. Solder a 120 Ωresistor
between Signal (–) and Signal (+) into 5-pin XLR plug and plug it into DMX output of the last xture.
The Robin iSpiider´s panel connectors are dust and water protected according to IP 65
by mating with related cable connectors. They cannot stay disconnected outdoor.
All unused panel connectors have to be sealed by the rubber caps.
1- Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected
1- Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected

12
4.4 Ethernet connection
To keep declared IP rating of the xture, all used RJ45 and XLR connectors and cables have to meet
IP 65 rating.
The xtures on a data link are connected to the Ethernet with appropriate communication protocol (e.g. ArtNet).
The control software running on your PC (or light console) has to support Art-Net protocol.
Art-Net communication protocol is a 10 Base T Ethernet protocol based on the TCP/IP.Its purpose is to allow
transfer of large amounts of DMX 512 data over a wide area using standard network technology.
IP address is the Internet protocol address.The IP uniquely identies any node (xture) on a network.
The Universe is a single DMX 512 frame of 512 channels.
The Robin iSpiider is equipped with two 8-pin RJ- 45 socket for Ethernet input.Use a network cable category 5
(with four “twisted” wire pairs) and standard RJ-45 plugs in order to connect the xture to the network.
RJ-45 socket (front view): RJ-45 plug (front view):
1- TD+ 5- Not connected
2- TD- 6- RX-
3- RX+ 7- Not connected
4- Not connected 8- Not connected
Patch cables that connect xtures to the hubs or LAN sockets are wired 1:1,that is,pins with the same numbers
are connected together:
1-1 2-2 3-3 4-4 5-5 6-6 7-7 8-8
If only the xture and the computer are to be interconnected,no hubs or other active components are needed.A
cross-cable has to be used:
1-3 2-6 3-1 4-8 5-7 6-2 7-5 8-4
If the xture is connected with active Ethernet socket (e.g. switch) the network icon will appear at the
bottom right corner of the screen:
Ethernet operation
Connect the xtures to the Ethernet network.
Option “Artnet (gMaI, gMA2 or sACN)" has to be selected from “Ethernet Mode” menu on the xture.
Set IP address (002.xxx.xxx.xxx / 010.xxx.xxx.xxx) and the Universe.
(DMX address=197) (DMX address=50) (DMX address=1)
IP addres=002.168.002.004 IP addres=002.168.002.003 IP addres=002.168.002.002
Universe=1 Universe=1 Universe=1
An advised PC setting: IP address: 002.xxx.xxx.xxx / 010.xxx.xxx.xxx (Di󰀨erent from xture IP addresses)
NET mask: 255.0.0.0
The iSpiider is equipped with Ethernet Pass Through Switch which sustains Ethernet integrity, when the xture
has no power, it automatically maintains network connectivity.
If you use the Ethernet IN-OUT way for the Ethernet connection, max. 8 xtures can be connected in
the IN-OUT line

13
Ethernet / DMX operation
Option “ Artnet" (gMaI or gMA2 or sACN) has to be selected from “Ethernet Mode” menu at rst xture.
Option “Ethernet To DMX” has to be selected from the menu “Ethernet Mode” at the rst xture (connected to
the Ethernet) in the xture chain, next xtures have standard DMX setting.
Connect the Ethernet-input of the rst xture in the data chain with the network. Connect the DMX output of
this xture with the input of the next xture until all xtures are connected to the DMX chain.
Caution: At the last xture, the DMX chain has to be terminated with a terminator. Solder a 120 Ωresistor
between Signal (–) and Signal (+) into a XLR-plug and connect it in the DMX-output of the last xture.
DMX address=197 DMX address=50 DMX address=1
IP addres=002.168.002.002
Universe=0
DMX address=197 DMX address=50 DMX address=1
IPaddres=002.168.002.003
Universe=1

14
4.5 Wireless DMX operation
The integrated wireless DMX/RDM module allows receiving wireless DMX. The ROBE wireless DMX/RDM
module has full support for wireless communication protocols at entertainment market. Modul is based on well
known LumenRadio RF technology, with implemented wire interface for connection with Robe products. RF
output for MCX interface antenna as standard output
The item " Wireless " from the menu "DMX Input" allows you to activate receiving of wireless DMX (Person-
ality--> DMX Input -->Wireless.). First two options from the "DMX Input" menu are stated in DMX chart as well
(channel Power/Special functions , range of 10-19 DMX). If DMX input option is changed by DMX command,
the change is permanently written into xture´s memory.
DMX range of 10-19 switching xture to the wired/wireless operation is active only during rst 10 sec-
onds after switching the xture on.
After switching the xture on, the xture checks both modes of receiving DMX in the following order:
1. For the rst ve seconds, the xture receives DMX signal from the wired input. If the Power/Special functions
channel is set at some DMX input option, the xture will receive DMX value according to this option. If DMX input
option is set to the wired input , this option is saved and checking procedure is nished. If DMX input option is
not set, the xture continues next 5 seconds in scanning wireless DMX signal-see point 2.
2. For the next 5 seconds the xture receives wireless DMX signal and again detects if the Power/Special
functions channel is set at some DMX input option, if not, the xture will take option which is set in the xture
menu "DMX Input".
To link the xture with DMX transmitter.
The xture can be only linked with the transmitter by running the link procedure at DMX transmitter .
After linking , the level of DMX signal ( 0-100 %) is displayed in the menu item “Wireless State“ (Information
-->Wireless State).
To unlink the xture from DMX transmitter.
The xture can be unlinked from receiver via the menu item “ Unlink Wireless Adapter“ (Information--> Wireless
State --> Unlink Wireless Adapter).
Note: If the option "Wireless In/XLR Out" is selected (Personality--> DMX Input -->Wireless In/XLR Out), the
xture receives wireless DMX and sends the signal to its wired DMX output. The xture behaves as " Wireless/
Wired" adaptor.
Example:

15
5. Checking the IP65 integrity of the xture.
The Robin iSpiider is IP65 rated lighting xture which has been designed to be protected against the ingress
of dust and pressure water jets from any direction.
1. Smart pressure test - for this test serves the function "Pressure Test" in the tab Service. Unique testing
procedure allows you easy testing of the IP65 integrity of the xture. You do not need any external device con-
nected to the xture for running the test.
The xture has to be connected to mains (must not be in Standby mode) and a head temperature (at pressure
sensor) cannot be higher than 55°C. The pressure test takes about 5 minutes and can be run at earliest 10
minutes after closing light output of the xture. The pressure test can be repeated at earliest 2 minutes after
last pressure test.
The function "Pressure Test" should be run after the following actions:
- unscrewing/screwing back any watertight cover
- checking/replacing dessicants in small boxes in xture base and head
- replacing d esiccant in tube in the xture head ( tube with silica gel)
- replacing pan or tilt motor
The pressure test can be also run by DMX command (channel Power/Special function) or from web interface
REAP (Robe Ethernet Access Portal). During the pressure test xture does not respond to DMX commands
(except DMX value 9 on the channel Power/Special functions).
Examples of screens (front panel display) of the smart pressure test:
Fixture waits for 10 minutes period elapsing (inside of the xture is too hot)
Fixture waits for 2 minutes period elapsing (pressure test was repeated too early)
Setting fans
Test in progress
Legend:
07:44 ......Remaining Time (minutes) to nish of pressure test.
45°C.........Temperature at pressure sensor.
delta 2.56 hPa...Pressure di󰀨erence.
The pressure di󰀨erence has to be >7 hPa for successful test.

16
Test passed
Test failed
If the rst pressure test failed an the second is OK, the xture complies with IP65 integrity.
If the pressure test twice fails despite checking of correct tightening of the cover screws and gaskets under covers,
the xture has to be tested by means of "Enhanced pressure test". For this type of pressure test is needed the
Pressure IP Testing Set ROBE (P/N 10980659). Please ask your ROBE distributor for help.
The message "Valve Seal Error" means that valve or coil in the valve is defective or there is a connection
problem.
Check the connection between the valve and head, especially cable connector. Other reason can be faulty coil
in the valve or faulty valve.
Valve
Cable connector

17
The message "Not Available At The Moment" means that the xture is not connected to mains.
2. Enhanced pressure test - a special equipment Pressure IP Testing Set ROBE (P/N 10980659) is intended
for this kind of pressure test. Only trained technician should handle the equipment.
If this equipment is used for pressure test of the xture, the following values of pressure have to be kept:
Underpressure test.
300 mbar for 1 minute, pressure fall can be to 5 mbar maximally.
Overpressure test
150 mbar maximally!
6 . Operating the xture at ambient temperatures below 0°C
Design of the iSpiider allows its operation at ambient temperature up to -30°C, but you have to take some
specic into account before operating the xture.
1.Fixture is not in Standby mode.
Ambient temperatures from 0°C to -10°C.
The xture can be switched o󰀨 but after powered it on, xture reset can be delayed in range of 0 - 30 minutes
depending on ambient temperature (max. delay is at low ambient temperature).This delay is caused by heating
xture e󰀨ects on operating temperature. The xture does not respond to DMX during heating the xture on
operating temperature.
We recommend to switch the xture on at least 30 minutes before show.
Ambient temperatures from -11°C to -30°C.
The xture should be permanently powered on in order to keep operating temperature of xture´s e󰀨ects.
If the xture is switched o󰀨, reset of the xture will last long time (up to 1 hour depending on ambient
temperature) until xture e󰀨ects reach their operating temperature. The xture does not respond to DMX during
heating the xture on operating temperature.
2.Fixture is in Standby mode.
If the xture is switched to Standby mode (xture has to be connected to mains), the xture keeps internal
temperature on a level suitable for operation of xture´s e󰀨ects without delay, heating up of the xture inside
is done automatically.
Pressure IP Testing Set ROBE
in case:

18
7 . Standby mode
The xture can be switched to Standby mode by means of web interface REAP or DMX command (channel
Power/Special functions, DMX values 6).
Standby mode can be cancelled by means of web interface REAP, DMX command (channel Power/Special
functions, DMX values 7) or by switching the xture o󰀨 and on.
Standby mode helps conserve power when a xture is not in use, without fully powering it o󰀨. The max. power
consumption of the xture in Standby mode does not exceed 20 W ( if the xture is heated, power consumption
is higher). Standby mode is indicated by a notice on the xture display.
In the Standby mode, the xture display is functional and can be used for setting of the xture, but all motors
and fans are deactivated, light output is closed.
As the xture motors are deactivated, the xture does not respond to DMX values controlling e󰀨ects but the
channel Power /Special functions can be used for xture settings.
The xture in Standby mode provides information for RDM and REAP and also can be set its behaviour by
means of the RDM and REAP.
Main benets of Standby mode:
- there is not time delay of xture reset at ambient temperatures below 0°C.
- By means of REAP user has current information about xture (settings, temperatures, state of d esiccant in
the xture head).

19
8. Remotely controllable functions
Virtual colour wheel
This wheel contains 66 preset colours, rainbow e󰀨ect in both directions is available.
Colour temperarature correction (CTC)
This channel allows to set calibrated white colour from range of 8000K-2700K.
RGBW or CMY colour mixing system
The RGBW colour mixing system is based on red, green, blue and white high power LEDs. Option for switching
the xture to the CMY colour mixing system is available.
Colour Mix control
The Colour Mix control channel denes relation between global colours (RGBW, CTO, Virtual colour wheel)
and individual RGB pixels or Kling-Net.
Global = Global Colours (RGBW, CTO, Virtual Color Wheel)
Pixel = Pixel Colors (RGB individual pixels or Kling-Net)
DMX value Function
0-9 Global colours (Global has priority)
10-19 Maximum mode (highest values have priority)
20-29 Minimum mode (lowest values have priority)
30-39 Multiply mode (multiply Global and Pixel)
40-49 Addition mode (Global + Pixel) - default
50-59 Subtraction mode (Global – Pixel)
60-69 Inverted Subtraction mode (Pixel – Global)
70-79 Coloured background
80-127 Reserved
128 Global colours (Global has priority)
129-254 Crossfade (crossfade between Global and Pixel)
255 Pixel colours (Pixel has priority)
E.g. If you wish to control RGBW channels, set the Colour Mix Control channel to 0 DMX, if you
need to use pixel e󰀨ects, set the Colour Mix Control channel to 255 DMX.
Flower E󰀨ect
The ower e󰀨ect rotating in both directions allows to create many dynamic e󰀨ects.
Zoom
Motorized zoom o󰀨ers beam range of 4° to 50°.
Pixel control and pixel e󰀨ects
19 RGB pixels allow you to create many e󰀨ects or use 90 pre-dened pixel e󰀨ects
Pixel order:
Dimmer/Shutter unit
Smooth 0 - 100 % dimming is provided by the electronic control unit. This unit is also used for strobe e󰀨ects
with variable speed.

20
Pan/Tilt
Precise pan/tilt movement due to built-in electronic motion stabilizer. The electronic motion stabilizer ensures
precise position of the xture´s head during its movement and reduces its swinging when the truss shakes.
Pan movement range: 540°,tilt movement range: 220°.
