Robin Actor 6 ST User manual

1
Version1.2

2
Table of contents
1. Safety instructions ......................................................................................................... 3
2. Fixture exterior view ...................................................................................................... 5
3. Installation....................................................................................................................... 6
3.1 Connection to the mains ............................................................................................ 6
3.2 Installing the top hat and barndoors........................................................................... 7
3.3 Rigging the xture ...................................................................................................... 9
3.4 DMX-512 connection................................................................................................ 11
4. Control menu map........................................................................................................ 12
5. Robin Actor 6 ST - DMX chart ..................................................................................... 14
5.1 Virtual colour wheel - colour mixing chart ................................................................ 18
5.2 LED zone order ........................................................................................................ 22
6. Control menu ............................................................................................................... 23
6.1 Addressing (DMXA) ................................................................................................. 23
6.2 Zoom (Zoom) ........................................................................................................... 23
6.3 Virtual colour wheel (Vir C) ...................................................................................... 23
6.4 Dimmer (Dimm)........................................................................................................ 23
6.5 Fixture information (Info) .......................................................................................... 23
6.6 Personality (Pers)..................................................................................................... 24
6.7 Manual Control (Manual).......................................................................................... 24
6.8 Test program (Test Prg)........................................................................................... 25
6.9 Stand-alone (St Alone)............................................................................................. 25
6.10 Reset...................................................................................................................... 25
6.11 Special functions (Special)..................................................................................... 25
7. RDM ............................................................................................................................... 27
8. Wireless DMX operation .............................................................................................. 27
9. Error and information messages ................................................................................ 28
10. Technical Specications............................................................................................ 28
11. Maintenance and cleaning......................................................................................... 30
11.1 Replacing fuse ....................................................................................................... 31
12. ChangeLog.................................................................................................................. 32
13. Photometric diagrams................................................................................................ 32
Robin Actor 6 ST

3
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE POWERING OR INSTALLING YOUR ROBIN Actor 6 ST !
Save it for future reference.
This device has left our premises in absolutely perfect condition. In order to maintain this condition and to
ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning
notes written in this manual.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this
manual or any unauthorized modication to the device.
Please consider that damages caused by manual modications to the device are not subject to warranty.
The Robin Actor 6 ST was designed for indoor use and it is intended for
professional application only. It is not for household use.
1. Safety instructions
DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS
UNIT!
Make sure that the available voltage is not higher than stated on the xture.
This xture should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power supplied, consult your authorized distributor or local power company.
Always disconnect the xture from AC power before cleaning, removing or installing the fuses, or any part.
The power plug has to be accessible after installing the xture. Do not overload wall outlets and extension cords
as this canresult in re or electric shock.
Do not allow anything to rest on the power cord. Do not locate this xture where the cord may be damaged by
persons walking on it.
Make sure that the power cord is never crimped or damaged by sharp edges. Check the xture and the power
cord from time to time.
Refer servicing to qualied service personnel.
This xture falls under protection class I. Therefore this xture has to be connected to
a mains socket outlet with a protective earthing connection.
Do not connect this xture to a dimmer pack.
LED light emission. Risk of eye injury. Do not look into the beam at a distance of less
than 2 meters from the front surface of the product. Do not view the light output with
optical instruments or any device that may conncentrate the beam
If the xture has been exposed to drastic temperature uctuation (e.g. after transportation), do not switch it on
immediately. The arising condensation water might damage your device. Leave the device switched off until
it has reached room temperature.
Do not shake the xture. Avoid brute force when installing or operating the xture.
This xture was designed for indoor use only, do not expose this unit to rain or use near water.
When choosing the installation spot, please make sure that the xture is not exposed to extreme heat, moisture

4
or dust.
Air vents and slots in the xture´s head and base are provided for ventilation, to ensure reliable operation of
the device and to protect it from overheating.
Do not block the LEDs array with any object when the xture is under operation.
The openings should never be covered with cloth or other materials, and never must be blocked.
This xture should not be placed in a built-in installation unless proper ventilation is provided.
Only operate the xture after having checked that the housing is rmly closed and all screws are tightly faste-
ned.
Always use a secondary safety cable when mounting this xture.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing the xtu-
re.
Do not block the front objective LEDs with any object when the xture is under operation.
The xture becomes very hot during operation. Allow the xture to cool approximately 20 minutes prior to
manipulate with it.
Operate the xture only after having familiarized with its functions. Do not permit operation by persons not
qualied for operating the xture. Most damages are the result of unprofessional operation!
Please use the original packaging if the xture is to be transported.
Please consider that unauthorized modications on the xture are forbidden due to safety reasons!
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, crash etc.

5
2. Fixture exterior view
5 - Apertures for safety chain
6 - DMX out
7- DMX in
8 - PowerCon socket
9 - Fuse holder
10 - Apertures for quick-turn
fasteners
1- Moving head
2 - Tilt lock
3 - Control buttons
4- Display

6
3. Installation
Fixtures must be installed by a Qualied electrician in accordance with all
national and local electrical and construction codes and regulation.
3.1 Connection to the mains
For protection from electric shock, the xture must be earthed!
The Robin Actor 6 ST is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz
AC power source from 100-240 Volts.
Install a suitable plug on the power cord, note that the cores in the power cord are coloured according to the
following table. The earth has to be connected!
If you have any doubts about proper installation, consult a qualied electrician.
Core (EU) Core (US) Connection Plug Terminal Marking
Brown Black Live L
Light blue White Neutral N
Yellow/Green Green Earth
This device falls under class one and must be earthed (grounded)!

7
3.2 Installing the top hat and barndoors
Switch off the xture before top hat or barndoors installation
To install the top hat
1.Unscrew the four fastening screws (3) which securing flange (4) to the head (5) and install new flange. Keep
its right position- the cutouts (A) in the flange must look towards the arms.
Original flange New flange
2.Place the top hat (1) on the head (5), press locks (2) and turn the top hat counter-clockwise until it snap into
slots (B) in the flange.

8
To install the barndoors
1. Unscrew the four fastening screws (2) which securing ange (1) to the head and screw the new ange (3).
Keep its right position- the cutouts (A) in the ange have to look towards the xture arms.
2. Put the barndoors holder (4) on the head in this way that pins (D) have to be in slots (B) in the ange (3) , press
locks (5) and turn the top hat counter-clockwise until it snap into slots (B) in the ange and release locks (5).
3. Insert the barndoors (8) into the second slot in the barndoors holder (4) and secure it by means of the lock
(6). The rst slot serves for diffuser (9), which has to be secured by means of the lock (7).
4. On each side of the xture, pull the snap hook (11) on the wire (10) through the aperture (12) to make the
secondary security of installed barndoors. Do not operate xture with unsecured barndoors.
To avoid damage of the xture´s optic system, do not operate the xture with closed
barndoors! No barndoor can cover light output!

9
3.3 Rigging the xture
The overhead installation must always be secured with a secondary safety attachment, e.g. an appropriate
safety rope. This secondary safety attachment must be constructed in a way that no part of the installation can
fall down if the main attachment fails.
When rigging, derigging or servicing the xture staying in the area below the installation place, on bridges,
under high working places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and machine-technical installations are approved by an expert
before taking into operation for the rst time and after changes before taking into operation another time.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert after every four year in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are approved by a skilled
person once a year.
The xture should be installed outside areas where persons may walk by or be seated.
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including (but not limited to)
calculating working load limits, installation material being used, and periodic safety inspection of all installation
material and the projector. If you lack these qualications, do not attempt the installation yourself, but instead
use a professional structural rigger. Improper installation can result in bodily injury or damage to property.
The xture has to be installed out of the reach of people.
If the xture shall be lowered from the ceiling or high joists, professional trussing systems have to be used. The
xture must never be xed swinging freely in the room.
Caution: Fixture may cause severe injuries when crashing down! If you have doubts concerning the safety of
a possible installation, do not install the moving head!
Before rigging make sure that the installation area can hold a minimum point load of 10 times the xture’s
weight.
When installing the device, make sure there is no highly inammable
material (decoration articles, etc.) in a distance of min. 0.4 m.
CAUTION!
Use an appropriate clamp to rig the xture on the truss.
Follow the instructions mentioned at the bottom of the base.
Make sure that the device is xed properly! Ensure that the
structure (truss) to which you are attaching the xtures is secure.
The xture can be placed directly on the stage oor by means of the removable stand (4) or rigged on a truss
by means of the omega holder (1) and clamp (2) without altering its operation characteristics. Both removable
stand and omega holder can be fastened with two 1/4-turn locks to the bottom of the xture. Adjust xture´s
head to desired position and tighten tilt lock (5) to secure the head position.
.

10
For securing the xture to the truss install a safety wire that can hold at least 10 times the weight of the xture.
Use only a safety wire with screw-on snap-hook. Thread the snap-hook through two apertures in the xture
base and the wire around the truss as shown on the picture below.
1-Safety wire
2-Apertures for safety wire
3-Trust
When installing xtures side-by-side, avoid illuminating one xture with
another!

11
3.4 DMX-512 connection
The xture is equipped with 5-pin XLR sockets for DMX input and output. Only use a shielded twisted-pair
cable designed for RS-485 and 5-pin XLR-plugs and connectors in order to connect the controller with the
xture or one xture with another.
DMX - output DMX-input
XLR mounting-sockets (rear view): XLR mounting-plugs (rear view):
If you are using the standard DMX controllers, you can connect the DMX output of the controller directly with
the DMX input of the rst xture in the DMX-chain. If you wish to connect DMX controllers with other XLR-out-
puts, you need to use adapter cables.
Building a serial DMX-chain:
Connect the DMX-output of the rst xture in the DMX-chain with the DMX-input of the next xture. Always
connect one output with the input of the next xture until all xtures are connected. Up to 32 xtures can be
interconnected.
Caution: At the last xture, the DMX-cable has to be terminated with a terminator. Solder a 120 Ωresistor
between Signal (–) and Signal (+) into a 5-pin XLR-plug and plug it in the DMX-output of the last xture.
1- Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected
1- Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected

12
4. Control menu map
Default settings=Bold print
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Level 7
DMXA Set DMXA 001-255
Zoom
Vir C
Dimm
MENU Info POn Time Total
Reset
DMX In Pover 0-255
:
Dimm F 0-255
Temp Current
Highest
High Res
Sw Ver IC-1
IC-2
IC-3
Pers
DMX Pres Mode 1
:
Mode 6
DMX In Wired
Wireless
Display Turn
On/Off T On, Off
Contrast 0-100%
Backlight 0-100%
C Cal M On, Off
C Mix M RGBW, CMY
Mic Sens 0...10...19
Fans Auto, High
Temp Uni °C, °F
I Ef Pos Pan
:
Dimm F
Store
Defaults
Test Prg
Manual Pres Eff Pover Pos 1-Pos 3
:
Dimmer Pos 1- Pos 5
Manual Pover 0-255
Dimm F 0-255
Sta Alone Music T On, Off
Aut Run Off
Test
Prog 1
Prog 2
Prog 3
Pr Play Test Prg

13
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Level 7
Prog 1
Prog 2
Prog 3
Pr Edit Prog 1 Step 1 Pan
Prog 2 : :
Prog 3 Step 40 F.Tim 0-25.5
S.Tim 0-25.5
COPY
Prg End 1-40
Reset
Special RDM Low
RDM Hight
Wireless Stat
Unlink
Adjust DMX Val Pover 0-255
:
Dimm F 0-255
Calib Red C 0-255
Gren C 0-255
Blue C 0-255
Whit C 0-255
Store
Sw Upd On, Off

14
5. Robin Actor 6 ST - DMX chart
Version 1.0
Mode/Channel Value Function Type of
control
1 2 3 4 5 6
1No function
2No function
3No function
4No function
5No function
1 1 1 1 1 6
0 - 9
10 - 14
15 - 19
20-29
30-39
40-49
50-169
170 - 179
180 - 189
190 - 199
200 - 209
210 - 239
240
241 - 255
Special functions
Reserved
To activate following functions , stop in DMX value for
at least 3sec. and shutter must be closed at least 3sec.
(Shutter channel 30/14/9/4/4/35 must be at range of
0-31DMX). Corresponding menu items are temporily
overrided except DMX Input.
DMX input: Wired DMX *
DMX input: Wireless DMX*
* function is active only10 seconds after switching the xture on
Reserved
RGBW colour mixing mode
CMY colour mixing mode
Reserved
To activate following reset function, stop in DMX value
for at least 3 sec.
Save current DMX values into xture **
Zoom reset
Reserved
Total reset
Reserved
Disable "Silent mode" of fans
"Silent mode of fans":fans noise from min. to max.
step
step
step
step
step
step
step
step
proportional
- 2 2 - - - 0-255
Red/Cyan (8 bit) - all zones
Red or cyan LEDs saturation control (0-100%) proportional
- 3 - - - - 0-255
Red/Cyan ne(16 bit) - all zones
Fine red or cyan LEDs saturation control proportional
- 4 3 - - - 0-255
Green/Magenta (8 bit) - all zones
Green or magenta LEDs saturation control(0-100%) proportional
- 5 - - - - 0-255
Green/Magenta ne (16 bit) - all zones
Fine green or magenta LEDs saturation control proportional
- 6 4 - - - 0-255
Blue/Yellow (8 bit) - all zones
Blue or yellow LEDs saturation control (0-100%) proportional
- 7 - - - - 0-255
Blue/Yellow ne (16 bit) - all zones
Fine blue or yellow LEDs saturation control proportional
- 8 5 - - - 0-255
White (8 bit) - all zones
If RGBW mode is selected:
White colour saturation control coarse (0-100%)
If CMY mode is selected:
No function
proportional
- 9 - - - - 0-255
White ne (16 bit) - all zones
Fine white LEDs saturation control (RGBW mode) proportional
2 - - - 9 7 0-255
Red/Cyan (8 bit) - zone 1
Red or cyan LEDs saturation control (0-100%) proportional
3 - - - 10 8 0-255
Red/Cyan ne (16 bit) - zone 1
Fine red or cyan LEDs saturation control proportional

15
Mode/Channel Value Function Type of
control
1 2 3 4 5 6
4 - - - 11 9 0-255
Green/Magenta (8 bit) - zone 1
Green or magenta LEDs saturation control(0-100%) proportional
5 - - - 12 10 0-255
Green ne (16 bit) - zone 1
Fine green or magenta LEDs saturation control proportional
6 - - - 13 11 0-255
Blue/Yellow (8 bit) zone 1
Blue or yellow LEDs saturation control (0-100%) proportional
7 - - - 14 12 0-255
Blue/Yellow (16 bit) zone 1
Fine blue or yellow LEDs saturation control) proportional
8 - - - 15 13 0-255
White (8 bit) - zone 1
If RGBW mode is selected:
White colour saturation control coarse (0-100%)
If CMY mode is selected:
No function
proportional
9 - - - 16 14 0-255
White (16 bit) - zone 1
Fine white LEDs saturation control (RGBW) proportional
10 - - - 17 15 0-255
Red/Cyan ( 8bit) - zone 2
Red or cyan LEDs saturation control (0-100%) proportional
11 - - - 18 16 0-255
Red/Cyan ne (16 bit) - zone 2
Fine red or cyan LEDs saturation control proportional
12 - - - 19 17 0-255
Green/Magenta (8 bit) - zone 2
Green or magenta LEDs saturation control(0-100%) proportional
13 - - - 20 18 0-255
Green/Magenta ne (16 bit) - zone 2
Fine green or magenta LEDs saturation control proportional
14 - - - 21 19 0-255
Blue/Yellow (8 bit) - zone 2
Blue or yellow LEDs saturation control (0-100%) proportional
15 - - - 22 20 0-255
Blue/Yellow ne (16 bit) - zone 2
Fine blue or yellow LEDs saturation control proportional
16 - - - 23 21 0-255
White (8 bit) - zone 2
If RGBW mode is selected:
White colour saturation control coarse (0-100%)
If CMY mode is selected:
No function)
proportional
17 - - - 24 22 0-255
White (16 bit) - zone 2
Fine white LEDs saturation control (RGBW mode) proportional
18 - - - 25 23 0-255
Red/Cyan (8 bit) - zone 3
Red or cyan LEDs saturation control (0-100%) proportional
19 - - - 26 24 0-255
Red/Cyan ne (16 bit) - zone 3
Fine red or cyan LEDs saturation control proportional
20 - - - 27 25 0-255
Green/Magenta (8 bit) - zone 3
Green or magenta LEDs saturation control(0-100%) proportional
21 - - - 28 26 0-255
Green/Magenta ne (16 bit) - zone 3
Fine green or magenta LEDs saturation control proportional
22 - - - 29 27 0-255
Blue/Yellow (8 bit) zone 3
Blue or yellow LEDs saturation control (0-100%) proportional
23 - - - 30 28 0-255
Blue/Yellow ne (16 bit) zone 3
Fine blueoe yellow LEDs saturation control proportional
24 - - - 31 29 0-255
White (8 bit) zone 3
If RGBW mode is selected:
White colour saturation control coarse (0-100%)
If CMY mode is selected:
No function
proportional
25 - - - 32 30 0-255
White ne (16 bit) zone 3
Fine white LEDs saturation control (RGBW mode) proportional

16
Mode/Channel Value Function Type of
control
1 2 3 4 5 6
26 10 6 - 7 31 0
1-255
CTC
No function
Colour temperature correction from 20000K to
2700K)
step
proportional
27 11 7 2 8 32
0
1-2
3
4-5
6
7-9
10-12
13-15
16
17-55
56
57 - 95
96
97 – 134
135
136 - 174
175
176 -214
215
216 - 246
247
248
249
250
251
252
253
254
255
Virtual Colour Wheel
For detailed description see " Virtual colour wheel- colour mixing chart
No function
White 2700 K
White 2700 K (Halogen lamp mode***)
White 3200 K
White 3200 K (Halogen lamp mode***)
White 4200 K
White 5600 K
White 8000 K
Blue (Blue=full, Red+Green+White=0)
Red=0, Green->up,Blue =full, White=0
Light Blue (Red=0, Green=full, Blue =full, White=0)
Red=0, Green=full, Blue->down, White=0
Green (Red=0, Green=full, Blue =0, White=0)
Red->up, Green=full, Blue=0, White=0
Yellow (Red=full, Green=full, Blue=0, White=0)
Red=full, Green->down, Blue=0, White=0
Red(Red=full, Green=0, Blue=0, White=0)
Red=full, Green=0, Blue->up, White=0
Magenta (Red=full, Green=0, Blue=full, White=0)
Red -> down, Green=0, Blue=full, White=0
Blue (Red=0, Green=0, Blue=full, White=0)
--------------------------------------------------------------------
Speed of the following effects can be controlled by the
Shutter/Strobe channel (DMX values of 96-127)
Rainbow effect (with fade time)
Rainbow effect
Zone effect 1
Zone effect 2
Zone effect 3
Zone effect 4
Zone effect 5
Zone effect 6
step
step
step
step
step
step
step
step
step
proportional
step
proportio-
nalstep
proportional
step
proportional
step
proportional
step
proportional
step
step
step
step
step
step
step
step
step
28 12 8 3 2 33 0 - 255
Zoom (8 bit)
Zoom from min. to max. beam angle proportional
29 13 - - 3 34 0 - 255
Zoom ne (16 bit)
Fine zooming from min. to max. proportional
30 14 9 4 4 35
0-31
32-63
64-95
96-111
112-127
128-143
144-159
160-175
176-191
192-223
224-255
Shutter/Strobe
Shutter closed
Strobe effect from slow--> fast (zone 3 only)
Strobe effect from slow--> fast (All zones together)
--------------Set value on Virtual colour wheel--------------
Zone effects+rainbow effects speed control, slow--> fast
Zone effects+rainbow effects speed control, fast--> slow
/opposite direction/
---------------------------------------------------------------------------
Opening pulses in sequences from slow--> fast
(All zones together)
Closing pulses in sequences from fast--> slow
(All zones together)
Random strobe effect from slow--> fast (random zone)
Random strobe effect from slow--> fast (random zone +
random strobe)
Random strobe effect from slow --> fast (All zones together)
Shutter open
step
proportional
proportional
proportional
proportional
proportional
proportional
proportional
proportional
proportional
step

17
Mode/Channel Value Function Type of
control
1 2 3 4 5 6
31 15 10 5 5 36 0-255
Dimmer (8 bit)
Dimmer intensity from 0% to 100% proportional
32 16 - - 6 37 0-255
Dimmer ne (16 bit)
Fine dimming proportional
** DMX values of all channels are saved into xture and will be recall after switching the xture on (without
DMX controller connected).
***In the Halogen lamp mode the Dimmer channel imitates behaviour of the halogen lamp during dimming.

18
5.1 Virtual colour wheel - colour mixing chart
Scale*
Virtual Colour Wheel
Red
Green
Blue
White
DMX
DMX
DMX
DMX
DMX
1-2 (White 2700K) 250 118 0 63
3 (White 2700K /Hal.mode/) 250 118 0 63
4-5 (White 3200K) 255 141 5 89
6 (White 3200K /Hal.mode/) 255 141 5 89
7-9 (White 4200K) 254 141 3 255
10-12 (White 5600K) 254 207 37 255
13-15 (White 8000K) 228 255 79 255
16 0 0 255 0
17 0 3 255 0
18 0 6 255 0
19 0 9 255 0
20 0 12 255 0
21 0 15 255 0
22 0 18 255 0
23 0 21 255 0
24 0 24 255 0
25 0 27 255 0
26 0 30 255 0
27 0 36 255 0
28 0 41 255 0
29 0 46 255 0
30 0 52 255 0
31 0 58 255 0
32 0 64 255 0
33 0 68 255 0
34 0 74 255 0
35 0 80 255 0
36 0 86 255 0
37 0 92 255 0
38 0 98 255 0
39 0 104 255 0
40 0 110 255 0
41 0 119 255 0
42 0 129 255 0
43 0 138 255 0
44 0 147 255 0
45 0 156 255 0
46 0 165 255 0
47 0 174 255 0
48 0 183 255 0
49 0 192 255 0
50 0 201 255 0
51 0 210 255 0
52 0 219 255 0
53 0 228 255 0
54 0 237 255 0
55 0 246 255 0
56 0 255 255 0
57 0 255 246 0
58 0 255 237 0
59 0 255 228 0
60 0 255 219 0
61 0 255 210 0
62 0 255 201 0
63
0
255
192
0
Page 1

19
Robin 600 LED Wash - Virtual Colour Wheel
Scale*
V
irtual Colour Wheel Red Green Blue White
DM
X
DM
X
DM
X
DM
X
DM
X
64 0 255 183 0
65 0 255 174 0
66 0 255 165 0
67 0 255 156 0
68 0 255 147 0
69 0 255 138 0
70 0 255 129 0
71 0 255 119 0
72 0 255 110 0
73 0 255 104 0
74 0 255 98 0
75 0 255 92 0
76 0 255 86 0
77 0 255 80 0
78 0 255 74 0
79 0 255 68 0
80 0 255 64 0
81 0 255 58 0
82 0 255 52 0
83 0 255 46 0
84 0 255 41 0
82 0 255 36 0
86 0 255 30 0
87 0 255 27 0
88 0 255 24 0
89 0 255 21 0
90 0 255 18 0
91 0 255 15 0
92 0 255 12 0
93 0 255 9 0
94 0 255 6 0
95 0 255 3 0
96 0 255 0 0
97 3 255 0 0
98 6 255 0 0
99 9 255 0 0
100 12 255 0 0
101 15 255 0 0
102 18 255 0 0
103 21 255 0 0
104 24 255 0 0
105 27 255 0 0
106 30 255 0 0
107 36 255 0 0
108 41 255 0 0
109 46 255 0 0
110 52 255 0 0
111 58 255 0 0
112 64 255 0 0
113 68 255 0 0
114 74 255 0 0
115 80 255 0 0
116 86 255 0 0
117 92 255 0 0
118 98 255 0 0
Page 2

20
Robin 600 LED Wash - Virtual Colour Wheel
Scale*
V
irtual Colour Wheel Red Green Blue White
DM
X
DM
X
DM
X
DM
X
DM
X
119 104 255 0 0
120 110 255 0 0
121 119 255 0 0
122 129 255 0 0
123 138 255 0 0
124 147 255 0 0
125 156 255 0 0
126 165 255 0 0
127 174 255 0 0
128 183 255 0 0
129 192 255 0 0
130 201 255 0 0
131 210 255 0 0
132 219 255 0 0
133 228 255 0 0
134 240 255 0 0
135 255 255 0 0
136 255 246 0 0
137 255 237 0 0
138 255 228 0 0
139 255 219 0 0
140 255 210 0 0
141 255 201 0 0
142 255 192 0 0
143 255 183 0 0
144 255 174 0 0
145 255 165 0 0
146 255 156 0 0
147 255 147 0 0
148 255 138 0 0
149 255 129 0 0
150 255 119 0 0
151 255 110 0 0
152 255 104 0 0
153 255 98 0 0
154 255 92 0 0
155 255 86 0 0
156 255 80 0 0
157 255 74 0 0
158 255 68 0 0
159 255 64 0 0
160 255 58 0 0
161 255 52 0 0
162 255 46 0 0
163 255 41 0 0
164 255 36 0 0
165 255 30 0 0
166 255 27 0 0
167 255 24 0 0
168 255 21 0 0
169 255 18 0 0
170 255 15 0 0
171 255 12 0 0
172 255 9 0 0
173 255 6 0 0
Page 3
