Robin R 1700i Instruction Manual

Model
R 1700i
S pec. No. R AS 17023091
IS S UE E MD-G P 6345
IS S UE DAT E
2006.10
P AR T S C AT AL OG
for C ANA DA
(E H092DN8521)

ABBREVIATIONS/略語 DESCRIPTION 説明
Ａ ＡＭＰＥＲＥ アンペア
ＡＣ ＡＩＲＣＬＥＡＮＥＲ エアクリーナ
ＡＹ ＡＳＳＥＭＢＬＹ アッセンブリ
Ｂ ＢＲＥＡＤＴＨ 幅
ＢＢ ＢＡＬＬＢＥＡＲＩＮＧ ボールベアリング
ＣＤ ＣＥＮＴＥＲＤＩＳＴＡＮＣＥ 中心間距離
ＣＰ ＣＯＭＰＬＥＴＥ コンプリート
Ｄ ＤＩＡＭＥＴＥＲ 内径、外径、中心径
ＥＸ ＥＸＰＯＲＴ 輸出
ＥＸ ＥＸＨＡＵＳＴ 排気
ＦＩＧ ＦＩＧＵＲＥ フィギュア（図解）
ＦＲ ＦＲＯＮＴ 前側
Ｈ ＨＥＩＧＨＴ 高さ
ＨＺ ＨＥＲＴＺ ヘルツ
ＩＮ ＩＮＣＨ インチ
ＩＮ ＩＮＴＡＫＥ 吸入
Ｌ ＬＩＴＥＲ リットル
Ｌ ＬＥＮＧＴＨ 長さ
ＬＨ ＬＥＦＴＨＡＮＤ 左側
ＭＧ ＭＡＧＮＥＴＩＣ マグネチック
Ｎ ＮＵＭＢＥＲ 数、巻数
ＮＲＹ ＮＥＷＲＯＢＩＮＹＥＬＬＯＷ 新ロビン色
ＯＳ ＯＩＬＳＥＮＳＯＲ オイルセンサ
Ｏ.Ｓ. ＯＶＥＲＳＩＺＥ オーバーサイズ
Ｐ ＰＩＴＣＨ ピッチ
ＰＤ ＰＩＴＣＨＤＩＡＭＥＴＥＲ 中心径
ＰＴＯ ＰＯＷＥＲＴＡＫＥＯＦＦ 動力取出し
ＲＥＦ ＲＥＦＥＲＥＮＣＥ レファレンス（照合）
ＲＨ ＲＩＧＨＴＨＡＮＤ 右側
ＲＲ ＲＥＡＲ 後側
ＳＴ ＳＴＡＲＴＥＲ スタータ
ＳＴＤ ＳＴＡＮＤＡＲＤ 標準
ＳＷ ＳＰＲＩＮＧＷＡＳＨＥＲ スプリングワッシャ
ＳＷ ＳＷＩＴＣＨ スイッチ
Ｔ ＴＨＩＣＫＮＥＳＳ 厚さ
ＴＨ ＴＨＲＯＴＴＬＥ スロットル
ＵＮ ＵＮＩＴ ユニット
Ｕ.Ｓ. ＵＮＤＥＲＳＩＺＥ アンダーサイズ
Ｖ ＶＯＬＴＡＧＥ ボルト
Ｗ ＷＡＳＨＥＲ ワッシャ
Ｗ ＷＡＴＴ ワット
Ｗ ＷＩＤＴＨ 幅
Ｗ/ ＷＩＴＨ 付き
Ｗ/Ｏ ＷＩＴＨＯＵＴ 無し
2003/4
Tableofabbreviations/略語一覧

CONTENTS
ENGINE PARTS
FIG.
1 CRANKCASE 100
2 CRANKSHAFT, PISTON 200
3 INTAKE, EXHAUST 300,315
4 GOVERNOR, OPERATION 400
5 COOLING, STARTING 500,520
6 FUEL, LUBRICANT 600,642
7 ELECTRIC DEVICE 700,770
GENERATOR PARTS
22 GENERATOR 2200
23 BASE FRAME 2300
24 CONTROL 2400
25 COVER 2500
26 FUEL TANK 2600
29 ACCESSORIES LABEL 2900

610
26 20 70
51
30 75
10
830
225
2840100104
EH092
FIG. 100
710
680
690
630
631
620
700
40 50
810
860
840
820
270
280
290
230
80
90
300
250
260
960-GASKET SET
210
930
632
637

1CRANKCASEGROUP
REF. PARTNUMBER PARTNAME QTY REMARKS CODENO. INTERCHANGEP/NO. UNITP FIG.
10 284‑10103‑11 CRANKCASECP 1 ‑ 100
20 237‑14202‑03 VALVEGUIDE 2 5.5DX9.5DX27L ‑ 100
26 277‑16010‑01 STEMSEAL 1 5.5DX9.5DX15DX7.8B ‑ 100
30 044‑02000‑70 OILSEAL 1 20DX32DX6B ‑ 100
40 060‑02001‑40 BALLBEARING 1 20DX42DX12B ‑ 100
50 031‑00600‑20 DOWELPIN 2 6DX14.5L ‑ 100
51 277‑15011‑03 PIPEKNOCK 2 10.3DX8.5DX14L ‑ 100
70 010‑50604‑20 STUD 2 M6X1.0X84L ‑ 100
75 044‑00600‑20 OILSEAL 1 6DX10DX2.5B ‑ 100
80 040‑11400‑30 PLUG 1 M14X1.5X20DX12L ‑ 100
90 021‑11400‑20 GASKET 1 14.1DX19DX2.3T ‑ 100
210 284‑11201‑21 MAINBEARINGCOVERCP 1 ‑ 100
225 230‑17102‑03 PLUG(RUBBER) 1 ‑ 100
230 060‑02001‑40 BALLBEARING 1 20DX42DX12B ‑ 100
250 284‑45003‑01 GOVERNORGEARCP 1 44DX20TN=26 ‑ 100
260 205‑41901‑03 GOVERNORSLEEVE 1 6DX9DX16DX26L ‑ 100
270 230‑63601‑01 OILGAUGECP 1 M18X1.5L=38+18 ‑ 100
280 021‑31600‑20 GASKET 1 16DX23DX1.2TRUBBER ‑ X21‑31600‑20 100
290 284‑16003‑03 GASKET(BEARINGCOVER 1 T=0.3 ‑ 100
300 011‑00601‑01 FLANGEBOLT 8 M6X1.0X13DX28L ‑ 100
610 284‑13003‑11 CYLINDERHEADCP 1 6972‑ 100
284‑13003‑01 CYLINDERHEADCP 1 ‑6971 100
620 284‑15001‑13 GASKET(HEAD) 1 T=0.2 ‑ 100
630 011‑00802‑10 FLANGEBOLT 2 M8X1.25X16DX55L ‑ 100
631 011‑00803‑01 FLANGEBOLT 1 ‑ 100
632 010‑00804‑20 BOLT 1 M8X1.25X60L ‑ 100
637 020‑00802‑10 WASHER 1 8.5DX17DX3.2T ‑ 100
680 284‑15501‑03 ROCKERCOVER 1 ‑ 100
690 284‑16004‑03 GASKET(ROCKERCOVER) 1 T=0.7 ‑ 100
700 277‑15011‑03 PIPEKNOCK 2 10.3DX8.5DX14L ‑ 100
710 011‑00604‑20 FLANGEBOLT 4 ‑ 100
810 284‑14301‑01 BREATHERCOVERCP 1 ‑ 100
820 284‑14401‑01 BREATHERPLATECP 1 ‑ 100
830 230‑16006‑13 GASKET(TAPPETCOVER) 1 T=0.8 ‑ 100
840 230‑16007‑03 GASKET(BREATHER) 1 T=2 ‑ 100
860 011‑00600‑20 FLANGEBOLT 2 M6X1.0X14DX12L ‑ 100
930 33K‑58317‑03 SPONGECRANK 1 ‑ 100
960 284‑99002‑17 GASKETSET 1 ‑ 100

FIG. 200
EH092 2840200005
380
350
360
361
362
370
371
372
310
40
41
42
10
320
70 90
50

2CRANKSHAFTPISTON
REF. PARTNUMBER PARTNAME QTY REMARKS CODENO. INTERCHANGEP/NO. UNITP FIG.
10 284‑20601‑01 CRANKSHAFTCP 1 L=171 ‑ 200
40 023‑02001‑00 SPACER 1 20.5DX28DX0.8T ‑ 200
41 023‑02001‑10 SPACER 1 20.5DX28DX1.0T ‑ 200
42 023‑02001‑20 SPACER 1 20.5DX28DX1.2T ‑ 200
50 002‑18140‑00 NUT 1 ‑ 200
70 005‑32031‑01 WOODRUFFKEY 1 ‑ 200
90 020‑01500‑40 WASHER 1 15.3DX25DX2.5T ‑ 200
310 284‑22501‑30 CONNECTINGRODAY 1 66CDX18B21D‑11D ‑ 200
320 284‑23001‑03 CONNECTINGRODBOLT 2 M5X0.8X11DX25L ‑ 200
350 230‑23301‑03 PISTONPIN 1 11DX8DX40L ‑ 200
360 284‑23401‑H3 PISTON 1 STD(51DX31H) ‑ 200
361 284‑23402‑H3 PISTON 1 0.25O.S.(51DX31H) ‑ 200
362 284‑23403‑H3 PISTON 1 0.50O.S.(51DX31H) ‑ 200
370 284‑23501‑07 PISTONRINGSET 1 STD(51D) ‑ 200
371 274‑23502‑07 PISTONRINGSET 1 0.25O.S.(51D) ‑ 200
372 274‑23503‑07 PISTONRINGSET 1 0.50O.S.(51D) ‑ 200
380 056‑51100‑10 CLIP 2 12DX1D ‑ 200

FIG. 300
EH092
10
37 35 34 38 36
310
317 315
538
580
570
2840300105
560
540
550
365
350
340
405 90
80
50
210
260
60
70 240
95
220
230
930
750
850
931 535
418

3INTAKEEXHAUST
REF. PARTNUMBER PARTNAME QTY REMARKS CODENO. INTERCHANGEP/NO. UNITP FIG.
10 284‑31701‑21 CAMSHAFTCP 1 L=9263DX6.6BN=38 ‑ 300
34 227‑38601‑23 PIN(SPRING) 1 3.8DX7.5DX14L ‑ 300
35 284‑36401‑03 RELEASELEVER 1 ‑ 300
36 005‑19041‑00 SPRINGPIN 1 4.4DX10LX0.8T ‑ 300
37 003‑15170‑00 SNAPRINGOUTER 1 ‑ 300
38 274‑38701‑23 RETURNSPRING 1 5DX0.5DX5.2LN=9.7 ‑ 300
50 274‑33301‑03 TAPPET 2 17DX8DX32L ‑ 300
60 274‑33601‑03 VALVESPRING 2 17.1DX2DX26.7LN=5.5 ‑ 300
70 274‑33702‑03 SPRINGRETAINER 2 ‑ 300
80 284‑33401‑H3 INTAKEVALVE 1 21DX5.5DX63.6L 6972‑ 300
274‑33401‑03 INTAKEVALVE 1 21DX5.5DX63.6L ‑6971 300
90 284‑33501‑H3 EXHAUSTVALVE 1 18DX5.5DX63.6L 6972‑ 300
274‑33501‑03 EXHAUSTVALVE 1 18DX5.5DX63.6L ‑6971 300
95 132‑10KA0‑31 COLLET‑VALVE 4 ‑ 300
210 274‑35301‑03 PUSHROD 2 4DX121.6L ‑ 300
220 284‑36001‑03 ROCKERARM 2 7122‑ 300
274‑36003‑03 ROCKERARM 2 ‑7121 284‑36001‑03 300
230 269‑35801‑03 BOLT(PIVOT) 2 M6X0.75X19LSOCKETH ‑ 300
240 017‑00600‑90 NUT 2 M6X0.75X5.1H ‑ 300
260 274‑36501‑03 GUIDEPLATE 1 ‑ 300
310 284‑30201‑20 MUFFLERAY 1 ‑ 300
315 269‑37601‑01 SPARKARRESTERCP 1 ‑ 300
317 015‑00400‑60 TAPPINGSCREW 1 M4X6L ‑ 300
340 230‑35204‑01 GASKETCP(EXHAUST) 2 T=1.320D6.5DX38P ‑ 300
350 018‑00600‑30 FLANGENUT 2 ‑ 300
365 011‑00801‑10 FLANGEBOLT 1 M8X1.25X14DX80L ‑ 300
405 284‑34101‑13 EXHAUSTPIPE 1 ‑ 300
418 001‑14061‑60 BOLTANDWASHERAY 2 M6X1.0X16LW/W,SW ‑ 300
535 284‑32904‑01 STAYBAFFLECP 1 ‑ 300
538 277‑46701‑03 GASKET(CHOKE) 1 T=0.3 ‑ 300
540 284‑32903‑03 INSULATOR 1 ‑ 300
550 227‑35902‑03 GASKET2(INSULATOR) 1 T=0.325D6.5DX42P ‑ 300
560 157‑35001‑03 GASKET(INSULATOR) 1 T=0.320D6.5DX42P ‑ 300
570 002‑38060‑00 FLANGENUT 2 M6X1.0X13DX6H ‑ 300
580 011‑00601‑80 FLANGEBOLT 1 M6X1.0X14DX18L ‑ 300
750 284‑32101‑03 DUCT 1 ‑ 300
850 085‑10803‑60 RUBBERPIPE 1 8DX11DX37.5L ‑ 085‑10800‑00 300
930 33K‑58315‑13 SPONGEINS 1 ‑ 300
931 33K‑58321‑13 SPONGEINS2 1 ‑ 300

FIG. 315
EH092
510
-520
-2
2840315104

3INTAKEEXHAUST
REF. PARTNUMBER PARTNAME QTY REMARKS CODENO. INTERCHANGEP/NO. UNITP FIG.
510 284‑32630‑00 AIRCLEANERAY 1 ‑ 315
‑2 227‑36004‑13 GASKET(AIRCLEANER) 1 ‑ 315
‑520 284‑32631‑08 ELEMENT 1 ‑ 315

FIG. 400
EH092 2840400008
20
60
70
10
200 207
50

4GOVERNOROPERATION
REF. PARTNUMBER PARTNAME QTY REMARKS CODENO. INTERCHANGEP/NO. UNITP FIG.
10 284‑42305‑03 GOVERNORLEVER 1 ‑ 400
20 230‑42201‑13 GOVERNORSHAFT 1 7061‑ 400
230‑42201‑03 GOVERNORSHAFT 1 ‑7060 230‑42201‑13 400
50 003‑13050‑00 CLIP 2 ‑ 400
60 001‑14062‑50 BOLTANDWASHERAY 1 M6X1.0X25LW/W,SW ‑ 400
70 018‑60600‑20 NUT 1 M6X1.0X4.9HSQUARE ‑ 400
200 284‑46003‑03 CONTROLBRACKET 1 ‑ 400
207 011‑00600‑10 FLANGEBOLT 2 M6X1.0X14DX8L ‑ 400

863
2840500103
FIG. 500
EH092
80
10
220
41
40
60
81
37
861
860
110
130
865
863
862
864
851
61

5COOLINGSTARTING
REF. PARTNUMBER PARTNAME QTY REMARKS CODENO. INTERCHANGEP/NO. UNITP FIG.
10 284‑51201‑03 BLOWERHOUSING 1 ‑ 500
37 284‑55501‑03 GROMMET 1 ‑ 500
40 011‑00801‑60 FLANGEBOLT 1 M8X55L ‑ 500
41 011‑00803‑02 FLANGEBOLT 3 ‑ 500
60 284‑53601‑01 CYLINDERBAFFLECP 1 ‑ 500
61 284‑53603‑03 CYLINDERBAFFLE(E/G) 1 ‑ 500
80 011‑00600‑20 FLANGEBOLT 1 M6X1.0X14DX12L ‑ 500
81 011‑00801‑50 FLANGEBOLT 3 M8X1.25X16DX12L ‑ 500
110 284‑54201‑13 COOLINGFAN 1 ‑ 500
130 056‑60002‑60 CLAMP 1 8.5DX10BX95LX0.4T ‑ 500
220 011‑00601‑40 FLANGEBOLT 3 M6X1.0X14DX18L ‑ 500
851 284‑51203‑03 SEALSPONGEBL 1 ‑ 500
860 284‑53606‑23 INSULATIONSEATB1 1 ‑ 500
861 284‑53605‑03 SEALRUBBER 1 ‑ 500
862 284‑53609‑03 SEALSPONGEBAFFLE2 1 ‑ 500
863 284‑53610‑03 SEALSPONGEBAFFLE3 2 ‑ 500
864 33K‑58323‑03 SPONGEBAFFLE4 1 ‑ 500
865 284‑53608‑03 SEALSPONGEBAFFLE 1 ‑ 500

2840520102
FIG. 520
EH092
-32
210
-3
-6
-2
-7
-1
-56
-4
-5
-57
-8
-10
-31

5COOLINGSTARTING
REF. PARTNUMBER PARTNAME QTY REMARKS CODENO. INTERCHANGEP/NO. UNITP FIG.
210 284‑50221‑10 RECOILAY 1 ‑ 520
‑1 284‑50224‑08 SPIRALSPRING 1 ‑ 520
‑2 284‑50222‑08 REEL 1 ‑ 520
‑3 284‑50233‑08 STARTERROPE 1 ‑ 520
‑4 530‑50021‑10 STARTERKNOBECP 1 ‑ 520
‑5 284‑50223‑08 RACHET 1 ‑ 520
‑6 284‑50226‑08 FRICTIONSPRING 1 ‑ 520
‑7 284‑50227‑08 RETURNSPRING 1 ‑ 520
‑8 284‑50225‑18 FRICTIONPLATE 1 ‑ 520
‑10 284‑50231‑08 RETAININGRINGCTY 1 ‑ 520
‑31 284‑56101‑03 GUIDE 1 ‑ 520
‑32 33K‑53001‑03 KNOBCOVER 1 ‑ 520
‑56 284‑50229‑08 RETAININGRINGETYP 1 ‑ 520
‑57 284‑50228‑08 RACHETGUIDE 1 ‑ 520

2840600104
EH092
FIG. 600
220 221
222
223
225

6FUELLUBRICANT
REF. PARTNUMBER PARTNAME QTY REMARKS CODENO. INTERCHANGEP/NO. UNITP FIG.
220 085‑00300‑40 VINYLPIPE 1 3.5DX5.5DX175L ‑ 085‑09300‑00 600
221 085‑00300‑50 VINYLPIPE 1 3.5DX5.5DX210L ‑ 085‑09300‑00 600
222 085‑00300‑60 VINYLPIPE 1 3.5DX5.5DX140L ‑ 085‑09300‑00 600
223 284‑67101‑03 YCONNECTOR 1 ‑ 600
225 056‑90000‑20 PURSELOCK 1 ‑ 600

2840642103
EH092
FIG. 642
-40-41
-11
-1
-2
-8
-23
-25
-3
-2
-5
-151
-152
-18
-22
-19
-16
-17
-12
-28
-15
-14
-117
210
-102
-412
-410
-406 -400
-402
-408
-420
-103
-109
-155
-414
