ROCK RSD0624 User manual

Quick Installation Guide
Need FREE technical support?
Scan the QR code or visit
https://rockspaceworld.com/
24/7 Online After-sales Service
Hot-line: +1 (833) 816-6558
Email: [email protected]
Service Time: EST 10:00-21:00 from Monday to Friday
AX1800 Wi-Fi 6 Mesh System
Model No. RSD0624 (3-pack)

Meet Your Router
LED indicator LAN port WAN port Power port
Reset button
Reset button: Press for 2 second to reset your router to factory default settings.
LED Status
Primary node
Pulsing green: Connecting to the Internet
Solid green: Connection succeeded
Pulsing red: Connection failed
Blinking five times: Resetting
Secondary node
Pulsing green: Connecting to the primary node
Solid green: Connection succeeded, good signal strength
Solid yellow: Connection succeeded, fair signal strength
Pulsing red: Connection failed

Set Up Your Mesh Wi-Fi System
I. Connect your router
II. Set up the primary node
Method 1: Via the ROCK WIFI App
1. Power the router on using the included power adapter and plug it into an outlet.
The light turns solid green to indicate that it's on and ready for setup.
2. Connect your modem or your main Ethernet cable (if your Internet connection
does not require a modem) to the WAN port on your router using an Ethernet cable.
The WAN LED indicator turns on.
1. Download the ROCK WIFI app.
Note: If you are a new user, follow the onscreen instructions to register rst. With this App, you can
manage your network easily and conveniently no matter where you are.
Download on the
App Store
Get it on
Google Play ROCK WIFI
Modem
Internet
Power

2. Connect your smart phone to the router.
3. Open the ROCK WIFI app. Select your router model: RSD0624-AX1800 Mesh.
Select any of the nodes to connect. The default SSID (network name) is printed on
the label at the bottom of the router.
Select model

4. The App detects your connection type automatically.
If detection fails, choose your connection type manually. There are 3 connection types
supported, please refer to FAQ > Q1 below.
5. Set your Wi-Fi Name and Wi-Fi Password.
Ready to connect Networking setting
Congure WiFi

Method 2: Via a Web Browser
6. Primary node setup complete.
1. Connect to your router (wireless or wired).
Wireless
Find the SSID (network name) printed on the bottom label of the router and select
the SSID from your network list to connect your device to the network.
Wired
Connect your computer to the LAN port on your router via an Ethernet cable.
Conguration completed

2. Connect the router to the Internet.
(1) Launch a web browser and enter 192.168.0.1 or www.rockspacewifi.com in the
address bar to log into the router’s web interface.
(3) Set your Wi-Fi Name, Wi-Fi Password and Login Password.
(2) The webpage detects your connection type automatically. If detection fails, choose
your connection type manually. There are 3 connection types supported, please refer
to FAQ > Q1 below.

Add A Node
III. Add the secondary nodes
ROCK mesh Wi-Fi nodes can be added to the network you've created with your
router. All additional Wi-Fi devices added are considered nodes in the mesh network.
You can choose one of the following method to add.
Method 1: Via the ROCK WIFI App
1. Open the ROCK WIFI app.
2. Tap the device > More settings > Add a secondary node.
(4) Primary node setup complete.
After setting up the primary node, the other two nodes in the kit will automatically
be added to the mesh network after plugging it in.
More settingsDevice information

Method 2: Via a Web Browser
3. Scan QR code of secondary nodes (labeled on the bottom of the mesh box).
4. The node will now connect.
5. If you'd like to add another node, repeat these steps for additional nodes.
1. Connect the Ethernet cable to your primary node's LAN port. Then, connect the
other end to the secondary node's WAN port.
2. Log in to the router's web management page.
3. Tap Add +. Choose “wired connection”. Tap Next.
Add a secondary node

5. After successful setup, you can relocate the node to achieve wider Wi-Fi coverage.
Just plug it into a wall outlet, the node will connect. The LED indicator on your mesh
router shows the status of your device.
6. If you'd like to add another node, repeat these steps for additional nodes.
To check the full list of ROCK Wi-Fi devices,
scan the QR code or visit https://rockspaceworld.com/
4. Follow the instructions to complete setup.
Enjoy the internet!

Dynamic IP (recommended) -- Obtain IP address from ISP automatically, choose this
option if your ISP does not provide username and password.
Static IP -- Choose this option if your ISP provided an IP address and other information.
PPPoE -- Choose this option if your Internet Service Provider (ISP) provided PPPoE
username and password.
A2: First, open the ROCK WIFI app, and select More settings, then click WiFi setting.
Now you can try to edit the SSID and password, after you change the password and SSID,
tap save. To use the Wi-Fi, you need to reconnect to it.
Q1: What connection type should I choose if the router fails to detect automatically?
Q2: How can I change my SSID and password?
A3: With the nodes powered on, press and hold the reset pinhole on the back of the
primary node using a paper clip or something pointed, release when the LED indicator
blinks fast. Your network is reset successfully when the LED indicator lights solid on then
blinks again. And all nodes are restored to factory settings.
Note: After the primary node is reset and recongured, please power o the other two
secondary nodes in case of abnormality display on the App.
Q3: How to restore my network to factory settings?
A4: Please make sure that your 5GHz band is on and not be hided. In this case, you can
check the status of 5GHz through ROCK WIFI app > More Setting > NETWORK SETTINGS >
MAIN WIFI SETTING. Turn on the 5GHz band if it's o.
Otherwise, you should make sure the your devices are supporting 5GHz signals. Only
those support 5GHz signals could be detected and connected.
Q4: Why cannot my device connect to the 5GHz Wi-Fi signals?
A5: First please make sure that your Ethernet cable with Internet connection is securely
plugged into the WAN port rather than the LAN port.
Second, make sure the mesh system is set up correctly according to the Quick Installation
Guide.
Q5: What if the app could not recognize the device or connect to the device?
FAQ

FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
> Reorient or relocate the receiving antenna.
> Increase the separation between the equipment and receiver.
> Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
> Consult the dealer or an experienced radio/TV technician for help.
This device is restricted to be used in the indoor.
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Radiation Exposure Statement
This device complies with FCC radiation exposure limits set forth for an uncontrolled environment
and it also complies with Part 15 of the FCC RF Rules.
This equipment should be installed and operated with minimum distance 20cm between the
radiator & your body.
Caution:
Any changes or modications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
All transmission frequencies of U-NII-1 and U-NII-3 comply with 47 CFR FCC Part15.407(g) and
the manufacturer declares that their transmission is maintained within the U-NII-1 and U-NII-3
bands.
NOTE: (1) The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modications to this equipment. (2) To avoid unnecessary radiation interference, it is recommended to use
a shielded RJ45 cable.
