NETGEAR GS716TNA User manual

350 East Plumeria Drive
San Jose, CA 95134
USA
August 2012
202-10510-03
v2.0
GS716T/GS724T
Hardware Installation Guide

2
GS716T/GS724T Gigabit Smart Switch
© 2012 by NETGEAR, Inc. All rights reserved
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any language in any form or by any means without the written permission of NETGEAR, Inc.
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of
NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change
without notice. Other brand and product names are registered trademarks or trademarks of their respective
holders. © NETGEAR, Inc. All rights reserved.
Technical Support
Thank you for choosing NETGEAR. To register your product, get the latest product updates, get support online, or
for more information about the topics covered in this manual, visit the Support website at
http://support.netgear.com
Phone (US & Canada only): 1-888-NETGEAR
Phone (Other Countries): Check the list of phone numbers at
http://support.netgear.com/app/answers/detail/a_id/984
Statement of Conditions
To improve internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes
to the products described in this document without notice. NETGEAR does not assume any liability that may occur
due to the use, or application of, the product(s) or circuit layout(s) described herein.
Revision History
Publication Part Number Version Publish Date Comments
202-10510-03 2.0 August 2012 Second publication

3
Contents
Chapter 1 Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 2 Physical Description
GS716T Front and Back Panel Configuration . . . . . . . . . . . . . . . . . . . . . . 10
GS724T Front and Back Panel Configuration . . . . . . . . . . . . . . . . . . . . . . 11
LED Designations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Port LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
System LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Device Hardware Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
RJ-45 Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
SFP GBIC Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Factory Defaults Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Chapter 3 Applications
Desktop Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Chapter 4 Installation
Step 1: Prepare the Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Step 2: Install the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Install the Switch on a Flat Surface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Install the Switch in a Rack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Step 3: Check the Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Step 4: Connect Devices to the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Step 5: Install an SFP GBIC Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Step 6: Apply AC Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Step 7: Manage the Switch using a Web Browser or the Smart Control
Center Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Appendix A Troubleshooting
Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Additional Troubleshooting Suggestions . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Network Adapter Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Switch Integrity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4
GS716T/GS724T Gigabit Smart Switch
Auto-Negotiation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Appendix B Technical Specifications
Appendix C Notification of Compliance
Index

5
1
1. Introduction
Congratulations on the purchase of the NETGEAR Smart Switch. The NETGEAR Smart
Switch is a state-of-the-art, high-performance, IEEE-compliant network solution designed for
users who require a large number of ports and want the power of Gigabit connectivity to
eliminate bottlenecks, boost performance, and increase productivity. To simplify installation,
the switch is shipped ready for use out of the box.
This chapter serves as an introduction to the Smart Switch and provides the following
information:
• Overview
• Features
• Package Contents

6
GS716T/GS724T Gigabit Smart Switch
Overview
This Installation Guide is for the following NETGEAR Smart Switches:
•GS716T – This product offers support for 16 ports of 10/100/1000 Mbps and two
Form-factor slots, which support 1000 (1000BASE-SX/LX)/100 Mbps Small Form-factor
Pluggable (SFP).
•GS724T – This product offers support for 24 ports of 10/100/1000 and two Form-factor
slots, which support 1000 (1000BASE-SX/LX)/100 Mbps SFP.
Using Gigabit ports, high-speed connections can be made to a server or network backbone.
For example:
•Linking to high-speed servers
•Providing 10/100/1000 Mbps copper and fiber connectivity
The Smart Switch also provides the benefit of administrative management with a complete
package of features for the observation, configuration, and control of the network. With a
Web-based Graphical User Interface (GUI), the switch’s many capabilities can be viewed and
used in a simple and intuitive manner. The switch’s management features include
configuration for port and switch information, VLAN for traffic control, port trunking for
increased bandwidth, IPv6 Management support to enable IPv6 operation over the network
port, IPv6 QoS, IPv6 ACL and Class of Service (CoS) for traffic prioritization. These features
provide better understanding and control of the network. Initial discovery of the switch on the
network requires the Smart Control Center program, a utility that runs on a computer.
The Smart Switch can be free-standing, or rack mounted in a wiring closet or equipment
room. It is IEEE-compliant and offers low latency for high-speed networking. All ports can
automatically negotiate to the highest speed. This capability makes the switch ideal for
environments that have a mix of Ethernet, Fast Ethernet, or Gigabit Ethernet devices. In
addition, all RJ-45 ports operate in half-duplex or full-duplex mode. The maximum segment
length is 328 feet (100 meters) over Category 5 Unshielded Twisted-Pair (UTP) cable, but
much longer for fiber connections using SFP GBIC modules.

7
GS716T/GS724T Gigabit Smart Switch
Features
The following list identifies the key features of the NETGEAR Smart Switch.
•16/24 RJ-45 10/100/1000 Mbps auto sensing Giga switching ports.
•2 Small Form-factor Pluggable (SFP) GBIC slots which function as combo ports. Combo
ports are single ports with two physical connections, SFP fiber and RJ-45 copper. The
RJ-45 copper ports corresponding to the Combo ports are the last four 10/100/1000
Mbps auto sensing Giga switching ports on each device. If both devices are plugged in,
the fiber connection is active, with fiber port taking priority if both are connected. The
following SFP types are supported:
•1000BASE-SX
•1000BASE-LX
•100BASE-FX
•The devices support full NETGEAR Smart Switch functionality.
•The devices provide full compatibility with IEEE standards:
•IEEE 802.3i, (10BASE-T)
•IEEE 802.3u (100BASE-TX, 100BASE-FX)
•IEEE 802.3x (Full-duplex flow control)
•IEEE 802.3ab (1000BASE-T)
•IEEE 802.3z (1000BASE-X)
•Auto-sensing and auto-negotiating capabilities for all ports.
•Auto Uplink™ on all ports to make the right connection.
•Automatic address learning function to build the packet-forwarding information table. The
table contains up to 8K Media Access Control (MAC) addresses.
•Full-duplex and half-duplex functions for all 10/100/1000 Mbps ports.
•Store-and-Forward transmission to remove bad packets from the network.
•Full-duplex IEEE 802.3x pause frame flow control.
•Active flow control to minimize packet loss/frame drops.
•Half-duplex back-pressure control.
•Per port LEDs, System LEDs.
•Standard 1U high, rack-mountable 17-inch chassis.

8
GS716T/GS724T Gigabit Smart Switch
Package Contents
Figure 1 shows the package contents of the NETGEAR GS716T and GS724T Series Smart
Switch.
Verify that the package contains the following:
•NETGEAR Smart Switch
•Rubber footpads for tabletop installation
•Power cord
•Rack-mount kit for installing the switch in a 19-inch rack
•Quick Installation guide
•Smart Switch Resource CD with Smart Control Center and User’s manual
•Warranty/Support Information Card
If any item is missing or damaged, contact the place of purchase immediately.
Figure 1. Package Contents
MODEL GS724T
ProSafe 24 Port Gigabit Smart Switch
23F 24 F
Link/
ACT
Link/
ACT
Factory
Defaults
Reset PWR
57911
6810
12
17 19 21 23T
18 20 22 24T
LINK/ACT
SPD
FDX
LINK/ACT
SPD
FDX
18
17
20
19
22
21
24
23
Yellow (100 M)
Green (1000 M)
Uplink
™
Auto
2
1
4
3
6
5
8
7
10
9
12
11
14
13
16
15
®13
24
13 15
14 16

9
2
2. Physical Description
This chapter describes the NETGEAR Smart Switch hardware features. Topics
include:
• GS716T Front and Back Panel Configuration
• GS724T Front and Back Panel Configuration
• LED Designations
• Device Hardware Interfaces

10
GS716T/GS724T Gigabit Smart Switch
GS716T Front and Back Panel Configuration
The GS716T is a 24-port 10/100/1000 Mbps + 2 SFP Combo ports Smart Switch. Every
RJ-45 port is capable of sensing the line speed and negotiating the operation duplex mode
with the link partner automatically
Figure 2 illustrates the NETGEAR GS716T Smart Switch front panel:
The front panel contains the following:
•16 RJ-45 connectors for 10/100/1000 Mbps auto sensing Gigabit Ethernet switching
ports.
•Two SFP slots for SFP modules supporting 1000 (1000BASE-SX/LX)/100 Mbps SFP.
•Reset button to restart the device.
•Recessed default reset button to restore the device back to the factory defaults.
•Port LEDs
•System LEDs
Figure 3 illustrates the NETGEAR GS716T Smart Switch back panel:
The back panel contains the following:
•A 100-240VAC/50-60 Hz universal input, which is a standard AC power receptacle for
accommodating the supplied power cord.
Figure 2. GS716T Front Panel
Figure 3. GS716T Back Panel
MODEL GS716T
ProSafe 16 Port Gigabit Smart Switch
15F 16F
Link/
ACT
Link/
ACT
Factory
Defaults
Reset PWR
1357
2468
9111315T
10 12 14 16T
®
LINK/ ACT
SPD
FDX
LINK/ ACT
SPD
FDX
2
1
4
3
6
5
8
7
10
9
12
11
14
13
16
15
Yellow (100M )
Green (1000 M)
Uplink
™
Auto
System LEDs
SFP Ports
10/100/1000 Mbps Ethernet Ports
100-240 V ~ 50-60Hz
Power Connector

11
GS716T/GS724T Gigabit Smart Switch
GS724T Front and Back Panel Configuration
The GS724T is a 24-port 10/100/1000 Mbps Smart Switch + 2 SFP Combo ports switch.
Every RJ-45 port is capable of sensing the line speed and negotiating the operation duplex
mode with the link partner automatically
Figure 4 illustrates the NETGEAR GS724T Smart Switch front panel:
The front panel contains the following:
•24 RJ-45 connectors for 10/100/1000 Mbps auto-sensing Gigabit Ethernet switching
ports.
•Two slots for SFP slots for SFP modules supporting 1000 (1000BASE-SX/LX)/100 Mbps
SFP.
•Reset button to restart the device.
•Recessed default reset button to restore the device back to the factory defaults.
•System LEDs
Figure 5 illustrates the NETGEAR GS724T Smart Switch back panel:
The back panel contains the following:
•A 100-240VAC/50-60 Hz universal input, which is a standard AC power receptacle for
accommodating the supplied power cord.
Figure 4. GS724T Front Panel
Figure 5. GS724T Back Panel
MODEL GS724T
ProSafe 24 Port Gigabit Smart Switch
23F 24F
Link/
ACT
Link/
ACT
Factory
Defaults
Reset PWR
57911
6810
12
17 19 21 23T
18 20 22 24T
LINK/A CT
SPD
FDX
LINK/A CT
SPD
FDX
18
17
20
19
22
21
24
23
Yello w (100 M )
Green (1000 M)
Uplink
™
Auto
2
1
4
3
6
5
8
7
10
9
12
11
14
13
16
15
®13
24
13 15
14 16
System LEDs
SFP Ports
10/100/1000 Mbps Ethernet Ports
100-240 V ~ 50-60Hz
Power Connector

12
GS716T/GS724T Gigabit Smart Switch
LED Designations
Port LEDs
The following table describes the port LED designations.
Table 1. Port LEDs
Port LED Designation
16/24-10/100/1000 Mbps
Ports - 3 LEDs per port
LINK/ACT
SPD
FDX
•Solid Green - A valid 1000 Mbps link is
established on the port.
•Flashing Green - Packet transmission or
reception is occurring on the port at
1000 Mbps.
•Solid Yellow - A valid 10/100 Mbps link is
established on the port.
•Flashing Yellow - Packet transmission or
reception is occurring on the port at
10/100 Mbps.
•Off - No 10/100 Mbps link is established
on the port.
•Solid Green - Full-duplex link is
established on the port.
•Off - No full-duplex or half-duplex link is
established on the port.
2 SFP Ports - 1 LED per
port
SFP LINK/ACT •Solid Green - A valid 1000 Mbps SFP
module link is established on the port.
•Flashing Green - Packets transmission
or reception is occurring on the port at
1000 Mbps.
•Solid Yellow - A valid 100 Mbps SFP
module link is established on the port.
•Flashing Yellow - Packets transmission
or reception is occurring on the port at
100 Mbps.
•Off - No SPD link is established on the
port.

13
GS716T/GS724T Gigabit Smart Switch
System LEDs
The following table describes the system LED designations.
Table 2. System LEDs
LED Designation
Power LED •Solid Green - Power is supplied to the switch and the switch is
operating normally.
•Off - Power is disconnected.

14
GS716T/GS724T Gigabit Smart Switch
Device Hardware Interfaces
RJ-45 Ports
RJ-45 ports are auto-sensing ports. When inserting a cable into an RJ-45 port, the switch
automatically ascertains the maximum speed (10, 100, or 1000 Mbps) and duplex mode
(half-duplex or full-duplex) of the attached device. All ports support only unshielded or
shielded twisted-pair (UTP or STP) cable terminated with an 8-pin RJ-45 plug.
To simplify the procedure for attaching devices, all RJ-45 ports support Auto Uplink. This
technology allows attaching devices to the RJ-45 ports with either straight-through or
crossover cables. When inserting a cable into the switch’s RJ-45 port, the switch
automatically:
•Senses whether the cable is a straight-through or crossover cable.
•Determines whether the link to the attached device requires a “normal” connection (such
as when connecting the port to a computer) or an “uplink” connection (such as when
connecting the port to a router, switch, or hub).
•Configures the RJ-45 port to enable communications with the attached device, without
requiring user intervention. In this way, the Auto Uplink technology compensates for
setting uplink connections, while eliminating concern about whether to use crossover or
straight-through cables when attaching devices.
SFP GBIC Module
The GBIC module bays accommodate standard SFP GBIC modules, such as the AGM731F,
AGM732F, or AGM733 from NETGEAR, allowing fiber connections on the network. The
module bay is a combo port, sharing a connection with an RJ-45 port. Being a combo port,
only one type of connection can be active at any given time. For example, both copper and
fiber port cannot be used at the same time. If both connectors are plugged in at the same
time, the fiber port will be active.
The SFP GBIC bay accommodates a standard SFP GBIC module.
Factory Defaults Button
The Smart Switch has a Factory Default button so that you can remove the current
configuration and return the device to its factory settings. When you enable the Factory
Default button, all settings, including the password, VLAN settings and port configurations will
be removed.

15
3
3. Applications
Your NETGEAR Smart Switch is designed to provide flexibility in configuring your network
connections. It can be used as a stand-alone device or with 10 Mbps, 100 Mbps, and 1000
Mbps hubs and switches.

16
GS716T/GS724T Gigabit Smart Switch
Desktop Switching
The NETGEAR Smart Switch can be used as a desktop switch to build a small network that
enables users to have 1000 Mbps access to a file server. With full-duplex enabled, the switch
port connected to the server or computer can provide 2000 Mbps throughput.
Figure 6. Desktop Switching
Internet
Computer
Firewall Server
Computer
MODEL
GS724T
ProSafe24 Port Gigabit Smart Swit ch
23F 24F
Link/
ACT
Link/
ACT
Factory
Defaults
Reset PWR
57911
6810 12
17 19 21 23T
18 20 22 24T
LINK /A C T
SPD
FDX
LINK/ACT
SPD
FDX
18
17
20
19
22
21
24
23
Yellow
(100M)
Green
(1000M)
Uplink
™
Auto
2
1
4
3
6
5
8
7
10
9
12
11
14
13
16
15
®
13
24
13 15
14 16

17
4
4. Installation
This chapter describes the installation procedures for your NETGEAR Smart
Switch. Switch installation involves the following steps:
Step 1: Prepare the Site
Step 2: Install the Switch
Step 3: Check the Installation
Step 4: Connect Devices to the Switch
Step 5: Install an SFP GBIC Module
Step 6: Apply AC Power
Step 7: Manage the Switch using a Web Browser or the Smart Control Center Utility

18
GS716T/GS724T Gigabit Smart Switch
Step 1: Prepare the Site
Before you install the switch, ensure the operating environment meets the operating
environment requirements in the following table.
Table 3. Site Requirements
Characteristics Requirements
Mounting •Desktop installations - Provide a flat table or shelf surface.
•Rack-mount installations - Use a 17-inch (48.3-centimeter) EIA standard
equipment rack that is grounded and physically secure. The rack-mount kit supplied
with the switch is also required.
Access Locate the switch in a position that allows access to the front panel RJ-45 ports, view the
front panel LEDs, and access power connector.
Power source Provide a power source within 6 feet (1.8 meters) of the installation location. Power
specifications for the switch are shown in
Appendix A . Ensure the AC outlet is not
controlled by a wall switch, which can accidentally turn off power to the outlet and the
switch.
Environmental •Temperature - Install the switch in a dry area, with ambient temperature between 0
and 55ºC (32 and 131ºF). Keep the switch away from heat sources such as direct
sunlight, warm air exhausts, hot-air vents, and heaters.
•Operating humidity - The installation location should have a maximum relative
humidity of 90%, non-condensing.
•Ventilation - Do not restrict airflow by covering or obstructing air inlets on the sides
of the switch. Keep at least 2 inches (5.08 centimeters) free on all sides for cooling.
Be sure there is adequate airflow in the room or wiring closet where the switch is
installed.
•Operating conditions - Keep the switch at least 6 ft. (1.83 m) away from nearest
source of electromagnetic noise, such as a photocopy machine.

19
GS716T/GS724T Gigabit Smart Switch
Step 2: Install the Switch
The NETGEAR Smart Switch can be installed on a flat surface or in a standard 19-inch rack.
Install the Switch on a Flat Surface
The switch ships with four self-adhesive rubber footpads. Stick one rubber footpad on each of
the four concave spaces on the bottom of the switch. The rubber footpads cushion the switch
against shock/vibrations.
Install the Switch in a Rack
To install the switch in a rack, use the following procedure (and see Figure 7, Rack Mount on
page 19). To perform this procedure, the 17-inch rack-mount kit supplied with switch is
required.
1. Attach the supplied mounting brackets to the side of the switch.
2. Insert the screws provided in the rack-mount kit through each bracket and into the bracket
mounting holes in the switch.
3. Tighten the screws with a #1 Phillips screwdriver to secure each bracket.
4. Align the mounting holes in the brackets with the holes in the rack, and insert two pan-head
screws with nylon washers through each bracket and into the rack.
5. Tighten the screws with a #2 Phillips screwdriver to secure the switch in the rack.
Figure 7. Rack Mount

20
GS716T/GS724T Gigabit Smart Switch
Step 3: Check the Installation
Before applying power perform the following:
•Inspect the equipment thoroughly.
•Verify that all cables are installed correctly.
•Check cable routing to make sure cables are not damaged or creating a safety hazard.
•Ensure all equipment is mounted properly and securely.
