Rockett Pedals APE User manual

!
MIX
REPEATS
DELAY
TIME
OUT
IN
YOUR FAVORITE DELAY
INPUT
The APE can be configured in several different ways. The above configuration “A” is the
series setup. This allows you to use the APE in front of your delay. This will introduce the
famous EP sound as well but will not color the delayed notes like in Loop configuration. All
of your delay controls will work as they normally do, however, the APE will function
differently. In this configuration the APE acts as a preamp with no controls it just simply
adds the influence of the EP sound which is wider and warmer. It introduces a fat sound
across the spectrum. Since it runs at 22.5v just like a real EP everything in between the
notes is cleaner and clearer. To introduce any controllable effect you must engage the
loop switch. Once the loop switch is engaged the “REC” knob becomes a treble boost
and gain. The “Mix” knob also controls output.
NOTE: Be careful to not crank the repeats control on the APE when in series or it can squeal
loudly.
NOTE: When using the APE with delays that do not have a mix control or go 100% wet we
recommend that you use it in the “A” configuration. The APE in the “B” configuration works
best with “flat frequency” digital delays. PT Chip delays and Analog delays seem to work
best in the “A” configuration. We encourage you try all configurations with any delay since
we cannot try them all. You may discover a great setup. The APE was intended to add the
EP sound to those digital delays lacking the warmth and fatness of the analog influence of
an old EP, especially those that claim to be a recreation of an EP.
OTHER SETUPS: You can run your guitar into the “guitar input” and come out of the
standard output but you can also come out of the send or return. When you use the
“Return” as the output you get a fully bypass-able treble boost/gain controlled by the
“REC” knob. When you use “Send” as the output you get a non bypass-able clean boost
controlled by the “REC” knob.
The APE works really with BASS guitar!!
CONFIGURATION “A”
TO
AMP
A.P.E. (Analog Preamp Experiment)

!
MIX
REPEATS
DELAY
TIME
OUT
IN
ALWAYS SET REPEATS
TO ABSOLUTE
MINIMUM OR 1 REPEAT
ALWAYS SET MIX TO
ABSOLUTE MAXIMUM
OR FULLY WET
YOUR FAVORITE DELAY
SET TO
DESIRED
DELAY TIME
The APE can be configured in several different ways. The above configuration “B” is the loop setup.
This allows you to loop your delay into the APE and let the APE take over some of the controls. You
will need to set your delay to 100% MIX or fully wet. You will need to set your repeats to only 1 repeat
or minimum. The APE will handle the repeats and the mix along with the record head level. The
Record head level adds gain to the delayed note. If you set the record head level low and the mix
high you will get cleaner delays. If you set the Record head leave; high and the mix low you will
have grittier delays, please experiment.
NOTE: Be careful to not crank the repeats control on the APE when in series or it can squeal loudly.
The APE can be used in loop configuration or in series just like a typical pedal. Run the APE before
any delay and it will introduce the famous EP sound into your entire signal path. We prefer the APE
at the end of the chain just before a delay and/or reverb in loop or series configuration.
Things to experiment with: Try overdrives or boosts into the loop and you will find some amazing
sounds.
Guitar Input
Guitar Output
CONFIGURATION “B”
A.P.E. (Analog Preamp Experiment)

Warranty
Warranty
Rockett Pedals LLC.will repair or replace,at its discretion,defective
workmanship or materials on all new Rockett Pedals products directly
or through; the selling dealer or an authorized service technician,for
one year from the date of purchase at no cost to the original
purchaser.
Repair and replacement parts installed will be warranted for the
unexpired portion of the original
warranty term.
Before sending product in for repair please contact us at
[e-mail] or
[e-mail] call [phone].
This warranty does not cover shipping costs,product appearance or
damages caused by
accident,abuse,misuse or alteration.
A dated sales slip or order number (issued by a tech,dealer or Rockett
Pedals) must accompany a product being returned for warranty
service.Repairs without a return authorization number will be
refused.Please allow 4weeks for warranty service.For more
information please contact Rockett Pedals www.rockettpedals.com or
[phone].
No other warranty is expressed or implied.
A.P.E. (Analog Preamp Experiment)
