Rockwell Automation Allen-Bradley PowerFlex 20-COMM-L User manual

LonWorks
Adapter
20-COMM-L
FRN 1.xxx
User Manual

Important User Information
Solid state equipment has operational characteristics differing from those of
electromechanical equipment. “Safety Guidelines for the Application, Installation
and Maintenance of Solid State Controls” (Publication SGI-1.1) describes some
important differences between solid state equipment and hard-wired
electromechanical devices. Because of this difference, and also because of the
wide variety of uses for solid state equipment, all persons responsible for applying
this equipment must satisfy themselves that each intended application of this
equipment is acceptable.
In no event will the Allen-Bradley Company be responsible or liable for indirect or
consequential damages resulting from the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative
purposes. Because of the many variables and requirements associated with any
particular installation, the Allen-Bradley Company cannot assume responsibility or
liability for actual use based on the examples and diagrams.
No patent liability is assumed by Allen-Bradley Company with respect to use of
information, circuits, equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written
permission of the Allen-Bradley Company is prohibited.
Throughout this manual we use notes to make you aware of safety considerations.
Attentions help you:
•identify a hazard
•avoid the hazard
•recognize the consequences
Important: Identifies information that is especially important for successful
application and understanding of the product.
!
ATTENTION: Identifies information about practices or circumstances
that can lead to personal injury or death, property damage, or economic
loss.
Shock Hazard labels may be located on or inside the drive to alert
people that dangerous voltage may be present.

Summary of Changes
This is the first release of the LonWorks adapter FRN1.xxx.

S-ii Summary of Changes

Table of Contents
Preface About This Manual
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-1
Conventions Used in This Manual . . . . . . . . . . . . . . . . . . . . . P-1
Rockwell Automation Support. . . . . . . . . . . . . . . . . . . . . . . . P-2
Chapter 1 Getting Started
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Compatible Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Required Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Modes of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Chapter 2 Installing the Adapter
Preparing for the Installation . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Connecting the Adapter to the Network . . . . . . . . . . . . . . . . 2-1
Connecting the Adapter to the Drive . . . . . . . . . . . . . . . . . . . 2-3
Applying Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Chapter 3 Configuring the Adapter
Configuration Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Using the PowerFlex HIM . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Setting the I/O Configuration. . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Setting the Comm Fault Action . . . . . . . . . . . . . . . . . . . . . . . 3-4
Setting the Idle Fault Action . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Resetting the Adapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Viewing the Adapter Configuration . . . . . . . . . . . . . . . . . . . . 3-7
Chapter 4 Configuring the LonWorks Network
Overview of LonWorks Functionality . . . . . . . . . . . . . . . . . . 4-1
Operating the Drive Using a LonMark Profile. . . . . . . . . . . . 4-2
Node Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Network Variable Inputs (NVIs) . . . . . . . . . . . . . . . . . . . . . . 4-5
Network Variable Outputs (NVOs) . . . . . . . . . . . . . . . . . . . . 4-9
Network Configuration Inputs (NCIs) . . . . . . . . . . . . . . . . . 4-13
Conditions Required for Operation . . . . . . . . . . . . . . . . . . . 4-19
Resource Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20

ii Table of Contents
Chapter 5 Troubleshooting
Locating the Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . 5-1
PORT Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
MOD Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
NET A Status Indicator (Service Indicator). . . . . . . . . . . . . . 5-4
Viewing and Clearing Adapter Diagnostic Items. . . . . . . . . . 5-5
Viewing and Clearing Events. . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Appendix A Specifications
Communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Mechanical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Appendix B Adapter Parameters
Parameter List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Appendix C Logic Command/Status Words
PowerFlex 70 and PowerFlex 700 Drives . . . . . . . . . . . . . . . C-1
Glossary
Index

Preface
About This Manual
Documentation can be obtained online at http://www.ab.com/manuals.
The following conventions are used throughout this manual:
•Parameter names are shown in the following format Parameter xxx
- [*]. The xxx represents the parameter number. The * represents the
parameter name. For example Parameter 01 - [DPI Port].
•Menu commands are shown in bold type face and follow the format
Menu > Command. For example, if you read “Select File > Open,”
you should click the File menu and then click the Open command.
Topic Page
Related Documentation P-1
Conventions Used in This Manual P-1
Rockwell Automation Support P-2
Related Documentation
For: Refer to: Publication
DriveExplorer™ DriveExplorer Getting Started Manual
DriveExplorer Online Help
9306-GR001…
DriveTools 2000™ DriveTools 2000 Online Help
HIM HIM Quick Reference 20HIM-QR001…
PowerFlex™ 70 Drive PowerFlex 70 User Manual
PowerFlex 70/700 Reference Manual
20A-UM001…
PFLEX-RM001…
PowerFlex 700 Drive PowerFlex 700 User Manual
PowerFlex 70/700 Reference Manual
20B-UM001…
PFLEX-RM001…
Network Cabling LonMark Layers 1-6 Interoperability
Guidelines, Appendix A “Cable
Requirements for the TP/FT-10 Channel.”
www.lonmark.org
Conventions Used in This Manual

P-2 About This Manual
•The firmware release is displayed as FRN X.xxx. The “FRN”
signifies Firmware Release Number. The “X”is the major release
number. The “xxx”is the minor update number. This manual is for
Firmware release 1.xxx.
•This manual provides information about the LonWorks adapter and
using it with PowerFlex 70 and 700 drives. Refer to the
documentation for your product for specific information about how it
works with the adapter.
Rockwell Automation offers support services worldwide, with over 75
sales/support offices, over 500 authorized distributors, and over 250
authorized systems integrators located through the United States alone.
In addition, Rockwell Automation representatives are in every major
country in the world.
Local Product Support
Contact your local Rockwell Automation representative for sales and
order support, product technical training, warranty support, and support
service agreements.
Technical Product Assistance
If you need to contact Rockwell Automation for technical assistance,
please review the information in Chapter 5, Troubleshooting, first. If you
still have problems, then call your local Rockwell Automation
representative.
Rockwell Automation Support
U.S. Allen-Bradley Drives Technical Support:
E-mail: [e-mail]
Tel: [phone]
Fax: [phone]
Online: www.ab.com/support/abdrives
UK Customer Support Center:
E-mail: [e-mail]
Tel: [phone]
Fax: [phone]
German Customer Service Center:
E-mail: [e-mail]
Tel: [phone]
Fax: [phone]

Chapter 1
Getting Started
Chapter 1 provides information about the 20-COMM-L LonWorks
adapter, an embedded communication option specifically for PowerFlex
70 and 700 (Standard) drives.
Figure 1.1 Components of the Adapter
Topic Page Topic
Components 1-1 Safety Precautions 1-3
Features 1-2 Quick Start 1-5
Compatible Products 1-2 Modes of Operation 1-6
Required Equipment 1-3
Components
#Part Description
➊Status Indicators Three LEDs indicate the status of the connected drive, adapter,
and network. Refer to Chapter 5, Troubleshooting, for details.
➋DPI Connector A 20-pin, single-row shrouded male header. An Internal
Interface cable connects to this connector and one on the drive.
➌Terminal Block A 6-screw terminal block connects the adapter to the network.
➌
➋
➊

1-2 Getting Started
The LonWorks adapter features the following:
•The adapter is mounted in the drive and receives its required power
from the drive.
•Status indicators report the status of the drive communications,
adapter, and network. They are visible both when the drive cover is
opened and when it is closed.
•Based on the LonMark Functional Profile: “Variable Speed Motor
Drive: 6010.”
•Send and receive Datalink data.
•Read/write access to parameters is available. You can configure and
monitor parameter values over the networks.
•User-defined fault actions let you determine how the adapter and
drive respond to communication disruptions on the network.
•LonMark conformance tested.
•Flash-upgradable.
DPI (Drive Peripheral Interface) is a second generation peripheral
communication interface and a functional enhancement to SCANport.
The LonWorks adapter is compatible with specific Allen-Bradley
PowerFlex 7-Class drives. At the time of publication, compatible
products include:
•PowerFlex 70 drives
•PowerFlex 700 (Standard) drives
The PowerFlex 70/700 are used for examples in this manual. Refer to the
respective user manuals for additional information.
Important: The LonWorks adapter will only work with the above
specified products. It will NOT work with other products
susch as PowerFlex 700S, PowerFlex 7000, and PowerFlex
700 Vector.
Features
Compatible Products

Getting Started 1-3
Equipment Shipped with the Adapter
When you unpack the adapter, verify that the package includes:
User-Supplied Equipment
To install and configure the LonWorks adapter, you must supply:
Please read the following safety precautions carefully.
Required Equipment
❑One LonWorks adapter
❑A 2.54 cm (1 in.) and a 15.24 cm (6 in.) Internal Interface cable
(only one cable is needed to connect the adapter to the drive)
❑One grounding wrist strap
❑This manual
❑Diskette containing resource files
❑A small flathead screwdriver
❑Network-specific cable to connect the adapter to the network. Refer
to the network-specific documentation for the cable
recommendations and requirements.
❑Configuration tools, such as:
–PowerFlex HIM
–DriveExplorer (version 2.01 or higher)
–DriveExecutive (version 1.01 or higher)
–LonMaker configuration software
Safety Precautions
!
ATTENTION: Risk of injury or equipment damage exists. Only
qualified electrical personnel familiar with drive and power products
and the associated machinery should plan or implement the installation,
start up, configuration, and subsequent maintenance of the product
using a LonWorks adapter. Read and understand this manual in its
entirety before proceeding. Failure to comply may result in injury and/
or equipment damage.
!
ATTENTION: Risk of injury or death exists. The drive may contain
high voltages that can cause injury or death. Remove all power from the
drive, and then verify power has been removed before installing or
removing a LonWorks adapter.

1-4 Getting Started
!
ATTENTION: Risk of injury or equipment damage exists. DPI or
SCANport host products must not be directly connected via 1202
cables. Unpredictable behavior due to timing and other internal
procedures can result if two or more hosts are connected in this manner.
!
ATTENTION: Risk of injury or equipment damage exists. If the
LonWorks adapter is transmitting control I/O to the drive, the drive may
fault when you reset the adapter. Determine how your drive will
respond before resetting an adapter.
!
ATTENTION: Risk of injury or equipment damage exists.
Parameter 6 - [Comm Flt Action] lets you determine the action of the
adapter and connected drive if communications are disrupted. By
default, this parameter faults the drive. You can set this parameter so
that the drive continues to run. Precautions should be taken to ensure
that the setting of this parameter does not create a hazard of injury or
equipment damage. When commissioning the drive, verify that your
system responds correctly to various situations (for example, a
disconnected cable).
!
ATTENTION: Risk of injury or equipment damage exists. Parameter
7 - [RcvHrtBeat Time] lets you determine how long it will take your
adapter to detect network communication losses. By default, this
parameter is set to 120 seconds. You can set it so that the duration is
shorter, longer, or disabled. Take precautions to ensure that the setting
does not create a risk of injury or equipment damage. When
commissioning the drive, verify that your system responds correctly to
various situations (for example, a disconnected cable).
!
ATTENTION: Risk of injury or equipment damage exists. When a
system is configured for the first time, there may be unintended or
incorrect machine motion. Disconnect the motor from the machine or
process during initial system testing.
!
ATTENTION: Risk of injury or equipment damage exists. The
examples in this publication are intended solely for purposes of
example. There are many variables and requirements with any
application. Rockwell Automation does not assume responsibility or
liability (to include intellectual property liability) for actual use of the
examples shown in this publication.
!
ATTENTION: Risk of equipment damage exists. The adapter
contains ESD (Electrostatic Discharge) sensitive parts that can be
damaged if you do not follow ESD control procedures. Static control
precautions are required when handling the adapter. If you are
unfamiliar with static control procedures, refer to Guarding Against
Electrostatic Damage, Publication 8000-4.5.2.

Getting Started 1-5
This section is designed to help experienced users start using the
LonWorks adapter. If you are unsure how to complete a step, refer to the
referenced chapter
Quick Start
Step Action Refer to
1Review the safety precautions for the adapter. Throughout this
manual
2Verify that the drive is properly installed. Drive User
Manual
3Install the adapter.
Verify that the drive and the network are not powered. Then,
connect the adapter to the network and to the drive. Use the
captive screws to secure and ground the adapter to the drive.
Chapter 2,
Installing the
Adapter
4Apply power to the adapter.
Verify that the adapter and network are installed correctly and
then apply power to them. The adapter receives power from
the drive. The topmost status indicator should be solid green.
Refer to Chapter 5, Troubleshooting, for a description of the
other LEDs.
Chapter 2,
Installing the
Adapter
5Configure the adapter for your application.
Install and bind network variables. Set the parameters for the
following features as required by your application:
•I/O configuration
•Fault actions
Chapter 3,
Configuring the
Adapter
6Set up the network to communicate with the adapter.
Use a network tool (such as LonMaker) to configure the
adapter on the network.
Chapter 4,
Configuring the
LonWorks
Network

1-6 Getting Started
The adapter uses four status indicators to report its operating status. They
can be viewed on the adapter or through the drive cover.
Figure 1.2 Status Indicators (location on drive may vary)
If any other conditions occur, refer to Chapter 5, Troubleshooting.
Modes of Operation
#Status
Indicator
Normal
Status
Description
➊PORT Flashing
Green
Normal Operation. The adapter is establishing an I/O
connection to the drive. It will turn solid green or red.
Green Normal Operation. The adapter is properly connected and
communicating with the drive
➋MOD Flashing
Green
Normal Operation. The adapter is operating but is not
transferring I/O data.
Green Normal Operation. The adapter is operating and transmitting
I/O data.
➌NET A Off Normal Operation. The adapter is configured.
PWR
STS
PORT
MOD
NET A
NET B
➋
➊
➌
➋
➊
➌

Chapter 2
Installing the Adapter
Chapter 2 provides instructions for installing the LonWorks adapter in a
PowerFlex 70 or 700 drive.
Before installing the adapter, verify that you have all required
equipment. Refer to Chapter 1, Getting Started.
1. Remove power from the drive.
2. Use static control precautions.
3. Open the drive cover.
Topic Page
Preparing for the Installation 2-1
Connecting the Adapter to the Network 2-1
Connecting the Adapter to the Drive 2-3
Applying Power 2-5
Preparing for the Installation
!
ATTENTION: Risk of equipment damage exists. The adapter
contains ESD (Electrostatic Discharge) sensitive parts that can be
damaged if you do not follow ESD control procedures. Static control
precautions are required when handling the adapter. If you are
unfamiliar with static control procedures, refer to Guarding Against
Electrostatic Damage, Publication 8000-4.5.2.
Connecting the Adapter to the Network
!
ATTENTION: Risk of injury or death exists. The drive may contain
high voltages that can cause injury or death. Remove all power from the
drive, and then verify power has been removed before installing or
removing an adapter.

2-2 Installing the Adapter
4. Connect a cable to the network, and route it through the bottom of
the drive. (See Figure 2.3 on page 2-4. Refer to the LonMark Layers
1-6 Interoperability Guidelines, Appendix A “Cable Requirements
for the TP/FT-10 Channel.”)
5. Connect a six-pin linear plug to the network cable. (See Figure 2.1
for the terminal definitions.)
Figure 2.1 Bus Topology with Shield Example
Terminal Name Function
1SHIELD(1)
(1) It is recommended to use shielded network cable. This shield must be grounded
at one point on the network via a 470K ohm, 1/4 watt, ≤ 10% metal film resistor.
Noise mitigation(2)
(2) For noise mitigation, LON trunk lines should not be run in close proximity to drive
or equipment power distribution feeds.
2NET A Network connection, polarity insensitive
3NET B Network connection, polarity insensitive
4TERM BUS Connect to TERM COM for termination of Bus(3)
topology networks.
(3) To terminate a Bus Topology network (one termination at each end of the
network), connect TERM COM to TERM BUS.
5TERM COM Termination common
6TERM FT Connect to TERM COM for termination of Free(4)
topology networks.
(4) To terminate a Free Topology network (one termination per segment), connect
TERM COM to TERM FT.
Node 1 Node 2 Node "n"
SHIELD
NET A
NET B
TERM BUS
TERM COM
TERM FT
SHIELD
NET A
NET B
TERM BUS
TERM COM
TERM FT
SHIELD
NET A
NET B
TERM BUS
TERM COM
TERM F
T

Installing the Adapter 2-3
1. Remove power from the drive and network.
2. Use static control precautions.
3. Connect the Internal Interface cable to the DPI port on the drive and
then to the DPI connector on the adapter.
Figure 2.2 DPI Ports and Internal Interface Cables
Connecting the Adapter to the Drive
#Description #Description
➊15.24 cm (6 in.) Internal Interface cable ➌Network cable
➋DPI Connector ➍2.54 cm (1 in.) Internal Interface cable
➋
➊
➍
➌
LonWorks Adapter
PowerFlex 700 Drive
0 – 1 Frame
PowerFlex 700 Drive
2 Frame and Larger
PowerFlex 70 Drive

2-4 Installing the Adapter
4. Secure and ground the adapter to the drive by doing the following:
–On a PowerFlex 70, fold the Internal Interface cable behind the
adapter and mount the adapter on the drive using the four captive
screws.
–On a PowerFlex 700, just mount the adapter on the drive using
the four captive screws.
Important: All screws must be tightened since the adapter is
grounded through a screw. Recommended torque is 0.9
N-m (8.0 lb.-in.).
Figure 2.3 Mounting and Grounding the Adapter
PowerFlex 70 Drive
Adapter mounts in drive.
Internal Interface cable folds behind
adapter and in front of the drive.
Drive
Adapter
PowerFlex 700 Drive (0 and 1 Frames)
Adapter mounts on door.
PowerFlex 700 Drive (2 & Larger Frames)
Adapter mounts in drive.

Installing the Adapter 2-5
1. Close the door or reinstall the cover on the drive. The status
indicators can be viewed on the front of the drive after power has
been applied.
2. Apply power to the drive. The adapter receives its power from the
connected drive. When you apply power to the drive for the first
time, the topmost status indicator on the adapter should be solid
green. If it is not green, refer to Chapter 5, Troubleshooting.
Applying Power
!
ATTENTION: Risk of equipment damage, injury, or death exists.
Unpredictable operation may occur if you fail to verify that parameter
settings are compatible with your application. Verify that settings are
compatible with your application before applying power to the drive.

2-6 Installing the Adapter
Notes:
