Rocstor Y10A266-A1 User manual

Features
USB Type-C Male
(Connect to a host computer)
• Type-C supports reversible plug
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• 1 x Main Unit
• User Manual
This is a premium Rocstor Type-C to DVI, HDMI and VGA adapter. It allows you to
transmit signals from a Type-C source to a high definition DVI or HDMI or VGA display
(TV sets, projectors, etc). It is compatible with all DP Alt mode supported Type-C or
Thunderbolt 3 hosts. With this multiport adapter, you can watch video or slideshows
on a big screen.
Upstream:
Downstream:
Specification
How to Use
System Requirement
Input / Output Connector
Input
Output USB-C Male x1
HDMI Female x1
USB-C Female x1 (for data or Charging)
USB-A Femalex1
USB Type-C Male x1
Warranty
Limited Warranty 3 Year
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Regulatory Approvals
Certifications FCC, CE
Mechanical
Size (L-W-H)
Weight (Net)
85x45x14.5mm - 3.3”x 1.7”x 0.5”
39gr - (0.08lbs)
Accessories
User Manual English Version
1- Connect this multiport adapter to the host computer.
2-ConnecttheDVIporttoaDVImonitor.3- Connect the HDMI port to an HDMI monitor.
4- Connect the VGA port to a VGA monitor.
Host computer with an available USB-C Port
- USB 3.0/3.1/3.2
Operating systems
- Windows 7 / 8 / 10 / 11
- Android OS
- Chrome OS
- Linux OS
- Mac OS v10.5 or above
0°C to + 45°C - (32°F to + 113°F)
10% to 90 % RH (no condensation)
-10°C to + 70°C - (14°F to + 158°F)
10% to 90 % RH (no condensation)
Introduction
®
USB Type-C® Multiport Adapter 3-in-1 USB Type-C® to
HDMI® 4K/60Hz, VGA, or DVI™ 1080p - Gray
User Manual
Y10A266-A1
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
VGA
• Supports VGA resolution up to
1920x1200@60Hz
• Supports RGB
4:4:4/ YCbCr 4:2:2/ YCbCr 4:2:0
• Supports HDCP1.4&2.2
HDMI
• Supports HDMI resolution up to
4Kx2K@60Hz
• Supports HDMI 8/10/12bit
• Supports HDR
• Supports HDMI 9 Gbps Bandwidth
DVI
• Supports DVI Resolution up to
1080P@60Hz
FEATURES
• Allows HDMI and VGA to output simultaneously with 1080P/60Hz under SST mode
• Allows DVI and VGA to output simultaneously with 1080P/60Hz under SST mode
• HDMI and DVI can not work at the same time
• Priority: VGA>DVI>HDMI

Technical Support / RMA
Hours: 9:00 am - 5:00 pm PST
Monday to Friday (except holidays)
Tell: [phone] (National and international)
Fax: [phone]
Email: [e-mail]
Support
Warranty Information
Technical support is available to all the registered users of Rocstor products.
Connection Diagram
Safety Information:
©2021 Rocstroge, Inc. All rights reserved. Rocstor is registered trademark of Rocstorage, Inc.
Apple®, the Apple logo, Mac®, MacBook®, MacBook Pro®, MacBook Air®, iPad®, iPad Air®, iPad mini®,
iPad Air®, iPhone®, MacOS® are registered trademarks of Apple, Inc. Google® and Chromebook™ are
registered trademarks of Google, LLC. Microsoft® is registered trademarks of Microsoft corporation. Al
other product names and logos mentioned herein may be trademarks of their respective companies.
Thunderbolt is a trademark of Intel Corporation or its subsidiaries. USB Type-C® and USB-C® are
registered trademark of USB Implementers Forum. Feature and specification are subject to change
without notice. All trademarks and registered trademarks are the property of their respective. All
rights reserved.
WARNING: Please follow these safety instructions. Failure to do so may result damages or injury.
It is normal that the Rocstor Multi-port Hub adapter becomes very warm during use.
Please note that:
Continuous contact with warm surfaces for extended time may cause discomfort or injury. In order to
reduce the possibility of overheating or heat-related injuries, always allow needed ventilation around
the Rocstor Multi-port Hub adapter and use care when handling it. Avoid instances where your skin is
in extended contact with the hub when plugged into the host computer. It is not recommended to
sleep with the adapter when plugged into a host computer. Avoid placing the hub adapter under a
pillow, blanket, or your body when connected to a host computer. If you have a medical condition
that affects your ability to detect heat against the body, extra care should be used. Never use the
adapter in locations with water, such as a sink, bathtub, or shower stall. Never connect or disconnect
the adapter with wet hands.
!
Limitation of Liability
In no event shall the liability of Rocstorage, Inc. and Rocstor (or their officers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of
the product exceed the actual price paid for the product. Some states do not allow the exclusion or
limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
Warranty Information
This product is backed by a (3)three-year warranty. Rocstor warrants its products against defects in
materials and workmanship for the periods noted, following the initial date of purchase. During this
period, the products may be returned for repair, or replacement with equivalent products at our
discretion. The warranty covers parts and labor costs only. Rocstor does not warrant its products from
defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
