ROCWARE RC15 User manual

ROCWARE RC15 Quick Start Guide
1 Product Appearance



2 Packing List
Name Quantity
Camera 1
Quick Start 1
3 Product Features
1080P Full HD Wide Angle
Support 1080P full HD, can provide 1080P@30fps/25fps image coding
output, and downward compatible with 720P equal resolution. Wide-angle
lens with wider field Angle.
USB 2.0
Full-featured USB 2.0 interface, power supply, video and audio all in one.
Built-in Microphone
Built-in microphone array with omnidirectional sound pickup, the unique
noise suppression algorithm makes your voice perfect presentation.
EPTZ
There is no need for mechanical transmission, which realizes more
accurate rotation, no noise, more reliable and durable pan-tilt function.
Low Illumination
The application of 2D and 3D noise reduction algorithm greatly reduces the
image noise. Even under the condition of ultra-low illumination, it keeps the
picture clean and clear, and the SNR of image is as high as 55dB.
Easy Installation
Standard damping bracket support, suitable for market 100% monitor, easy
installation, stable and reliable.
4 Product Specifications
Camera
Sensor 1/2.8'', CMOS, Effective Pixel: 2.07M
Scanning Mode Progressive
Lens Mount M12
Lens Focus: f=2.2mm
Minimal Illumination 0.5 Lux @ (F2.2, AGC ON)
Shutter 1/30s ~ 1/10000s
White Balance Auto, Manual
Camera bracket Standard Damping Rotary Support
Digital Noise
Reduction 2D&3D Digital Noise Reduction
Backlight
Compensation Support
Digital Zoom 4x
USB Feature
Operate System Windows 7/8/10, Mac OS X, Linux, Android
Color/Compression MJPEG/YUY2/H.264
Video Format
1080P@30fps/25fps, 720P@30fps/25fps,
960x540P@30fps/25fps,
640x360P@30fps/25fps
USB Communication
Protocol UVC 1.1
EPTZ Support Panning and Zooming
Input/Output Interface
USB Interface 1 x USB 2.0: Type A
Physical Parameter
Input Voltage 5V (USB power supply)
Input Current 0.27A
Operating
Temperature -10°C ~ 40°C
Storage Temperature -40°C ~ 60°C
Power Consumption 1.4W
Dimension 118mm x 37.2mm x 30.8mm (without bracket)
Net Weight 0.1Kg

The manual white balance, digital zoom, EPTZ and other functions can
only be realized by using an application with this function.

5 Safety Precautions
Careful Transportation
Transportation, custody and installation process to prevent heavy pressure,
violent vibration, immersion damage to the product.
Careful Installation
This product should be placed on the smooth desktop. The shell of the
product is an organic material and is strictly prohibited from contact with
any liquid, gas or solid material that may cause corrosion to the shell.
Do not Unauthorized Disassemble
This product has no parts which can be repaired by the user. The damage
caused by the user's own disassembly is not covered by warranty.
Electromagnetic fields at specific frequencies may affect image of machine.
6 Camera Installation
When the monitor thickness is less than or equal to 45mm, the mounting
method can be selected to mount the conference camera product on the
monitor. The specific installation is shown in the following figure:

7 Maintenance and Troubleshooting
Camera Maintenance
If the camera is not in long-term use, please disconnect the power
switch after use.
Use soft cloth or cotton paper to remove dust from the camera housing.
When cleaning the camera lens, please use dry soft cloth to wipe, if dirt
is serious, use neutral cleaner gently. Do not use strong or corrosive
detergent, lest the lens scratch, affect the image effect.
Avoid Using
Do not shooting particularly bright objects, such as sunlight, lights, etc.
Do not work under unstable lighting conditions, otherwise the image will
flash.
Do not use around facilities that can transmit high-power radio waves,
such as television station or radio-transmitting station.
Troubleshooting
Image jitters after the camera is properly connected
1) Check that the camera installed position is stable.
2) Check that any vibrating machinery or object near the camera.
8 Toxic and Harmful Substances
Part Name
Toxic or harmful substances or elements
(Pb) (Hg) (Cd) (CrVI) (PBB) (PBDE)
Metal x ΟΟΟΟΟ
Plastic ΟΟΟΟΟΟ
Glass x ΟΟΟΟΟ
Circuit board x ΟΟΟΟΟ
Power x ΟΟΟΟΟ
Attached x ΟΟΟΟΟ
This form is compiled in accordance with SJ/T 11364.
Ο: Indicates that the content of the hazardous substance in all
homogenized materials of the component is subject to the limit specified
in GB/T 26572.
x: Said the hazardous substance in at least one of the components
homogenized material content in excess of the GB/T 26572 limit
requirements, and there are no mature alternatives.
079.79.1101223_V1.0
