Roda RW11 User manual

A. LCD Panel Opened
1. Embedded Antennas (Optional):
GPS, WiFi/Bluetooth x 2
2. Embedded Mic
3. LED Indicators
(Please see “F”for details.)
4. Power Button
5. Touchpad
6. Touchpad Left and Right Button
B. Bottom View
1. Multi Bay Port
C. Right View
1. Battery pack
2. Optional 3rd~4th SATAII SSD
3. USB 2.0 x 2
4. Optional 2nd GLAN x 1
5. GLAN x 1
D. Left View
1. Audio/Line-in/Microphone
2. USB 3.0
3. USB 3.0 (USB Battery Charging)
4. Standard 1st SATAIII SSD
Optional 2nd SATAIII SSD
5. Battery pack
1
2
5
1
1
Recycled/Recycleable
Printed in Taiwan
P/N: G630110000
Quick Guide
Workstation Computer
RW11
12 3 4 5
3
4
6
2
3
4
5

E. Rear View
1. DC-In conn.(Military 2 pin conn.)
2. Display port
3. VGA port
4. Serial DB9 x 4
F. LED Indicators (Left to right)
1. Charging Indicator/Battery Low:
Orange/Flashing Orange
2. SSD/Heater Indicator (Dual LED):
Green (SSD)/Orange (Heater)
3. Power Indicator:
Green (Power)/Flashing Green (S3)
G. Connecting with AC Adapter
1. Insert the DC Jack to the end and lock the connector
well clockwise.
2. Plug the AC cord to the AC adapter.
3. Plug the AC cord to a right electrical outlet.
H. Turning ON the Power
1. Make sure the battery is mounted or power cords are
well connected for the stable power supply.
2. Now, you are able to turn ON the power of your
computer by pressing “Power Button”.
1
Note:
The power is able to be ON without
any battery mounted once all the
power cords are connected well.
Please see more information in
“User’s Guide”.
3
4
2
