ROHS QH-NVR User manual

Network Video Recorder User Manual

Network Video Recorder User Manual
i
Statement
Thank you for purchasing our product. If there is any question or
request, please do not hesitate to contact dealer.
This manual may contain several technical inaccuracies or
typographical errors, or places that do not match the product. If you
have any unsolved problems in the process of using product according
to this manual, please contact our technical support department.
The content of this manual may be updated at irregular intervals without
prior notice.
This manual is for reference only. NVR’s functions and operations with
different models may be different, please regard the actual product as
the truth.

Network Video Recorder User Manual
ii
Cautions
1. Please read this user manual carefully before using the NVR, and keep it
well for future reference.
2. Please avoid heavy stress or violent vibration.
3. Please transport, use and place the NVR in allowable temperature and
humidity range.
4. Please comply with all instructions and notice that all warning signs.
5. Please turn off the power until you're done with the installation.
6. Must observe all electrical safety standards; make sure the power supply
is correct before using the NVR.
7. To reduce the risk of fire or electrical shock, do not expose this product
near the heat, water or moisture.
8. Do not block any ventilation openings and provide good ventilation
around the machine.
9. If cleaning is necessary, use a clean, dry cloth and wipe it gently.
10. Please disconnect any cables during an electrical storm or the NVR will
not be used for an extended period of time.
11. If the product does not work properly, please contact your dealer or the
nearest service center. Never attempt to disassemble the NVR yourself.

Network Video Recorder User Manual
iii
Table of Contents
Chapter 1 Product Introduction ..................................................................................... 1
1.1 Overview................................................................................................................. 1
1.2 Main Features......................................................................................................... 1
1.3 Special Instructions................................................................................................. 5
1.4 Convention.............................................................................................................. 5
Chapter 2 Getting Started............................................................................................... 6
2.1 Open-package Check ............................................................................................. 6
2.2 Install Hard Drive..................................................................................................... 6
2.3 Front Panel Description........................................................................................... 7
2.4 Rear Panel Description ........................................................................................... 9
2.5 Remote Controller................................................................................................. 10
2.6 Control with Mouse ............................................................................................... 12
2.6.1 Connect Mouse.............................................................................................. 12
2.6.2 Use Mouse..................................................................................................... 12
2.7 Power On/Off ........................................................................................................ 13
2.7.1 Power On....................................................................................................... 13
2.7.2 Power Off....................................................................................................... 13
2.8 Login..................................................................................................................... 14
Chapter 3 Menu Setup Guide ....................................................................................... 15
3.1 Menu Item Functionality........................................................................................ 15
3.1.1 Live Preview................................................................................................... 16
3.1.2 E-Zoom.......................................................................................................... 17
3.1.3 PTZ Control.................................................................................................... 17
3.1.4 Live Playback................................................................................................. 18
3.2 Configuration Management................................................................................... 18
3.2.1 Basic Configuration........................................................................................ 19
3.2.1.1 System.................................................................................................... 19
3.2.1.2 Date & Time............................................................................................ 20
3.2.1.3 DST......................................................................................................... 21
3.2.2 Live Configuration.......................................................................................... 21
3.2.2.1 Main Monitor........................................................................................... 21

Network Video Recorder User Manual
iv
3.2.2.2 Spot ........................................................................................................ 22
3.2.2.3 Preview the permissions......................................................................... 23
3.2.3 Record Configuration..................................................................................... 23
3.2.3.1 Enable..................................................................................................... 23
3.2.3.2 Time........................................................................................................ 24
3.2.3.3 Recycle Record ...................................................................................... 25
3.2.4 Schedule Configuration.................................................................................. 25
3.2.4.1 Schedule................................................................................................. 25
3.2.4.2 Motion..................................................................................................... 26
3.2.4.3 Sensor .................................................................................................... 27
3.2.4.4 Reboot the System ................................................................................. 28
3.2.5 Alarm Configuration........................................................................................ 28
3.2.5.1 Sensor .................................................................................................... 28
3.2.5.2 Motion..................................................................................................... 30
3.2.5.3 Other Alarm............................................................................................. 32
3.2.5.4 Alarm Out................................................................................................ 32
3.2.6 Network Configuration.................................................................................... 34
3.2.6.1 Network................................................................................................... 34
3.2.6.2 Email....................................................................................................... 35
3.2.6.3 Wireless Network.................................................................................... 36
3.2.6.4 Other Settings......................................................................................... 36
3.2.7 User Management ......................................................................................... 41
3.2.8 Advanced Configuration................................................................................. 42
Chapter 4 Manage NVR................................................................................................. 43
4.1 Search and Playback............................................................................................ 43
4.1.1 Time Search................................................................................................... 43
4.1.2 Event Search ................................................................................................. 44
4.1.3 File Management ........................................................................................... 45
4.2 Backup.................................................................................................................. 46
4.3 View Information ................................................................................................... 47
4.3.1 System Information........................................................................................ 47
4.3.2 Event Information........................................................................................... 47
4.3.3 Log Information.............................................................................................. 47

Network Video Recorder User Manual
v
4.3.4 Network Information....................................................................................... 48
4.3.5 Online Users Information ............................................................................... 48
4.4 Manual Alarm........................................................................................................ 48
4.5 IPC Settings.......................................................................................................... 48
4.5.1 IPC Settings................................................................................................... 48
4.5.2 Stamp............................................................................................................. 50
4.5.3 Live ................................................................................................................ 51
4.5.4 Mask .............................................................................................................. 52
4.5.5 Record Bitrate................................................................................................ 52
4.5.6 Motion............................................................................................................ 53
4.5.7 PTZ................................................................................................................ 55
4.5.8 Instruction ...................................................................................................... 57
4.6 Disk Management................................................................................................. 57
4.6.1 Format Disk.................................................................................................... 57
4.6.2 Advanced....................................................................................................... 58
4.7 Upgrade ................................................................................................................ 58
4.8 Logoff.................................................................................................................... 58
Chapter 5 Remote Surveillance.................................................................................... 59
5.1 IE Remote Surveillance......................................................................................... 59
5.1.1 On LAN.......................................................................................................... 59
5.1.2 On WAN......................................................................................................... 60
5.2 Remote Live Preview............................................................................................ 62
5.2.1 PTZ Control.................................................................................................... 63
5.2.2 Preview Control.............................................................................................. 63
5.3 Remote Playback & Backup.................................................................................. 64
5.3.1 Time Search................................................................................................... 64
5.3.2 Event Search ................................................................................................. 66
5.3.3 File Management ........................................................................................... 67
5.3.4 Remote Backup ............................................................................................. 67
5.4 Remote Configuration & Management.................................................................. 68
5.4.1 Remote Configuration.................................................................................... 68
5.4.2 Remote Management..................................................................................... 68
5.4.3 Remote Query Information............................................................................. 69

Network Video Recorder User Manual
vi
Chapter 6 Mobile Surveillance ..................................................................................... 70
For Android................................................................................................................ 71
6.1 Main Functions...................................................................................................... 71
6.2 Installation............................................................................................................. 71
6.3 Application Running .............................................................................................. 72
6.3.1 Interface Description...................................................................................... 72
6.3.2 Live Preview................................................................................................... 74
6.3.3 Add Device..................................................................................................... 75
6.3.4 Switch Channel.............................................................................................. 76
6.3.5 PTZ Control.................................................................................................... 77
6.3.6 Local Video.................................................................................................... 78
6.3.7 Saved Photos................................................................................................. 79
6.3.8 Switch Language ........................................................................................... 79
6.3.9 Video Remote ................................................................................................ 79
6.3.10 Real-Time Alarm .......................................................................................... 80
For Iphone.................................................................................................................. 80
6.4 Main Functions...................................................................................................... 80
6.5 Installation............................................................................................................. 81
6.6 Application Running .............................................................................................. 81
6.6.1 Interface Description...................................................................................... 81
6.6.2 Live Preview................................................................................................... 83
6.6.3 Add Device..................................................................................................... 84
6.6.4 Switch Channel.............................................................................................. 85
6.6.5 PTZ Control.................................................................................................... 86
6.6.6 Local Video.................................................................................................... 87
6.6.7 Saved Photos................................................................................................. 88
6.6.8 Switch Language ........................................................................................... 88
6.6.9 Video Remote................................................................................................ 89
6.6.10 Real-Time Alarm .......................................................................................... 89
Appendix A FAQ ....................................................................................................... 90
Appendix B Calculate Recording Capacity ............................................................ 97
Appendix C Compatible Devices............................................................................. 98

Network Video Recorder User Manual
1
Chapter 1 Product Introduction
1.1 Overview
The new generation NVR (Network Video Recorder) is designed for high performance
digital surveillance. It adopts the embedded processors and embedded Linux system,
applies excellent encode chip and decode chip, and integrates many of the advanced
technologies, such as standard H.264 with low bit rate, embedded system technology,
large capacity hard disc storage technology, TCP/IP network technology, intelligent
technology, etc. Burning applications in FLASH can make the system more stable, images
clearer and function much more powerful. NVR is a networking device which based on
TCP/IP protocols, and accesses the digital video streams from video & audio capture
devices and alarm devices via an IP network to implement functions like preview, record,
playback, camera control, alarm, etc. NVR has a strong flexibility in building network video
surveillance system, and remotely managing devices via LAN or WAN.
It can work independently, can also be used for making up the powerful network
monitoring center, and widely used in bank, telecommunication, transportation, factory,
warehouse and other related applications.
1.2 Main Features
Configure IP channel
Support adding IP channel manually
Support adding IP channel by searching
Support modifying or deleting IP channel, and show the connection status
Preview
All channels use master stream when the preview screen is less than or equal to 4ch,
and use sub-stream when the preview screen is greater than 4ch
Preview screen can be divided into 16 windows
Support E-Zoom

Network Video Recorder User Manual
2
Support display mode selection, window drag, color adjustment, privacy mask, etc
The image of specified channel can be masked
Open or close the sound of live video
The volume of live video is adjustable
The resolution of VGApreview is adjustable
The main monitor supports dwell function, and the channel combination and dwell
time are configurable
Support SPOT output, the dwell time is configurable
The menu output device is selectable
Record
Standard H.264 video compression technology
Support dual stream
Support encoding with only video and video & audio (synchronous)
The video encoding parameters of each channel are adjustable
Support 1080P; frame rate (1-30(N)/1-25(P) fps), encode (VBR/CBR) and bitrate of
for recording are adjustable
Support OSD overlay (including camera name and time)
Support the recycle record and not overwrite after HDD full
Record modes: Manual, Schedule, Motion detection and Sensor alarm recording
Support setting a daily schedule with multiple periods
Support pre-recording
Playback
Support searching the video files by time, channel and type
Support instantly replaying the video within 5 minutes
Support the event search; double click an event file to playback
Use different color to mark the date which has video file in the calendar
Support the fast forward, rewind, single-frame play, pause and other playback control
Support the position playback by dragging the progress bar
Play the next video automatically after a video was played
Support locking the video files in the HDD
Open or close the sound of specified channel, its volume is adjustable
Backup
Select the backup files by channel and type

Network Video Recorder User Manual
3
Support batch backup
Show the progress during backup
The backup files are in .AVI format
Back up the data files by mobile HDD, USB disk.
Back up the data files by SATA DVD-ROM
Remote backup via network
Network backup supports backing up to. AVI format
Alarm
Support setting the detecting schedule of alarm input/ output
Support motion detection alarm, sensor alarm, disk full alarm, disk error alarm, disk
lost alarm, IP conflict alarm, network disconnection alarm, alarm output, etc
The area and sensitivity of motion detection are configurable
Support manual alarm
Linkage channel (optional) to record the video
Linkage channel (optional) to full-screen display
Linkage buzzer to buzz
Linkage mailbox to send notification email
Support alarm delay, the delay time is configurable
PTZ
Support accessing the IP PTZ
Control the direction (eight directions) of PTZ rotation
Zoom, focus and iris are adjustable
The rotational speed is adjustable
Support preset, patrol (cruise) and pattern (track)
Network
Support multi-user concurrent access
Support TCP/IP protocol stack: PPPoE, DHCP, DDNS, DNS, UPNP, HTTP, NTP,
SADP, SMTP, etc
Support disconnecting the access of network users on device
Built-in Web server
Disk Management
Support S.M.A.R.T function
Support formatting the HDD
