VP-770 Vocal & Ensemble Keyboard KC-880 Stereo Keyboard Amplifier
Expanding the Role of
the Keyboardist
High-Powered Performance for the Entire Band
Roland’s VP-550 introduced the world to a new
category of musician — the vocal keyboardist.
Today, the VP-550’s successor has arrived,
broadening the scope of the vocal
keyboardist. With the latest
technology onboard, the VP-770
allows a single musician to create
realistic backing parts that range
from futuristic electronic vocal
textures to incredible emulations of
large-scale gospel choirs and beyond.
The new flagship of the KC amp series is packed with high-performance
features. With five channels of stereo input, 320 watts of power and
Roland’s famous DSP effects built in, the KC-880 is a portable
powerhouse for keyboards, vocals, and more.
● New patches with significant improvements
to the Vocal Designer®
● Enhanced expression with
SuperNATURAL™-powered Brass
● High-quality headset microphone (DR-HS5,
included) significantly reduces feedback
● Premium mic preamps built in
● High-grade appearance with wood side
panels and metal chassis
● Flagship stereo keyboard amplifier with five
channels of stereo input
● 320-watt stereo power amplifier, 12-inch woofers
and two horn tweeters
● DSP effects (Reverb, Chorus, Tremolo, Rotary)
● Flexible I/O (XLR mic input, stereo XLR line outputs,
headphone out), Stereo Link for chaining multiple
KC-880s
■ DR-HS5 (Included)
DR-HS5 is a dynamic, head-worn microphone
optimized for the Vocal Designer features.The
hands-free design helps prevent feedback and
maximizes the ability of the Vocal Designer
functions during live performance.
VP-770 Specifications
■ Keyboard 49 keys (with velocity and channel aftertouch) ■ Tones Vocal Designer: CLASSIC,
MALE & FEMALE, GOSPEL, POP, BACKGROUND, VOCODER, EXT IN, Ensemble: SuperNATURAL
BRASS SECTION, SuperNATURAL SOLO BRASS, STRING SECTION, SOLO STRINGS, PAD1,
PAD2, CHOIR, JAZZ SCAT, Bass & Percussion: BASS1, BASS2, BASS3, PERC ■ Ambience HALL1,
HALL2, STUDIO ■ Maximum Polyphony 128 voices (varies according to the sound generator load)
■ Auto Harmony Function 6 types ■ Auto Note Function Chromatic, Diatonic (Key Assignable)
■ Audio Key Function File Format: WAV, AIFF (44.1 kHz, 16-bit linear), MP3 ■ Sound Looper
Function Maximum Recording Time: 18 Seconds, Recording Method: Overdubbing, Play Method:
Loop Play ■ Controllers D Beam Controller, Pitch Bend / Modulation Lever, Assignable Switches
(S1, S2), V-LINK Button ■ Octave Shift -3 to +3 Octarve ■ Key Transpose -6 to +5 (in semitones)
■ Number of Registration Memories 24 ■ Master Tune 415.3 Hz to 466.2 Hz ■ Nominal Input Level
INPUT (MIC): -50 to -10 dBu, INPUT (EXT IN): -36 to +4 dBu ■ Input Effects 3Band Equalizer,
Compressor, Noise Suppressor ■ Connectors Headphones Jack (Stereo 1/4 inch phone type),
Output Jacks A (L/MONO, R) (1/4 inch TRS phone type), Output Jacks B (L , R) (1/4 inch phone
type), Mic Jack: 1/4 inch phone type or XLR type (phantom power), External Input Jack (1/4 inch
phone type), MIDI Connectors (IN, OUT), Hold Pedal Jack, Expression Pedal Jack (1, 2), AC Inlet,
USB Memory Connector ■ Display 128 x 64 dots graphic LCD (with backlit) ■ External Storage
Device USB Flash Memory ■ Power Supply AC 115 V, AC 117 V, AC 220 V, AC 230 V, AC 240 V
(50/60 Hz) ■ Power Consumption 16 W ■ Dimensions 886 (W) x 369 (D) x 118 (H) mm / 34-15/16
(W) x 14-9/16 (D) x 4-11/16 (H) inches ■ Weight 11 kg / 24 lbs 5 oz ■ Accessories Owner’s Manual,
Leaflet “USING THE UNIT SAFELY”, Audio Key Utility 3 Quick Guide, CD-ROM Audio Key Utility
3), Hands-free Microphone DR-HS5, USB Memory Protector, Hex Wrench, Hex Screw, Power Cord
■ Options Keyboard Stand: KS-12, Pedal Switch: DP Series, Expression Pedal: EV-5
* 0 dBu= 0.775 Vrms
* The specifications are subject to change without notice.
KC-880 Specifications
■ Rated Power Output 320W (160W +160W) ■ Nominal Input Level (@1 kHz) CH1 (MIC/LINE):
-50–20 dBu, CH2–4 (LINE): -20 dBu, AUX IN/MONITOR IN: -20 dBu, STEREO LINK IN: 0 dBu
■ Nominal Output Level (@1 kHz) LINE OUT (XLR type, Phone type): +4 dBu, STEREO LINK OUT:
0 dBu ■ Speakers 30 cm (12 inches) Woofer x 2, Horn Tweeter x 2 ■ Controls <CHANNEL
CONTROL> CH1, Volume Knob, EFX Button, CH2, Volume Knob, EFX Button, CH3, Volume Knob,
EFX Button, CH4, Volume Knob, EFX Button, EFX Knob, SPEED Button <MASTER CONTROL>
AUX IN/MONITOR IN, LEVEL Knob, MUTE, SPEAKER Button, LINE OUT Button, EQUALIZER, LOW
Knob, MIDDLE Knob, HIGH Knob, PHONES VOLUME Knob, VOLUME Knob, POWER Switch, GND
LIFT Switch ■ Indicators EFX x 2, POWER ■ Connectors CH1 Input Connector (XLR type), CH1–4
Input (L/MONO, R) Jacks, (1/4” phone type), AUX IN/MONITOR IN: AUX 1 Input (L/MONO, R)
Jacks, (1/4” phone type), AUX 2 Input (L/MONO, R) Jacks, (RCA phono type), AUX 3 Input Jacks
(Stereo miniature phone type), PHONES Jack (Stereo 1/4” phone type), STEREO LINK OUT (L, R)
Jacks, (1/4” phone type), STEREO LINK IN Jack (1/4” phone type), LINE OUT (L, R) Jacks (1/4”
phone type), LINE OUT (L, R) Jacks (XLR type), FOOT SW Jack (TRS phone type) ■ Power Supply
AC 117 V, AC 230 V, AC 220 V, AC 240 V (50/60 Hz) ■ Power Consumption 98 W ■ Dimensions
734 (W) x 445 (D) x 590 (H) mm / 28-15/16 (W) x 17-9/16 (D) x 23-1/4 (H) inches (including casters),
734 (W) x 445 (D) x 536 (H) mm / 28-15/16 (W) x 17-9/16 (D) x 21-1/8 (H) inches (excluding casters)
■ Weight 44 kg / 97 lbs 1 oz ■ Accessories Owner’s Manual, Caster x 4
* 0 dBu= 0.775 Vrms
* The specifications are subject to change without notice.
■ Rear Panel
■ Front Panel
■ Top Panel
■ Rear Panel
■ Front Panel
