Roland Picza PIX-4 User manual

Thank you very much for purchasing the PIX-4.
• To ensure correct and safe usage with a full understanding of
this product's performance, please be sure to read through this
manual completely and store it in a safe location.
• Unauthorized copying or transferral, in whole or in part, of
this manual is prohibited.
• The contents of this operation manual and the specifications of
this product are subject to change without notice.
• The operation manual and the product have been prepared and
tested as much as possible. If you find any misprint or error,
please inform us.
USER'S MANUAL

For the USA
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE
STATEMENT
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated
in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference
to radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Unauthorized changes or modification to this system can void
the users authority to operate this equipment.
The I/O cables between this equipment and the computing
device must be shielded.
For Canada
CLASS A NOTICE
This Class A digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
CLASSE A AVIS
Cet appareil numérique de la classe A respecte toutes les
exigences du Règlement sur le matériel brouilleur du
Canada.
ROLAND DG CORPORATION
1-6-4 Shinmiyakoda, Hamamatsu-shi, Shizuoka-ken, JAPAN 431-2103
MODEL NAME : See the MODEL given on the rating plate.
RELEVANT DIRECTIVE : EC MACHINERY DIRECTIVE (98/37/EC)
EC LOW VOLTAGE DIRECTIVE (73/23/EEC)
EC ELECTROMAGNETIC COMPATIBILITY DIRECTIVE (89/336/EEC)

1
Windows®and Windows NT®are registered trademark or trademark of Microsoft®Corporation in the United States and/or other countries.
i486 and Pentium are registered trademarks of Intel Corporation in the United States.
AutoCAD®is registered trademark of Autodesk, Inc.
Mac OS, Macintosh, Power Macintosh, PowerBook, and AppleTalk are registered trademarks or trademarks of Apple Computer, Inc. in the USAand other
countries.
PowerPC is trademark of International Business Machines Corporation.
Copyright © 1999 ROLAND DG CORPORATION
Table of Contents
To Ensure Safe Use ..........................................2
About the Labels Affixed to the AC
Adapter and Unit .....................................4
Pour utiliser en toute sécurité ...................5
À propos des étiquettes collées
sur l’adaptateur AC et sur
l’appareil.......................................................7
Using PICZA (Some Examples of Actual Use) ............ 8
Creating elements for 3D computer graphics
software ..............................................................8
Adding 3D graphics to an internet web page .....9
Cutting a three-dimensional object with a
modeling machine ............................................ 10
1 Check the included items ....................................... 11
2 Part names.............................................................. 11
3 Setting up and connection...................................... 12
4 Installing the Dr.PICZA ......................................... 14
Symbols used in the section on software ......... 14
Overview of Dr. PICZA ................................... 14
Installing...........................................................15
5 Starting Dr. PICZA ................................................ 17
About Help ................................................. 17
6 Selecting a communication port ............................18
7 Powering ON ......................................................... 19
8 Load the object to be scanned on the PIX-4 ..........19
Maximum scanning area of the PIX-4 ............. 19
Load the object to be scanned on the PIX-4 ....20
9 Starting scanning....................................................22
About scanning conditions
and the scanning area ................... 22
Setting scanning conditions
and starting scanning....................22
Setting the scanning area ............................24
Rescanning a particular portion.................. 25
Cancels scanning/Pauses scanning .............25
10 Saving scanned data ..............................................26
Edit the scanned data ..................................26
11 Powering OFF........................................................26
When not in use ..........................................26
12 Ending Dr. PICZA .................................................27
13 Items that may not be copied................................. 27
14 What to do if... .......................................................27
15 Specifications ........................................................28

2
To Ensure Safe Use
Used for instructions intended to alert the user to the risk of death or severe
injury should the unit be used improperly.
About and Notices
Used for instructions intended to alert the user to the risk of injury or material
damage should the unit be used improperly.
* Material damage refers to damage or other adverse effects caused with
respect to the home and all its furnishings, as well to domestic animals or
pets.
About the Symbols
The symbol alerts the user to important instructions or warnings. The specific meaning of
the symbol is determined by the design contained within the triangle. The symbol at left means
"danger of electrocution."
The symbol alerts the user to items that must never be carried out (are forbidden). The
specific thing that must not be done is indicated by the design contained within the circle. The
symbol at left means the unit must never be disassembled.
The symbol alerts the user to things that must be carried out. The specific thing that must
be done is indicated by the design contained within the circle. The symbol at left means the
power-cord plug must be unplugged from the outlet.
Do not disassemble, repair, or
modify.
Doing so may lead to fire or abnormal
operation resulting in injury.
Do not use with any electrical power
supply that does not meet the
ratings displayed on the AC adapter.
Use with any other power supply may lead
to fire or electrocution.
Do not use with any power supply
other than the dedicated AC adapter.
Use with any other power supply may lead
to fire or electrocution.
Do not use with a damaged AC
adapter, power cord, or power-cord
plug or with a loose electrical outlet.
Use with any other
power supply may
lead to fire or
electrocution.
When not in use for extended
periods, unplug the AC adapter from
the electrical outlet.
Failure to do so
may result in
danger of shock,
electrocution, or fire
due to deterioration
of the electrical
insulation.
Do not use while in an abnormal
state (i.e., emitting smoke, burning
odor, unusual noise, or the like).
Doing so may result in fire or electrical
shock.
Immediately unplug the AC adapter from
the electrical outlet, and contact your
authorized Roland DG Corp. dealer or
service center.

3
Install on a stable surface.
Failure to do so
may result in
falling of the unit,
leading to injury.
Do not place hands near the main
unit while in operation.
Doing so may
result in injury.
Do not injure or modify the electrical
power cord, nor subject it to
excessive bends, twists, pulls,
binding, or pinching, nor place any
object of weight on it.
Doing so may
damage the
electrical power
cord, leading to
electrocution or fire. Do not allow liquids, metal objects
or flammables inside the machine.
Such materials
can cause fire.
Do not allow children to operate
without adult supervision or operate
within reach of young children.
Doing so may result in injury.
When unplugging the AC adapter
from the power outlet, grasp the
adapter unit or the plug, not the cord.
Unplugging by
pulling the cord
may damage it,
leading to fire or
electrocution.
Store clay out of the reach of
children. Do not attempt to unplug the AC adapter with wet hands.
Doing so may
result in electrical
shock.

4
: Indicates information to prevent machine breakdown or malfunction and ensure correct use.
: Indicates a handy tip or advice regarding use.
In addition to the and symbols, the symbols shown below are also used.
NOTICE
About the Labels Affixed to the AC Adapter and Unit
These labels are affixed to the body of this product and theAC adapter. The following figure describes the location. The
configuration of the AC adapter varies according to regional differences in voltage. Please note that the descriptions in this
manual are for the 117 V adapter.
Rating label
Do not use with any
electrical power supply
that does not meet the
ratings displayed on the
AC adapter.
When not in use for prolonged periods,
unplug the AC adapter from the electrical
outlet.
Front
Rear
Do not place hands
near the main unit
while in operation.
Model label

5
Utilisé pour avertir l'utilisateur d'un risque de décès ou de blessure grave en
cas de mauvaise utilisation de l'appareil.
Avis sur les avertissements
Utilisé pour avertir l'utilisateur d'un risque de blessure ou de dommage
matériel en cas de mauvaise utilisation de l'appareil.
* Par dommage matériel, il est entendu dommage ou tout autre effet
indésirable sur la maison, tous les meubles et même les animaux
domestiques.
À propos des symboles
Le symbole attire l'attention de l'utilisateur sur les instructions importantes ou les
avertissements. Le sens précis du symbole est déterminé par le dessin à l'intérieur du triangle.
Le symbole à gauche signifie "danger d'électrocution".
Le symbole avertit l'utilisateur de ce qu'il ne doit pas faire, ce qui est interdit. La chose
spécifique à ne pas faire est indiquée par le dessin à l'intérieur du cercle. Le symbole à
gauche signifie que l'appareil ne doit jamais être démonté.
Le symbole prévient l'utilisateur sur ce qu'il doit faire. La chose spécifique à faire est
indiquée par le dessin à l'intérieur du cercle. Le symbole à gauche signifie que le fil électrique
doit être débranché de la prise.
Pour utiliser en toute sécurité
Ne pas démonter, réparer ou
modifier.
Le non-respect de cette consigne pourrait
causer un incendie ou provoquer des
opérations anormales entraînant des
blessures.
Ne pas utiliser avec une alimentation
électrique autre que l’adaptateur AC
conçu à cet effet.
Une utilisation avec toute autre alimentation
électrique pourrait provoquer un incendie
ou une électrocution.
Ne pas utiliser avec une alimentation
électrique ne respectant pas les
caractéristiques indiquées sur
l’adaptateur AC.
Une utilisation avec toute autre alimentation
électrique pourrait provoquer un incendie
ou une électrocution.
Ne pas utiliser si l'appareil est dans
un état anormal (c'est-à-dire s'il y a
émission de fumée, odeur de brûlé,
bruit inhabituel etc.).
Le non-respect de cette consigne pourrait
provoquer un incendie ou des décharges
électriques.
Débrancher immédiatement l’adaptateur AC
et contacter votre agent agréé de la
compagnie Roland DG ou votre centre de
service.

6
Ne pas utiliser avec un adaptateur
AC ou un fil électrique endommagé
ou avec une prise électrique qui a du
jeu.
Une utilisation avec
toute autre
alimentation électrique
pourrait provoquer un
incendie ou une
électrocution.
Quand l’appareil reste inutilisé
pendant plusieurs heures,
débrancher l’adaptateur AC.
Le non respect de
cette consigne
pourrait causer des
risques de décharges
électriques,
d’électrocution, ou
d’incendie dus à la
détérioration de
l’isolation électrique.
Ne pas endommager ou modifier le
fil électrique. Ne pas le plier, le
tordre, l'étirer, l'attacher ou le serrer
de façon excessive. Ne pas mettre
d'objet ou de poids dessus.
Une négligence à
ce niveau pourrait
endommager le fil
électrique ce qui
risquerait de
provoquer une
électrocution ou un
incendie.
Lorsque vous débranchez
l’adaptateur AC, saisir et tirer le bloc
adaptateur et non le fil électrique.
Débrancher en tirant sur le fil pourrait
l'endommager et risquer de provoquer un
incendie ou une électrocution.
Ne pas débrancher l’adaptateur AC
avec des mains mouillées.
Une négligence à
ce niveau pourrait
provoquer des
décharges
électriques.
Ne pas introduire de liquide, d'objet
métallique ou inflammable dans
l'appareil.
Ce genre de
matériel peut
provoquer un
incendie.
Installer l’appareil sur une surface
stable.
Une négligence à
ce niveau pourrait
provoquer la chute
de l’appareil et
entraîner des
blessures.
Ne pas placer vos mains près de
l’unité principale pendant son
fonctionnement.
Le non respect de cette consigne pourrait
causer des blessures.
Ne pas laisser des enfants faire
fonctionner l’appareil sans la
surveillance d’un adulte ni laisser
l’appareil en fonctionnement à la
portée d’enfants en bas âge.
Une négligence à ce niveau pourrait
provoquer des blessures.
Ranger la pâte hors de la portée des
enfants.

7
Nom du modèle
À propos des étiquettes collées sur l’adaptateur AC
et sur l’appareil
Ces étiquettes sont collées sur le corps de l’appareil et sur l’adaptateur AC. Le dessin suivant indique leur emplacement. La
configuration de l’adaptateur AC varie selon les différences de voltage régionales. Veuillez noter que les descriptions dans ce
manuel correspondent à un adaptateur de 117 volts.
Étiquette des
caractéristiques électriques
Ne pas utiliser avec une
alimentation électrique ne
respectant pas les
caractéristiques indiquées sur
l’adaptateur.
Quand l’appareil reste inutilisé pendant
une longue période, débrancher
l’adaptateur AC.
Avant
Arrière
Ne pas placer vos
mains près de
l’unité principale
pendant son
fonctionnement.

8
Using PICZA (Some Examples of Actual Use)
This section presents some actual examples of how PICZA can be put to use.
Creating elements for 3D computer graphics software
Dr. PICZA offers a function for exporting files in three-dimensional DXF format (AutoCAD®Release 12 format). This section explains
how to use a commercially available 3D computer-graphics software application that can import DXF-format files to create your own
original illustrations. (This product does not include 3D computer-graphics software, which must be obtained from another source.)
1Visualize in detail the design illustration you wish to create. In this
example, we'll make the illustration shown below. 2Create the elements that make up the
illustration. In this example, we'll use
the clay included with the product to
make the face, and the graphics
software to make the other element
(the pyramid).
3Scan the clay face and export the data
in DXF format. 4Launch the 3D graphics application
and import the DXF file. Make the
pyramid and arrange the face and the
pyramid using the layout shown below.
Use the 3D graphics software to color the illustration, then
print it out.
5
DXF-format file

9
Adding 3D graphics to an internet web page
Dr. PICZA comes with a function for exporting files in VRML format (Ver.1.0). VRML (Virtual Reality Modeling Language) is a
language used to display 3D graphics on the World Wide Web, where they can be viewed using a web browser capable of displaying
VRML files. Color data from Dr. PICZA is also preserved in these VRML files. In this example, we'll add the image of a original fishing
lure scanned with the PIX-4 to a web page. (This product does not include a web browser or web-page authoring software, which must be
obtained from another source.)
1Set the lure in place on the workpiece table and scan it with the PIX-4.
In this example, we'll scan only one side of the lure, and use Dr.
PICZA's [Add Backside Faces] function to make a complete three-
dimensional representation. 2Use Dr. PICZA to color the scanned data.
(For details on adding color, please refer to
the help screens for Dr. PICZA.)
3Under [File] - [Preferences...], click
[Add Backside Faces] to turn it on,
then export the data in VRML format.
4VRML files can be opened and viewed with a
web browser that supports the VRML format.
By adding a link to a VRML file from a web
page, you can also display the VRML file on
the World Wide Web. (For details on how to
do this, please refer to the documentation for
your web-page authoring software or a third-
party guide to HTML.)
VRML-format file

10
1Get a suitable leaf from a tree, and
press it into a piece of clay to transfer
the image of the leaf to the clay. 2Set the piece of clay on the workpiece table and scan it with
the PIX-4.
3Use [Edit] - [Invert] to invert the
scanned shape, then export the data to
MODELA PLAYER.
4Use MODELA PLAYER to cut the shape on the
MODELA. 5Color the cut object.
Before inversion
After inversion
Export to
MODELA
PLAYER
Cutting a three-dimensional object with a modeling machine
Dr. PICZA has a function for exporting data to MODELA PLAYER. MODELA PLAYER is software for cutting three-dimensional
objects on the MODELA, CAMM-3, or CAMM-2, three-dimensional modeling machines made by Roland DG Corp. Dr. PICZA can
output 3D data directly to MODELA PLAYER. In this example, we'll use the MODELA in combination with Dr. PICZA to make a
paperweight in the shape of a leaf. The explanation assumes that you already have the MODELA installed and set up.

11
Dr.PICZA for Windows
disks: 2
1 Check the included items
AC adapter: 1 The configuration of the AC
adapter varies according to
regional differences in voltage.
Please note that the descriptions in
this manual are for the 117 V
adapter.
Dr.PICZA for Mac OS
disk: 1
Do not attempt to move the table by hand.
Do not put the hands inside the unit.
Doing so may result in breakdown
of the unit.
NOTICE
2 Part names
Sensor
This remains inside the cover
except during scanning.
Serial connector
AC adapter jack
Table
The grid on the table serves as a guide for mounting the
object to scan.
It does not indicate the scanning area for Dr. PICZA.
The scale is in 10-mm (about 3/8 in.) units.
Clay: 1 PIX-4 User's manual: 1
Do not put
hands inside.
STANDBY key
STANDBY
LED

12
3 Setting up and connection
Do not use with any power supply
other than the dedicated AC adapter.
Use with any other power supply may lead
to fire or electrocution.
Do not use with any electrical power
supply that does not meet the
ratings displayed on the AC adapter.
Use with any other power supply may lead
to fire or electrocution.
Install on a stable surface.
Failure to do so
may result in
falling of the unit,
leading to injury.
Use within a temperature range of 5 to 40°C (41 to 104°F) and within a humidity range of 35 to 80%.
Securely connect the power cord, computer I/O cable and so on so that they will not be unplugged and cause
failure during operation. Doing so may lead to faulty operation or breakdown.
NOTICE
When you carry the PIX-4, use two hands to
securely grip this area on the left and right sides.
Never install this unit in any of the following situations, as it could result in damage:
Places where the installation surface is unstable or not level.
Places with excessive electrical noise.
Places with excessive humidity or dust.
Places with poor ventilation, because the PIX-4 generates considerable heat during operation.
Places with excessive vibration.

13
AC adapter jack
For IBM PC or PC compatible For Macintosh
Serial connector
Use a commercially available Phillips screwdriver to
tighten the screws at either end of the serial cable.
Crossover serial
cable
Included AC adapter
Printer port
Modem port
Connect to either port.
Serial connector Crossover
serial cable
(for Macintosh)
Screw Screw
• During scanning, the table moves forward and backward. If the mounted scan object (the three-dimensional object to be scanned) is
larger than the table size, it may extend beyond the front and rear of the unit. Do not place any objects in the area.
• For the cable, use a commercially available crossover serial cable (RS-232C rating). A straight serial cable such as is commonly used
to connect a modem cannot be used. For more on how to connect a serial cable for Macintosh, see "15 Specifications -- Serial Cable
for Macintosh."
• Make sure the power to the computer and the PIX-4 is switched off before attempting to connect the cables.
Freeing the table
Before using the unit, remove the screw
and the retainer shown in the figure. The
table does not move if it remains secured
in place by the retainer.
1
Attach the retainer in the orientation
shown in the figure, and tighten the
screws.
* The screws and retainer are necessary
when repacking the unit. Do not
discard them.
2
1)
2)
Screw
Retainer
Screw

14
4 Installing the Dr.PICZA
Symbols used in the section on software
When the procedures for Windows and for the Mac OS are different, both are described. When the procedures are similar, the explana-
tions use the screens for the Windows version. In such cases, the screen images may differ from those for the Mac OS version, but the
procedures do not change.
Overview of Dr. PICZA
A Quick Overview of Available Functions Toolbar button
View scanned 3D data from various angles
Zoom in or out on the on-screen view of scanned data
Make settings for how scanned 3D data is displayed
Color the faces of scanned 3D data
Adjust the slant of scanned 3D data
Specify the data format and save the scanned 3D data
Launch the MODELA PLAYER
Set scanning conditions and perform scanning
Edit scanned 3D data
Displays the coordinates of the scanned object
* For details, please refer to the help screens for Dr. PICZA.

15
Installing
Dr.PICZA for Windows
Personal computer running Windows 95, Windows 98, or Windows NT 4.0
If you're using Windows 95: i486SX or better (Pentium 100 MHz recommended)
If you're using Windows 98 or Windows NT 4.0: i486DX or better (Pentium 100 MHz recom-
mended)
If you're using Windows 95: 8 MB or more (10 MB or more recommended)
If you're using Windows 98 or Windows NT 4.0: 16 MB or more (32 MB or more recommended)
3 MB or more of free space
Setting Up the Windows Version of the Program
Operating environment
Computer
CPU
System Memory
Hard Disk
Setup
* When setting up the software under Windows NT 4.0, log on as the member of a group other than [Guest].
Hard disk : C
Floppy-disk drive : A * If your drive-name assignments differ from the ones shown at left, make the appropriate changes.
Switch on the computer and start Windows.
1
2Insert the Dr. PICZA for Windows disk 1/2 included with the unit.
Double-click on the [My Computer] icon on screen.
3Double-click on the [3-1/2 Floppy] icon. 4

16
Double-click on the [setup.exe] icon.5
This starts the setup program. Follow the messages to carry out setup.
For MODELA PLAYER, at the screen for selecting the machine,
make the setting for the Roland DG Corp.'s modeling machine you're
using.
Setting Up the Mac OS Version of the Program
Operating environment
Dr.PICZA for Mac OS
A Power Macintosh, or PowerBook with a PowerPC processor.
Mac OS 7.5 or higher
20 MB or more (40 MB or more recommended)
3 MB or more of free space
Computer
System
System Memory
Hard Disk
Setup
Double-click the disk icon.3Double-click the [Read Me] icon and read the file.
When you're finished reading, open the [File] menu
and choose [Quit].
4
Turn off any virus-detection software.
1
2Insert the Dr. PICZA for Mac OS disk in the disk drive.
Double-click the Installer icon.
5When the Installer's start screen appears, click [Con-
tinue...].
6
Choose where to install the program and click [Install].
Installation starts.
7When installation finishes, click [Quit].8

17
5 Starting Dr. PICZA
About Help
If you're unsure how perform an operation while you're working, taking a look at Help can find the answer. If you're using Dr. PICZA
for the first time, please be sure to read the Help screens. You can call up Help from the software menus.
For Dr. PICZA for Windows OS
Press the Start button
and select [Dr.
PICZA].
For Dr. PICZA for Mac OS
For Dr. PICZA for Windows OS For Dr. PICZA for Mac OS

18
Select the port where the cable is connected, then click
[OK].
2
For Dr. PICZA for Mac OS
Press the File button and select [Preferences...].1
Click either one or the other
If Dr. PICZA selects the same communication port as
AppleTalk, the scanning cannot be processed. In
this case, please change the setting of Dr. PICZA so
as to use another port. Or, disable the AppleTalk.
6 Selecting a communication port
From the [File] menu, click [Settings].
1Select the port where the cable is connected, then click
[OK].
2
For Dr. PICZA for Windows OS
If You're Using Windows NT 4.0
If the printer port for Windows driver and the communication port for Dr. PICZA are
set to the same port, you cannot use Dr. PICZA.
To perform scanning, specify an unused port for the Dr. PICZA communication port.
