Roland’s most powerful onstage workstation also has unrivalled studio- and
music-production capabilities. The ability to switch between modes optimized
for stage or studio means, from sound source and effects through to
operation control, you are always instantly prepared in either environment.
The Fantom-G is also the first electronic musical instrument to provide
SuperNATURAL™sounds via ARX-series expansion boards. Explore a new
dimension of musical creativity with the Fantom-G live workstation.

■Choose from five different modes that
change the behavior of the pitch bend
lever. Opens new possibilities to
expressive keyboard performance!
■Arpeggio and Chord Memory
controls enable a wide variety of
playing techniques
■152-track sequencer: 24 stereo
audio tracks, 128 MIDI tracks ■Coaxial digital audio in/out
■Standard / XLR combo jacks for audio recording; condenser
mics and guitar or bass can be directly connected
■Onstage and in the studio, the Fantom-G instantly
brings your favorite real-time controller assignments
to your fingertips with each patch
■PHA II Ivory Feel keyboard (Fantom-G8)
Fantom-G6 and -G7 feature flagship
synth-action keyboard
■Powerful wave source system with a stunning
collection of newly developed sounds
■Highly refined sampling functions
outperform dedicated sampling units
■All fundamental built-in sounds have been significantly
upgraded, including the stereo multi-sampled 88-key piano
■V-LINK capability provides a new visual dimension you
can control in real time during live performance
■The luxurious wide-format 8.5-inch color VGA TFT-LCD monitor significantly eases workflow
■Three modes – LIVE, STUDIO, and SINGLE – optimize
the instrument for specific playing environments
■The Favorite function lets you immediately
recall settings for live performance
■New soundsets with dedicated programming and effects
engines on each ARX-series SuperNATURAL™expansion board
■The jog dial and front-panel controls let you quickly
and easily get on with the process of music creation ■Stylish, slim-line aluminum body,
high-quality components
■Whether you’re performing live or creating music in a studio,
the 16-key dynamic pad is a convenient and powerful tool
■Skip Back sampling function lets you instantly capture
improvised playing before it gets lost in the moment
■USB memory port for fast, convenient storage
and retrieval of project data
■Compatible with USB two-button wheel
mouse (sold separately) for ultra-fast editing
■USB audio and MIDI compatibility for complete
compatibility with DAW applications
■Compatible with sounds edited using VSTi
and AU tools via computer.
Librarian software also supplied
■Multi-effects can be applied to
single sounds; simultaneous
use of up to 22 effects
   

1
ARTISTS'
IMPRESSIONS
ARTISTS'
IMPRESSIONS
■Profile
There are few artists who came to prominence in the eighties who
are as prolific and hard working as Howard Jones. He seems to be
constantly out on tour or creating diverse and superbly crafted
albums in his studio in Somerset England. In 2007 alone he released
3 albums and played over 60 concerts around the world including
UK, USA, Australia, Denmark, Sweden, Italy and Dubai.
Howard signed to WEA records in 1983 and had a string of hits
including 'New Song', 'What is Love', 'Hide and Seek', 'Like to Get To
Know You Well', 'Pearl in the Shell', 'Things Can Only Get Better', 'Life in
One Day', 'Look Mama', 'Everlasting Love' and 'No One is To Blame'. To
date Howard has sold over eight million albums.
Recently most of Howard's concerts are acoustic where he uses his
superb ability as a songwriter combined with his well honed skills as a
piano player to great effect. This is interspersed with the occasional
electric show which sees him performing at the very cutting edge of
technology.
This is not a tweak of the
Fantom series but no less than a major
evolution of electronic keyboards. The hi res large
screen presents information in a rich and exciting
graphic way, like we are used to on our studio
computers but with the bullet proof Roland reliability
that you can be confident of on the road.
A colossal new sound engine has been
developed for the Fantom-G series, with
double the wave capacity of the
predecessor. The acclaimed stereo
multi-sampled 88-key piano sound of the
Fantom-X has been resampled and
improved for the Fantom-G. Potent
upgrading extends to synth, drums, bass,
strings, and other fundamental sound sets
Sound Engine
For Live Performance
Immense potential consolidated
in a single live workstation
LIVE mode organizes sound sources and effects for incredible ease and convenience on stage. Using
8-part multi-timbral mode, you can freely adjust settings for layers and splits, maximizing expression
onstage. The high quality of the sound sets give you a radically refreshed stage sound, while the
new-generation keyboard action and SuperNATURAL™expansion sets gives you the musical palette
for newfound expressiveness. Every feature of the Fantom-G has been designed to completely
revitalize your live performance!
as well. The new wind-instrument sounds,
such as flute and oboe, are particularly
expressive. In LIVE mode you can use eight
independent parts to freely create layers
and splits. While playing live, with the Patch
Remain function, sound release and effects
are seamless. All you desire for expression
during live performance is fully supported
right from the sound source.
High-quality, expressive sounds provide new impact
■Patch Pro Edit Screen ■Patch Zoom Edit Screen ■Sample Edit Screen
■Patch List Screen
Howard
Jones
Howard
Jones

SuperNATURAL™Expansion Board ARX Series New Keyboard System
