  9. Rolls RM65 6 x 4 User manual

Rolls RM65 6 x 4 User manual

ROLLS RM65 6 x 4 MIXER
The new ROLLS RM65 6 x 4 mixer is a breakthrough in size/performance for
an au io mixer, it is a full function 6 channel mixer in a single space 19" rack
chassis. It is inten e for soun reinforcement, stu io, choir, an other
applications where high channel to size ratio is esirable. The RM65 is in-
ten e for professional applications an has sockete IC's, ouble si e
circuit boar an painte steel chassis. It has 6 XLR microphone an 6 1/4"
line inputs. The mic inputs have in ivi ual 36V phantom power switches an
input gain trims locate on the rear panel.
FEATURES
 Full function 6 channel console mixer in 1 rack space
 6 XLR mike inputs an 6 1/4" line input jack
 36 Volt Phantom Power
 In ivi ual phantom power switches for each XLR
 Input gain trim control for each mic input
 Clip in icators for each channel
 Monitor, effects sen an Pan pots on each channel
 Treble an Bass tone controls for each channel
 R & L Master volumes an FX Return master channel
 Stan ar 19" x 1.75 EIA rack chassis
SPECIFICATIONS
Input Impe ance: 600 9 balance
50K 9 unbalance (1/4")
Output Impe ance: 50 W TRS Balance
Max Input Level: -15 BV XLR 600 W
+18 BV 1/4"
Phase Shift: < 10 eg. 20 Hz - 20 kHz
Input Connectors: XLR an 1/4"
Phantom Power: 36 Volts DC
Outputs: 1/4" main balance +17 B max
1/4" monitor +17 B max
1/4" FX sen
Max Gain: (Mains) 60 B mic
26 B line
(Monitor) 55 B
Tone controls: 20 B treb, bass cut/boost, 400 Hz center
Max S/N Ratio: 106 B
THD < .003%
IMD (SMPTE) < .003%
CMRR 52 B
Power 120 VAC 50-60 Hz, 15 W
Weight: 7 lbs (3KG)
Size: 19" x 1.75" x 6.5" (48cm x 4.5cm x 17cm)
ROLLS Coporation 8/97
5143 South Main Street, Salt Lake City, UT, 84107
(801) 263-9053 FAX (801) 263-9068
[email protected] • www.rolls.com
CHANNEL 1
MIC
LINETRIM
CHANNEL 2
MIC
LINE
TRIM
CHANNEL 3
MIC
LINE
TRIM
CHANNEL 4
MIC
LINE
TRIM
CHANNEL 5
MIC
LINE
TRIM
CHANNEL 6
MIC
LINE
TRIM
PHANTOM
POWER
AUX
BUSS IN
FX
SEND
FX
RETURN
MONITOR
OUT
RIGHT
OUT
LEFT
OUT
MODEL RM65
120 VAC
50/60 Hz 15 VA
SERIAL NUMBER
65-
MADE IN U.S.A.
WARNING
:
DO NOT EXPOSE THIS EQUIPMENT TO RAIN
OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT NOT REMOVE BACK.
NO USER SERVICABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISQUE DE CHOC - NE PAS ENLEVER
C US
FX
SEND
PANTREBLE
BASS
MONITOR
010 010-+-+LR
FX
SEND
PANTREBLE
BASS
MONITOR
010 010-+-+LR
VOLUME
VOLUME
CLIP
CLIP
FX
SEND
PANTREBLE
BASS
MONITOR
010 010-+-+LR
FX
SEND
PANTREBLE
BASS
MONITOR
010 010-+-+LR
VOLUME
VOLUME
CLIP
CLIP
FX
SEND
PANTREBLE
BASS
MONITOR
010 010-+-+LR
PWR
+17
+8
0
-4
-13
LEFT RIGHT
EFFECTS
RETURN
MASTERVOLUME
FX
SEND
PANTREBLE
BASS
MONITOR
010 010-+-+LR
VOLUME
VOLUME
CLIP
CLIP
RM65 Professional
Audio Mixer

This manual suits for next models

1
