ROODER Mangosteen M6 User manual

1. Product Overview..........................................................................02
2. Notes for Safe Riding....................................................................03
3. Description of Components...........................................................04
4. Key and Remote Control...............................................................05
5. Battery and Charger.......................................................................06
6. Troubleshooting.............................................................................10
7. Maintenance and Servicing............................................................12
8. Basic Parameters............................................................................14
9. After-sales Service.........................................................................16
Table of Contents
01
Please read this manual carefully! This product operation manual contains safety precautions for the vehicle!
Please do not use an electric two-wheeled motorcycle without fully understanding its performance!
Please keep this product operation manual properly!
Product Operation Manual
M O D E L˖M 6

0302
Thankyou for purchasing M6 electric two-wheeled scooter,which is hereinafter referred to as M6.
Pleaseread this manualcarefully before riding and keep it properly.Pleasedo not ride the M6 without knowing its performance .Pleaseread
carefullytheimportantsafetyprecautions in this manual. Please abideby local lawsandregulations duringtheride and ride safely.
1 Product Overview 2 Notes for Safe Riding
·Please read this product operation manual carefully. Please do not use an electric two-wheeled motorcycle without fully understanding its
performance.
Please obey the traffic laws and regulations. Don't go in a direction not allowed by traffic regulations, run a red light, etc. Don't use your·
mobile phone while riding.
Please do not use the third-party accessories or disassemble, crack or modify without permission. The loss caused by this will be borne by·
you and you will lose our warranty commitment.
As the product is constantly improved, the vehicle you purchased may be slightly different from the one in this manual. Please refer to the·
actual vehicle. If you have any questions about the usage, repair and installation of the vehicle, please contact our dealer or after-sales
service center.
For the safety of you and others,please read the following contents carefully:
Riders shall abide by traffic laws and regulations and take care to ride safely
Before riding, please carefully read the Product Operation Manual and check whether all parts and components are in good condition to·
ensure your riding safety. If any problem is found, please contact the dealer or after-sales service center in a timely manner.
To ensure your safety, please wear safety helmet, gloves and other protective equipment during riding. .Please do not wear loose clothing,·
as it will make you uncomfortable and unsafe while riding.
You should be in good health and not tired so that you can control the vehicle in good condition. Riding is prohibited after taking drugs or·
drinking alcohol.
This vehicle is not restricted under the rain and snow weather, but cannot excessively wade through the water. Wading through the water·
forcibly when the water level exceeds 10 cm depth may cause short circuit of electrical components and circuits of the vehicle, please be
sure to pay attention!
Please observe the traffic laws and regulations. Please slow down in rain, snow and slippery areas. Please increase the braking distance when·
braking to ensure safety .
Please do not disassemble the parts and components by yourself.·
Riders shall abide by traffic laws and regulations and take care to ride safely
Do not park electric motorcycles in building foyers, evacuation stairs, walkways and emergency exits;·
Do not charge and park the electric motorcycle in the residential building. When charging, the electric vehicle shall be far away from·
combustibles, and charging time shall not be too long.

0504
4QFFEEJTQMBZ
%SJWJOHNPEF
4UBOEBSENPEF
&DPOPNJDNPEF
4QPSUNPEF
3FWFSTF %SJWJOHCFBN
%JSFDUJPOJOEJDBUPSUFMMUBMF- %JSFDUJPOJOEJDBUPSUFMMUBMF3
3FBEZ
#BUUFSZVOEFSWPMUBHF
#BUUFSZTUBUVTDBQBDJUZ
%SJWJOHCFBN
1BTTJOHCFBN
.JMFBHF
)BOEMFXBSOJOH3FE &MFDUSJDNPUPSDPOUSPMVOJUXBSOJOH3FE &MFDUSJDNPUPSXBSOJOH3FE
-FGUEJSFDUJPOJOEJDBUPS
)PSO
3JHIUEJSFDUJPOJOEJDBUPS
4IJGU

4
3 Description of Components
Indicator light
It will light up when any key of the remote control is pressed, indicating
that the remote control is working properly.
Note: Before using the remote control, please ensure that the battery has
been properly installed in the vehicle body, and that the straight-line
distance between the remote control and the vehicle should be less than 50
m.
Unlock key
Press this key to release the alert mode.
Vehicle search key
After pressing the vehicle search key, the vehicle lighting system will be on,
indicating the location of the vehicle.
9 Lock key
When the ride is over, press the lock key and the car will be locked.
Remote control
4 Key and Remote Control

0706
Battery operation instructions
The vehicle will provide you with two ways of battery charging and body charging for you to choose.
External charging mode
Take out the battery and insert the charging plug of the charger into the battery charging port
for external charging. At this point, the battery's electric quantity indicator light will light up.
V ehicle charging mode
Put the battery into the battery holder, connect the power plug to the battery, and then insert the
charging plug of the charger into the vehicle body charging port in the seat cask to charge the
whole vehicle.
Description of the battery's electric quantity indicator light
In the charging state, it displays how much electric quantity the battery has. When the vehicle is fully charged, all the indicator lights will stay on and no
longer blink.
In the non-charging state, if you press the electric quantity display key:
5 Batteryand Charger
·Under normal conditions, the indicator light will display the electric quantity in the battery.
·If the electric quantity in the battery is less than 20%, a section of indicator light will remind you to charge.
·When the vehicle is fully charged, the charger will appear green, indicating that it has been fully charged.
·Before use, please confirm that the battery is the original battery of the whole vehicle. Please do not use batteries of other brands or other models.
Check whether the appearance of the battery is in good condition and ensure that there is no damage, leakage, heat generation, water immersion,
smoke and other obvious phenomena.
In order to ensure the safety of transportation, the battery's ex-factory electric quantity is about 30%. It is a normal phenomenon that there is low or
no electric quantity when it is used for the first time due to the electric quantity consumption factors such as transportation and storage period.
Please do not worry and just charge it according to the charging instructions.
The used batteries shall not be disassembled without authorization and shall be returned to the relevant professional departments for recycling and
disposal.
Use environment
Please use the battery at
-10°C-45°C
Please keep the battery from
getting wet with water, beverages
and corrosive liquids
Please keep the battery away from
heat source, openfire, fl ammable
and explosive gases (liquid).
Please prevent metal foreign
matters from entering the battery
compartment
At low temperature, the available capacity of the battery will experience attenuation to different degrees. Specific reference degrees are as follows: The
available capacity is 70% at -10°C, 85% at 0°C, and 100% at 25°C. If the battery smells, heats up, distorts and has other abnormal conditions,
please stop using it immediately, stay away from the battery and contact the after-sales department.
A Battery is not a part that can be repaired by users. If there is any abnormal phenomenon, please contact the after-sales department for maintenance.
Users who disassemble the battery without permission will not enjoy the policy of "three guarantees", and unauthorized disassembly may cause the
battery to produce heat, smoke, fire or explosion.
Instructions before battery use
%FUBJM
*EFOUJDBUJPOOVNCFSQPTJUJPO
*EFOUJDBUJPOOVNCFSQPTJUJPO.(4%

0908
Please use the original charger matching with
the battery for charging, and do not use a
charger of other brands or models for charging.
Please charge the battery at an ambient
temperature of 0°C-35°C.
Do not charge for more than 12 hours, so as not
to affect the battery life.
·In the early stage of charging, the electric quantity will rise quickly, but in the later stage, it will rise slowly, which is the procedure set for charging
safety and is a normal phenomenon.
·During charging in winter, when the outdoor temperature is low and the environment is below 0P, the battery charging will stop, which is a normal
phenomenon. Please place the battery at an appropriate ambient temperature for charging to ensure the charging effect.
·During the charging process, some aluminum case chargers have temperature rise effect and higher surface temperature, which is normal. Please
feel free to use. Please be careful to avoid the touch of children.
Notes for charger use
·The charger can only be used indoors.
·Charging in confined space or under hot sun or high temperature is strictly prohibited; do not put the charger in the seat cask or tail box for
charging.
·When charging, you should first plug in the battery, then add the power supply; when the vehicle is fully charged, you should cut off the power
supply first and then unplug the battery.
·When the green light is on, the power shall be cut off in time. Do not connect the charger to the AC power without load for a long time without
charging.
·During the charging process, if there is any abnormality or peculiar smell in the indicator light or overheating of the charger case, stop charging
immediately and repair or replace the charger.
·It is prohibited to disassemble or replace the components of the charger by yourself.
·The charger shall be replaced to match the battery model.
Charging environment Charging environment
·If the battery is placed on the vehicle, the work of the intelligent system and alarm system of the vehicle will consume the electric quantity of the battery in real
time. After the vehicle is placed for a period of time, the meter will display the decrease of the electric quantity, which is a normal phenomenon. In general, if the
vehicle is parked for 8 hours, the electric quantity of the battery will be consumed by about 5%, which is a normal phenomenon.
·Please store the battery at an ambient temperature of 0°C - 25°C. Please do not store the battery in an environment higher than 40°C, otherwise the battery will
experience irreversible capacity attenuation.
·For vehicles that are not in use for a long time (such as in winter, summer or other special circumstances), the battery shall be taken out for separate storage and
maintained and charged regularly, or the battery may be completely depleted and irreversibly damaged. Battery failure caused by such problems will not be
included in the range of "three guarantees".
·For the battery, the most appropriate storage capacity is 50%. If it is lower than 10% or higher than 90%, long-term storage will lead to irreversible capacity
attenuation of the battery.
·For the lithium battery, the technical standards of the electric quantity consumption protection mode for safe storage are as follows:
(1) If it is not used for a long time and stored on the vehicle (without unplugging the battery), the safety period shall be at most one month, otherwise the
battery feed may occur and the problem cannot be repaired.
(2) If it is not used for a long time, the electricity quantity shall not be less than 50%, and it shall be stored separately or placed on the vehicle (disconnect
the plug). The maximum safety period is 3 months. Otherwise, battery feeding, which cannot be repaired may occur.
·Avoid storing the battery in a place where there is a risk of falling, which may cause uncontrollable damage to the battery and may lead to leakage, heating,
smoking, fire or explosion of the battery.
The battery undervoltage caused by the above-mentioned improper behaviors shall not be covered by the warranty.
Precautions
for Battery
·Please make sure that the battery had been exhausted when you use the battery for the first time, then charge it and repeat this process for two or three times to
ensure that the actual capacity of the battery is consistent with the displayed capacity on the dashboard.
·Ensure that the battery power is not less than 20% and charge it in time, which can prolong the service life of the battery.
·In daily life, it is recommended to use a mid-range speed. Start slowly and operate the throttle handle to accelerate gradually, which also can prolong the battery
life.
·As the number of times the battery is used increases, there will be deviation between the actual capacity of the battery and the displayed capacity on the
dashboard. Please fully discharge and recharge the battery regularly (no more than 3 months). The internal battery cell and intelligent system can automatically
calibrate the electricity quantity to improve your experience.
·It is recommended to check the power plug of the battery every two months for carbon deposition and oxidation blackening on the contact reed.
ȑThe battery shall not be placed in the rain or get or even be soaked in the water. The whole battery compartment shall not be soaked in the water ,
otherwise water will enter the battery, causing internal short circuit and permanent failure of the battery. In the above-mentioned case, it is strictly prohibited
to charge the whole vehicle or battery again, otherwise it will cause fire, combustion and explosion. Please hand over the battery to the designated network for
maintenance immediately.

1110
Problem phenomenon Reason Treatment method
Turn on the power supply, but the whole
vehicle has no power output
No power supply to the vehicle 1.Check whether the power plug is connected properly
2.Battery undervoltage. Please charge it.
Turn on the power supply and turn the
speed regulating handle, and the motor
does not start up.
1. The vehicle is braked
2. The vehicle is parked
3. The side brace is not retracted.
4. Start switch failure
1. Check whether the brake handle is in the braking state
2. Refer to that "start-up operation" section of the instruction
manual
3. Pack up the side brace
4. Contact the after-sales service and check the start switch
Insuf¿cient endurance mileage
1. Low battery
2. Insuf¿cient tire pressure
3. Frequent brake and start or overloading
4. Battery aging or normal electric quantity decay
5. Low ambient temperature or reduced battery
capacity
1. Check the charger for damage
2. Check the tire pressure before use
3. Develop good driving habits
4. Replace the battery
5. It is normal
The battery cannot be charged
1. The charger plug is not connected properly
2. The battery temperature is too low
3. The battery temperature is too high
1. Check whether the plug connection is loose
2. Wait for the battery to recover to the normal temperature
3. Wait for the battery to recover to the normal temperature
6 Troubleshooting
Problem phenomenon Reason Treatment method
The battery has no electricity and light bar is not on
after pressing the button The battery runs out Charge
After turning on the power, light bars all flash The battery runs out or the battery failed Charge it and contact the branches for
detection
When driving at low power, such as 5%, the power
is off and the screen turns black. The battery runs out, which is normal Charge it
After parking, power on within a short period of
time, such as 1 to 2 hours, the displayed capacity
increases or decreases dramatically
Internal calibration calculation of battery
cell electric quantity is a supplement to
inaccurate dynamic electric quantity for
riding.
Normal service
When driving with normal electric quantity, such as
15%, the power is off and the screen turns black
It is normal to see the battery runs out
Long-term use of batteries leads to the
inaccurate calculation of capacity
Carry out fully charging and discharging
After parking, power on within a short period of
time, such as 1 to 2 hours, the displayed capacity
increases or decreases dramatically
It is normal to see the battery runs out
Long-term use of batteries leads to the
inaccurate calculation of capacity
Normal use
After parking, power on within a long period of
time. For example, the displayed capacity of the
dashboard decreases dramatically overnight
The alarm consumes electricity about 5%
for 8 hours Normal use
Judgment of common faults and troubleshooting of lithium battery

1312
7
Inspection items of regular maintenance
Regular maintenance can extend the value of vehicles from products to daily use.
Adjustment in run-inperiod:After using the new purchased vehicle for one month (distance: 500km), conduct adjustment in run-in period so that the
vehicle can be integrated into your life in the most perfect posture.
Firstmaintenance:After using the new purchased vehicle for four months (distance: 1,500km), carry out the first maintenance for your vehicle that has
been with you for several months.
Second maintenance: After using the new purchased vehicle for ten months (distance: 3,000km), carry out the second maintenance to prolong the
service life of your vehicle.
All maintenance items are shown in the following table. The actual maintenance items can be flexibly selected according to the vehicle type, riding
mileage and time:
Description Inspection item
Structural member
Nut fastener of the whole vehicle
Bolt fastener of the whole vehicle
Tire inspection
Brake system
brake fluid inspection
Abnormal sound inspection when braking
Braking effect inspection
Brake disc inspection
Electrical components
Inspection of power lock and alarm
Light inspection
Inspection of the dashboard
Combined switch inspection
Electrical components Voltage inspection of the charger
Inspection of the function of APP
Suspension + steering
system
Front and rear shock absorption inspection
Steering inspection of the handlebars
Front wheel inspection
Battery
Appearance inspection of battery box
Waterproofness inspection
Battery detection
Charging test
Vehicle riding
Vehicle operation inspection
Inspection of abnormal sound of whole vehicle
Parking inspection
Maintenance and Servicing
Please scrub the vehicle with tap water and a neutral detergent. After that, wipe it clean with a soft cloth.
Vehicle storage method
·Please store the vehicler in a stable, well-ventilated and dry position.
·Avoid the exposure of vehicler to the sunand rain as much as possible, which can reduce the damage or aging of parts.
·For long-term storage, please refer to Instructions for Battery Use and Maintenance for battery maintenance.
·When reusing after long-term storage, please fully charge the battery.
·Please confirm there is no abnormality in all parts before riding.
V ehicle cleaning
A It is prohibited to use high-pressure water gun to directly wash the battery box on both sides and inside the rear.The charger,controller
and other electronic parts are located in the side cover above the rear wheel. Do not flush disctly to avoid water damage.

1514
8 Basic Parameters
/P




1BSU/BNF
4QFFEPNFUFS
)FBEMJHIUESJWJOHQBTTJOHCFBN
GSPOUQPTJUJPOMJHIU
%BZUJNFSVOOJOHMJHIU
'SPOUEJSFDUJPOJOEJDBUPS
1SPQVMTJPOCBUUFSZ
/P





1BSU/BNF
&MFDUSJDNPUPS
$POUSPMMFS
#SBLFMJHIUSFBSMJHIU
3FBSSFHJTUSBUJPOQMBUFMJHIU
3FBSEJSFDUJPOJEJDBUPS





 


Items
Model
Overall dimensions Length * Width * Height (mm)
Frame material
Curb weight of the scooter (kg)
Maximum speed (km/h)
Tire size (front and rear wheels)
Tire pressure (Front/Rear) (KPa)
Types of power storage batteries
The capacity of power storage batteries
Numbers of power storage batteries
Braking model
Motor type
Rated voltage of motor controller (V)
Rated output power of the motor (W)
The current of controller
Working principle of motor
Parameters
M6
1820x375x770mm
Seamless steel tube
76kg
60km/h
12 inch aluminum wheel
Front 300/rear 350
Lithium battery
Configuration I: 20Ah Configuration II: 30Ah
1
Permanent
Front and rear hydraulic disc brake
magnet
60 V
3000 W
45 A
DC motor

1716
Note: This warranty card is invalid without the seal of the distributor.
User name Address Postcode
Engine No. VIN Date of purchase
Maintenance record sheet Distribution (seal):
Date Repair and replacement Repairman Comments
Warranty Card

EEC
