RAEV BULLET PRO User manual
User Manual of Electric Bicycle
Note:
PRO version means
a single battery and
GT version means
double batteries
BULLET
PRO / GT
1.Basic Information......................................................................02
1.1 Unpacking Information.........................................................02
1.2 Parts Description...................................................................... 03
2.Installation Procedure.....................................................04
2.1 Handlebar Installation ..........................................................04
2.2 Front Wheel Installation.....................................................04
2.3 Pedal Installation.....................................................................05
2.4 Headlamp Installation .........................................................06
2.5 Battery Installation and Removal ................................ 06
3.Battery Charging ...................................................................07
4.Riding Introduction.................................................................08
4.1 Riding Mode ................................................................................08
4.2 Introduction to Instrument Key Functions........... 09
5.Use of Gearbox ........................................................................10
5.1 Diagram of Gearbox ...............................................................10
5.2 Pay Attention to the Following Details When Using
the Drive System......................................................................10
1.Basic Information......................................................................02
1.1 Unpacking Information.........................................................02
1.2 Parts Description...................................................................... 03
2.Installation Procedure.....................................................04
2.1 Handlebar Installation ..........................................................04
2.2 Front Wheel Installation.....................................................04
2.3 Pedal Installation.....................................................................05
2.4 Headlamp Installation .........................................................06
2.5 Battery Installation and Removal ................................ 06
3.Battery Charging ...................................................................07
4.Riding Introduction.................................................................08
4.1 Riding Mode ................................................................................08
4.2 Introduction to Instrument Key Functions........... 09
5.Use of Gearbox ........................................................................10
5.1 Diagram of Gearbox ...............................................................10
5.2 Pay Attention to the Following Details When Using
the Drive System......................................................................10
6.Precautions about Use....................................................11
6.1 Compliance with Traffic Laws and Traffic
Safety Tips ............................................................................................11
6.2 Safety Precautions about Electric Bicycle............. 11
6.3 Preparation for Riding .........................................................11
6.4 Code Position Diagram.......................................................11
7.Battery ................................................................................................12
7.1 Precautions about Use of Lithium Battery............. 12
7.2 Operating Environment......................................................12
7.3 Charging Environment........................................................13
7.4 Storage Environment........................................................... 13
8.Technical Parameters..................................................... 14
Contents
01
1. Basic Information
User Manual
RL
02
1x Bicycle 1x Wheel 1x Light
1x Charger 2x Pedal
8x Tool
1x Front Fender
1x User ManualGT Version 1x Battery
PRO Version 2x Key
GT Version 4x Key
1x Bicycle
1x Wheel
1x Light
1x Charger
2x Pedal
1x front fender
GT Version 1x Battery
8x Tool
PRO Version 2x Keys
GT Version 4x Keys
1x User Manual
1.1 Unpacking Information
1.2 Parts Description
Cushion
Taillight
Rear suspension
Trigger shifter
Handlebar cover
Motor
Rear gearbox
Pedal
Controller
LCD Display
Brake handlebar
Car light
Battery
GT version battery
Front disc
brake
Front fork
03
04
2. Installation Procedure
2.2 Front Wheel Installation
2.1 Handlebar Installation
90°
Remove the pre-tightened set screws of the handlebar end cover using 4mm socket head wrench
Place the handlebar, adjust it to a suitable angle, close the end cover of the handlebar and pre-tighten 4 screws
using 4mm socket head wrench
Tighten set screws of the handlebar end cover in the order of 1, 2, 3 and 4
Align the front disc at the space of the gateway lining, align the front axle at the front fork axle hole and insert it
into the hole
Install gaskets and cap nuts on both sides
Tighten cap nuts on both sides using 15mm open spanner
14
32
05
2.3 Pedal Installation
Differentiate the identifiers of left and right pedals, L means left pedal and R means right pedal
When installing pedals, keep the pedal bolt end face vertical to the mounting hole of the crank and tighten and
fix it using 15mm open spanner
(When installing the left pedal, rotate it anticlockwise; when installing the right pedal, rotate it clockwise)
L
L
R
R
R
L
L
R
During installation
Align the left to left and
the right to right
L R
06
2.4 Headlamp installation
2.5 Battery Installation and Removal
Take the headlamp accessories out of the accessory box and install the fixed support of the headlamp;
Adjust the headlamp angle and tighten set screws of the supports on both sides using 5mm socket head wrench;
Connect the connecting line of the headlamp
Insert the key, rotate it to ON state and place the battery in the body preset position
Forcibly push the battery until you hear a crisp sound
Rotate the key to Lock state and pull it out
GT version battery installation
Open the soft cover on the battery side
Insert the plug of the charger into the charging port of the battery and connect the other plug to the power supply;
The status light of the charger is red in the charging process
After the battery is fully charged, the status light of the charger is green
Remove the charger, keep it properly and close the soft cover after charging
If the battery is charged on board, please power off the instrument
3. Battery Charging
07
Charging Port
Soft cover
Soft cover
Charging Port
GT version battery
4.1 Riding mode
4.Riding Introduction
08
In EV mode, press and hold ON. After power-off, adjust the gears (1-3) by Instrument ± Key, and pull the speed
thumb shifter to enter EV mode
In assistant mode, press and hold ON. After power-on, adjust the gears (1-3) by Instrument± Key, step on the
pedal for more than half a cycle to enter assistant mode
In manual riding mode-press and hold ON. After power-on, adjust the gear (0) by Instrument ± Key, and step on
the pedal to enter manual riding mode
Note: The maximum speed at gear 1 is 12mph, that at gear 2 is 20mph and that at gear 3 is 28mph
Brake
handlebar
Handlebar grip
Instrument
Speed thumb shifter
Speed thumb shifter key ±
MPH
Km/h
W POWER
Mile Km
TRIP
ODO
TIME
MAX
AVG
ON/OFF: Press and hold ON for more than 2s to turn on the power; in startup state, press and hold ON for more than 2s
to turn off the power;
In startup state, short press ON/OFF, and the displayed information is switched among total distance (mileage/h), trip
distance (mileage/h), riding time (h), output power (W), total distance (mileage/h), maximum speed (mileage/h) and
average speed (mileage/h);
± key: In startup state, press and hold + for 2s to turn on the instrument backlight and turn on the headlamp. When the
headlamp is turned on, press and hold for 2s to turn off the headlamp. Short press ± to switch among assistance gears
(0-3) of the electric bicycle. Gear 1 means that the instrument is turned on, and gear 0 means parking mode and no
motor output;
09
4.2 Introduction to Instrument Key Functions
UP key
Power indication
Headlamp indication
Speed per hour
Mileage (switch)
Gear indication
�Speed unit
Mileage display
Down key
ON/OFF key
10
5.1 Gearbox Diagram
5. Use of Gearbox
When using the transmission system, try not to change speed over gears to avoid damaging the gearbox. That is, do not
switch more than two gears each time but gear by gear to protect the transmission system
When the electric bicycle stops or goes downhill, do not run the drive system reversely, which may damage the drive
system and cause an accident
If the gearbox breaks down, or the gear is inaccurate, gearbox performance may be affected. In this case, timely
maintain it at a repair shop to avoid aggravation of fault
5.2 Pay Attention to the Following Details When Using the Drive System
1-3
4-5
6-7
Gear SpeedStrength
Relaxed Slow
Fast
MediumModerate
Laboursome
For acceleration, run at a low speed at first. With acceleration, switch to a high gear.
When driving uphill, the speed will decrease. Lower the gear to keep a certain riding speed
It is easier to accelerate in the wind direction. Raise the gear to keep a certain riding speed
Rising suggestions are given above, and gears can be reasonably adjusted according
to personal habit
Gear -
Gear indicator
Gear +
11
6. Precautions about Use
(Front of frame controller box)
6.1 Compliance with Traffic Laws and Traffic Safety Tips
6.2 Safety Precautions about Electric Bicycle
Do not park an electric bicycle in the lobby, escape stair, passage and emergency exit
of buildings
Do not charge and park the electric bicycle in a residential building, keep far away from
combustibles in the charging process and do not charge the electric bicycle for a long
time
Correctly use and maintain the batteries. Waste batteries should not be dismantled
arbitrarily and should be recycled by related departments
Understand safe use methods and warning signs of charger
The charger should match the battery
To avoid an accident potential caused by wetting of internal electronic parts and
circuits, do not wash an electric bicycle with water
When adjusting the handlebar or the saddle, safety signs of handlebar pipe and saddle
pipe should not be exposed (if applicable)
The electric bicycle should be regularly maintained.
It should be maintained twice and complex parts should be taken care by a repair shop
6.3 Preparation for Riding
Do not refit the electric bicycle without permission; with maximum load of 100kg, the
electric bicycle must not be overloaded
Do not lend the electric bicycle to people who cannot drive it to avoid injury
The electric bicycle should carry personnel or articles according to laws and
regulations
The driver must wear a helmet and be cautious when driving an electric bicycle and
must not hold the handlebar by no or one hand
Slow down during rainy and snowy weather as brake distance will extend. Then
during stormy and severe weather try not to ride the electric bicyle
When waiting for the traffic light for a long time, please adjust to gear 0, or hold the
brake instead of stepping on the pedal to starting the electric bicycle
Check whether the power circuit and
the light are normal;
Check whether the front and rear
brakes work normally;
Check whether the handlebars and
front and rear wheels are tightened;
Whether the tire pressure is normal;
(see the tire label)
Check whether the reflector is
damaged or polluted before driving;
XXXXXXXXXXXXXXX
6.4 Code Position Diagram
Confirm the battery model if it’s original. Do not use batteries of other brands without permission
Check whether the lithium battery is intact and has damage, leakage, heat emission, moisture, smoke and other
obvious phenomena
To ensure transportation safety, the battery quantity is about 30% upon delivery. Due to power consumption during
transportation and storage, it is normal that the battery quantity is low or the battery has run out of power when used
for the first time.
Please charge the battery for 24h when it is used for the first time after purchased or stored for a long time
The optimal operating temperature is 10℃-45℃
The battery capacity may decrease in varying degrees at low temperature as follows
The available capacity is about 70% at -10℃, about 85% at 0℃and about 100% at 25℃; if the battery gives out peculiar
smell, emits heat, deforms and has other abnormal conditions, please immediately stop using it, keep far away from it
and contact the after-sales service department
7.2 Operating Environment
7. Battery
7.1 Precautions about Use of Lithium Battery
Battery is not a repairable part. In case of abnormalities, the battery may emit heat,
give out smoke and cause a fire and explosion.
Warning
12
Charge the battery using original charger instead of charger of other brands or models
Please charge the battery at 0℃-40℃in a well-ventilated place and keep off combustibles
Charging time: Do not charge the battery for more than 12h; otherwise, the battery life will be affected and a potential
safety hazard will be caused
The battery capacity will rise quickly in the early charging process and then slow down, which is a normal procedure to
ensure safety
Do not charge the battery outdoors in severe weather
If the surface temperature of the battery box is very high (higher than 55℃) in the charging process, it indicates that the
battery box breaks down and should be immediately powered off and sent to the designated repair station. It is normal
that the charger box is slightly hot (no more than 60℃) in the charging process
7.3 Charging Environment
After the battery is installed, the battery capacity will be slowly consumed when the electric bicycle runs. The fully charged battery can be placed for no more
than two months and it is normal that the instrument displays a drop of battery capacity
When the battery is left unused for a long time (more than a month), please be sure to remove it from the electric bicycle and charge the battery to
half-saturated state (after fully discharged, charge the battery for 1.5-2h using charger). Then, store the battery in a cool and dry place (the optimal
temperature is 5℃-25℃) and charge it for about 3h every two months
The battery and the charger should be stored in clean, dry and well-ventilated place and far away from corrosive substances, ignition and heat sources (no
less than 2m) and combustibles and they should be disconnected
The optimal battery capacity is 50%. If the battery is stored for a long time when the capacity is lower than 10% or higher than 90%, the capacity will decrease
irreversibly
Do not store the battery in a high place, since drop may cause uncontrollable internal damage, leakage, heat, smoke, fire or explosion to battery
The electric vehicle and battery should be protected from rain, ice, snow and chemical substance when used and stored and must not be washed with water
to avoid an accident potential caused by wetting of internal electronic parts and circuits
7.4 Storage Environment
13
8. Technical Parameters
Product name
Net weight
Product size
Packaging box size
Maximum gradient
Load
Maximum speed
Endurance mileage
Motor
Battery capacity
Charging voltage
Wheel diameter
Charging time
Waterproofing grade
Storage temperature
Operating temperature
Charging temperature
Warranty
Bullet PRO
37kg
1720*670*1055mm
1500*375*820mm
15° (load 100kg)
265lb./100kg
28mph/45km/h
31miles/50km
750W
48V20Ah
90-264V
20in.
7 hours
IPX4
20°C-25°C/68°F-77°F
-4°F-140°F1-20°C~60°C
32°F-104F/0°C-40°C
1 Year Limited
Bullet GT
40kg
1720*670*1055mm
1500*375*820mm
15° (load 100kg)
265lb./100kg
28mph/45km/h
43miles/70km
750W
48V28Ah
90-264V
20in.
9.5 hours
IPX4
20°C-25°C/68°F-77°F
-4°F-140°F1-20°C~60°C
32°F-104F/0°C-40°C
1 Year Limited
14
The endurance mileage is measured when the battery is fully charged, at load of 70kg, temperature of about 25℃,
gear 1 and constant speed of 12mph, on flat road surface, in a windless environment. Actual endurance mileage
may differ with load, temperature, wind speed, road surface, operating habit and other factors.
Company: E-LINK TECHNOLOGY CO.,LTD
Address: 4~5F/ B Block, Ding Bao Hong Green High-Tech
ParkNo.8 Industrial2nd Road, ShiYan BaoAn District,
Shenzhen, China.
Email: support@raevbikes.com
Website: raevbikes.com
Made In PRC
This manual suits for next models
2
Table of contents
