Roomware AK-008A-1 User manual

Please read the instruction manual carefully before using the product.
Please keep this manual properly for future reference.
Please use it correctly on the basis of fully understanding the content.
INSTRUCTION MANUAL
ROOMWARE HANDELD
VACUUM CLEANER
www.roomware.nl AK-008A-1

PRODUCT OVERVIEW
PACKAGE INCLUDES
SPECIFICATIONS
INTRODUCTION
FEATURES
HOW TO USE
MAINTENANCE
SAFETY INSTRUCTIONS
WARRANTY
TABLE OF CONTENTS
02
03
03
04
04
05
07
08
10

01
THANK YOU!
Dear Customer
Thank you for purchasing the Roomware vacuum cleaner. We
always endeavor to bring you technology superior appliances,
designed to let you live life on your terms. Roomware
multipurpose, power pack, daily use vacuum cleaner gives you
immense cleaning power. Its high suction and amazingly low
power consumption make it an ideal cleaning device.
To always ensure the optimal functioning and performance of
your product, we would like to advise the following:
1) Before using the appliance for the first time, carefully read
the operating and safety instructions and adhere to these at all
times.
2) In case you pass on this product to someone else, please
ensure that you hand over the user manual along with it.
3) If you have any further questions, visit www.roomware.nl, or
for any assistance you can rest assured that we are just a call
away.
Roomware Vacuum Cleaner Instruction Manual

Switch Button Charging Port
Air Outlet
Dust Bin
PRODUCT OVERVIEW:
Power Display
02
Roomware Vacuum Cleaner Instruction Manual

• Bag
• Filter
• Extended hose
• Connecting pipe
• Slot pipette
• Brush nozzle
• Cleaning brush
• Charger
• Manual
Model
Brand
Motor
Weight
Material
Battery
Suction power
Input Voltage
Motor Speed
Suction Levels
AK-008A-1
Roomware
Brushless motor
0.82kg
Metal 304 stainless steel Hypa filter
2500 mAh 3 batteries
6.000Pa and 11.000Pa
12V 120W
10000rpm
2 levels
PACKAGE INCLUDES:
SPECIFICATIONS:
03
Roomware Vacuum Cleaner Instruction Manual

The Roomware handheld vacuum cleaner is designed with
advanced cyclonic technology that effectively collects dust from
the surface. It is built with a high-performance brushless motor that
provides strong suction to clear dirt, hair, and other debris. It has a
range of attachments to tackle difficult cleaning tasks at home. The
fast rechargeable 2500mAh premium lithium battery works for
25-35 minutes of running time. The detachable dust bin makes it
easy to dispose of the debris once the cleaning job is completed.
• Brushless motor
• 2500 mAh 3 long life batteries
• LED Display Function
• Low noise operation 70 db
• Maximum power needed to run is 120 watts
• Reusable metal 304 stainless steel Hypa filter
• Two levels of strong suction pressure are
6000Pa and 11000Pa
• Large collection container: 0.5 L
• European standard adapter
• Handy and portable to carry
INTRODUCTION:
FEATURES:
04
Roomware Vacuum Cleaner Instruction Manual

Charging Instructions:
1) Plugin the USB cable into the charging port of the vacuum
cleaner.
2) Insert the charging adapter in to the socket.
3) Once the charger is connected a red LED light will turn on
indicating that the product is charging.
4) Once the vacuum cleaner is fully charged a blue LED light will
be on indicating that the battery is full.
Attachments:
1) Crevice tool: used to clean the areas that are hard to reach
like sofa corners etc.
2) Brush nozzle: used to clean carpets, mats, or pet/human hair.
3) Stainless steel filter: can be reused up to 500 times
4) Extended hose: Stretch to where you want to go.
Usage Instructions:
1) Before start using make sure the vacuum cleaner is fully charged.
2) Press the power button to turn the device ON.
3) Select the attachment type to clean specific areas.
4) Start running the vacuum cleaner to clean dust, dirt, pet/human
hair, or other debris.
GETTING STARTED:
05
Roomware Vacuum Cleaner Instruction Manual

5) You can use the hoover wirelessly and does not need to be
connected to the mains.
6) Clean the dust bin and filter aer each use.
Note: Click the On/Off button for a second the hoover will go to a
higher setting. To turn off the hoover press the On /Off button for 2
seconds.
Dust bin & Filter Cleaning Instructions:
1) Turn off the vacuum cleaner.
2) Hold the vacuum cleaner (preferably the handle) with the dust
bin facing down. The plastic film in the suction port prevents dust
from leaking when use it.
3) Press the lock button and remove the dust bin from the body the
disassemble accordingly.
4) Remove the dust cover, empty the cup and pour dust into the
trash can.
5) Tap the filter and clean it. rinse the dust bin and filter and then
let them dry in the air.
Note: Always disconnect the plug from the socket before opening
the dust component.
Storage Method:
• Store your device in a cool and dry place to avoid moisture as it
can damage the filter.
• When all components of the vacuum cleaner are completely
air-dried, fully charge the vacuum cleaner before storing it.
06
Roomware Vacuum Cleaner Instruction Manual

• Empty the vacuum cleaner dust bin regularly before and aer
use.
• Do not expose the vacuum cleaner to extreme weather
conditions such as rain etc.
• Clean the filter aer each use as it can comprise the suction
power and release the dust back into the air.
• Do not put the components in the dishwasher.
• Repair or replace the damaged or broken parts of the vacuum
cleaner on time to avoid potential hazards and injuries.
• Do not use abrasive cleaners and thinners as they can damage
the surface of the body or components.
• Use a damp cloth to wipe the dust off outside of the vacuum
cleaner.
• Clean the body, dust, filters, and accessories with a wet towel to
ensure that no liquid flows inside the vacuum cleaner.
• Keep inspecting all the attachments before and aer use and
remove dirt or hair from them.
• Do not keep the device docked to its charger all the time or
constantly fully charge as it will reduce the battery life.
MAINTENANCE:
• Keep the device along with its attachments in the bag (provided
with the product) aer use and then store it.
07
Roomware Vacuum Cleaner Instruction Manual

• This is an electronic product be aware of electric shock.
• Charge the product before using it.
• If the power cord is damaged or has other obvious damages,
please stop using the product.
• Do not disassemble the product or the battery pack as it
requires professional maintenance personnel to repair it.
• Keep this product and its charger away from moisture to prevent
electric shock.
• Do not use it to heat ash, cigarettes butts, burning matches, sharp
items, and broken glass. Doing so will damage the vacuum cleaner
as well as may endanger personal safety. Ashes and cigarette that
are still burning can cause internal filter or certain fittings to fire.
• Do not let children play with packaging materials in case of the
hazard of suffocation.
• Do not use the charger that does not meet the technical
parameters of the provided charger as it can damage the
product.
• Disconnect the charger before start using it.
• If the product, charger, power cord, and any other accessories
are damaged or missing, please contact the seller immediately.
• Do not expose the vacuum cleaner to extreme weather
conditions (e.g., rain, sun exposure).
SAFETY INSTRUCTIONS:
08
Roomware Vacuum Cleaner Instruction Manual

• Turn off or pull out the power plug off from the vacuum cleaner
while cleaning or repairing the parts such as replacing the filter
etc.
• Despite the filter, this product still releases a small amount of dust
and if that dust is inhaled by young kids, it will cause allergic
reactions.
• Keep this product away from children’s reach when not in use.
• Do not sit or stand on this vacuum cleaner.
• Make sure to use the vacuum cleaner when the filter and dust
chamber are properly placed.
• Do not place this product near any heat source.
• If the product is handed over to a third person, please also attach
this instruction book.
09
Roomware Vacuum Cleaner Instruction Manual

1- Year Limited Lifetime Warranty
The original purchaser for this unit is provided with a 1-YEAR
WARRANTY.
Covered Under Warranty:
The warranty begins from the date of purchase. For the first year,
coverage is for both parts and labor on warranty repair services.
Note:Customers have to provide proof of purchase to initiate the
repair work under warranty. We strongly recommend keeping the
original receipt.
Not Covered Under Warranty
1. We do not offer a warranty for products that have been bought
secondhand or as a resold product.
2. We do not replace defective units or provide refunds for
products purchased from us aer 30 days from the date of
purchase.
3. Issues of replacement and refunds on units purchased less than
days from an authorized dealer must be addressed to the dealer
directly.
4. If the products purchased from an authorized dealer are aer
30 days from the date of purchase, please send the units to us for
service and repair.
5. We do not cover the cost of repairs and replacements due to
misuse by the owner’s improper maintenance, and/or lost units.
WARRANTY:
10
Roomware Vacuum Cleaner Instruction Manual

6. Any water damage on the water resistant remote and the
water-resistant receiver of our product series will not be covered.
7. All replacement costs for either the remote or receiver will be the
owner’s responsibility.
8. The warranty is void if the unit has been altered or an
unauthorized person has damaged the unit while attempting repair
work.
9. We reserve the right to retain and discards any part or
accessories that have been found damaged upon replacement and
repair.
11
Roomware Vacuum Cleaner Instruction Manual

Lees de gebruiksaanwijzing aandachtig door voordat u het product in gebruik neemt.
Bewaar deze handleiding op de juiste manier zodat u deze in de toekomst kunt raadplegen.
Gebruik de kruimeldief op de juiste manier en op basis van een volledig begrip van de inhoud.
HANDLEIDING
ROOMWARE HAND
STOFZUIGER
www.roomware.nl AK-008A-1

PRODUCTOVERZICHT
INHOUD VERPAKKING
SPECIFICATIES
INVOERING
FUNCTIES
HOE TE GEBRUIKEN
ONDERHOUD
VEILIGHEIDSINSTRUCTIES
GARANTIE
INHOUDSOPGAVE
02
03
03
04
04
05
07
08
10

01
DANK U!
Beste klant
Bedankt voor het aanschaffen van de Roomware stofzuiger.
We streven er altijd naar om u duurzame en kwalitatief geode
apparaten aan te bieden, ontworpen om u te laten leven op
uw voorwaarden. De multifunctionele, krachtige stofzuiger van
Roomware is voor dagelijks gebruik en gee een enorme
reinigingskracht. De hoge zuigkracht en het verbazingwekkend
lage stroomverbruik maken het een ideaal reinigingsapparaat.
Om altijd een optimale werking en prestatie van onze product
te garanderen, adviseren wij het volgende:
1) Lees voor het eerste gebruik van het apparaat de
bedienings- en veiligheidsinstructies aandachtig door en volg
deze te allen tijde op.
2) Mocht u dit product aan iemand anders doorgeven, zorg er
dan voor dat u de gebruiksaanwijzing meegee.
3) Bij vragen, bezoek dan gerust onze website:
www.roomware.nl, of neem contact met ons op per telefoon of
e-mail.
Roomware kruimeldief AK-008A, handleiding

Aan/uit knop
(Uit = 2 sec indrukken) Oplaad poort
Luchtuitlaat
Stofreservoir
PRODUCTOVERZICHT:
Batterij indicator
02
Roomware kruimeldief AK-008A-1, handleiding

• Roomware kruimeldief
• Opbergtas
• Stale HEPA filter
• Verlengstuk
• 2 koppelstukken
• Sleufopzetstuk
• Borstelopzetstuk
• Schoonmaakborstel
• Oplader
• Handleiding
Model
Merk
Motor
Gewicht
Filter
Batterij
Zuigkracht
Ingangsspanning
Motorsnelheid
Zuigniveaus
AK-008A-1
Roomware
Borstelloze motor
0.82kg
Hypa-filter van roestvrij staal
2500 mAh 3 batterijen
6.000Pa of 11.000Pa
12V 120W
10000rpm
2 niveaus
INHOUD VERPAKKING:
SPECIFICATIES:
03
Roomware kruimeldief AK-008-1, handleiding

De Roomware handstofzuiger is ontworpen met geavanceerde
cycloontechnologie die stof effectief van het oppervlak verzamelt.
Het is gebouwd met een krachtige borstelloze motor die een sterke
zuigkracht biedt om vui en haar en te verwijderen. Het hee een
reeks hulpstukken om moeilijke schoonmaaktaken thuis aan te
pakken. De snel oplaadbare 2500mAh premium lithiumbatterij is
goed voor 25-35 minuten looptijd. De afneembare stofbak maakt
het gemakkelijk om het vuil weg te gooien zodra de
schoonmaakklus is voltooid.
• Borstelloze motor
• 2500 mAh 3 batterijen met lange levensduur
• LED-weergavefunctie
• Geluidsarme werking 70 db
• Het maximale vermogen dat nodig is om te
draaien is 120 watt
• Herbruikbaar Hypa-filter van roestvrij staal
• Twee niveaus van sterke zuigkracht 6000 Pa
en 11000 Pa
• Grote opvangbak: 0,5 L
• Europese standaardadapter
• Handig en draagbaar om mee te nemen
INVOERING:
FUNCTIES:
04
Roomware kruimeldief AK-008-1, handleiding

Oplaadinstructies:
1) Steek de USB-kabel in de oplaadpoort van de stofzuiger.
2) Steek de oplaadadapter in het stopcontact.
3) Zodra de oplader is aangesloten, gaat een rood LED-lampje
branden om aan te geven dat het product wordt opgeladen.
4) Zodra de stofzuiger volledig is opgeladen, gaat er een groen
LED-lampje branden om aan te geven dat de batterij vol is.
Bijlagen:
1) Spleufopzetstuk: wordt gebruikt om de moeilijk bereikbare
plaatsen zoals bankhoeken enz. schoon te maken.
2) Borstelopzetstuk: wordt gebruikt om tapijten, matten of
huisdieren/mensenhaar te reinigen.
3) Roestvrijstalen filter: kan tot 500 keer worden hergebruikt.
4) Verlengstuk: Rek uit tot waar u heen wilt.
Gebruiksinstructies:
1) Zorg ervoor dat de stofzuiger volledig is opgeladen voordat u
hem gaat gebruiken.
2) Druk op de aan/uit-knop om het apparaat AAN te zetten.
3) Selecteer het type hulpstuk om specifieke gebieden te reinigen.
4) Start de stofzuiger om stof, vuil, haren van huisdieren/mensen
of ander vuil te verwijderen.
HOE TE GEBRUIKEN:
05
Roomware kruimeldief AK-008-1, handleiding
