Roper RT14BKXSQ User instructions

Top Mount Refrigerator
PRODUCT MODEL NUMBERS OVERALL DIMENSIONS
LOCATION REQUIREMENTS
RT14BKXS
RT14DKXS
RT18BKXS
RT18SKXR
RT18VKXS
Electrical: A 115 Volt, 60 Hz., AC only 15 or 20
amp fused, grounded electrical supply is
required. It is recommended that a separate
circuit serving only your refrigerator be provided.
Use an outlet that cannot be turned off by a
switch. Do not use an extension cord.
Water: Connect the ice maker to a cold water
line with water pressure between 30 and 120 psi
(207 - 827 kPa).
If a reverse osmosis water filtration system is
connected to your cold water supply, the water
pressure to the system needs to be a minimum
of 40 to 60 psi (276 - 414 kPa).
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. 2316018
07-10-06
3" (7.5 cm)
2" (5.08 cm)
To ensure proper ventilation for your refrigerator, allow for a ¹⁄₂" (12.70 mm) space
on each side. Allow 3" (7.5 cm) of space between overhead cabinets and
refrigerator top. Allow at least 1" (25.40 mm) between back of cabinet and the wall.
If your refrigerator has an ice maker, make sure you leave some extra space at the
back for the water line connections.
If you are installing your refrigerator next to a fixed wall, leave 2" (5.08 cm)
minimum on the hinge side (depending on your model) to allow for the door to
swing open.
NOTE: Do not install the refrigerator near an oven, radiator, or other heat source,
nor in a location where the temperature will fall below 55°F (13°C).
D
includes
rollers
extended 3/4"
E
includes
rollers
extended 3/4"
A
overall to
back of coils
EEC
B
Depth Cab. Width Door Width Cab. Height Overall Height
Model "A" "B" "C" "D" "E"
RT14BKXS 29 3/4" 28" 28" 62 3/4" 63 1/4"
RT14DKXS 29 3/4" 28" 28" 62 3/4" 63 1/4"
RT18SKXR 31" 28" 28 1/8" 67 3/8" 68"
RT18VKXS 31 1/8" 28" 28" 67 3/8" 67 7/8"
RT18BKXS 31 1/8" 28" 28" 67 3/8" 67 7/8"
®
