Rosco Dual-Vision XC4 User manual

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
This guide will show the proper way to install a Dual-Vision XC4 Camera in a Setra Coach Bus. Please
review the Installation Guidelines for grounding and making connections prior to installing. In this guide
you will find dash removal, wire locations, & mounting locations.
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
vehicle has any damage
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
accidental shorts or blown fuses
UPDATED October 15th,2018
***NEW PART***
***Harness DV457 is needed if trigger wires are being connected***
For Technical Support please contact our support team at:
[e-mail]
Gray –Caution
Red –Warning
Blue –Extra Installation Parts Needed
Purple –New Installation

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
Before starting your install, its best to prep the windshield for recorder mounting
Giving the VHB tape time to cure before mounting the Recorder will give you a permanent
bond and prevent recorders from falling.
A- Squeeze to release primer and apply to the windshield
B- Apply Primer to the bracket
C- Wait for the primer to dry leaving a dull haze on the windshield
IMPORTANT: VHB Tape should only be applied when windshield temperature is within 50°F-
100°F (10°C-38°C) to allow proper curing of mounting adhesive pads.
Run the defrost on high heat or use a heat gun in colder temperatures
After windshield is the correct temperature apply the VHB tape marked PERMANENT by rolling
the tape on the windshield (D)
Using your thumb push firmly around all edges of the VHB tape
Proceed to the next page for Step 1 of the installation
A
B
C
D

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
Installation Layout
Before starting your installation, please take note of component mounting
locations.

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
Step 1 - Dash Removal:
•Start by removing the two T-20 screws on both sides of the center dash

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
PLEASE NOTE THESE ARE 24 VOLT CONNECTIONS. ALWAYS CONFIRM CORRECT WIRING WITH
YOUR DIGITAL MULTIMETER
Step 2 - Power Connections:
•Connect ring terminals to the DV’s Constant, Ignition, & Ground wires
•Connect the YELLOW IGNITION WIRE to the vehicles top terminal
•Connect the RED CONSTANT WIRE to the vehicles bottom terminal
This vehicle has a multiplexer which causes a power delay. When the vehicle is powered down, the
recorder will stay powered up for 30 seconds to one minute before switching to parking mode

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
•Lift the glove box door and remove the two (2) T-20 screws holding the starage compartment
(Photo A)
•This will give you access to the vehicles fuse box, and mounting locations for the PDC & Modem
(Photo B)
A
B

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
Step 3 - Antenna Mounting:
The Manufacture recommends mounting the antenna on the windshield
Mount the antenna on the same side of the vehicle as the PDC
Notice the angled part of the antenna is on the inside of the vehicle (Photo A &
B). Make sure the FLAT SIDE of the antenna has a CLEAR VIEW OF THE SKY and is
facing OUTSIDE (Photo C)
A
B
C
After all connections are
made, coil up all the
extra antenna cable
(Photo A)
Never bend the cable.
This will cause signal
loss and damage to the
antenna (Photo B)
Please refer to the
Antenna Installation
Guideline for complete
details
A
B

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
Antenna Mounting and Cable Routing (Continued):
•Using a unibit, carefully drill a hole in the back of the fuse panel (Photo A)
•Mount the antenna on the lower windshield & route the antenna cable into the fuse box (Photo
B)
A
B

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
Step 4 - PDC & Modem Connections:
•Connect the USB cable from the modem to the PDC and secure with a zip tie (Photo A)
•Connect the Antenna cable to the modem (Photo B)
•Make these connections prior to mounting the modem & PDC
•Make sure the screw on the modem cover is secured and doesn’t move or bend (Photo C)
A
B
C
Connect the MIMO 2
antenna wire to the
Modems DIV
connector
Connect the MIMO 1
antenna wire to the
Modems PRI
connector

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
Step 5 - PDC & Modem Mounting:
•Secure the PDC & Modem to the factory harness with zip ties (Photo A)
•Make sure all connections are made prior to component mounting
•Neatly bundle up extra cables and zip tie them behind the fuse panel (Photo B)
IT’S IMPORTANT TO NEATLY ZIP TIE WIRES TO A FACTORY BRACKET OR HARNESS TO PREVENT FROM
FALLING. KEEP AWAY FROM THE STEERING FUNCTIONS AND ANY MOVING PARTS
PLEASE READ THE RECORDER MOUNTING & VHB TAPE INSTALLATION GUIDELINE BEFORE
PROCEDING TO THE NEXT STEP
A
B

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
Step 6 - Camera Mounting and wire Routing:
For small passenger vehicles, mount the Recorder under the rear-view mirror (Photo A).
If the vehicle has any factory sensors under the rear-view mirror, mount the Recorder to the right of the mirror, not causing a
distraction to the driver (Photo B).
For larger trucks or busses (With split windows), mount the Recorder on the right panel (Photo C) and INSIDE the wipe swipe.
Keeping the Recorder INSIDE the swipe will ensure rain or snow will not interfere with the video.
When working on emergency vehicles use extreme caution when routing wires around emergency lights and equipment
(Photo D)
Always pull down the vehicles sun visors to make sure they don’t block or interfere with the Recorder or the video (Photo E).
Notice the swipe of the wiper blades. For vehicles like this, mount the Recorder under the visor, inside the swipe.
A
B
C
Small Passenger Vehicle
Factory Sensor under Mirror
Large truck with split window
Emergency Vehicle
Recorder
Mounting
D
E
Mount away from sun visors & Inside the wiper swipe

Setra Coach Bus Installation Guide
Version 4.10.2
Proprietary and Confidential Setra Coach Bus
To verify proper angle & correct mounting, press the driver activity button. Logon to your Rosco account
and view activity to confirm proper angle
