Rosewill RSV-X4000 User manual

4U Rackmount Chassis RSV-X4000
User Manual


4U Rackmount Chassis RSV-X4000 User Manual
1
Overview
zSupport ATX motherboard
zLockable front panel door
zFoldable Zink Alloy handle
Exploded Diagram
Product Concept
RSV-X4000 is 19” 4U height rackmount chassis designed for
various kinds of server computer. This full sealed and
well-ventilated steel chassis is specially designed to withstand
heavy shock, dust, humidity, trembling, vibration and extremely
high operating temperature in the harsh environment.

4U Rackmount Chassis RSV-X4000 User Manual
2
Specification
Dimension: 430mm (w) x 177mm (h) x 536mm (d)
Construction: All SECC with Zinc Alloy handle
Motherboard: Full size ATX
Drive bay: 3 x 5.25” & 7 x 3.5”
Indicator: LED display for power on/off and HDD
Cooling Fan: 8cm x 2 (front) & 12cm x 1 (back)
Power Supply: ATX or Redundant PSU (optional)
Extension Slot: 7 slots
Available Color: Silver & Black
System Installation
Removing top cover
The top cover is fixed to the chassis by four screws.
zRelease screws on the chassis
zSlide the cover out
zLift up the cover and gently remove the top cover

4U Rackmount Chassis RSV-X4000 User Manual
3
Install Storage Device
User may customize the installation of storage device. Basically, 3
x 5.25” and 7 x 3.5” bay are provided.
Motherboard installation
zUnfasten the screws of add-on card retainer
zTake off the add-on card retainer.

4U Rackmount Chassis RSV-X4000 User Manual
4
zPut the MB clippers in the accessory bag.
zIf you are using big MB, you may need to install plastic stand-off
on the MB screw hole
zInstall the MB with screws
5.25” drive bracket installation
zUnfasten screws of on the top of drive bracket.

4U Rackmount Chassis RSV-X4000 User Manual
5
zRemove drive bracket from chassis.
zInstall 3 x 5.25” device into front 5.25” drive bay
zInstall another 3.5” device on the right side of bracket.

4U Rackmount Chassis RSV-X4000 User Manual
6
3.5” drive bracket installation
zRemove the screws of on the top of drive bracket.
zDrive bracket being removed
zInstall 3 x 3.5” device into 3.5 drive bay and secure it
zInstall another 3.5”device on the holder.

4U Rackmount Chassis RSV-X4000 User Manual
7
zInstall floppy on the holder fasten by screws.
zUser may house in the device bracket into the chassis and
fasten all screws.
Install Add-On Card
zApply add-on cards onto the slots
zSecure add-on cards on card retainer
zCPU, memory and other devices can be mounted at this stage
on the convenience of user.
zFasten the add-on card retainer back.
Thank you for purchasing a quality Rosewill Product.
Please register your product at : www.rosewill.com for complete warranty information and future support
for your product.
