Rosito BisanI CPG User manual

INSTRUCTION MANUAL
THE MONTAGUE COMPANY
1830 Stearman Avenue P.O. BOX 4954
HAYWARD,CA 94540-4954
TEL: [phone] FAX: [phone]
Gas Cooker
ROSITO BISANI
MODEL:
CPG
Keep area around appliances free and clear from combustibles.
PLEASE RETAIN THIS MANUAL
FOR FUTURE REFERENCE.
These instructions should be read thoroughly before attempting installation.
Set up and installation should be performed by qualified installation personnel.

2
TABLE OF CONTENTS
PAGE
1. INSTRUCTIONS TO PREVENT ACCIDENTS ………. 4
2. INSTALLATION ………. 5
2.1 Preliminary Instructions ………. 5
2.2 Handling and Unpacking ………. 5
2.3 Connecting to the water-main ………. 6
2.4 Connecting to the gas supply mains ………. 6
2.4.1 Setting up and adjusting ………. 6
2.4.2 Checks ………. 7
3. USER INSTRUCTIONS ………. 8
4. SPECIFICATIONS ………. 9
5. PUTTING INTO OPERATION ………. 10
5.1 Operations prior to starting ………. 10
5.2 Lighting and shutdown instructions ………. 10
5.3 Instructions to prevent accidents ………. 11
6. TROUBLE SHOOTING ………. 12
7. CLEANING AND MAINTENANCE INSTRUCTIONS ………. 13
7.1 Special Maintenance ………. 13
7.1.1 Replacing the main burner ………. 13
7.1.2 Replacing the pilot burner ………. 14
7.1.3 Replacing the valve cock ………. 14
FIGURES ………. 15-22

3
IMPORTANT
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause property damage, injury
or death. Read the operating
and maintenance instructions
thoroughly before installing or
servicing this equipment.
FOR YOUR SAFETY:
Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
INSTRUCTIONS TO BE FOLLOWED IN THE EVENT THE USER SMELLS GAS MUST BE
POSTED IN A PROMINENT LOCATION. THIS INFORMATION MAY BE OBTAINED BY
CONSULTING THE LOCAL GAS SUPPLIER.
SHIPPING DAMAGE CLAIM PROCEDURE
For your protection, please note that equipment in this shipment was carefully inspected
and packed by skilled personnel before leaving the factory. The transportation company
assumes full responsibility for safe delivery upon acceptance of this shipment.
If shipment arrives damaged:
1. VISIBLE LOSS OR DAMAGE—Be certain this is noted on freight bill or express receipt,
and signed by person making delivery.
2. FILE CLAIM FOR DAMAGES IMMEDIATELY—Regardless of the extent of damage.
3. CONCEALED LOSS OR DAMAGE—If damage is unnoticed until merchandise is un-
packed, notify transportation company or carrier immediately, and file “concealed dam-
age” claim with them. This should be done within fifteen (15) days of date that delivery
was made to you. Be sure to retain container for inspection.
We cannot assume responsibility for damage incurred in transit. We will, however, be glad
to furnish you with necessary documents to support your claim.

4
INSTRUCTIONS TO PREVENT ACCIDENTS
Read this manual carefully to be able to refer to it in every case of need.
 Keep appliance area clean and clear from combustibles.
 The place where the machine is to be installed must be aerated enough. This is in order to sup-
ply the necessary air for combustion, to prevent reaching too high percentages of gas to aid
evacuation of the products of combustion.
 Installation must conform with local codes, or in absence of it, with the National Fuel Gas Code,
ANSI Z223.1 or with the Natural Gas Installation Code CAN/CGA-B149.1.
A. The appliance and its individual shutoff valve must be disconnected from the gas supply
piping system during any pressure testing of that system at test pressures in excess of 1/2
psig (3.45 kPa).
B. The appliance must be isolated from the gas supply piping system by closing its individual
manual shut off valve during any pressure testing of that system at test pressures in excess
of 1/2 psig (3.45 kPa).
 Make certain that the air intake openings in the bottom of the appliance are not obstructed. They
are essential for proper combustion and operation of the appliance.
 Maintain adequate clearance in front of unit for servicing and proper operation. NOTE: All
servicing can be done through the front door.
THIS APPLIANCE IS EQUIPPED FOR NATURAL GAS, with orifices sized for operation with
natural gas.
This equipment is to be installed to comply with the appliance Federal State or local
plumbing codes having jurisdiction.
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE, OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY, OR DEATH. READ THE
INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE
INSTALLING OR SERVICING THIS EQUIPMENT.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors or liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
 Do not try to light appliance.
 Do not touch any electric switch; do not use any phone in the building.
 Immediately call your gas supplier from a neighbor’s phone. Follow the gas
supplier’s instructions.
 If you cannot reach your gas supplier, call the fire department.

5
INSTALLATION
2.1 Preliminary Instructions
Installation must be carried out by following the instructions contained in this handbook and only by
a licensed tradesman in accordance with local codes, or in absence of it, with the National Fuel
Gas Code ANSI Z223.1 or with the Natural Gas Installation Code CAN/CGA-B149.1. The
manufacturer cannot be held liable for any damage caused by faulty installation.
The place where the machine is to be installed must have aeration equal to at least that give
in Table 1.1. This is in order to supply the necessary air for combustion, to prevent reaching too
high percentages of gas and to aid evacuation of the products of combustion. The installation room
must be in conformity with the current fire regulations.
The unit must operate in a level position. Slight floor irregularities can be compensated by turning
the adjustable feet of the cooker either clockwise or counterclockwise.
Clearances from combustible and noncombustible construction are give in table 1.2.
Table 1.1 Minimum change of air in relation to the thermal power installed.
Table 1.2 Clearances from combustible and noncombustible construction.
2.2 Handling and Unpacking
To move the machine to the place of installation, use a fork lift truck. Do not drag the appliance on
the floor. Take the adhesive protection off the steel surfaces, taking care not to leave any remains
of glue, in which case, use appropriate thinner to remove them.
Model Power (BTU/hr) Air flow (m³/h)
CPG1 60000 (13.2 kW) 490
CPG2 120000 (26.4 kW) 980
CPG3 180000 (39.6 kW) 1470
CPG7/1 31000 (9 kW) 315
CPG7/2 62000 (18 kW) 630
Clearances Combustible
construction
Noncombustible
construction
Side 6.0” 0”
Rear 6.0” 0”
Floor 6.0” 0”
Ceiling 48”
INSTALLATION

6
INSTALLATION
2.3 Connecting to the water-main
The unit should be connected to your water supply by way of a water faucet. The water pressure should fall
between 14.5 and 72.5 PSI. If the water pressure is excessive, a pressure regulator must be installed.
The pipe used to discharge the water must be heat resistant and allow for the free flow of the discharge
water. A funnel may be used between the unit discharge pipe and the floor drain but you should never
restrict or reduce the diameter of the discharge pipe.
The following operations are to be carrier out only by specialized technical personnel.
Having verified that the available water system is adequate, you can go ahead and make the connection:
1. Clear the pipe of any ferrous waste by letting a certain amount of water flow through.
2. Place the cooker in the desired position and close to the water-main.
3. Position the appliance level, adjusting the feet of the cooker.
4. Connect mains pipe to machine pipe (fig. 1) using a mechanical filter and an interception cock.
5. Connect machine outlet pipe (Fig. 1) to a suitable manifold that withstands high temperature.
2.4 Connecting to the gas supply mains
Before connecting up the gas, consult the gas board, all the installation and maintenance
operations should be carried out by gas board or authorized fitters. Make sure the data of the rating
plate correspond to the mains values. The rating plate is located at the bottom of the screen door panel.
Having verified that the gas supply system available is adequate, you can go ahead with the connection:
1. Connect the mains pipe to the machine pipe (pos. G. in fig. 1) using a quick closing interception cock
which is easy to reach. You must use a pressure regulator to set the manifold pressure as in tab
4.1.
2. Go ahead with setting up and adjusting as described in paragraph 2.4.1.
3. Make all the checks listed below.
2.4.1 Setting up and adjusting
The first operation to carry out is to check the supply pressure, proceeding as follows:
1. Make sure the gas supply has been cut off.
2. Open the front door, unscrew the closing screw (pos. 9 in fig. 6) of the pressure socket of the supply
pipe (pos. 1 in fig. 6).
3. Connect a pressure gauge to the socket (e.g. a manometer).
4. Open the gas interception cock and measure the value of the supply pressure.
5. CAUTION: If the value of the supply pressure measured lies outside the interval shown in table
2.2, it is not possible to go ahead with installation and it is necessary to inform the gas board of
the anomaly with the mains.
6. Close the gas interception cock, disconnect the pressure gauge, screw the closing screw back on and
close the front door.
Table 2.2 Permissible limits for the gas supply pressure
Type of gas Supply pressure Inches Water column (kPa)
minimum maximum rated
natural gas (methane) 3.5" (0.87) 10.5" (2.61) 7.0" (1.74)

7
INSTALLATION
Setting up and adjusting
After checking the supply pressure, it is necessary to adjust the pressure at the nozzle, proceeding
as described below:
1. Make sure the gas supply as been cut off.
2. Take off the door by unscrewing the screw fixing it to the support.
3. Remove the water loading knob (1 di fig. 3) and unscrew the two screws fixing the instrument
panel to the under-panel. Remove the instrument panel taking care over the wire of the igniter.
4. Open the gas inception cock and ignite the burner flame by following the instructions of par 5.2
positioning the knob onto the maximum position.
5. Adjust the pressure regulator since the manifold pressure is 4” W.C.
6. Operate the appliance in the maximum conditions for at least 15 minutes, and then turn the
knob onto the minimum position.
7. Turn the minimum adjustment screw (pos. a in fig. 7) to obtain a reduced flame but sufficiently
stable and homogeneous.
8. Turn off the burner by following the instructions of par. 5.2, close the gas interception cock,
disconnect the pressure gauge, screw the closing screw back and refit the instrument panel
and the front door.
2.4.2 Checks
For the purposes of operating safety it is essential to make the following checks:
*Checking air-tightness: Check there are no leaks in gas pipe using a solution of soap water.
*Checking operation: Check the burner, the regularity and extinguishing of the flame, following
the instructions in this handbook.
*Checking the flue gas evacuation system: Make sure there is a functional flue gas evacuation
system.
INSTALLATION

8
USER INSTRUCTIONS
This manual is an integral part of the product. It is recommended to read the instructions and
notices contained in it carefully before starting to use the cooker since it contains essential
information on using and servicing the machine safely.
This approach is designated for professional use. All the personnel assigned to using this machine
must be trained to use it.
The machine should be destined only for the use it has been designed for, every other use is to be
considered improper and therefore unreasonable. The manufacturer declines all liability for any
damage to persons or things caused by improper, erroneous, or unreasonable use.
Any tampering or modification to the appliance that has not previously been authorized by the
manufacturer frees the manufacturer from damage deriving from or referable to the above
mentioned acts.
CAUTION: THE UNIT HAS BEEN DESIGNED AND MADE TO BE USED TO
COOK OR STEAM WITH WATER ONLY. WHEN IN USE, THE EQUIPMENT
SHOULD NOT BE LEFT UNATTENDED.

9
SPECIFICATION
MODELS:
CPG 1: Gas unit with a single tank of 10.56 gallons.
CPG 2: Gas unit with two tanks of 10.56 gallons each.
CPG 3: Gas unit with three tanks of 10.56 gallons each.
CPG 7/1: Gas unit with a single tank of 7.4 gallons.
CPG 7/2: Gas unit with two tanks of 7.4 gallons each.
TECHNICAL DATA CPG1 CPG2 CPG3 CPG7/1 CPG 7/2
Length 35.4" (900mm) 27.6" (700 mm)
Width 17" (430mm) 31.5" (800mm) 47.2" (1200mm) 15.7" (400mm) 31.5" (800mm)
Height 34.4" (875mm)
Adjustable feet height 115" (175mm)
Weight 65Kg 101Kg 144Kg 50Kg 93Kg
Tank capacity at maximum level 10.6 gal (45l) 10.6+10.6 gal
10.6+10.6+10.6
gal 7.4 gal (28l) 7.4+7.4 gal
Gas supply mains connection Φ1/2"
Water mains connection Φ1/2"
Water outlet connection Φ 1"
Rated thermal power 60000 BTU/hr 120000 BTU/hr 180000 BTU/hr 31000 BTU/hr 62000 BTU/hr
Thermal power at minimum 13000 BTU/hr 26000 BTU/hr 39000 BTU/hr 13000 BTU/hr 26000 BTU/hr
Natual gas manifold pressure 4" W.C.
Primary air adjustment FIXED
NOZZLE Natural gas G20
Diameter (1/100 mm) code diameter (1/100mm)
main burner 335 275
pilot burner 50 110161 50
minimum screw (bypass) adjustable adjustable
Tab. 4.1 Main technical particulars of the CPG gas cooker

10
PUTTING INTO OPERATION
5.1 OPERATIONS PRIOR TO STARTING
WARNING! If you do not follow these instructions exactly, a fire or explosion may result,
causing property damage, personal injury, or loss of life.
Make sure the basin is clean, otherwise clean it as described in paragraph 7.1.
If you are using the cooker for the first time, you need to thoroughly clean all the parts that can
come into contact with foodstuffs. In this case, proceed as follows:
 Fill the basin with water and ordinary detergent.
 Put the machine into operation as described in the following paragraph.
 When the water is boiling, wait for a few minutes, and then turn off the flame as described in the
following paragraph.
 Open the door and drain by moving the lever inside into the open position.
 Rinse the basin carefully with clean water.
With ordinary use, the first thing to do is to load with water.
 Close the drain by moving the drain lever onto the closed position.
 Turn knob 1 of figure 3 anticlockwise.
 Wait for the basin to fill up to the top notch and then close the inlet cock by turning knob 1 of fig-
ure 3 clockwise.
CAUTION! Do not leave the cooker in operation with no water in the basin.
When lighting the pilot, follow these instructions exactly:
1. BEFORE LIGHTING smell all around the appliance area for gas. Be sure to smell next to the
floor because some gas is heavier than air and will settle on the floor. If you smell gas, you must
follow the instructions placed in front view of the appliance.
2. Never use tools to push in or turn the gas control knob. If it will not push in or turn by hand, don’t
try to repair it, call a qualified service technician. Force or attempted repair may result in a fire or
explosion.
3. Don’t use this appliance if any part has been under water. Call a qualified service technician to
inspect the appliance and to replace any part which has been under water.
5.2 LIGHTING AND SHUTDOWN INSTRUCTIONS
1. Carry out the procedures prior to putting the cooker into operation given in the above paragraph.
CAUTION: fill the cooker basin with water up to the top reference notch.
2. Open the gas interception cock, located upstream of the machine.
3. Turn the knob of valve (pos.2 in fig. 3) onto the OFF position and wait 5 minutes to clear out any
gas. If you smell gas, you must follow the instructions placed in front view of the appliance.
4. Turn the knob of the valve (pos. 2 in fig. 3) onto the PILOT position (pos. 1 in fig 3a). Open the
door.
5. Push the knob fully in and hold in, wait a few seconds and put a flame near the ignition pipe
(see Fig.5a) until the pilot flame ignites, which may be seen through the slot on the frame. Wait
for a few seconds and release the knob. If the flame fails to stay alight, repeat this operation.
ATTENTION: you must not put the flame into the pipe, but only near the edge of the ignition
pipe.
6. Turn knob 2 of figure 3 onto a position between the minimum and maximum ones (2 and 3 of fig.
3a), choosing the optimum value in relation to the quantity of product to be cooked.
7. Close the door and load the basket with the pasta to be cooked.
PUTTING INTO OPERATION

11
PUTTING INTO OPERATION
OPERATIONS PRIOR TO STARTING (continued)
8. Wait for the water in the basin to boil.
9. Put the full basket into the basin, resting it on the edge and wait for the cooking time to elapse.
10. Remove the basket using the special handles.
After cooking, turn off the main burner by turning knob 1 of figure 3 onto position 1 of fig. 3a and
turn off the pilot flame by turning it onto the off position (0 of fig. 3a), wait for at least five minutes
before draining off the water by moving the lever into the open position and finally proceed with the
cleaning.
CAUTION: Remember to close the gas interception cock.
5.3 Instructions to prevent accidents
The personnel assigned to using the electric cooker must keep to the instructions specified in this
manual. If the operator has not been sufficiently well trained, operation will not be optimum and the
risks concerning safety will increase.
It is compulsory to:
 Fill the basin with water up to a level between the two notches.
 Carry out all the routine maintenance and cleaning operations listed below.
 Keep the surfaces that can come into contact with foodstuffs clean.
 Make sure the gas pipes are always sound and well connected.
 Service the burners periodically— at least once a year.
It is forbidden to:
 Use the appliance dry.
 Keep or place inflammable objects by the appliance.
 Clean the machine using direct jets of water or high-pressure equipment.
 Put your hands or other parts of your body into the water in the basin while the machine is in
operation, or when the cooker is switched off but with the water still hot.
 Use objects that are not suitable for contact with foodstuffs to contain the pasta to be cooked.
PUTTING INTO OPERATION

12
TROUBLESHOOTING
CAUTION! For all the operations described below, close the gas interception cock and turn
to specialized and authorized personnel who have an adequate knowledge of the functions
of the various parts, and of the precautions to be taken.
Below are listed some possible malfunctions and the likely cause and remedy, if the problem is not
solved, or it is not accounted for in the following table, call our customer technical service.
MALFUNCTION LIKELY CAUSE REMEDY
The pilot burner will not ignite. *Malfunctioning of the spark
plug.
*Insufficient pressure at the pilot
burner.
*Check the spark plug fixing,
*Check the cable and the connec-
tions with the igniter and the spark
plug.
*Check the igniter and spark plug,
and replace if necessary.
*Check the supply pressure
(§2.4.1)
*Check the nozzle and clean it or
replace if necessary.
*Check the valve.
The pilot burner goes out as
soon as the knob is released.
*The pilot burner does not suffi-
ciently heat the thermocouple.
*Insufficient pressure at the
valve.
*Repeat the operation, pressing the
valve knob in more fully.
*Check the relative position of the
pilot and of the thermocouple.
*Check the supply pressure
(§2.4.1)
*Check the valve.
The main burner will not ignite
even if the pilot burner is ignited.
*Insufficient pressure at the
burner.
*Burner holes clogged.
*Check the supply pressure and the
pressure at the nozzle (§2.4.1).
*Check the valve.
*Check the nozzle and clean or
replace it if necessary.
*Clean the burner.
TROUBLESHOOTING

13
CLEANING AND MAINTENANCE
Routine maintenance consists of daily cleaning all the parts that can come onto contact with food-
stuffs and of the periodical maintenance of the burners, nozzles and of the outlet pipes.
The instructions to be followed for cleaning are listed below:
 Use a soft cloth and neutral detergents.
 To clean the stainless steel, do not use steel wool, iron scrapers, or brushes since they can
deposit ferrous particles that can oxidize leading to rust. To remove hardened residues, use
wooden or plastic spatulas, or stainless steel wool.
 If you use alkaline detergents, thoroughly rinse after washing.
 Do not spray with direct jets of water or with high-pressure equipment since any water getting
into the outer shell can jeopardize the safety of the machine.
 Periodically check whether any incrustations have formed in the overflow pipe (due to foam)
and clean it if necessary, without using objects that can damage the rubber pipe.
 When not being used, do not leave water in the basin.
When the appliance is not to be used for lengthy periods, spread a protective film over all the
stainless steel surfaces by passing a cloth soaked in Vaseline oil over them, and air the rooms
periodically.
The periodic annual maintenance of the burners must be done by specialized and
authorized personnel and it consists of keeping the holes clean for the fuel-comburent mixture to
flow in and out. Access to the burners and nozzles is explained in the following paragraphs.
7.1 Special Maintenance
The special maintenance procedures should be carried out by qualified and authorized personnel,
possibly by means of the technical service of the manufacturer of the component requiring
servicing.
CAUTION! It is recommended to use only genuine spare parts, in compliance with the same
technical specification as the ones replaced. In any case, before starting, the gas
interception cock located upstream of the appliance has to be closed.
7.1.1 Replacing the main burner
1. After making sure you have cut off the gas supply, open the door and unscrew the two screws
fixing the burner to the framework.
2. Unscrew the nuts fastening the valve pipe to the burner (pos. 3 and 4 of fig. 4), and remove the
pipe (pos. 1 of fig. 4).
3. Remove the burner and replace it with the new one, taking care to insert the end of the burner
into the hole from the other side of the frame.
4. Screw the two screws for fixing to the frame back on, and fit the pipe connecting the valve to
the burner. After these operations, it is necessary to check the seal of the gas circuit.

14
CLEANING AND MAINTENANCE
7.1.2 Replacing the pilot burner
1. After making sure you have cut off the gas supply, open the door and unscrew the two screws
fixing the pilot burner to the framework.
2. Unscrew the nuts fastening the thermocouple, the spark plug, and the pipe of the pilot burner
(pos. 7 of fig. 5). Caution, in doing this, keep the pilot unit on the inside of the framework, insert-
ing your hand from beneath.
3. Replace the pilot burner and the other defective parts of the assembly.
4. Screw the two screws for fixing to the framework back on and fit the pipe, thermocouple, and
sparkplug.
After these operations, it is necessary to check the seal of the gas circuit and the efficiency
of the pilot burner.
7.1.3 Replacing the valve cock
1. After making sure you have cut off the gas supply, remove the door by unscrewing the screw
fixing it to the support.
2. Remove the water inlet knob (1 of fig. 3) and unscrew the two screws fixing the instrument pan-
el to the under-panel. Remove the instrument panel.
3. Disconnect from the valve from the supply pipe, the pipe that goes to the burner and the one
that goes to the pilot burner and the thermocouple (pos. 1,4, 6, and 5 of fig. 6).
4. Disconnect the valve from the under-panel by unscrewing the two screws fixing it and replace it
with the new one.
5. Reconnect the gas pipes and the thermocouple in the same position as before.
6. Refit the instrument panel with the two screws taken out beforehand, fit the water knob onto the
relative shaft and fix the front door to the support.
After these operations, it is necessary to check the seal of the gas circuit, the efficiency of
the pilot burner and to repeat the adjustment operations.

15
DIAGRAM

16
DIAGRAM

17
DIAGRAM

18
DIAGRAM

19
DIAGRAM

20
DIAGRAM
