Rotabroach Element 14 1 User manual

Element 14 Manual Original instructions Nov 2019
1
METAL CUTTING SAW
Model Number Element 14/1, Element 14/3
This machine (Serial Number ...........................) is CE approved.
Rotabroach Ltd
Burgess Road
Sheffield, South Yorkshire
United Kingdom
S9 3WD
Tel: [phone] Fax: [phone]
Email: [e-mail] Website: www.rotabroach.co.uk

Element 14 Manual Original instructions Nov 2019
2
Thank you for purchasing our Element 14 Chop saw.
We would really like your feedback on this machine.
Other Products by Rotabroach:
Thank you for your purchase

Element 14 Manual Original instructions Nov 2019
3
CONTENTS OF THE MANUAL
Page
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
13)
14)
Intended use
General safety rules
Information plate symbols
Unpacking
Specification
Operational safety instructions
Operating instructions
Changing the blade
Extension cable selection
Maintenance
Machine breakdown
Parts list
Trouble shooting
Warranty statement
4
4
5
6
6
7
9
13
14
15
16
17
19
21
1) IN

Element 14 Manual Original instructions Nov 2019
4
1) INTENDED USE
The intended use of this saw, is to cut through metals. The vice is used to hold the workpiece in place whilst
the saw is functioning. It is designed for use in fabrication, construction and any other applications when
cutting metal.
Any deviation from its intended use will not be covered by warranty.
2) GENERAL SAFETY RULES
Using the machine with respect and caution will considerably lessen the possibility of personal injury.
However, if normal safety precautions are overlooked or ignored, personal injury to the operator may
result. This machine was designed for certain applications only. It is strongly recommended that this
machine NOT to be modified and/or used for any application other than for which it was designed.
Warning! Failure to follow these rules may result in serious personal injury.
1. FOR YOUR OWN SAFETY, READ INSTRUCTION MANUAL BEFORE OPERATING THE TOOL. Learn the tool's
application and limitations as well as the specific hazards peculiar to it.
2. 2.2.DO NOT USE the saw without the guards in position, in good working order and properly maintained.
3. ALWAYS WEAR EYE PROTECTION.
4.GROUND ALL TOOLS. If tool is equipped with three-prong plug, it should be plugged into a three-hole
electrical receptacle. If an adapter is used to for a two-prong receptacle, the adapter lug must be
attached to a known ground. Never remove the third prong.
5.REMOVE ADJUSTING KEYS & WRENCHES.
Have it a habit of checking to see that keys and adjusting wrenches are removed from tool before turning it
"ON."
6.KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents.
7.DON'T USE IN DANGEROUS ENVIRONMENT. Don’t use power tools in damp or wet location, or expose them
to rain Keep work area well lighted.
8. KEEP CHILDREN AND VISITORS AWAY. All children and visitors should be kept a safe distance from work
area.
9. MAKE WORKSHOP CHILDPROOF- With padlocks, master switches, or by removing starter keys.
10. DON'T FORCE TOOL. It will do the job better and be safer at the rate for which it was designed.
12. WEAR PROPER APPAREL. No loose clothing, gloves, neckties,rings, bracelets, or other jewelry could get
caught in moving parts. Nonslip footwear is recommended. Wear protective hair covering to contain long
hair.
13. ALWAYS USE SAFETY GLASSES AND HEARING PROTECTION. Also use face or dust mask if cutting operation
is dusty. Wear gloves for handling saw blades and rough material.
14. SECURE WORK. Use clamps or a vise to hold work pieces when practical. It's safer than using your hand and
frees both hands to operate tool.
15. DON'T OVERREACH. Keep proper footing and balance at all times.
16. MAINTAIN TOOLS IN TOP CONDITION. Keep tools sharp and clean for best and safest performance. Follow
instructions for lubricating and changing accessories.
17. DISCONNECT TOOLS before servicing and when changing accessories such as blades, bits, cutters, etc.
18. USE RECOMMENDED ACCESSORIES. The use of improper accessories may cause hazards.
19. REDUCE THE RISK OF UNINETIONAL STARTING. Make sure switch is in "OFF" position before plugging in
power cord.
20. NEVER STAND ON TOOL. Serious injury could occur if the tool is tipped or if the cutting tool is accidentally
contacted.
21. CHECK DAMAGED PARTS. Before further use of the tool, a guard or other part that is damaged should be
carefully checked to ensure that it will operate properly and perform its Intended function -check for
alignment of moving parts, binding of moving parts, breakage of parts, mounting, and any other part that
is damaged should be properly repaired or replaced.
22. DIRECTION OF FEED. Feed work into a blade or cutter against the direction of rotation of the blade or

Element 14 Manual Original instructions Nov 2019
5
cutter only.
23. NEVER LEAVE TOOL RUNNING UNATTENDED. POWER OFF. Don’t leave tool until it comes to a complete
stop.
24. DRUGS, ALCOHOL, MEDICATION. Do not operate tool while under the influence of drug, alcohol or any
medication.
25. MAKE SURE TOOL IS DISCONNECTED FROM THE POWER SUPPLY while motor is being mounted, connected
or reconnected.
26. WARNING: The dust generated by certain products can be injurious to your health. Always operate
machinery in well- ventilated areas and provide for proper dust removal. Use dust collection systems
whenever possible.
3) INFORMATION PLATE SYMBOLS
1 2 3 4
1. Refer to the user manual for operational and safety issues with regard to this machine.
2. Dispose of the machine and electrical components correctly.
3. Eye protection must be worn when operating the machine.
4. Ear defenders must be worn when operating the machine.

Element 14 Manual Original instructions Nov 2019
6
4) UNPACKING
5)SPECIFICATION
Motor Rating
2200w
Voltage
110-120
220-240
Amperes
15
7.5
Hertz (Cycles)
50-60
Phase
Single
RPM
1300
Rotation of Shaft
Counter-
clockwise
Ear and eye defenders must be worn when operating this machine. Wear gloves to protect hands when
operating the machine.
Suitable only for a single phase 50-60Hz A.C. power supply
DO NOT USE ON D.C. SUPPLY
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE
Your saw is shipped complete in one box
1. Remove the saw from the carton by lifting the saw with
the carrying handle.
2. Place the saw on a secure, stationary work surface and
look the saw over carefully.
Table of Loose Parts
The following parts are included:
NOTE: Before beginning assembly, check that all parts
are included. If you are missing any part, do not
assemble the saw.
Part or Assembly Qty.
A. Basic Saw Assembly…………………….1
B. Owner’s Manual………………………….1
C. Arbor Wrench (stored on base) …………2
D. Vise Handle……………………………….1
WARNING: Although compact, this saw is heavy. To
avoid back injury, get help whenever you have to lift
the saw.
B
C
D
A

Element 14 Manual Original instructions Nov 2019
7
RATIONAL SAFETY PROCEDURES
6) OPERATIONAL SAFETY PROCEDURES
Before Using Metal Cutting Saw.
To avoid injury from jams, slips or thrown pieces
。Completely assemble and align the saw.
。Learn the use and function of the ON-OFF switch, upper and lower blade guards, lock pin, and work piece
clamp. (See "Getting to Know Your Metal-Cutting Saw" section within.)
。Review and understand all safety instructions and operating procedures in this manual.
。Review the maintenance methods for this Metal- cutting saw. (See "Maintenance section within").
To avoid injury or death from electrical shock:
。Make sure your fingers do not touch the plug's metal prongs when plugging or unplugging the Metal-Cutting
saw
Before Each Use:
Inspect your saw.
Disconnect the Metal-Cutting Saw. To avoid injury from accidental starting, unplug the saw, before changing
the setup, changing the blade or adjusting anything.
Tighten the arbor screw.
Tighten the cover plate stop screw.
Check Damaged Parts. Check for:
。Alignment of moving parts,
。Damaged electric cords,
。Binding of moving parts,
。Broken parts,
。Stable mounting,
。Function of arm return spring and lower guard: Push the arm all the way down, then let it rise up until it
stops by itself. Check the lower guard to see if it closed fully. If it did not, follow the instructions in the
Troubleshooting section.
。Other conditions that may affect the way the saw works
If any part of this saw is missing, bent, or broken in any way, or any electrical parts don't work, turn the saw off
and unplug it. Report to the sales store to replace damaged, missing, or failed parts before using the saw
again.
Keep Guards in Place, in working order, and in proper adjustment
Maintain Tools with Care. Keep the saw clean for best and safest performance Follow instructions for
lubricating
Remove Adjusting Keys and Wrenches from tool before turning it on.
。Use Only Recommended Accessories. Consult this Owner's manual for recommended accessories. Follow
the instructions that come with the accessories. The use of improper accessories may cause risk of injury to
persons.
。Choose the right 355mm diameter metal cutting blade for the material and the type of cutting you plan to
do.
。Make sure the blade is undamaged and properly sharpened. Observe the maximum speed marked on the
saw blade.
。With the saw unplugged, push the power- head all the way down. Hand spin the blade and check for
clearance. If the blade hits anything, make the adjustments shown in the Maintaining Maximum Cutting
Capacity section.
。Ensure the blade and arbor collars are clean.
。Ensure the collars' recessed sides are facing the blade.
。Using the arbor wrench supplied, make sure the arbor screw is firmly hand tightened.
。Make sure all clamps are tight and there is no excessive play in any parts-
。Keep work area clean and properly lighted. Cluttered areas and benches invite accidents. Floor around
machine level shall be well maintained and free of loose material chip and cut-off and must not be slippery.
Know your saw. Read and understand the owner’s manual and labels affixed to the tool. Learn its application
and limitations as the specific potential hazards peculiar to this tool.

Element 14 Manual Original instructions Nov 2019
8
To avoid injury from accidental contact with moving parts, don't do layout, assembly, or setup work on the saw
while any parts are moving.
Avoid Accidental Starting. Make sure switch is "OFF" before plugging Metal-cutting saw into a power outlet.
Plan your work.
Use the Right Tool. Don't force the tool or attachment to do a job it was not designed to do. Use a different
tool for any work piece that can't be held in a solidly braced, fixed position.
CAUTION: when cutting any metals, sparks or hot fragments could cause a fire.
Plan Ahead to Protect Your Eyes, Hands, Face, Ears. Any power saw can throw foreign objects into the eyes.
This can result in permanent eye damage.
Wear safety goggle (not glasses) that comply with ANSI Z87.1 (shown on package). Everyday eyeglasses have
only impact resistant lenses. They are not safety glasses. Safety goggles are available at Sears retail stores.
Glasses or goggles not in compliance with ANSI Z87.1 could seriously hurt you when they break.
Dress for safety.
。Do not wear loose clothing, gloves, neckties or jewelry (rings, wrist watches) They can get caught and
draw you into moving parts.
。Wear no slip footwear-
。Tie back long hair.
。Roll long sleeves above the elbow.
。Noise levels vary widely. To avoid possible hearing damage, wear earplugs or muffs.
。For dusty operations, wear a dust mask or respirator along with safety goggles.
Plan your work to avoid thrown pieces caused when the work piece binds on the blade and is torn from your
hands.
Avoid awkward operations and hand positions where a sudden slip could cause fingers or hand to move into
the blade.
Don't Overreach. Keep good footing and balance.
Keep your face and body to one side of saw blade, out of line with possible thrown sparks or dusts.
Never cut Freehand:
。Clamp your work piece solidly against the bench and table top so it will not rock or twist during the cut.
。Make sure there's no debris between the work piece and its supports-
。Make sure no gaps between the work piece, the table will let the work piece shift after it is cut in two-
。Keep the cut off piece free to move sideways after it's cut off. Otherwise, it could get wedged against the
blade and could be thrown violently.
。Clear everything except the work piece and related support devises off the table before turning the saw on.
。Secure Work. Use clamps or a vise to help hold the work when it's practical.
Use extra caution with large, very small or awkward work pieces:
。Use extra supports (tables, saw horses, blocks, etc.) For any work pieces large enough to tip when not held
down to the table top.
。Never use another person as a substitute for a table extension, or as additional support for a work piece
that is longer or wider than the basic Metal-Cutting saw table or to help feed, support or pull the work piece.
。Do not use this saw to cut pieces too small to let you easily hold the work with the clamp.
。When cutting irregularly shaped work pieces, plan your work so it will not slip and pinch the blade and be
torn from the clamp.
Whenever Saw Is Running:
Warning! Don't allow familiarity (gained from frequent use of your Metal-Cutting saw) cause a careless
mistake. A careless fraction of a second is enough to cause a severe injury.
Before starting your cut, watch the Metal-Cutting saw while it runs. If it makes an unfamiliar noise or vibrates a
lot, stop immediately. Turn the saw off. Unplug the saw. Do not restart until finding and correcting the
problem.
Keep Children Away. Keep all visitors a safe distance from the saw. Make sure bystanders are clear of the saw
and work piece.
Never confine the piece being cut off. Never hold it, clamp it, touch it, or use length stops against it while the
blade is spinning. It must be free to move sideways on its own. If confined, it could get wedged against the
blade and thrown violently.

Element 14 Manual Original instructions Nov 2019
9
Let the blade reach full speed before cutting. Don't Force the Tool. It will do the job better and be safer at its
designed rate. Feed the saw into the workspace only fast enough to let the blade cut without bogging down or
binding.
Before freeing jammed material:
。Turn saw "OFF" by releasing trigger switch.
。Wait for all moving parts to stop.
。Unplug the Metal-Cutting saw.
After finishing a cut:
。Keep holding the power head down.
，Release the switch, and wait for all moving parts to stop before moving your hands.
Before Leaving the Saw:
Never Leave Tool Running Unattended. Turn power off Wait for all moving parts to stop.
Make Workshop Childproof. Lock the shop. Disconnect master switches. Store tool away from children and
other not qualified to use the tool.
Motor Safety Protection
Important: To avoid motor damage, this motor should be blown out or vacuumed frequently to keep dust from
interfering with normal motor ventilation.
1.Connect this tool to a power source with the appropriate voltage for your model and a 20-amp branch
circuit. Use with wrong size fuse can damage the motor.
2.If the motor won’t start, release the trigger switch immediately. Unplug the Tool. Check the saw blade to
make sure it turns freely. If the blade is free, try to start. See the “Motor Trouble-Shooting Chart.”
3.If the motor suddenly stalls while cutting, release the trigger switch, unplug the tool, and free the blade from
the work piece. The motor may now be restarted and the cut finished.
4.Fuses may “blow” or circuit breakers may trip frequently if:
a: Motor is Overloaded-Overloading can occur if you feed too rapidly or make too many start/stops in a short
time.
b: Line voltages should not be more than 10% above or below the nameplate voltage. For heavy loads,
however, the voltage at motor terminals must equal the voltage specified for your model.
c: Improper or dull saw blade are used.
5.Most motor troubles may be traced to loose or incorrect connections, overload, low voltage (such as small
size wire in the supply circuit) or to overly long supply circuit wire. Always check the connections, the load and
the supply circuit whenever motor doesn’t work well. Check wire sizes and length with the Wire Size Chart
below.
7) OPERATING INSTRUCTIONS
General Cutting Instructions
WARNING! Always securely fix the material to be cut by using the vise.
WARNING! Always wear safety glasses and protective gloves when operating the Metal-Cutting saw.
WARNING! Always disconnect the tool from power source before making any adjustment.
Familiarize yourself with the following functions of the Metal-Cutting saw before connecting it to a power
source and using it.
1. When starting this Metal-Cutting saw for the first time or after it has been idle for a while, always let the
machine run for one full minute with the blade completely recessed into the guard before making any cuts. If
there any unknown defects in the blade that could cause breakage, they usually would do so within the first
minute of operation. If the blade wobbles or vibrates, discard and replace immediately.
2. When beginning a cut with the saw, care should be exercised not to bump or slam the blade into the work;
once it has entered, continue the cut with an even smooth stroke. The faster a cut is made the less heat is
created in the work piece, preventing discoloring, and blade life is prolonged. Cut with maximum force without
overloading the motor
3. Use an outboard support when cutting long, heavy piece to prevent them from tipping the saw or falling
down after they are cut.

Element 14 Manual Original instructions Nov 2019
10
4. When transporting the saw secure the motor mount to the base to prevent damage.
5. When cut-off blade comes up to full speed, push the handle to begin cutting. It is important to cut with
steady and even pressure (Do Not Force) in order to obtain a uniform cut.
WARNING! To avoid injury from unexpected saw movement:
a.Before moving the saw, lock the power head in the lower position. Unplug electric cord.
b.To avoid back injury, hold the tool close to your body when lifting. Bend your knees so you can lift with your
legs, not your back. Life by using the handhold areas at each side of the bottom of the base or by the carrying
handle.
c.Never carry saw by the power cord or the trigger grip of the plastic handle. Carrying the tool by the power
cord could cause damage to the insulation or the wire connections resulting in electric shock or fire.
d.Place the saw so other people cannot stand behind it. Thrown debris could injury people in its path.
e.Place the saw on a firm, level surface where there is plenty of room for handling and properly supporting the
work piece.
f.Support the saw so the table is level and the saw does not rock.
g.Bolt or clamp the saw to its support.
Cleaning the Dust Tank
Loosen the screw (A), take out the dust tank (B) and clear it. Put back the dust tank (B) deck and tighter the screw
(A) again.
Adjusting the Stationary Vise
Clamping the work piece can be accomplished quickly and easily as follows:
1.Lift thread-nut(A)
2.Pull out screw handle (C) far enough to allow work piece (D) to be placed in the vise opening against rear vise
jaw (E) as shown.
NOTE: It is not necessary to thread screw handle (C) when the thread-nut (A) is in the raised position. The
screw handle (C) can be rapidly pulled out or pushed in.
3.Push screw handle (C) until front vise jaw (E) contacts the work piece (D).
4.Flip thread-nut (A) over to engage vice screw (B) and tighten screw handle (C) to securely clamp work piece
(D) in the vise.
A
B
A
B
C
D
E

Element 14 Manual Original instructions Nov 2019
11
Changing the Cutting Angle
The vise can be adjusted from 00 to 45° right.
1. Using the arbor wrench loosen the two bolts on the vise, then set working surface on the vise at the desired
angle.
2. Tighten the two bolts.
Big Blade Guard and Small Blade Guard
When the saw blade pressed down, the big blade guard and small blade guard appropriately separate to allow
cutting of materials.

Element 14 Manual Original instructions Nov 2019
12
Locking Switch, The “OFF” Position
Important: We suggest that when the machine is not in use, the switch be locked in the “OFF” position using a
padlock (G) through the holes in the switch trigger (F).
Work piece clamping
Positions work in vise so that if jam occurs. The blade shall not tend to move the work piece in the
vise. Clamp it securely.
Angle bar should be clamped in a position as shown.
Generally, the saw cuts most efficiently if the blade is cutting the thinnest section at any time.
F
G
Yes
No

Element 14 Manual Original instructions Nov 2019
13
Recommended Cutting Capacity
WARNING! Use of tool for greater than recommended capacities may lead to motor burnout and possible
electric shock.
Note: Cutting through any cross-sectional area of material thicker than 12.7mm (1/2”) tends to load up the
blade, and this will cause your tool to work harder.
Applicable Blade
Dimensions
350mm (14”) Outer Diameter ×25.4mm (1”) hole diameter
AT 45 Degrees
AT 90 Degrees
Work pieces
Configuration
(Cross-Section)
●
■
▬
●
■
▬
Maximum Cutting
Capacity
(4-1/8”)
105mm
(3-1/2” ×3-
1/2”)
90mm
×
90mm
(3-1/4” ×4”)
80mm
×
100mm
(5-1/8”)
130mm
(4-3/4” ×4-
3/4”)
120mm
×
120mm
(3-3/4” ×7”)
95mm
×
180mm
8) CHANGING THE BLADE
1. Disconnect the Machine from The Power Source.
2. Loosen the 3 screws (A), and remove the saw blade cover (B).
3. Press in on arbor lock (C) and at the same time rotate blade (G) by hand until the arbor lock is engaged
4. Using the 8 mm hex wrench provided, loosen arbor screw (D) by turning it counter clockwise, and remove
arbor screw (D), washer (E), outside blade flange (F) and blade (G). Do Not Remove Inside Blade Flange.
5. Make sure the inside surfaces of both the inside and outside blade flanges are clean and free from any
foreign substance
6. Install the new blade (G) Making Certain the Teeth of Saw Blade are Pointing Down at The Front and re-
assemble Outside blade flange (F), washer (E) and arbor screw (D). Turn arbor (D) clockwise to tighten.
7. Replace saw blade cover that was remove in STEP 2.
8. WARNNING: MAKE SURE ARBOR LOCK (C) IS DISENGAGED AND 8 MM HEX WRENCH IS REMOVED BEFORE
TURNING ON THE POWER.
A
B

Element 14 Manual Original instructions Nov 2019
14
9) EXTENSION CABLE SELECTION
Note: Make sure the proper extension cord is used and is in good condition.
The use of any extension cord will cause loss of power. To keep this to a minimum and prevent overheating and
motor burnout, use the information below to deter-mine the minimum wire size extension cord.
EXTENSION CORDS
Use only 3-wire extension cords that have 3-prong grounding plugs and 3-pole receptacles that accept the tool’s
plug. When using a power tool at a considerable distance from the power source, use an extension cord heavy
enough to carry the current that the tool will draw. An undersized extension cord will cause a drop-in line
voltage, resulting in a loss of power and causing the motor to overheat. Use the information provided below to
determine the minimum wire size required in an extension cord. Only round jacketed cords listed by
Underwriter’s Laboratories approval should be used.
For 110v supply: 3.5metres of 3 core x 1.5mm²
For230v supply: 26metres of 3 core x 1.5mm²
When working with the tool outdoors, use an extension cord that is designed for outside use. This is indicated
by the letters WA on the cord’s jacket.
Before using an extension cord, inspect it for loose or exposed wires and cut or worn insulation.
THE CHUCK
C
D
E
F
G

Element 14 Manual Original instructions Nov 2019
15
10) MAINTENANCE
DANGER: Never put injury from lubricants on the blade while it is spinning.
WARNING! To avoid injury from unexpected starting or electrical shock, unplug the power cord before
working on the saw.
Keep the tool clean. Remove accumulated dust from working parts.
Make sure that the tool operates properly, periodically check screws and bolts for tightness.
Feed oil at the oiling points once a month for extending machine service life (machine oil is suitable for the
saw).
。Oiling point
。Rotary part of shaft
。Rotary part of vise
。Slide way of vise
Replacing Carbon Brushes
The carbon brushes supplied will last approximately 50 hours of running time or 10,000 on/off cycles. Replace
both carbon brushes when either has less than 6.5mm length of carbon remaining. To inspect or replace
brushes, first unplug the saw. Then remove the black plastic cap on the side of the motor (caution, this cap is
spring loaded by the brush assembly). Then pull out the brush. Repeat for the other side. To reassemble
reverse the procedure. The ears on the metal end of the brush assemble go in the same hole the carbon part
fits into. Tighten the cap snugly but do not over tighten.
NOTE: To reinstall the same brushes, first make sure the brushes go back in the way they came out. Otherwise
a break-in period will occur that will reduce motor performance and increase brush wear.
Lubrication
All the motor bearings in this tool are lubricated with a sufficient amount of high-grade lubricant for the life of
the unit under normal operation conditions, therefore no further lubrication is required (see below).
Infrequent Lubrication as Required:
Chop pivot: Light machine oil or aerosol will penetrate from ends and junction points. Qualified service
technician can remove pivot unstop to relieve spring tension in order to drive shaft about 19mm right. Exposed
surfaces are lubricated with automotive type oil.
Central pivot of guard: Use light household oil (sewing machine oil) on metal-to-metal guard contact areas as
required for smooth, quiet operation. Avoid excess oil, to which cutting debris will cling and fire hazard from
sparks could be caused.

Element 14 Manual Original instructions Nov 2019
16
11) MACHINE BREAKDOWN

Element 14 Manual Original instructions Nov 2019
17
12) PARTS LIST
NO.
PART
NUMBER
DESCRIPTION.
NO.
PART
NUMBER
DESCRIPTION.
001
Q355-001
1 SAFETY COVER
1
094
Q355-094
FLAT WASHER
1
002
Q355-002
TOOTH LOCK
WASHERCOUNTERSINK
4
095
Q355-095
THREAD NUT
1
003
Q355-003
HEX SOC FLAT HD SCR
4
097
Q355-096
SELF-LOCKING NUT(CLIP)
1
004
Q355-004
SPRING
1
098
Q355-097
KNOB
1
005
Q355-005
M4X8MM PAN HD SCREW
2
099
Q355-098
HANDLE
1
006
Q355-006
LEVER
1
100
Q355-099
PLASTIC KNOB(WING SCREW)
1
007
Q355-007
SHOULDER SCREW
1
101
Q355-100
RING
1
008
Q355-008
SMALL BLADE GUARD
1
102
Q355-101
SCREW
1
009
Q355-009
LEVER
1
103
Q355-102
PIN
1
010
Q355-010
SPACER
1
104
Q355-104
SUPPORT
1
011
Q355-011
PAN HD SCREW + WASHER
2
105
Q355-105
CHAIN
1
012
Q355-012
PROTECTION PLATE
1
106
Q355-106
8MM PIN
1
012A
Q355-012A
COVER LABEL
1
107
Q355-107
HEX SOC HD SCREW +WASHER
2
013
Q355-013
BEARING BASS
1
108
Q355-108
SETTING UP PIECE
1
014
Q355-014
FLAT HD SCREW
3
109
Q355-109
HEX NUT
1
015
Q355-015
EXTL RETAINING RING
1
110
Q355-110
JUMPER WIRE
1
016
Q355-016
SPRING
1
111
Q355-111
VICE PLATE
1
017
Q355-017
M4X8MM PAN HD SCREW
2
112
Q355-112
FLAT WASHER
1
018
Q355-018
BIG BLADE GUARD
1
113
Q355-113
LOCK WASHER
1
019
Q355-019
SPACER
1
114
Q355-114
BOLT
1
020
Q355-020
FLANGE
1
115
Q355-115
LOCK LEVER
1
021
Q355-021
14" BLADE FOR
METALCUTTING SAW
1
116
Q355-116
LOCK WASHER M10
1
022
Q355-022
FLANGE
1
117
Q355-117
WASHER FLATD10.5X22ODX3T
1
023
Q355-023
M10 FLAT WASHER
1
118
Q355-118
SCALE
1
024
Q355-024
SPACER
1
119
Q355-119
DRIVE SCREW
2
025
Q355-025
HEX SOC HD SCREW
+WASHER
1
120
Q355-120
WASHER
1
026
Q355-026
FLAT WASHER
2
121
Q355-121
NYLON NUT
1
027
Q355-027
1 COVER 14"
1
122
Q355-122
ADJUSTING BUSHING
1
028
Q355-028
SCREW W/WASHER
3
123
Q355-123
FLAT WASHER
1
033
Q355-033
STOP
1
124
Q355-124
SPRING
1
034
Q355-034
PAN HD SCREW
1
125
Q355-125
FLAT WASHER
1
035
Q355-035
CORD GUARD
1
127
Q355-127
HEX SOC HD SCREW +WASHER
2
036
Q355-036
PAN HD SCREW
1
128
Q355-128
FLAT WASHER
2
037
Q355-037
TOOTH LOCK WASHER EXT'
2
129
Q355-129
SET SCREW
1
038
Q355-038
POWER CORD
1
130
Q355-130
BRACE BRACKET
1
039
Q355-039
SELF TAPPING SCREW
4
131
Q355-131
CONNECTOR WIRE
3
040
Q355-040
SCREW PAN HEAD
M5+WASHER
2
132
Q355-132
M8X45MM HEX HD SCREW
1
042
Q355-042
HANDLE UPPER
1
133
Q355-133
SET SCREW
1
043
Q355-043
SELF TAPPING SCREW
2
134
Q355-134
NUT HEX M8X1.25
1
044
Q355-044
SWITCH
1
135
Q355-135
PAN HD SCREW + WASHER
3
045
Q355-045
SELF TAPPING SCREW
2
136
Q355-136
NUT
1
046
Q355-046
CORD CLAMP
1
137
Q355-137
SHAFT
1

Element 14 Manual Original instructions Nov 2019
18
NO.
PART
NUMBER
DESCRIPTION.
NO.
PART
NUMBER
DESCRIPTION.
047
Q355-047
HANDEL LOWER
1
138
Q355-138
SPECIAL NUT
1
048
Q355-048
HEX NUT
2
139
Q355-139
M8X45MM HEX HD SCREW
1
049
Q355-049
PAN HD SCREW M5X12
2
140
Q355-140
8MM HEX WRENCH
1
050
Q355-050
LOCK WASHER
2
141
Q355-141
WRENCH HOLDER
1
051
Q355-051
END COVER
1
142
Q355-142
6MM HEX WRENCH
1
052
Q355-052
PAN HD SCREW M5X12
2
143
Q355-143
WRENCH HOLDER
1
055
Q355-055
MOTOR HOUSING
1
153
Q355-153
PAD
2
055A
Q355-055A
SPECIFICATION LABEL
1
156
Q355-156
PAN HD SCREW + WASHER
2
056
Q355-056
PIN RUBBER
1
157
Q355-157
BASE
1
057
Q355-057
HOLDER BRUSH
2
158
Q355-158
PAN HD SCREW + WASHER
6
058
Q355-058
BRUSH
2
159
Q355-159
SUPPORT PLATE
1
059
Q355-059
CAP BRUSH
2
160
Q355-160
CHIP BOX
1
060
Q355-060
SHOULDER SCREW
1
161
Q355-161
HEX NUT
1
061
Q355-061
JUMPER WIRE14X190MM
(YELLOW)
1
162
Q355-162
WASHER FLAT
1
062
Q355-062
SLEEVING
2
163
Q355-163
LOCK WASHER
1
063
Q355-063
CHAIN HOOK
1
164
Q355-164
KNOB
1
064
Q355-064
FIELD ASS'Y 230V
1
165
Q355-165
WING SCREW
1
065
Q355-065
HEX HD SCREW + WASHER
2
166
Q355-166
TERMINAL BLOCK
2
066
Q355-066
BAFFLE
1
167
Q355-167
SLEEVE
1
067
Q355-067
BALL BEARING
1
168
Q355-168
PIN
1
068
Q355-068
ARMATURE
1
169
Q355-169
FILTER CAP
1
069
Q355-069
BALL BEARING
1
169.1
Q355-169.1
FILTER
1
070
Q355-070
PIN RUBBER
1
170
Q355-170
FILTER BOX
1
071
Q355-071
INNER GEAR HOUSING
1
171
Q355-171
PAN HD SCREW M5X12
2
071A
Q355-071A
WARNING LABEL
1
172
Q355-172
SHOULDER SCREW
1
072
Q355-072
STOP
1
173
Q355-173
SHOULDER SCREW
1
073
Q355-073
BALL BEARING
1
174
Q355-174
SHOULDER SCREW
1
074
Q355-074
SPRING
1
175
Q355-175
SLEEVING
1
075
Q355-075
LOCK PIN
1
176
Q355-176
SLEEVING
1
075.
1
Q355-075.1
LOCK PIN
1
177
Q355-177
TIE-CABLE
4
076
Q355-076
E-RING (ETW)
1
178
Q355-178
JUMPER WIRE14X230MM (BLUE)
1
077
Q355-077
STOP
1
179
Q355-179
FIBER PLATE
2
078
Q355-078
FRONT GEAR
1
185
Q355-185
SET SCREW
1
079
Q355-079
SQUARE KEY
1
186
Q355-186
M6X30MM PAN HD
SCREW+WASHER
2
080
Q355-080
GEAR SHAFT
1
187
Q355-187
HANDLE CARRY
1
081
Q355-081
BALL BEARING
1
188
Q355-188
HANGER HANDLE
1
082
Q355-082
BACK GEAR
1
189
Q355-189
LOCKING BAR
1
083
Q355-083
STOP
1
190
Q355-190
TRIGGER
1
084
Q355-084
BEARING BALL6200LLU CM,
1
191
Q355-191
SPRING COMPERSSION
1
085
Q355-085
PIN
2
211
Q355-211
SPRING
1
086
Q355-086
OUTER GEAR HOUSING
1
212
Q355-212
M4X8MM PAN HD SCREW
1
086.
1
Q355-086.1
OIL SEAL
1
213
Q355-213
NUT HEX M5X0.8
1
087
Q355-087
PIN
1
214
Q355-214
BRACE BRACKET
1
088
Q355-088
SQUARE KEY
1
215
Q355-215
FLAT WASHER
2
089
Q355-089
SPINDLE
1
216
Q355-216
HEX SOC HD SCREW +WASHER
2
090
Q355-090
BALL BEARING
1
217
Q355-217
LEVER
1

Element 14 Manual Original instructions Nov 2019
19
NO.
PART
NUMBER
DESCRIPTION.
NO.
PART
NUMBER
DESCRIPTION.
091
Q355-091
WASHER
FLATD10.5X22ODX3T
1
218
Q355-218
WASHER FLAT D8
1
092
Q355-092
PIN
1
219
Q355-219
SHOULDER SCREW
1
093
Q355-093
VISE JAW
1
13) TROUBLE SHOOTING
Problem
Probable Case
Suggested Corrective Action
Motor does not start
1.Fuse
2.Brushes worn
3.Other
4.Low voltage
-15amp time delay fuse, or circuit breaker.
-See “Maintenance” section
-Check power supply for proper voltage and
Correct as needed
Brush sparking when switch
released.
1.Normal automatic brake working
properly
-None
Motor stalls easily
1.Low voltage
2.Excessive wheel pressure when
cutting
-Check power supply for proper voltage and correct
as needed
-Pull wheel through work at a slower pace
General
Problem
Probable Case
Suggested Corrective Action
Blade hits base or work
surface
1.Misalignment
2.Adjust down stop
-Check alignment
Cut not square
1.Defecitive wheel
2.Work not positioned properly
3.Excessive wheel pressure
-Replace immediately
-Position work properly
-Lessen wheel pressure
Power head won’t fully rise or
blade guard won’t fully close
1.Lubrication needed
2.Part failure
3.Pivot spring or guard spring not
replaced properly after service
4.Dirt sticking to stops
-See “Lubrication” section
-Inspect/clean stops

Element 14 Manual Original instructions Nov 2019
20
Blade binds, jams, burns
workpiece.
Rough cuts
1.Improper operation
2.Dull blade
3.Improper blade
-See “ Operation” section
-Replace or sharpen wheel
-Replace with 14” diameter wheel designed for the
material being cut
Tool vibrates or shakes
1.Sawblade not round
2.Sawblade damaged
3.Sawblade loose
4.Other
-Replace wheel
-Replace wheel
-Tighten arbor screw
Power head hard to pull/push
down
1.Lube needed
-See- “Lubrication” section
