Rotabroach ELEMENT 14 User manual

Element 14 Manual
Original instructions
May 2020
1
METAL CUTTING
SAW
Model Number Element 14/1, Element 14/3
This machine (Serial Number ...........................) is CE approved.
Rotabroach Ltd
Burgess Road
Sheffield, South Yorkshire
United Kingdom
S9 3WD
Tel: [phone] Fax: [phone]
Email: [e-mail] Website: www.rotabroach.co.uk

Element 14 Manual
Original instructions
May 2020
2
Thank you for
purchasing our Element 14 Chop saw.
We would really like your feedback on this machine.
Other Products by Rotabroach:
Thank you for your purchase

Element 14 Manual
Original instructions
May 2020
3
CONTENTSOF THE MANUAL
1)
Intended use
Page
4
2)
General safety rules
4
3)
Additional Safety Instructions
6
4)
Information plate symbols
8
5)
Unpacking
8
6)
Specification
9
7)
Operating instructions
10
8)
Extension cable selection
14
9)
Maintenance
15
10)
Machine breakdown
16
11)
Parts list
17
12)
Trouble shooting
18
13)
Warranty statement
19

Element 14 Manual
Original instructions
May 2020
4
1) INTENDED USE
WARNING: This product is a Hand Operated Chop Saw and has been designed to be used with special
Rotabroach blades. Only use accessories designed for use in this machine and/or those recommended
specifically by Rotabroach Power Tools Ltd. When fitted with an appropriate blade this machine can be used to
cut:
Mild Steel
Aluminium
Wood
302, 303 & 304 Grade Stainless Steel
Note: Cutting galvanised steel may reduce blade life.
WARNING: This product is a Hand Operated Chop Saw and must only be used as such. It must not be modified
in anyway or used to power any other equipment or drive any other accessories other than those mentioned in
this Instruction Manual.
WARNING:This machine is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerningthe safe use of the machine by a person responsible for their safety and who is
competent in its safe use. Children should be supervised to ensure that they do not have access to, and are
not allowed to play with, this machine
2) GENERAL SAFETY RULES
Please read these operating and safety instructions carefully and completely. For your own safety, if you are
uncertain about any aspect of using this equipment please access the relevant technical helpline, the number
of which can be found on the Rotabroach website.
ELECTRICAL SAFETY: This machine is fitted with the correct moulded plug and mains lead for its designated
use.
If the power cord is damaged, it must be replaced by an approved cord or assembly available from the
manufacturers or its service agent.
OUTDOOR USE: WARNING: For your protection if this tool is to be used outdoors it should not be exposed to
rain, or used in damp locations. Do not place the tool on damp surfaces. Use a clean, dry workbench if
available. For added protection use a residual current device (R.C.D.) that will interrupt the supply if the
leakage current to earth exceeds 30mA for 30ms. Always check the operation of the residual current device
(R.C.D.) before using the machine.
If an extension cable is required it must be a suitable type for use outdoors and so labelled. The
manufacturer’s instructions should be followed when using an extension cable.
POWER TOOL GENERAL SAFETY INSTRUCTIONS
(These General Power Tool Safety Instructions are as specified in BS EN 60745-1:2009 & EN 61029-1:2009).
WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructionsmay
result in electric shock, fire and/ or serious injury. Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated
cordless power tool.
General Power Tool Safety Warnings (Work area safety)
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating power tool. Distractionscan cause you to lose control.
General Power Tool Safety Warnings [ElectricalSafety]
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs

Element 14 Manual
Original instructions
May 2020
5
with earthed
(grounded) power tools. Unmodifiedplugs and matching outlets will reduce the risk of electric
shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected
supply. Use of an RCD reduces the risk of electric shock.
General Power Tool Safety Warnings [PersonalSafety].
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a
power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust masks,
non-skid safety shoes, hard hat or hearing protection used for appropriate conditions will reduce personal
injuries.
c) Prevent unintentional starting. Ensure the switch is in the off position before connectingto power source
and or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or
energising the power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or key left attached to a
rotating part of a power tool may result in personal injury.
e) Do not overreach. Always keep proper footing and balance. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure that these are
connected and properly used. Use of dust collection can reduce dust-relatedhazards
General Power Tool Safety Warnings [Power tool use and care].
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do
the job better and safer at a rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on or off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the power tool from the power source and/or battery pack from the power tool before making
any adjustments, changing accessories, or storing power tools. Such preventative safety measures reduce the
risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool
or these Instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of moving parts and any
other condition that may affect the power tools operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely
to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, considering

Element 14 Manual
Original instructions
May 2020
6
the working conditions and the work to be
performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
GeneralPower Tool Safety Warnings [Service]
a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained.
HEALTH ADVICE:
WARNING: When using this machine, dust particles may be produced. In some instances, depending on the
materials you are working with, this dust can be particularly harmful. If you suspect that paint on the surface of
material you wish to cut contains lead, seek professionaladvice. Lead based paints should only be removed by
a professional and you should not attempt to remove it yourself. Once the dust has been deposited on
surfaces, hand to mouth contact can result in the ingestion of lead. Exposure to even low levels of lead can
cause irreversible brain and nervous system damage. The young and unborn children are particularly
vulnerable. You are advised to consider the risks associated with the materials you are working with and to
reduce the risk of exposure. As some materials can produce dust that may be hazardous to your health, we
recommend the use of an approved face mask with replaceable filters when using this machine.
You should always:
•Work in a well-ventilated area.
•Work with approved safety equipment, such as dust masks that are specially designed to filter microscopic
particles.
WARNING: The operation of any power tool can result in foreign objects being thrown towards your eyes,
which could result in severe eye damage. Before beginning power tool operation, always wear safety goggles
or safety glasses with side shield or a full-face shield where necessary.
3)ADDITIONAL SAFETY INSTRUCTIONS
a) DANGER: Keep hands away from cutting area and the blade. Keep your second hand on auxiliary handle, or
motor housing. If both hands are holding the saw, they cannot be cut by the blade.
b) Do not reach underneath the workpiece. The guard cannot protect you from the blade below the
workpiece.
c) Adjust the cutting depth to the thickness of the workpiece.Less than a full tooth of the blade teeth should
be visible below the workpiece.
d) Never hold piece being cut in your hands or across your leg. Secure the workpiece to a stable platform. It is
important to support the work properly to minimize body exposure, blade binding, or loss of control.
e) Hold power tool by insulated gripping surfaces when performing an operation where the cutting tool may
contact hidden wiring or its own cord. Contact with a “live”wire will also make exposed metal parts of the
power tool “live”and shock the operator.
f) When ripping always use a rip fence or straight edge guide. This improves the accuracy of cut and reduces
the chance of blade binding.
g) Always use blades with correct size and shape (diamond versus round) of arbor holes. Blades that do not
match the mounting hardware of the saw will run eccentrically, causing loss of control.
h) Never use damaged or incorrect blade washers or bolt. The blade washers and bolt were specially designed
for your saw, for optimum performance and safety of operation.
i) Do not use High Speed Steel (HSS) saw blades.
j) Inspect the machine and the blade before each use. Do not use deformed, cracked, worn or otherwise
damaged blades.
k) Never use the saw without the original guard protection system. Do not lock the moving guard in the open
position. Ensure that the guard operates freely without jamming.

Element 14 Manual
Original instructions
May 2020
7
l) Only use blades that comply with the
characteristics specified in this manual. Before using accessories,
always compare the maximum allowed RPM of the accessory with the RPM of the machine.
Causes and operator prevention of kickback:
Kickback is a sudden reaction to a pinched, bound or misaligned saw blade, causing an uncontrolled saw to lift
up and out of the workpiece toward the operator:
1. When the blade is pinched or bound tightly by the kerf closing down, the blade stalls and the motor reaction
drives the unit rapidly back toward the operator.
2. If the blade becomes twisted or misaligned in the cut, the teeth at the back edge of the blade can dig into
the top surface of the workpiece causing the blade to climb out of the kerf and jump back towards the
operator.
Kickback is the result of saw misuse and/ or incorrect operating procedures or conditionsand can be
avoided by taking proper precautions as given below.
a) Maintain a firm grip with both hands on the saw and position your arms to resist kickback forces. Position
your body to either side of the blade, but not in line with the blade. Kickback could cause the saw to jump
backwards, but kickback forces can be controlled by the operator, if proper precautions are taken.
b) If the blades are binding, or when interrupting a cut for any reason, release the trigger and hold the saw
motionless in the material until the blades come to a completestop. Never attempt to remove the saw from
the work or pull the saw backward while the blades are in motion or kickback may occur. Investigate and take
correctiveactions to eliminate the cause of blade binding.
c) When restarting a saw in the workpiece,centre the saw blade in the kerf and check that saw teeth are not
engaged into the material. If saw blade is binding, it may walk up or kickback from the workpiece as the saw
is restarted.
d) Support large panels to minimise the risk of blade pinching and kickback. Large panels tend to sag under
their own weight. Supports must be placed under the panel on both sides, near the line of cut and near the
edge of the panel.
e) Blade depth and bevel adjusting locking levers must be tight and secure before making a cut. If the blade
adjustment shifts while cutting it may cause binding and kickback.
f) Do not use dull or damaged blades. Unsharpened or improperly set blades produce a narrow kerf causing
excessivefriction, blade binding and kickback.
g) Use extra caution when making a “plunge cut” into existing walls or other blind areas. The protrudingblade
may cut objects that can cause kickback.
h) Check lower guard for proper closing before each use. Do not operate the saw if lower guard does not move
freely and close instantly. Never clamp or tie the lower guard into the open position. If saw is accidentally
dropped, lower guard may be bent. Raise the lower guard with the retracting handle (if equipped) and make
sure, it moves freely and does not touch the blade or any other part, in all angles and depths of cut.
i) Check the operation of the lower guard spring. If the guard and the spring are not operating properly, they
must be serviced before use. Lower guard may operate sluggishly due to damaged parts, gummy deposits, or a
build-up of debris.
j) Lower guard may be retracted manually only for special cuts such as “plunge cuts”and “compound cuts.”
Raise lower guard by retracting handle and as soon as blade enters the material, the lower guard must
be released. For all other sawing, the lower guard should operate automatically.
k) Always observe that the lower guard is covering the blade before placing saw down on a bench or the floor.
An unprotected, coasting blade will cause the saw to walk backwards, cutting whatever is in its path. Be aware
of the time it takes for the blade to stop after switch is released.
WARNING: If any parts are missing, do not operate your machine until the missing parts are replaced. Failure
to follow this rule could result in serious personal injury.

Element 14 Manual
Original instructions
May 2020
8
4) INFORMATION PLATE SYMBOLS
1 2 3 4
1. Refer to the user manual for operational and safety issues with regard to this machine.
2. Dispose of the machine and electrical components correctly.
3. Eye protection must be worn when operating the machine.
4. Ear defenders must be worn when operating the machine.
5) UNPACKING
Caution: This packaging contains sharp objects. Take care when unpacking. Remove the machine, together
with the accessories supplied from the packaging. Check carefully to ensure that the machine is in good
condition and account for all the accessories listed in this manual. Also make sure that all the accessories are
complete. If any parts are found to be missing, the machine and its accessories should be returned together in
their original packaging to the retailer. Do not throw the packaging away; keep it safe throughout the
guarantee
period. Dispose of the packaging in an environmentally responsible manner. Recycle if possible.
Do not let children play with empty plastic bags due to the risk of suffocation.

Element 14 Manual
Original instructions
May 2020
9
6)SPECIFICATION
110v
230v
Motor Rating
1800w
2200w
Voltage
110
230-240
Amperes
16
10
Hertz (Cycles)
50-60
50-60
Phase
Single
RPM
1500
Weight
28kgs
Sound Pressure Level
108 dB(A)
Sound Power Level
121 dB(A)
Vibration Level
1.39 m/s²
Ear and eye defenders must be worn when operating this machine. Wear gloves to protect hands when
operating the machine.
Suitable only for a single phase 50-60Hz A.C. power supply
DO NOT USE ON D.C.
SUPPLY
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE

Element 14 Manual
Original instructions
May 2020
10
7) OPERATING INSTRUCTIONS
GETTING STARTED – PREPARATION
RELEASING the CUTTING HEAD
The cutting head will automatically rise to the upper position once it is released from the locked down
position.
To Release the cutting head from the Locked Down position: Gently press down on the cutting handle.
•Pull out the head latching pin and lock in the outer position
(Fig. 1) Allow the cutting head to rise to its upper position.
Fig.1
If Release is Difficult:
•Gently rock the cutting head up and down.
•Pull the latching pin fully out and turn 1/4 of a turn to lock in the outer position.
Note: We recommend that when the machine is not in use the cutting head is locked in its down position with
the latching pin fully engaged in its socket.
INSTALLING or REMOVING a BLADE
WARNING: Only use genuine Rotabroach blades, or Rotabroach approved blades which are designed for this
machine. Ensure that the maximum recommended blade speed of the blade is compatible with the machine.
WARNING: Only perform this operation with the machine disconnected from the power supply.
Note: It is recommended that the operator considers wearing protective gloves when handling the blade
during installation or when changing the machine’s blade.
Removing a Blade:
•Ensure that the cutting head is in its upper position.
•Loosen the fastener screw securing the arbor guard and rotate
the guard upwards to reveal the machine’s arbor. (Fig. 2)
Fig.2
•Engage the arbor lock by pressing the arbor lock button.
(Fig. 3)

Element 14 Manual
Original instructions
May 2020
11
Fig.3
•Use the supplied hex key to loosen the arbor screw. (Fig. 4)
Fig.4
Note: The arbor screw has a right-hand thread. Turn clockwiseto tighten. Turn counter clockwiseto loosen.
•Remove the arbor screw, washer and outer blade flange and store safely for future installation.
•Retract the lower blade guard up into the upper blade guard by rotating it by hand. (Fig. 5)
Fig.5
•Remove the blade, leaving the inner blade flange in its service position.
Installing a Blade:
•Ensure that all components are free from dirt and debris.
•Install the blade onto the inner blade flange and arbor,
ensuring that the direction and rotation arrow on the
blade matches the direction of arrow rotation found on the machine’s upper blade guard. (Fig. 6)
Fig 6.
•Reinstall the outer blade flange, washer and arbor screw.
•Lock the arbor by pressing the arbor lock button.
•Tighten the arbor screw using the 8mm hex key.
•Return the arbor guard to its service position and tighten the crosshead screw.
•Check that the arbor lock has been released by rotating the blade by hand.
•Ensure that the hex key is removed from the arbor screw and is safely stored for future use.
•Check the installation, and particularly the operation of the retractable lower blade guards by lowering and
raising the cutting head a few times.
WARNING: After installing a new blade, always run the machine, without load, for a couple of minutes. Stand
away from the blade. If the blade were to contain an undetected flaw, it could shatter during this trial run.

Element 14 Manual
Original instructions
May 2020
12
CUTTING HEAD TRAVEL
• Cutting Head Downward Travel Adjustment
To prevent the blade from contacting any part of the machine’s metal base the downward travel of the
cutting head can be adjusted. Lower the cutting head and check for any blade contact with the machine’s base.
If the downward travel of the cutting head needs to be adjusted:
•Loosen the locknut on the downward travel stop screw. (Fig. 7a)
Fig.7
•Turn the adjusting screw (Fig. 7b) out (counter clockwise) to decrease the downwards travel of the cutting
head.
•Turn the adjusting screw in (clockwise) to increase the downwards travel of the cutting head.
•Tighten the adjustment screw locknut when satisfactory downward travel of the cutting head is achieved.
CUTTING ANGLE ADJUSTMENT
Note: The rear vise jaw can be turned through 450.
The rear vise jaw is factory set at 00 (at 900 to the blade) so that the blade cuts squarely across material
positioned in the vise. For angled cuts, the rear vise jaw can be swung through (up to) 450, with a protractor
scale being included on the vise jaw for ease and accuracy of setting.
To angle the rear vise jaw:
•Loosen the M10 socket headed screw and the lever handled locking screw. (Fig. 8)
Fig.8
•Turn the rear vise jaw to the required angle.
•Tighten the socket headed screw securely using the supplied hex key and tighten the lever handled locking
screw.
Note: The lever handle locking screw has a spring-loaded repositionable lever. Repositioning of the lever may
be necessary to ensure that the locking screw can be tightened sufficiently when the rear vise jaw is angled. To
reposition the lever on the screw, pull the lever upwards and rotate the lever to a convenient position (one
that allows the screw to be tightened) release the lever and tighten the screw. The front vise jaw will
automatically compensate for any set angle of the rear jaw, or to accommodate irregular shaped workpieces.
REPOSITIONING THE REAR VISE JAW
The rear vise jaw can be removed from the machine’s base and repositioned. (Fig.9)

Element 14 Manual
Original instructions
May 2020
13
Fig.9
•Reposition the rear vise jaw; there are three (3) possible
positions available because of the six (6) threaded holes in the machine’s base. Replace lever handled locking
screw and the socket headed screw into their new service positions. Ensure that all standard and locking
washers are correctly positioned.
Repositioning the rear vise jaw to the rear-most position will enable wider pieces of material to be cut than is
possiblewith the rear vise jaw in either of the more forward positions.
‘V’ Clamp Jaw (If supplied)
The ‘V’ Clamp Jaw slips over the moving front vise jaw It should be used when cutting round material as it
provides greater
clamping security. It should also be used to cut square tube in a diamond position (Fig. 10).
Fig.10
OPERATING INSTRUCTIONS
WARNING: The tool is
recommended to always be supplied via a residual current device with a rated residual
current of 30 mA or less.
PREPARINGTO MAKE A CUT
Do not overreach.Keep good footing and balance. Stand to one side so that your face and body are out of line
of a possible kickback.
Caution: The minimum cut off piece must be 8mm (5/16”) or greater in length to avoid the piece falling
through the blade slot and causing any potential danger. (Fig 11)
Fig.11
WARNING: Freehand cutting is a major cause of accidents and should not be attempted. Ensure that the
workpiece is firmly secured in the vise.

Element 14 Manual
Original instructions
May 2020
14
•The machine’s base should be clean and free from any swarf or sawdust etc. before the
workpiece is
clamped into position.
•Ensure that the ‘cut-off’material is free to move sideways away from the blade when the cut is completed.
Ensure that the ‘cut-off’
piece cannot become ‘jammed’in any other part of the machine.
•Do not use this saw to cut small pieces. If the workpiece
being cut would cause your hand or fingers to be within 150mm of the saw blade, the workpiece is too small.
Angles should be clamped in an inverted position so that the point of the section is uppermost. (<5.2)
THE ON/OFF TRIGGER SWITCH
This machine is equipped with a safety start trigger switch.
To start the tool:
•Push in the safety lock button on the side of the handle with your thumb.
•Depress the main trigger switch to start the motor.
WARNING: Never start the saw with the cutting edge of the saw blade in contact with the workpiece surface.
MAKING A CUT
•With the cutting head in the upper position, switch on the motor and allow it to reach
full operationalspeed.
•Gently lower the cutting head.
•Introduce the blade into the material slowly, using light pressure at first to keep the blade from grabbing.
•Gradually increase the pressure as a blade enters the workpiece.Do not ‘force’the machine. Let the saw
blade do the work.
Note: Cutting performance will not improve by applying undue pressure on the machine and doing so may
cause blade and motor life to be reduced.
Reduce the pressure as the blade begins to exit the material.
•On completion of a cut allow the cutting head to return to its upper position and turn off the motor.
•Only remove your hands, or the workpiece from the machine, after the motor has completely stopped and
the stationary blade is covered by the lower blade guard
8) EXTENSION CABLE SELECTION
Note: Make sure the proper extension cord is used and is in good condition.
The use of any extension cord will cause loss of power. To keep this to a minimum and prevent overheating and
motor burnout, use the information below to deter-mine the minimum wire size extension cord.
EXTENSIONCORDS
Use only 3-wire extension cords that have 3-prong grounding plugs and 3-pole receptacles that accept the tool’s
plug. When using a power tool at a considerable distance from the power source, use an extension cord heavy
enough to carry the current that the tool will draw. An undersized extension cord will cause a drop-in line

Element 14 Manual
Original instructions
May 2020
15
voltage, resulting in a loss of power and causing the motor to overheat. Use the information provided below to
determine the minimum wire size required in an extension cord. Only round jacketed cords listed by
Underwriter’s Laboratories approval should be used.
For 110v supply: 3.5metres of 3 core x 1.5mm²
For230v supply: 26metres of 3 core x 1.5mm²
When working with the tool outdoors, use an extension cord that is designed for outside use. This is indicated
by the letters WA on the cord’s jacket.
Before using an extension cord, inspect it for loose or exposed wires and cut or worn insulation.
9) MAINTENANCE
Note: Any
maintenance must be carried out with the machine switched off and disconnected from the
mains/battery power supply.
Check that all safety features and guards are operating correctly on a regular basis. Only use this machine if all
guards/safety features are fully operational.
All motor bearings in this machine are lubricated for life. No further lubrication is required.
Use a clean, slightly damp cloth to clean the plastic parts of the machine. Do not use solvents or similar
products which could damage the plastic parts.
WARNING: Do not attempt to clean by inserting pointed objects through openings in the machine’s casings
etc. The machine’s air vents should be cleaned using compresseddry air. Excessive sparking may indicate the
presence of dirt in the motor or worn out carbon brushes.
If this is suspected have the machine serviced and the brushes replaced by a qualified technician with
Rotabroach recommended brushes.
CHIP COLLECTION TRAY
The chip collection tray should be emptied at regular intervals. We recommend that for efficiency purposes
the tray be emptied when it is approximately 60% full.
To check the Chip Collection Tray:
•Turn the locking lever to the horizontal position and withdrawthe tray from the machine to check the
contents.
•Empty the contents of the tray into a suitable recycling bin.
•It may be necessary to wear a dust mask when emptying the chip collection tray.
•Replace the chip collection tray and return the locking lever to the vertical position to secure
the tray within the machine’s base.
TRANSPORTATION/STORAGE
For ease and convenience, when transporting or storing the machine, the cutting head can be held in the
‘down’position.
To hold the cutting head down:
•Lower the cutting head to its lowest position.
•Rotate the cutting head Locking Pin 1/4 of a turn and allow it to deploy to the ‘locked down’position.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for recycling advice.

Element 14 Manual
Original instructions
May 2020
16
10) MACHINE BREAKDOWN

Element 14 Manual
Original instructions
Jan 2020
17
11) PARTS LIST
No.
Part No.
Description
Qty
No.
Part No.
Description
Qty
No.
Part No.
Description
Qty
1
PT0001
Screw M5x12
2
53
PT0056
Bearing 6201
1
108
PT0110
Moving Vice Jaw
1
2
PT0002
Dust Filter
1
54
PT0057
Gear II
1
109
PT0111
Circlip 22
1
3
PT0003
Bearing Support Plate
1
55
PT0058
Flat Key 6x12
1
110
PT0112
V-vice
1
4
PT0004
Washer
1
56
PT0059
Shaft(2)
1
111
PT0114
Back Vice
1
5
PT0005
Screw M5x10
2
57
PT0059
Bearing 6204
1
112
PT0115
Ring
1
6
PT0006
Contact Shield
2
58
PT0060
Gear box
1
113
PT0116
Washer 10
1
7
PT0007
Label
1
59
PT0061
Circlip
1
114
PT0117
Spring washer 10
1
8
PT0008
Cap Screw M5x15
2
60
PT0062
Screw M4x12
3
115
PT0118
Cap Screw M10x25
1
9
PT0009
Depth Stop
1
61
PT0063
Warning Lable
1
116
PT0119
Screw
1
10
PT0010
Motor Housing
1
62
PT0064
Plastic Cover
1
117
PT0120
Angle Adjust Handle
1
11
PT0011
Label
1
63
PT0065
Cap Screw M4x10
2
118
PT0121
Spring
1
12
PT0012
Washer
1
64
PT0066
Blade Housing
1
119
PT0122
Screw
1
13
PT0013
Screw M5x10
1
65
PT0067
Screw M5x90
4
120
PT0123
Angle Ruller
1
14
PT0014
Left Handle
1
66
PT0068
Rubber Ring
2
121
PT0124
Screw
2
15
PT0015
Tapping Screw ST4.2X16
10
67
PT0069
Screw M5x12
1
122
PT0125
Cast Iron Plate
1
16
PT0016
Screw M5x50
2
68
PT0070
Screw M4x10
1
123
PT0126
Cap Screw M8X40
2
17
PT0017
Screw M5x30
1
69
PT0071
Spring
1
124
PT0127
Sprign Washer 8
2
18
PT0018
Tapping Screw ST4.2X13
2
70
PT0072
Screw M4x10
1
125
PT0128
Washer 8
2
19
PT0019
Cable Clamp
1
71
PT0073
Blade Guard(2)
1
126
PT0129
Cap Screw M8X35
2
20
PT0020
Cable Sheath
1
72
PT0074
Circlip 42
1
127
PT0130
Rubber Foot
2
21
PT0021
Cable 110v
1
73
PT0075
Inner Flange
1
128
PT0131
Swarf Tray
1
PT0022
Cable 230v
1
74
PT0076
Screw
1
129
PT0132
Swarf Tray Cover
1
22
PT0023
Right Handle
1
75
PT0077
Wheel
1
130
PT0133
Screw M4x10
10
23
PT0024
Trigger
1
76
PT0078
Connecting Rod (1)
1
131
PT0190
Base
1
24
PT0025
Nut M5
4
77
PT0079
Screw
2
132
PT0142
Wrench Holder
1
25
PT0026
Lower Handle
1
78
PT0080
Connecting Rod (2)
1
133
PT0143
Screw M5x15
2
26
PT0027
Safety Switch
1
79
PT0081
Screw
1
134
PT0144
Rubber Ring
1
27
PT0028
Spring
1
80
PT0082
Screw
1
135
PT0145
Allen Wrench 8MM
1
28
PT0029
Upper Handle
1
81
PT0083
Blade Guard(3)
1
136
PT0146
Cap Screw M8X25
1
29
PT0030
Tapping Screw ST4.2X13
2
82
PT0084
Spring Washer 4
4
137
PT0147
Spring washer 8
1
30
PT0031
Switch
1
83
PT0085
Screw M4x10
4
138
PT0148
Washer 8
1
31
PT0032
Capacitor
1
84
PT0086
Label
1
139
PT0149
Lock
1
32
PT0033
Rubber Ring
1
85
PT0087
Blade Guard Cover
1
140
PT0150
Pin 3x18
1
33
PT0034
Carbon Brush Holder
2
86
PT0088
Washer
1
141
PT0151
Lock Base
1
34
PT0035
Carbon Brush
2
87
PT0089
Screw
1
142
PT0152
Spring
1
35
PT0036
Carbon Brush Holder Cap
2
88
PT0090
Label
1
143
PT0153
Lock Pin
1
36
PT0037
Field Coil 110v
1
89
PT0091
Screw
1
144
PT0154
Circlip 24
2
PT0038
Field Coil 230v
1
90
PT0092
Blade
1
145
PT0155
Pivot Pin
1
37
PT0039
Spring Washer M5
2
91
PT0093
Outer Flange
1
146
PT0156
666677
7766
Torsion spring
1
38
PT0040
Screw M5x80
2
92
PT0094
Washer
1
147
PT0157
Nut M8
1
39
PT0041
Air Buffle
1
93
PT0095
Spring Washer
1
148
PT0158
Screw M8 x 50
1
40
PT0042
Bearing 6200
1
94
PT0096
Cap Screw M10X30
1
149
PT0159
Grub screw M5
2
41
PT0043
Armature 110v
1
95
PT0097
Screw M6X63
1
150
PT0160
Washer M6
2
PT0044
Armature 230v
1
96
PT0098
Washer
1
151
PT0161
Spring washer M6
2
42
PT0045
Bearing 6202
1
97
PT0099
Plastic Handle
1
152
PT0162
Cap screw M6 x 20
2
43
PT0046
Gearbox Cover
1
98
PT0100
Nut
1
153
PT0163
Connecting plate
1
44
PT0047
Key M5x12
2
99
PT0101
Wheel Handle
1
154
PT0164
Movable seat
1
45
PT0048
Spring
1
100
PT0102
Pin 4x25
1
155
PT0165
Pin
1
46
PT0049
Circlip
1
101
PT0103
Screw Rod
1
47
PT0050
Spindle Lock
1
102
PT0104
Vice Screw Support
1
48
PT0051
Bearing 6000
1
103
PT0105
Washer
1
49
PT0052
Gear I
1
104
PT0106
Locking Nut M10
1
50
PT0053
Flat Key 5x12
1
105
PT0107
Washer
1
51
PT0054
Shaft
1
106
PT0108
Connecting Rod
1
52
PT0055
Bearing 6200
1
107
PT0109
Split Pin 3x26
1
•Applies to machines manufactured from August 2021 onwards

Element 14 Manual
Original instructions
Jan 2020
18
Prob l em
Probable Case
Suggested CorrectiveAction
Blade hits base or work
surface
1.Misalignment
2.Adjust down stop
-Check alignment
Cut not square
1.Defecitive wheel
2.Work not positioned properly
3.Excessive wheel pressure
-Replace immediately
-Position work properly
-Lessen wheel pressure
Power head won’t fully rise,
or blade guard won’t fully
close
1.Lubrication needed
2.Part failure
3.Pivot spring or guard spring not
replaced properly after service
4.Dirt sticking to stops
-See “Lubrication” section
-Inspect/clean stops
Blade binds, jams, burns
workpiece.
Rough cuts
1.Improper operation
2.Dull blade
3.Improperblade
-See “Operation”section
-Replace or sharpen wheel
-Replace with 14” diameter wheel designed for the
material being cut
Tool vibrates or shakes
1.Sawblade not round
2.Sawblade damaged
3.Sawblade loose
4.Other
-Replace wheel
-Replace wheel
-Tighten arbor screw
12) TROUBLE SHOOTING
Prob l em
Probable Case
Suggested CorrectiveAction
Motor does not start
1.Fuse
2.Brushes worn
3.Other
4.Low voltage
-15amp time delay fuse, or circuit breaker.
-See “Maintenance” section
-Check power supply for proper voltage and
Correct as needed
Brush sparking when switch
released.
1.Normal automatic brake working
properly
-None
Motor stalls easily
1.Low voltage
2.Excessive wheel pressure when
cutting
-Check powersupply for proper voltage and correct
as needed
-Pull wheel through work at a slower pace
General

Element 14 Manual
Original instructions
Jan 2020
19
13) WARRANTY STATEMENT
Rotabroach™ warrants its machines to be free from faulty materials, under normal usage of machines, for a period of 12
months from initial date of purchase. All other parts (excluding cutters) are under warranty for 90 days, provided that the
warranty registration card (or online registration) has been completed and returned to Rotabroach™or its designated
distributorwithin a period of (30) days from the purchase date. Failure to do so will void the warranty. If the stated is
adhered to Rotabroach™ will repair or replace (at its option) without charge any faulty items returned.
This Warranty does not cover:
1. Components that are subject to natural wear and tear caused by the use not in accordance with the operators’
instructions
2. Defects in the tool caused by non-compliance with the operating instructions, improper use, abnormal environment
conditions, inappropriate operating conditions overload or insufficient servicing or maintenance.
3. Defects caused by using accessories, componentsor spare parts other than original Rotabroach ™ parts.
4. Tools to which changes or additions have been made.
5. Electrical components are subject to manufacturer’s warranty.
Your online registration can be submitted atwww.rotabroach.co.uk
The warranty claim must be logged within the warranty period. This requires the submission or sending of the complete tool
in question with the original sales receipt which must indicate the purchase date of the product. A complaint form must also
be submitted prior to the return.
This can be found online at www.rotabroach.co.uk. Failure to completethis form will result in the delay of your claim.
All goods returned defective must be returned pre-paid to Rotabroach™, in no event shall Rotabroach® be liable for
subsequent direct, or indirect loss or damage.
THIS
WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, (EXPRESSED OR IMPLIED) INCLUDING ANY WARRANTY OF
MERCHANTABLITY OR FITNESS FOR A PARTICULAR PURPOSE. ROTABROACH™ RESERVE THE RIGHT TO MAKE
IMPROVEMENTS AND MODIFICATIONS TO DESIGN WITHOUTPRIOR NOTICE
Known and Trusted Worldwide for Quality, Performance and Reliability
