Roth Audio Charlie 2.0 User manual

www.rothaudio.co.uk
CHARLiE 2.0
Desktop Music System
Powered by RothDock
Designed to be used with:
iPhone/iPod, Any music-enabled
’phone, Desktop PC, Laptop, CD
Player, TV
USER MANUAL
ENGLISH
iPhone not included
CHARLiE 2.0 Manual 23-6-10.indd 1 24/6/10 09:03:48

2
Thank you...
For taking the Roth Audio CHARLiE home
We have designed CHARLiE to look beautiful and, with today’s
advanced technologies, to sound as good as he looks. We’re
pleased – actually we’re delighted - with the results and we hope
you will be too.
CHARLiE is no ordinary little fella, and we’re sure he’ll deliver for you
every bit as well as he has for us since we created him. He can party
hard, or he can play soft and gentle when you want him to – just
let him know, and he’ll fit right in with your moods. He’ll be happy
when you’re happy, but he’s happiest when he’s playing great
music – that’s what he does best.
Turn him on.
In the Box ......................................... 3
Safety instructions ............................. 3
Connecting ....................................... 4
Front and back controls ...................... 5
Remote Control ................................. 6
Dr Feelgood - symptoms & cures .......... 7
Specifications .................................... 8
Service ............................................. 8
Contents
In the Box
RothDock for iPod
CHARLiE stereo speakers –
sonically matched to give you
the best sound
Remote control
Cables: Speaker, USB, power
CHARLiE 2.0 Manual 23-6-10.indd 2 24/6/10 09:03:52

| 3
CHARLiE 2.0
USER MANUAL
ENGLISH
Please DO...
• Keep these instructions in a safe place for future
reference – can we politely recommend that
overflowing drawer where you keep all your other
manuals?
• Make sure that CHARLiE’s new home has adequate
ventilation. So don’t leave him on beds, sofas, rugs,
enclosed bookcases / cabinets and any other area
which might restrict his breathing and cause him
to overheat – a hot and bothered CHARLiE is a sorry
sight.
• Be sure to put CHARLiE on a clean, dry and flat
surface before operation. Nice wooden table =
good. Damp sandpit = bad.
• Please ensure CHARLiE is connected to the correct
power supply as indicated, and please unplug him
if you’re not using him for a while – this saves not
only CHARLiE’s insides, but also the world outside.
Always ensure power cables are placed safely and
are not obstructing a walkway.
• You really should get your CHARLiE serviced by an
authorised service engineer if:
1. The power supply or cord is damaged
2. It drops or is struck by a falling object
3. It’s exposed to rain or moisture
4. It’s not operating normally or shows a sudden
change in performance
Please DON’T...
• Put CHARLiE near water – he can’t swim, and he
hates damp. So avoid placing little CHARLiE near
bathtubs, sinks, washing machines, swimming pool,
sauna etc – he’s usually polite, but he won’t thank
you for it.
• Expose him to direct sunlight or to extremes of
temperature or humidity – best not leave CHARLiE
under a tanning lamp, then.
• Place CHARLiE near direct heat sources such as
radiators, stoves, gas fires, naked flames or candles
• Drop CHARLiE – he may break and he will definitely
get a fright – or apply excessive force to the
controls, or place heavy objects on top of him.
• Allow excessive levels of dust to gather on CHARLiE.
To clean him, use a soft dry cloth. If necessary, use
a damp cloth without any solvents – CHARLiE is no
fan of solvents.
• Try to remove CHARLiE’s back cover – there are no
user serviceable parts anyway, and you don’t want
an electric shock, so get out of there now!
NOTE: Any unauthorized changes or modifications to
CHARLiE render the manufacturer’s warranty null and
void.
Safety Instructions
CHARLiE is really easy to use, but please, before you
start him up, read the safety and operating instructions
CHARLiE 2.0 Manual 23-6-10.indd 3 24/6/10 09:03:56

4
1. Press the ID button on the top surface of RothDock
for 5 seconds until the led flashes on and off.
2. Then press the ID button on the back of the speaker
until the led flashes.
3. When both units are paired, the lights will remain
on, and you should hear a steady tone through
your speakers. The process should only take a few
seconds.
Connecting the RothDock
Plug in the supplied cable to the matching
3.5mm jack inputs on the back of the speakers.
Erm, that’s it.
Connecting the speakers
You can correct other devices by using the auxiliary
input on the back of the dock and also directly into the
speaker by using the auxiliary input or USB inputs.
• Music player (MP3, MP4 or mobile phone)
• CD Player
• Computer
Connecting other devices
Plug in the supplied cable to the matching
3.5mm jack inputs on the back of the speakers.
Connecting the speakers
ID Button
iPod/iPhone Connector
LED
Shows when
RothDock input’s
connected
MuteVolume
Up/Down
Select
CHARLiE 2.0 Manual 23-6-10.indd 4 24/6/10 09:04:02

| 5
CHARLiE 2.0
USER MANUAL
ENGLISH
Select For switching between different
sound sources - RothDock, Aux,
USB Inputs.
Volume Up Full control – you can turn it up…‘ray!
Volume Down Or you can turn it down… boo!
Mute You can cut the music quickly if you
need to, y’know, for phone calls ‘n’stuff!
The Front
Aux Input Mini USB
Input
Power On/Off
Power
Supply Input
ID
Button
Power Button Press to ON for power – the indicator
will light up while the power is ON. Later
on, try pressing it OFF to give it a rest.
Power Input With mains cable supplied, nice!
Aux input 3.5mm for connecting MP3 player, CD
player, computer, whatever.
ID Button For setting up the wireless link to
CHARLiE’s RothDock.
USB Input For connecting to your computer
for direct digital streaming.
Speaker Cable For connecting to the other speaker.
The Back
NOTE: Before you switch ON, set the volume control to the
lowest setting to avoid damage to the speakers. Just in case you
don’t, the speaker-protection circuit will mute the volume for a
few seconds after the power is switched ON.
few seconds after the power is switched ON.
MuteVolume
Up/Down
Select
