Rowenta DW9216 User manual

EN
FR
DE
NL
IT
ES
PT
EL
SV
NO
FI
DA
AR
www.rowenta.com
9
1
3
2
HIG
11
DW9216
1103912652 DW9216 D1 .qxp_110x220mm 15/01/15 15:24 Page2

EN
FR
DE
NL
IT
ES
PT
EL
SV
NO
FI
DA
AR
1*
5
4
8
7
6
15
14
13
9
10
3
2
12
HIGH PRECISION TIP
11
(*) Depending on model - Selon modèle - je nach Modell - al naar gelang het model - A seconda del
modello - Según el modelo - Consoante o modelo - ανάλογα ε το οντέλο - beroende på modell -
avhengig av modell -
mallista riippuen - afhængig af model -
EN ............................5
FR ...........................11
DE...........................17
NL...........................23
IT ............................29
ES...........................35
PT ...........................41
EL ...........................47
SV...........................53
NO..........................59
FI ............................65
DA ..........................71
AR ..........................82
•ºV «∞Luœ¥q
1103912652 DW9216 D1 .qxp_110x220mm 15/01/15 15:24 Page3

fig.3
fig.2
fig.1
fig.5 fig.6
fig.7 fig.8
fig.4
1103912652 DW9216 D1 .qxp_110x220mm 15/01/15 15:24 Page4

fig.12-b
fig.10
fig.13
fig.9
fig.11 fig.12-a
1 min.
1103912652 DW9216 D1 .qxp_110x220mm 15/01/15 15:24 Page5

1
EN
SAFETY INSTRUCTIONS
• Please read these instructions carefully and
keep them for further references.
• Never leave the appliance unattended when
it is connected to a power source; if it has not
cooled down for approximately 1 hour.
• The iron must be used and rested on a flat,
stable, heat-resistant surface.
• When you place the iron on the iron rest,
make sure that the surface on which you
place it is stable.
• Always unplug your appliance: before filling,
or rinsing the water tank, before cleaning it,
after each use.
• Children must be supervised to ensure that
they do not play with the appliance.
• Keep the iron and its cord out of reach of
children less than 8 years of age when it is
energized or cooling down.
• This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved.
• Cleaning and user maintenance shall not be
made by children without supervision.
• Damages on the iron’ soleplate and the
steaming function due to use of the wrong
water (see ‘what water may be used ?’) and
missing maintenance (see ‘Anti calc’) cannot
be accepted as return under warranty.
• The appliance must not be used if it has
fallen to the floor, shows evident of damage,
leaks or fails to function correctly. Never
dismantle your appliance. To avoid any
danger, have it inspected in an approved
service centre.
1103912652 DW9216 D1 .qxp_110x220mm 15/01/15 15:24 Page1

2
DESCRIPTION
Your iron has been designed to operate using untreated tap water. If in doubt, check with your
local water authority. However, if your water is very hard, you can mix 50% untreated tap water
with 50% distilled or demineralised water.
IMPORTANT Before doing anything else, remove the sticker on the side fig.1
Warning! Before using your iron with the steam function for the first time, we
recommend that you operate the steam in a horizontal position for a few moments,
away from your linen, i.e. press the Shot of Steam button a few times.
During the first few uses, a harmless odour and a small amount of smoke may be
noticeable.
This has no effect on the use of the iron and will cease quickly.
pon the first use, you may notice small particles coming out of the soleplate. This
is parf of manufacturing process and is not harmful to you or your garments. It will
disappear after several uses. You may accelerate this by using the self cleaning
function (fig.12a - 12b and shaking the iron gently.
BEFORE SE
1. Auto off*
2. Shot of steam button
3. Steam ON / Steam OFF
4. Cord
5. Handle
6. Spray trigger
7. Thermostat control light
8. Water tank
9. Self clean button
10. Spray
11. High precision tip
12. Soleplate
13. Filling inlet
14. Temperature control dial
15. Rear Cover
WHAT WATER MAY BE SED ?
ENVIRONMENT PROTECTION FIRST !
iYour appliance contains valuable materials which can be recovered or
recycled.
‹Leave it at a local civic waste collection point.
Keep these instructions
IMPORTANT RECOMMANDATIONS
• The voltage of your electrical installation must correspond to that of the
iron (220-240V). Always plug your iron into an earth socket. Connecting to
the wrong voltage may cause irreversible damage to the iron and will
invalidate the guarantee.
• If you are using a mains extension lead, ensure that it is corrected rated
(16A) with an earth, and is fully extended.
• If the electric power cord is damaged, it must be replaced by an Approved
Service Centre in order to prevent any danger.
• Do not unplug your appliance by pulling on the cord.
• Never immerse your steam iron in water or any other liquid. Never hold
it under the tap water.
• Never touch the electric cord with the soleplate of the iron.
• Your appliance gives off steam, which may cause burns, especially when
you are ironing close to the edge of your ironing board.
• Never direct the steam towards people or animals.
• For your safety, this appliance conforms to the applicable standards and
regulations (Low Voltage, Electromagnetic Compatibility, Environmental
Directives).
• This product has been designed for domestic use only. Any commercial
use, inappropriate use or failure to comply with the instructions, the
manufacturer accepts no responsibility and the guarantee will not apply.
• The surfaces which are marked with this
sign and the soleplate are very hot
during the use of the appliances. Don’t
touch these surfaces before the iron is
cooled down.
1103912652 DW9216 D1 .qxp_110x220mm 15/01/15 15:24 Page2

3
EN
IMPORTANT Heat concentrates the elements contained in water during evaporation.
The types of water listed below contain organic waste or mineral elements that can
cause spitting, brown staining or premature wear of the appliance:
water from tumble dryers, scented or softened water, water from refrigerators,
batteries or air conditioners, pure distilled or demineralised water or rain water should
not be used in your iron. Also do not use boiling, or bottled mineral water.
(*) Depending on model
1 • Filling the water tank
• Before filling the water tank, unplug the iron fig.1.
• Set the temperature control dial fig.2 on position (Min.)
• Open the filling inlet fig.3. Fill in water up to the Max. mark. fig.4. Close the filling
inlet and return the iron to the horizontal position.
• You can plug in your iron fig.5.
2 • Setting the temperature*
Select the fabric to be ironed on the thermostat dial. For perfect results, an optimum
position for each fabric has been pre-defined. This position is marked on the dial.
You can also set your iron based on the international temperature measurements •,
••, •••. Ensure your thermostat dial is positioned on these settings.
When your iron reaches the required temperature, the thermostat indicator turns off
fig.6. You can start ironing.
SE
FABRIC THERMOSTAT THERMOSTAT
INDICATION IRONING LABEL
Nylon (Synthetic
fibres, e.g. viscose,
polyester) NYLON
silk SILK
wool WOOL
cotton COTTON
linen LINEN
IMPORTANT The iron takes longer to cool down than to heat up. We recommend that
you start with fabrics to be ironed at a low temperature. For mixed fabrics set the
temperature for the most delicate fabric. At the first heating-up of the cold iron please
wait until the Thermostat indicator goes off the second time. Then the set temperature
is reached and you can begin ironing.
TIP: Always spray starch onto the reverse side of the fabric to be ironed.
3 • Dry ironing
Set the iron on for an ironing without steam, ideal for delicates or perfect finishes.
4 • Shot of steam (from temperature setting (••) upwards)
Press the shot of steam button to generate a powerful jet of steam concentrated at the tip
fig.7. This precision shot allows steam concentration in the front area to remove stubborn
creases. Wait a few seconds between each shot before pressing the button again.
IMPORTANT Leave an interval of a few seconds between each shot and wait until the
flow of steam has finished before standing the iron on its heel.
1103912652 DW9216 D1 .qxp_110x220mm 15/01/15 15:24 Page3

4
5 • Vertical shot of steam (from temperature setting (••) upwards)
Hold the iron vertically and press the shot of steam button to remove creases from suits, jackets,
skirts, hanging curtains etc. fig.8. Wait a few seconds between each shot before pressing the
button again.
AFTER SE
9 • Emptying
nplug the iron fig.1. Pour away remaining water Fig.11.
Set the temperature control dial fig.2 on position Min. Set the iron on dry position .
10 • Storing
Allow the appliance to cool down before winding the cord around the heel. Store the iron
on its heel in a dry and safe place fig.13.
TIP Hold the iron 10 to 20 centimetres away from the garment to avoid burning
delicate fabrics.
IMPORTANT Do not wind the cord around the hot soleplate. Never store your iron
placed down on the soleplate.
Remove the plug from the wall socket and let the iron cool down before
maintenance and cleaning.
IMPORTANT Never direct the steam at persons or animals!
13 • Self Clean (prolongs the life of the iron)
The Self Clean function flushes dirt and scale particles out of the steam chamber.
1. Fill the water tank with untreated tap water up to the max mark and heat the iron to the
••• temperature. Switch off the steam.
2. nplug the iron and hold it over a sink horizontally.
3. Push the self clean button for 1 minute fig.12a-12b and shake the iron gently: steam will
now begin to build up. After a few seconds water will emerge from the soleplate, rinsing
dirt and scale particles out of the steam chamber.
4. Plug in the iron and allow the iron to heat up again. Wait until the remaining water has
evaporated.
5. nplug from the mains and allow the iron to fully cool down. When cool, the soleplate
can be wiped with a damp cloth.
12 • Cleaning the iron
When the appliance has cooled down, wipe the iron down with a damp cloth or sponge. A non
abrasive cleaning agent can be used.
Alternatively the ROWENTA cleaning kit ZD100 D1 can be used. After cleaning the soleplate,
use the Self Clean function to remove residues of the cleaner from the steam holes.
MAINTENANCE AND CLEANING
IMPORTANT Do not use sharp or abrasive cleaning agents or objects to clean the
soleplate and other parts of the iron.
WARNING : Do not use descaling agents even if advertised for steam irons. They will
permanently damage your iron.
TIP se the Self Clean function approx. every 2 weeks. If the water is very hard,
clean the iron weekly.
(*) Depending on model
11 • Anti-scale system
Your iron contains an anti-scale cartridge to reduce scale deposits.
This considerably prolongs the operational life of your iron.
The anti-scale cartridge is an integral part of the water tank and does not need to be
replaced.
6 • Spray
Press the spray button to moisten difficult creases fig.9. You can use the spray function at
any temperature.
7 • Anti-Drip system
It prevents water dripping out of the soleplate when the temperature is too low.
8 • Auto Off function*
• For your safety, the electronic system cuts off the power and the auto off indicator
light flashes fig.10 when:
- The iron remains motionless for more than 8 minutes on its heel
- The iron remains flat or on its side for more than 30 seconds
To restart the iron, just move it gently until the warning light stops flashing.
1103912652 DW9216 D1 .qxp_110x220mm 15/01/15 15:24 Page4

5
EN
(*) Depending on model
Helpline:
If you have any product problems or queries, please contact our Customer Relations Team
first for expert help and advice:
0845 602 1454 - K
[phone] - Ireland
or consult our website - www.rowenta.co.uk
Subject to modifications !
PROBLEMS
Problem Cause Solution
The iron is plugged in, but
the soleplate of the iron
remains cold.
No mains supply. Check that the mains plug is
properly inserted or try
plugging the iron into a
different socket.
Temperature control set too
low. Set the temperature control to a higher temperature.
The automatic electronic
shut off is active.* Move your iron.
Thermostat control light
goes on and off This is normal. When the thermostat control light goes on and off
the iron is heating up.
None or too little steam is
being emitted. Temperature control set too low. Turn the temperature control to the steam area.
Not enough water in the
water tank. Fill the water tank.
Anti-Drip* is active
(§ 8). Wait for the soleplate to reach the correct temperature.
Brown streaks come
through the holes in the
soleplate and stain the
fabric.
Residues in the steam
chamber or on the soleplate. se the Self Clean function then clean your iron.
se the Self Clean function
and clean your iron if you
have used the above.
Fabric fibres have
accumulated in the holes of
the soleplate and are burning.
Clean the soleplate with a
non-metallic sponge.
Your linen is not rinsed
sufficiently or you have
ironed a new garment
before washing it.
Ensure linen is rinsed
thoroughly.
se of starch. Always spray starch onto
the reverse side of the
fabric to be ironed and
clean your iron soleplate
afterwards.
Pure distilled
/demineralised or softened
water is being used.
Only use untreated tap water
or mix half tap water with
half distilled/demineralised
water.
se the Self Clean function
and clean your iron.
Iron is leaking. Overuse of shot of steam
button. Allow more time between each shot.
Soleplate temperature too
low. Set the temperature control to a higher temperature.
se of chemical
descaling agents,
perfumed or scented
additives.
Do not add any descaling
agents, perfumed, or
scented additives to the
water in the water tank.
1103912652 DW9216 D1 .qxp_110x220mm 15/01/15 15:24 Page5

6
CONSIGNES DE SÉCURITÉ
• Merci de lire attentivement ces consignes et
de les conserver.
• Ne laissez jamais l’appareil sans surveillance
lorsqu’il est raccordé à l’alimentation
électrique ; tant qu’il n’a pas refroidi environ 1
heure.
• Le fer doit être utilisé et posé sur une surface
plane, stable et résistante à la chaleur.
• Lorsque vous posez le fer sur le repose-fer,
assurez-vous que la surface sur laquelle vous
le posez est stable.
• Débranchez toujours votre appareil : avant
de le remplir ou de rincer le réservoir, avant
de le nettoyer, après chaque utilisation.
• Il convient de surveiller les enfants pour
s’assurer qu’ils ne jouent pas avec l’appareil.
• Maintenir le fer et le cordon hors de portée
des enfants de moins de 8 ans lorsqu'il est
branché ou qu'il refroidit.
• Cet appareil peut être utilisé par des enfants
âgés de 8 ans ou plus et des personnes dont
les capacités physiques, sensorielles ou
mentales sont réduites, ou des personnes
dénuées d’expérience et de connaissance,
s'ils ont pu bénéficier d’une surveillance ou
d’instructions préalables concernant la
manière d’utiliser l’appareil en toute sécurité
et qu'ils comprennent les dangers potentiels.
• Les enfants ne doivent pas effectuer le
nettoyage et l'entretien sans surveillance.
• Les produits ayant subi des dommages sur
la semelle et la fonction vapeur dus à
l'utilisation d'un type d'eau inadéquat (voir
«quel type d'eau utiliser ?») et à un manque
d'entretien (voir «Anti calc» ne peuvent faire
l'objet d'un retour sous garantie.
• Ne pas utiliser l'appareil s'il est tombé au sol,
présente des dommages apparents, fuit ou
ne fonctionne pas correctement. Ne jamais
démonter l'appareil. Faites-le examiner dans
1103912652 DW9216 D1 .qxp_110x220mm 15/01/15 15:24 Page6
