ROXX CLUSTER S2 User manual

User
Manual
CLUSTER S2
USER MANUAL

2
User
Manual
User
Manual
CONTENT
1. Safety Informations
1.1. General Preventive Measures 3
1.2. Regulations for equipment that connects to power mains 4
1.3.Technical warnsigns and explanation 5
2. Introduction
2.1. About us 6
2.2.CLUSTER S2 6
3. General Product Information
3.1. Scope of delivery 7
3.2.Control Functions 7
3.3.Features 7
4. Installation & Setup
4.1 Physical Installation and Rigging 8
4.2 Connections 13
4.2.1. AC Power 13
4.2.2. DMX Connection 14
4.2.2.1. Cable Connection 14
5. Operation
5.1 Start up 15
5.2 Control Display 15
5.3 Display Short Cuts 15
5.4 Conguration 17
5.4.1 Set DMX Start Address (Direct Access) 17
5.4.2 Selecting DMX Mode 17
5.4.3 Stand Alone 18
5.4.4 Settings 22
5.4.5 System Info 29
6. Accessories
6.1 Accessories 30
7. Technical Data / Diagrams
7.1 Technical drawings and measurements 31
7.2 IP Rating 32
7. 3 Technical Data 33
7.4 DMX-Charts / Color Macro Charts / CCT Chart 35
7.5 RDM Templates 39
7.6 Firmware Update 40
8. Troubleshooting 41
9. Manufacturer´s Declaration 41

3
User
Manual
1. SAFETY INFORMATION
1.1. General Preventive Measures
1.1.1. Please read, understand and follow the instructions.
1.1.2. Store the instructions and information in a safe place.
Best solution is the ring binder provided by ROXX.
1.1.3. Follow all safety warnings. Under no circumstances remove safety warnings
or other information from the equipment.
1.1.4. Don’t use the equipment for any other intended purpose or manner.
1.1.5. Use only stable and compatible stands and/or brackets. Especially when x installed.
Make sure the wall brackets are properly installed and safe. Make sure the device is securely
installed and cannot fall.
1.1.6. Check the safety regulations applying for your country before and during installation.
1.1.7. Keep the device away from heat! Don’t place/install near heaters, ovens or any source of heat.
Make sure that the device always is efciently cooled and cannot overheat.
1.1.8. Always guarantee that ventilation and cooling slots are clean and not blocked.
1.1.9. Item must be away minimum 20cm from anything around and above it.
1.1.10. Do not use this device close to water.
1.1.11. Do not expose this equipment to ammable materials.
1.1.12. Make sure that no objects can fall into the device.
1.1.13. Only use this device with the accessories recommended by the manufacturer.
1.1.14. Always check the equipment for housing damages, so that no water can enter the device.
No containers containing liquids of any kind should be place on top of the unit.
1.1.15. Opening or modifying this device is only allowed by authorized and qualied persons.
1.1.16. All cables need to be checked after connecting the device in order to prevent damage or accidents.
1.1.17. Make sure that the device is transported safe and packed proper in order to prevent damage of any kind.
1.1.18. Once you notice improper function of your device due to damage, electric shock or anything similar,
immediately unplug the unit from the mains outlet and contact our service department.
1.1.19. Clean the device with a dry cloth.
User
Manual

4
User
Manual
1.1.20. Observe all disposal laws applicable in your country. Especially for the packaging.
1.1.21. Plastic bags are not a toy! Keep away from children!
1.1.22. Please note that changes or modications which are not approved by the party responsible
for compliance will void the user’s authority to operate the device.
1.2 Regulations for equipment that connects to power mains
1.2.1. If an earthing contact is available in the used power cord, it must used in combination
with an power outlet, providing a protective ground. In no circustances should the protective
ground be deactivated.
1.2.2. Do not switch on the device immediately after it has been in strong different temperatures,
especially after transport. Let the device acclimatize to the temparature in the room of usage
rst to prevent moisture and condensation.
1.2.3. Verify that the correct voltage and frequency are available in the area of operation, before
connecting the unit to the mains outlet.
1.2.4. If the plug doesn‘t t in your mains outlet, contact your electrician.
1.2.5. Make sure your power cord/adapter/connector does not show signs of kinks/warps or is being
stepped on.
1.2.6. Allwas disconnect the unit when not in use or being cleaned. Don‘t pull on the cord to disconnect.
Only touch power connections with dry hands!
1.2.7. Don‘t switch the unit on/off rapidly. This may cause damage.
1.2.8. If a fuse needs to be replaced, ALWAYS make sure that exact the same fuse will be used
(type and rating). Repeatedly blown fuses need to be checked by an authorised service technician.
1.2.9. In the risk of lighting strike all units need to be unpluged from the mains in order to prevent damage.
1.2.10. During installation there must be a voltage free condition.
1.2.11. The device needs to be cleaned and serviced regularly and will credit this with a longer life cycle.
Dust, dirt, moist, water, smoke, nicotine or anything similar inside the unit will cause
damage/malfunction.
1.2.12. The unit needs to have at least 0,5m distance to anything ammable.
1.2.13. You have to make sure that any electrical installation applys to the laws of your country.
Correct power cables and applying standards have to be used.
User
Manual

5
User
Manual
1.3. Technical warnsigns and explanation
In order to prevent the risk of an electric shock, under no circumstances remove the cover/back
or open the unit in any way! No user serviceable parts are inside. Service, maintenance and repairs
should only be done by qualied service personnel or the manufacturer.
Dangerous uninsulated voltage inside the device can cause an electrical shock when opened by
unqualied personnel.
Important operating and maintenance instructions apply!
Do not operate this device in tropical climates.
CAUTION! Intense LED light source! Risk of eye damage. Do not look into the light source
The housing surface of the spotlight can heat up to temperatures as high as 70 °C in regular use. Ensure
that it is not possible to come into contact with the housing unintentionally. Always allow sufcient time
for the lamp to cool down before dismantling, carrying out maintenance work or charging etc..
IMPORTANT IMFORMATION!
• This is a product which has been developed for professional usage
in event technology. It is not suitable as a houshold lighting.
• NEVER stare, not even temporarily, directly into the light source.
• Don‘t use magniers or any other optical instrument to look at the beam.
• The effects of this device, expecially the stroboscope effect, can cause
problems for sensitive people or may even cause epileptical seizures.
User
Manual

6
User
Manual
2. INTRODUCTION
2.1. About us
The name ROXX®came easily.
Combined with the concentrated knowledge and many years of experience, our three founders, who have been
leaving their mark in the event and lighting industry for many years already, came together in 2020 to start this
outstanding venture.
Product development, sales and marketing as well as the exceptional know-how and the profound rooting in the
eld of the professional lighting technology belong to our core competences and therefore guarantee extremely in-
novative and reliable products, excellent support and professional service in every aspect.
Designed & developed in Germany
ROXX®products are developed and designed in Germany. Always in tight consultation with our customers and
experts who will eventually be working with these tools. This ensures innovative, easy-to-use and performance-
oriented solutions, which provide added value for our customers.
Made to last
Recommended for permanent outdoor use, most ROXX®products feature additional corrosion protection and en-
hanced IP66 equipment protection, thereby providing that crucial extra for a wider range of applications. In addition
to architectural or theme park applications, even xed installations in coastal or offshore areas with high salt expo-
sure can be reliably implemented over long periods of time.
2.2. CLUSTER S2
The S2 is an advanced pixel mappable strobe and washlight that combines two complementary effects in one unit,
designed for extremely powerful and versatile applications. Thanks to the advanced and tool-free cluster mecha-
nism, ROXX S2 can be combined with all CLUSTER series products to provide lighting designers with new creative
possibilities in horizontal and vertical congurations and is suitable for small to large venues and stadiums.
CLUSTER S2 features a large number of build-in patterns and giving users a fast and simple way of creating stun-
ning effects whenever a media server is not available, or the installation requires a speedy solution.
ROXX also offers a wide range of magnetic, easy-to-apply accessory lters. The Blackface lter is especially useful
in TV applications, as it allows the devices to visually disappear in the stage design when switched off. The two
elliptical lters shape the light beam either vertical or horizontal with a frost effect, giving user even more effect
possibilities. ROXX CLUSTER S2 provides an IP65 protection, which guarantees its ideal use in outdoor applications.
User
Manual

7
User
Manual
3. GENERAL PRODUCT INFORMATION
3.1. Scope of delivery
1x CLUSTER S2
Power cord with plug (EU country specic, if not ordered differently)
Pre-installed PUK
We´re offering a wide range of professional accessories (optional). Please see under menu 6 or at our website
www.roxxlight.com
3.2. Control Functions
• 15CH Simple, 31CH Easy, 64CH Standard, 112CH Pure, 209CH Pure Mode, 168 CH Full Access,
265CH Full Access Extended
• Art-Net / sACN
• RDM (Remote Device Management)
• Stand Alone Functions including auto programs, LEE adjusted color macros, custom color templates
and Tunable White
• Master & Slave
3.3. Features
User
Manual
Art-Net
sACN

8
User
Manual
Closed
Open
4. INSTALLATION & SETUP
4.1 Physical Installation and Rigging
ROXX CLUSTER S2 may be installed in any orientation. For this purpose the product provides several options:
Standing:
The xtures Yoke includes two M8 inner threads to install the optional ROXX YOKE FLOOR EXTENSION.
Hanging:
The xture can be installed in different ways:
1. Directly by integrated 1/4 turn Camlocks on top- or rear side
User
Manual
Omega Bracket ST

9
User
Manual
2. By included yoke with several mounting points:
Multiple mounting points:
A: 3x Camlock with ¼ turn adapters
B: 3x M12 / ½“
C: 1x TV Spigot
3. Using optional ROXX RIGGING BRACKET
For seemless connection of multiple Blinders, to avoid gaps due to bracing of the truss structure by variable, sliding
mounting positions.
Product Clustering
All CLUSTER products can be easily connected both horizontal and vertically, by using the integrated
C-Lok system. The series is made to enable toolless multiple array congurations, scalable from a
single vertical line, to massive matrix like arrays.
To connect the devices with each other, proceed as follows in sequence:
1. Bring the devices together with the respective top and
bottom side.
A so-called centering puk is pre-installed on the top of
every cluster device.
This should always be installed when connecting the de-
vices to each other.
User
Manual
B
A
C

10
User
Manual
2. Pre-Link Magnets on top and side help to allign the x-
tures due cluster process and giving support operation
for convenient and save interlocking.
Important Note:
Even though the pre-link magnet system
is strong enough to hold the devices to-
gether, at least one hand must always
remain on the device for support during the connection.
3. Make sure that the C-Lok hooks are turned counterc-
lockwise (CCW) to the end-position rst before you nally
lock the C-Loks.
4. For locking all C-Lok´s, please turn them clockwise into
end-position.
Note:
As soon as both dot indicators are in line, the C-Lok is
securely locked
Maximum Tensile and Torsion Load
Before setting up Cluster congurations, be aware of the maximum tensile and torsion load, listed
here below. Also make sure the mounting clamps are capable of supporting the total weight of your
conguration.
The different rigging options of all Cluster products result in different maximum tensile and torsion loads that must
not be exceeded for a safe overhead installation.
User
Manual

11
User
Manual
The maximum loads listed here below take into account the 10-fold safety!
1. Rigging by integrated 1/4 turn Camlocks on top- or rear side
2. Rigging by Yoke with multiple mounting points
User
Manual
Max. Tension Load: 90kg
Max. Torsion Load: 18.703 Nmm
Max. Tension Load: 90kg
Max. Torsion Load: 14.201 Nmm
a. With 1x Mounting Clamp
Max. Tension Load: 40kg
Max. Torsion Load: 4.414 Nmm
c. With 1x Omega Bracket
Max. Tension Load: 51kg
Max. Torsion Load: 4.768 Nmm
b. With 2x Mounting Clamp
Max. Tension Load: 77kg
Max. Torsion Load: 7.308 Nmm
d. With 2x Omega Bracket
Max. Tension Load: 90kg
Max. Torsion Load: 5.943 Nmm

12
User
Manual
3. Using optional ROXX RIGGING BRACKET with 2x Mounting Clamps
Important Note:
Please be aware of using the centering PUK for safe RIGGING BRACKET installation to the
CLUSTER device.
User
Manual
Max. Tension Load: 72kg
Max. Torsion Load: 6.326 Nmm
e. YOKE 2.2 with 1x Mounting Clamp
Max. Tension Load: 88kg
Max. Torsion Load: 8.238Nmm
f. YOKE 2.2 with 1x Omega Bracket
Max. Tension Load: 66kg
Max. Torsion Load: 6.476Nmm

13
User
Manual
User
Manual
4.2 Connections*
A: Mains In: IP65 Power input connector with rubber sealing cap.Connect using the provided power cable (when not
in use, always close with rubber sealing cap).
B: Mains Out: IP65 Power output connector with rubber sealing cap. Provides power to additional xtures. Ensure that
the total power consumption of all daisy-chained devices connected do not exceed 8A (Ampere)! (when not in use,
always close with rubber sealing cap).
C: DMX IN: Male IP65 5-pin XLR connector (when not in use, always close with rubber sealing cap).
D: DMX OUT: Female IP65 5-pin XLR connector (when not in use, always close with rubber sealing cap ).
E: GoreTex
F: Safety Eyelet
G: IP65 USB port for rmware updates
H: Ethernet IN, Art-Net /sACN
I: Ethernet OUT, Art-Net /sACN
*Note:
In order to provide protection from spraying water, in accordance with protection class IP65, special IP65-
rated XLR connectors must be used correctly with the DMX input and output sockets, or they must be closed
using the rubber sealing caps. When connected correctly, or when sealed correctly with the rubber sealing
caps, the POWER IN and POWER OUT sockets are protected from spraying water, as in accordance with IP65.
4.2.1. AC Power
The CLUSTER S2 operates on any 100–260 V, 50/60 Hz AC mains power supply with a maximum power consump-
tion of 1250W. Connect the xture to AC power using the supplied cable or a similar one with Neutrik powerCON
TRUE1 NAC3FX-W or a compatible type, to ensure the correct ingress protection (IP).
For temporary installations, the mains cable must be tted with a grounded connector intended for exterior use. The
xture must be grounded/earthed and be able to be isolated from AC power. The AC power supply must incorporate
a fuse or circuit breaker for fault protection.
Warning!
Read “Safety Informations” starting on page 3 before connecting the xtures to AC mains power!
Do not connect the xture to an electrical dimmer system, as doing so may cause damage that is not
covered by the product warranty!
A
D
C
G
F
F
E
B
Wire Color (EU models) Wire Color (US models) Conductor Symbol
Brown Black Live L
Blue White Neutral N
Yellow / Green Green Ground (earth) or
H
I

14
User
Manual
4.2.2. DMX Connection
The CLUSTER S2 is fully controllable by DMX (USITT DMX512-A standard, based on RS-485) Art-Net, sACN and
RDM.
4.2.2.1. Cable Connection
If using a cabled DMX system, connect the DMX IN cable to the input connector (male 5-pin XLR connector) and
DMX OUT cable to the output (female 5-pin XLR connectors).
For outdoor installations, use only IP65-rated XLR connectors.
Use shielded twisted pair cable designed for RS-485 devices. The cables are daisy chained between the xtures,
and up to 32 xtures can be connected to the same DMX link. Up to 300 meters (1000ft.) of cable is achievable with
high quality DMX cables. All DMX links must be terminated in the last xture by connecting a DMX termination plug
to the last xture’s 5 pin DMX out connector.
Standard microphone cable is not suitable for transmitting DMX.
1DATA
GND
DMX Termination
on last xture DMX out
DATA -
DATA +
120 Ohm
+/- 5%
5
2 4
3
1DATA
GND
XLR pin out
DATA -
DATA +
5
2 4
3

15
User
Manual
5. OPERATION
5.1 Start up*
Once the xture is connected to AC power, the boot process starts and the following information will appear on the
display:
“Ready to ROXX”, the product name and the current software version.
After this process, the xture is ready for operation, and starts in the previous-
ly enabled mode.
*Note:
During boot process the fan spins up quickly to blow out some possible
dust from last use.
5.2 Control Display*
OLED Display with Touch-Sensitive controls
Press ENTER to access the selection menu for system settings or conrm changes.
Press ESC to take a step back in the menu.
Press arrows to scroll up and down inside the menu and change values, such as DMX address.
*Note:
For a smooth navigation thru the menu settings, please make sure the display surface is dry and dust free.
After approximately 1 minute of inactivity inside the menu settings, the display will automatically jump back
to home screen.
5.3 Display Short Cuts*
Short Cuts
For some always recurring functions the xture allows quick and user-friendly access at home screen over some dis-
play control short-cuts:
User Reset or Factory Reset*
Pressing ESC+ENTER simultaneously a Factory Reset or User Reset can be started.
By using the up/down arrows the Factory- or User Reset can be selected.
For conrming press ENTER, to jump back please press ESC.
*Note:
After Factory Reset all xture settings are set back to factory default values.
After User Reset all user selected reset functions and user default values will set back.
Also a short self-test will start immediately while dimming in and out each single color.
User
Manual
ESC
ENTER ESC
+
ENTER

16
User
Manual
Display Off
Pressing ESC + arrow down simultaneously the display backlight function will set to off and the display will turn off
immediately. Once a control is pressed the display backlight will turn on.
Manual display ip function*
The xture includes an auto display ip function by default.
To use the manual display ip function please disable the auto ip function under Settings / Display rst. Once the
auto display ip function is disabled you can use the manual display ip function by pressing arrow up + arrow down
simultaneously. The display will rotate 180. By pressing both arrows simultaneously again the display will ip back.
*Note:
Once the display is ipped both Up / Down controls will work according to the display rotation.
Quick Light function
(hold 3 seconds)
For easy and fast operation during setting the lights the xture includes a user-friendly Quick Light function (Daylight
5600 Kelvin). If DMX is not assigned please press and hold ENTER for 3 seconds at homescreen, after the Quick Light
function will appear.
Here dimmer can be adjusted from 0-100% by using up/down arrows, to take over the dimming value please press
ENTER to conrm.
User
Manual
ESC
ENTER
+
+

17
User
Manual
5.4 Conguration
Home Screen
After boot process the xture is ready for operation and starts in the previously enabled mode. At home screen the
following information will appear, depending on the current operating mode:
A DMX Adress
B Operating Mode (DMX Mode, Quick Light or Standalone Mode)
C Next available DMX address depending on the xtures DMX footprint
D External Data protocol (DMX / Art-Net / sACN).
E The dot indicates the active protocol
5.4.1 Set DMX Start Address (Direct Access)
At Home Screen the DMX address can be changed directly by using the up and down arrows. During this process the
DMX address starts blinking, once it´s conrmed by pressing ENTER it stops blinking.
If the DMX address will not be conrmed by ENTER within 10 seconds, the display will jump back and show the DMX
address from before and stops blinking.
5.4.2 Selecting DMX Mode*
At home screen please press ENTER to access to the main menu (level 1).
While using UP / DOWN arrows, please select the menu item “DMX Mode” and conrm
by pressing ENTER.
In the following sub-menu (level 2), you can now choose between 7 different DMX operating modes while using the
UP/Down arrows and conrm by pressing ENTER or jump back by pressing ESC.
After conrmation the display will jump back to main menu (level 1). Press ESC for homescreen, here the selected
DMX mode will be displayed.
*Note:
For detailed information about the several DMX modes including channel assignment please see our DMX
Control chart.
.
User
Manual
64 CH
STD Next
( 65 )
•DMX
1
B
A
C
D
E

18
User
Manual
5.4.3 Stand Alone*
Press ENTER to access to main menu (level 1).
While using the UP / DOWN arrows, please select the menu item “Stand Alone” and conrm
by pressing ENTER.
In the following sub-menu (level 2), you can now choose between 5 different Stand Alone operating modes (Auto,
Color Macro, Quick Color, Tunable White, User Color) ,Stop Stand Alone and Color Settings functions while using the
UP/Down arrows and conrm by pressing ENTER or jump back by pressing ESC.
To nally use Stand Alone programs please make sure DMX is disconnected to the xture, as this protocol has priority.
Stop Stand Alone
To stop a running Stand Alone mode immediately, please select “Stop Stand Alone” and conrm by pressing ENTER.
The display will automatically jump back to level 1.
Auto FX*
Select “Auto FX” by using the up/down arrows and press ENTER.
Here at sub-menu (level 3), you can choose between 10 different Auto Effects (Effect 1 - 10 ) and Stop Program. Using
the Up/Down arrows you can select one of the 10 Effects and conrm by pressing ENTER or step back by ESC.
After conrming your preferred Effect, you can now adjust speed and brightness at level 4.
To adjust speed, please use the UP / DOWN arrows to select the menu item “Speed”, and conrm with ENTER. After
use UP / DOWN arrows to adjust the speed value between 000-100 and conrm by ENTER or jump back by ESC.
To adjust brightness please select “Dim” as per the procedure previously described and conrm with ENTER. After
use UP / DOWN arrows again to adjust the brightness value between 000-100 and conrm by ENTER or jump back
by ESC.
Once it´s conrmed or denied the display will automatically jump back to level 3.
To stop running a selected Effect please chose “Stop Program” at level 3 or "Stop Stand Alone" at level 2.
For returning back to homescreen please press ESC three times.
At homescreen the selected Stand Alone mode “Auto” and the selected program will be displayed.
*Note:
Using arrows UP /DOWN at homescreen Auto programs can be directly changed according to the list.
User
Manual
Menu
Level 1
DMX Mode
Stand Alone
Settings
System Info
DMX Mode
Level 2
15CH Simple
31CH Easy
64CH Standard
112CH Pure
209CH Pure Mode
168 CH Full Access
265CH Full Access Extended
Menu
Level 1
DMX Mode
Stand Alone
Settings
System Info
Stand Alone Mode
Level 2
Stop Stand Alone
Auto FX
Color Macro
Quick Color
Tunable White
User Color
Color Settings

19
User
Manual
Color Macro*
46 different color macros (34x matched LEE color lters, 6 LED colors and 6 different Whites) are available as presets.
For each the brightness can be adjusted separately.
To select a color macro please press ENTER to access to main menu (level 1).
While using the UP / DOWN arrows select the menu item “Stand Alone” and conrm
by pressing ENTER. After please select the item “Color Macro” by using the up/down arrows and press ENTER again.
Using UP and DOWN controls, select your desired color preset and conrm with ENTER.
At level 3 you can adjust the brightness for the color preset between 000-100. Conrm by ENTER. For color blackout
choose the item “Color Off”.
Note: Using UP / DOWN arrows at homescreen Color Macros can be changed according to the list.
User
Manual
Effect 1
Auto FX
Menu
Level 1
DMX Mode
Stand Alone
Settings
System Info
Stand Alone Mode
Level 2
Stop Stand Alone
Auto FX
Color Macro
Quick Color
Tunable White
User Color
Color Settings
Color Macro
Level 3
Color Off
Color Macros
Color Macro Chart
Dim <0-100>
Menu
Level 1
DMX Mode
Stand Alone
Settings
System Info
Stand Alone Mode
Level 2
Stop Stand Alone
Auto FX
Color Macro
Quick Color
Tunable White
User Color
Color Settings
Auto
Level 3
Stop Program
Effect 1
Effect 2
Effect 3
Effect 4
Effect 5
Effect 6
Effect 7
Effect 8
Effect 9
Effect 10
Program
Level 4
Speed <0-100>
(Default 50)
Dim <0-100>

20
User
Manual
Quick Color*
The standalone mode “Quick Color” allows a direct adjustment of the single LED segments, Dimmer and Shutter.
To adjust your Quick Color please press ENTER to access to main menu (level 1).
While using the UP / DOWN arrows select the menu item “Stand Alone” and conrm
by pressing ENTER. After please select the item “Quick Color” by using the up/down arrows and press ENTER again.
Using UP and DOWN controls, select your desired LED segment or color and conrm with ENTER.
After you can adjust the brightness for the color between 000-255 and conrm by ENTER.
Besides the individual color mix also a master dimmer can be adjusted between 000-100.
For strobe effects please adjust the Shutter value between 000-255.
*Note: Please see detailed explanation for strobe effects inside DMX chart at the end of this manual.
Using UP/DOWN arrows at homescreen you can change Quick Color´s dimmer value.
User
Manual
Gels -
Color Macros for Standalone Mode
Pos. Gel Name Color Number
1Red
100% Red LED
2Fire LEE 019
3Medium Red LEE 027
4Primary Red LEE 106
5Med Amber LEE 020
6Dark Amber LEE 022
7 Deep Amber LEE 104
8 Orange LEE 105
9 Deep Golden Amber LEE 135
10 Yellow LEE 101
11 Green
100% Green LED
12 Lime Green LEE 088
13 Moss Green LEE 089
14 LEE Green LEE 121
15 Primary Green LEE 139
16 Jas Green LEE 738
Gels -
Color Macros for Standalone Mode
Pos. Gel Name Color Number
17 jade LEE 323
18 Blue
100% Blue LED
19 Sky Blue LEE 068
20 Tokyo Blue LEE 071
21 Light Blue LEE 118
22 Marine Blue LEE 131
23 Med Blue LEE 132
24 Congo Blue LEE 181
25 Mikkel Blue LEE 716
26 Rose Pink LEE 002
27 Med Pink LEE 036
28 Light Lavender LEE 052
29 Lavender LEE 058
30 Magenta LEE 113
31 Mauve LEE 126
32 Smokey Pink LEE 127
Gels -
Color Macros for Standalone Mode
Pos. Gel Name Color Number
33 Special Med Lavender LEE 343
34 Ultimate Violet LEE 707
35 Magical Magenta LEE 795
36 Chrysalis Pink LEE 798
37 Specia KH Lavender LEE 799
38 Bulb White 2700K
39 Halogen White 3200K
40 Neutral White 4200K
41 Daylight White 5600K
42 Cold White I 6000K
43 Cold White II 6300K
44
Amber (only if available) 100% Amber LED
45 Lime (only if available) 100% Lime LED
46 Cyan (only if available) 100% Cyan LED
Level 4
Menu
Level 1
DMX Mode
Stand Alone
Settings
System Info
Stand Alone Mode
Level 2
Stop Stand Alone
Auto FX
Color Macro
Quick Color
Tunable White
User Color
Color Settings
Quick Color
Level 3
Dimmer Center Tube <0-10 0>
Dimmer Single Tubes <0-10 0>
Dimmer RGB Panels <0-100>
Shutter <0-255>
Red <0-255>
Green <0-255>
Blue <0-255>
