RSF Europe MicroDVP-HD User manual
P
ro
DAP
RSF Europe
USER MANUAL
M
icro
DVP- H D
Commercial Division
RSF EUROPE S.A.
18 rue de l’Industrie
L8399 Windhof – G-D LUXEMBOURG
Tél : +352/49 74 20 40
Fax : +352/49 74 20 50
E-MAIL: info@rsf-int.com
Manufacturer
RSF
45, Avenue Marcel Dassault
(Parc de la Plaine)
31500 Toulouse - France
Tél : +33-5/61207909 Fax : +33-5/61800094
•
Chapter 1 : Introduction
Overview
•
Chapter 2 : Basic Operation
Startup
Supported files
Basic Functionality
Configuration
Input Contacts
Picture Display
•
Chapter 3 : advanced Operation
Configuration mode
RS 232 Commands
Table of contents
1. Compact Flash Access
2. Loop Indicator
3. Compact Flash Slot
4. Power Indicator
5. IR Receiver
6. LED Indicators
Chapter 1
Introduction
Overview
8
6
5
3
4
2
1
9
12 13
7. Input Contacts
8. Output Settings Dipswitches
9. Ethernet Port
10. RCA Analog Audio Outputs
11. HDMI Output
12. RS 232 Serial Input
13. VGA Output
14. Y/C Output
15. Video Composite Output
16. SPDIF Audio Output
17. Analog Jack 3.5mm Audio output
18. Power Input
19. Amplified Audio Output
10 11 14 15 16 17
18
19
7
Chapter 2
BASIC OPERATION
Start up
At startup the MicroDVP-HD analyses the files on the CF card and configures the internal electronics
according to the output combinations required.
The behaviour of the device depends of the script files selected.
Supported files
It is important that all videos are encoded with the same settings to avoid any desynchronisation of the
video.
The player accepts the following video formats:
Basic Functionality
Before switching on the device, configure the dipswitches to setup the graphical output.
The MicroDVP-HD video files must be copied on the CF card in a folder named ‘Media’ placed
on the root of the CF card.
If no script files are copied in this ‘Media’ folder, the clips are played looped in alphabetical or-
der.
If the script files are present, a predetermined clip is played looped waiting for an input trigger
to start the playback of another video, refer to the dedicated chapter for more detailed informa-
tion.
The script files can be downloaded from our web site http://rsf-int.com/prodap/content.php?
lan=en&cnt=downloads&sub=logiciels
Formats Codec Extension
MPEG-2 Part-1 MPEG-PS / MPEG-TS .MPG / .TP
MPEG-2 Part-2 MPEG-2 .MPG / .MP2 / .M2V
MPEG-4 Part-2 DivX / XviD .AVI
MPEG-4 Part-10 AVC / H264 .MP4 / .TS
QUICKTIME QUICKTIME .MOV
JPEG JPEG .JPG
Input Contacts
In Simple Play Mode (no script file), the inputs are assigned as follow:
Input 1 = START CLIP001xxx.mpg
Input 2 = START CLIP002xxx.mpg
Input 3 = START CLIP003xxx.mpg
Input 4 = START CLIP004xxx.mpg
Input 5 = START CLIP005xxx.mpg
Input 6 = START CLIP006xxx.mpg
In Play Mode, the inputs can have different assignment, refer to the txt file linked to the script for further
details.
Configuration
Select the graphical output with the 2 first dipswitches available on the rear side of the device.
Select the graphical output resolution with dipswitches 3 & 4.
It is important that all the videos on the CF card are encoded with the same encoding
parameters to avoid video processor reset and screen desynchronisation.
HDMI VGA COMPONENT COMPOSITE
1920x1080p @ 60 Hz
1280x720p @ 60 Hz
1600x1200p @ 60 Hz on VGA or NTSC
1024x768p @ 60 Hz on VGA or PAL
Picture Display
The MicroDVP-HD accepts images in bitmap format.
Max resolution is 1920x1080, 8, 24 and 32 bit accepted.
Display time of the picture can be adjusted with the last character of the picture file name.
1 to 9 seconds are accepted
Chapter 3
ADVANCED OPERATION
Configuration Mode
The MicroDVP-HD confiugration mode enables you to setup several parameters such as OSD and vo-
lume.
To switch the device on Configuration, power it on with input 8 shunt.
The screen will show the configuration mode, you can release the input 8.
Configuration Mode
MAC : 000000000000
Kernel Version : V2.83.01.10
Version : V1.09.10 VS500
Volume : 25<
TZ :+2 YY:10 MM:06 DD:15 hh:07 mm:11 ss:10
OSD : OFF Datalog : OFF
System Message : OFF
Save and Exit
Use input 8 to navigate the menu.
Use buttons 6 & 7 to change the parameter value.
When configuration done, use button 8 to select ‘Save and Exit’ and use button 7 to confirm.
IR remote (delivered in option) can also be used to access this menu.
Each latch on ‘Display’ button toggles the OSD on and off.
Press and hold the ‘Display’ button to enter the configuration mode.
RS 232 Commands
RS 232 script is available in the script list.
Copy the files in the ‘Media’ folder to be able to send RS 232 commands to the MicroDVP-HD.
Parameters are:
9600 Bds
8 bits
No parity
1 Stop bit
Table of commands:
String Command Function HEX codes
0001 PLAY 30 30 30 31 0D
0002 STOP 30 30 30 32 0D
0003 PAUSE 30 30 30 33 0D
0004 REPEAT 30 30 30 34 0D
0005 NEXT 30 30 30 35 0D
0006 VOLUME UP 30 30 30 36 0D
0007 VOLUME DOWN 30 30 30 37 0D
0008 MUTE 30 30 30 38 0D
CLIP001 Play CLIP 1 43 4C 49 50 30 30 31 0D
CLIP002 Play CLIP 2 43 4C 49 50 30 30 32 0D
CLIP003 Play CLIP 3 43 4C 49 50 30 30 33 0D
CLIP004 Play CLIP 4 43 4C 49 50 30 30 34 0D
CLIP005 Play CLIP 5 43 4C 49 50 30 30 35 0D
BOUCLE Play Clip Wait 42 4F 55 43 4C 45 0D
