RTcom DD-D12 User manual

RT Com. Co., Ltd.
1X2 DVI Distribution Amplifier (DD-D12)
1X5 DVI Distribution Amplifier (DD-D15)
User’s Manual

Unpacking
Each DVI Link DVI Distributor package includes the following items;
• DD-D12 / DD-15 DVI LINK DVI Distribution Amplifier Unit x 1
• 5V Power Supply Adapter x 1
• User manual x 1

CONTENTS
Contents 1-1
Description, General Specification 1-2
Environmental and Reliability Specifications 1-3
MainFeatures 1-4
VideoConnection 1-5
MechanicalSpecification 1-6
TechnicalSpecification 1-7
WarrantyInformation 1-8
Troubleshooting 1-9
1-1 Contents

Description , General Specification
.DVI Link DD-D12 and DD-D15, DVI Distribution Amplifiers, allow one digital
video sources to be spilt into multiple digital displays. The built-in amplification
function enables DVI signal distribution without signal loss
ITEM DESCRIPTION DESCRIPTION
Model Name DD-D12 DD-D15
Input Signal DVI (TMDS),Single Link DVI (TMDS),Single Link
Output Signal DVI Single Link , 2port, DVI Single Link , 5port
Resolution VGA / SVGA / XGA /UXGA
480i/p , 720i/p , 1080i/p
VGA / SVGA / XGA /UXGA
480i/p , 720i/p , 1080i/p
Receptacle DC Power Jack
DVI DC Power Jack
DVI
HDCP Support OK OK
Power Consumption DC +5V , 5W Max DC +5V , 5W Max
Dimension 188x123x26 mm 347x123x26 mm
1-2 Description , General Specification

Environmental and Reliability Specifications
1 Operating Conditions
Temperature : 10℃~ 40℃
Humidity : 10% ~ 80%, non-condensing
Altitude : maximum 3,000m
2 Transportation Conditions
Temperature : -25℃~ 60℃
Humidity : 5% ~ 95%, non-condensing
Altitude : maximum 15,000m
3 Storage Conditions
Temperature : -20℃~ 45℃
Humidity : 5% ~ 95%, non-condensing
Altitude : maximum 3,000m
4 Reliability Specifications
MTBF : more than 50,000 hours at 90% confidence level
Reliability specification and items : refer to “Specification
of reliability test for LCD monitor”
1-3 Environmental and Reliability Specifications

Main Features
High Quality Picture - No Signal Loss and Digital Noise Free
Our Distribution Amplifiers are built to deliver the highest quality picture preserving the
native resolutions of the video sources without any signal loss. At the same time, the
digital noises that may affect the picture quality will be eliminated. Due to the nature of
the digital signals and passing through multiple stages of connection when using
distribution amplifiers, it is important to eliminate the digital noises and boost the signal
strength to preserve/enhance the video signal quality.
Signal Amplification for signal reliability and long length signal
transmission.
Our 5V power adapter supplies adequate power to amplify the video signals from the
video source. This is necessary as the overall length from the video source to the
displays is longer when using the distribution amplifiers(distance from the video source
to the distribution amplifier + distance from the distribution amplifier to the display). In
most cases, the overall distance that the DVI signal will need to travel is over 10ft. Due
to the nature of DVI signals, amplification is necessary to warrant the video quality and
reliability. (Without amplification, there may be occasional blackouts or blinking effects)
With this amplification feature, your video display can be extended up to 2300ft using
our fiber optical DVI cables.
HDCP(High-bandwidth Digital Content Protection) Compliant
Our DVI distribution amplifiers are fully HDCP compliant. Many video sources such as
DVD players and Satellite/Cable Receivers are HDCP encrypted. For these video
sources to be displayed correctly, HDCP compliant devices(e.g., TV, DVI Switch,
distribution amplifier) are required.
1-4 Main Features

Video Connection
1. Connect your video source’s DVI output port to the DD-D12/D15’s DVI input port
using standard DVI cables(not included). Make sure all your DVI source and the
displays are turned off before connecting the cables.
2. Connect your DVI display’s DVI input port to DD-D12/D15’s DVI output port. Make
sure your DVI display is turned off before connecting the cables.
3. Plug the 5V power supply into the switch’s power input port.
4. Plug the 5V wall mount power supply into the wall outlet.
5. Turn on your displays.
6. Turn on your video source.
DDC On/Off Switch
DD-D12/D15 are equipped with DDC on/off dip switches in the back for each DVI
output port. DDC communication is required for some video sources and
displays(such as PC and LCD monitor) to correctly display the picture. In most cases,
you will not need to change the factory settings.
When the DDC is turned on for both DVI output ports, some video source may not
work correctly as it sees multiple (conflicting) DDC information. Please turn on DDC
for the video display you would like the video source to recognize as the default
display and at the same time, turn off DDC for all other DVI out ports. In such case,
other DVI ports will transmit video according to the default display setting (DVI port
with DDC turned on)
1-5 Video Connection

Mechanical Specification
Dimensions
DD-D12 : 188x123x26 mm
DD-D15 : 347x123x26 mm
POWER : DC 5V Input
DVI IN : DVI-D Input Signal
DVI OUT CH1~5 : DVI-D Output Signals
DDC SET-UP SW1-5 : DDC on/off dip switches
1-6 Mechanical Specification

Technical Specification
Frequency bandwidth: 1.65 Gbps (Single Link)
Supporting Graphic Resolution: UXGA (1600 X 1200 at up to 75Hz)
(1920 X 1080 at up to 60Hz)
Inputs: DVI-D Female ports
Output: DVI-D Female port( DD-D12/ 2 port, DD-D15/ 5 port).
Power supply: DC 5V, 1.2A Adapter included.
Connector Pin Assignment
DVI-D Input , Output
Part No. Pin No. Description Remarks
1 TMDS DATA 2M
2 TMDS DATA 2P
3 TMDS DATA 2/4 Shield
4 TMDS DATA 4M(N.C)
5 TMDS DATA 4P(N.C)
6 DDC Clock
7 DDC Data
8 N.C
9 TMDS DATA 1M
10 TMDS DATA 1P
11 TMDS DATA 1/3 Shield
12 TMDS DATA 3M(N.C)
13 TMDS DATA 3P(N.C)
14 5V
15 GND
16 Hot Plug Detect
17 TMDS DATA 0M
18 TMDS DATA 0P
19 TMDS DATA 0/5 Shield
20 TMDS DATA 5M(N.C)
21 TMDS DATA 5P(N.C)
22 TMDS DATA Clock Shield
23 TMDS Clock P
DVI-D 29pin
24 TMDS Clock M
1-7 Technical Specification

Warranty Information
1 (One) Year Warranty
RT Com. warrants this DVI Link DD-D12 and DD-D15, DVI Distribution Amplifiers to be
free from defects in workmanship and materials, under normal use and service, for a
period of one (1) year from the date of purchase from RT Com or its authorized resellers.
If a product does not work as warranted during the applicable warranty period, RT Com
shall, at its option and expense, repair the defective product or part, deliver to customer an
equivalent product or part to replace the defective item, or refund to customer the
purchase price paid for the defective product.
All products that are replaced will become the property of RT Com.
Replacement products may be new or reconditioned.
A
ny replaced or repaired product or part has a ninety (90) day warranty or the reminder of
the initial warranty period, whichever is longer.
RT Com. shall not be responsible for any software, firmware, information, or memory data
of customer contained in, stored on, or integrated with any products returned to RT Com
for repair under warranty or not.
Warranty Limitation and Exclusion
RT Com. shall have no further obligation under the foregoing limited warranty if the
product has been damaged due to abuse, misuse, neglect, accident, unusual physical o
r
electrical stress, unauthorized modifications, tampering, alterations, or service other than
by RT Com or its authorized agents, causes other than from ordinary use or failure to
properly use the Product in the application for which said Product is intended.
1-8 Warranty Information
