RTI RSO-1 User manual

RSO-1
Digital to Analog Audio Converter
Reference Guide
The RSO-1 makes it simple to deliver optical digital audio from
devices such as Blu-ray players, media streamers or TVs to an RTI
AD-4x/AD-8x/AD-16x distributed audio system.
1
•Converts Optical Digital signal up to 24bit/192kHz into analog
stereo audio signals.
•Supports all common audio rates between 8kHz and 192kHz.
•The RSO-1 is intended for use only with RTI AD-4x/8x/16x Audio
Distribution Systems - See “NOTE” in No. 1 above.
•RSO-1 receives power via the AD-x Remote Source port - no
power supply is required.
No. Name Function
1 RJ-45
Connector
Plug into Remote Source Input of RTI
AD-4x/AD-8x/AD-16x.
NOTE: Set the AD-x unit’s input switch
to “Remote”. See the AD-x installation
manual for instructions.
2 3” Cable
RJ-45>RJ-45
Included cable used for connection
between RSO-1 and RTI AD-x.
NOTE: Standard Cat-5 cabling may
be used to extend the audio from a
remotely located source.
3 RJ-45 Port Plug included 3” cable into RJ-45 port.
PINOUT:
Pin1: L+, Pin2: L- (GND)
Pin3: +12VDC, Pin6: GND
Pin7: R+, Pin8: R-(GND)
Pin4/5: Not Used
4 RSO-1 Digital to Analog Audio Converter.
5 Toslink Optical
Audio Input
Plug in optical cable and wire to optical
audio source (e.g. Streamer, TV).
2 3 4 5
Installation Notes

•One (1) RSO-1 Optical to Analog Audio Converter
• One (1) 3” Cable
• One (1) Reference Guide
Product Contents
Service & Support
For news about the latest updates, new product information,
and new accessories, please visit our web site at: www.
rticorp.com
For general information, you can contact RTI at:
Remote Technologies Incorporated
5775 12th Ave. E Suite 180
Shakopee, MN 55379
Tel. [phone]
Fax [phone]
[email protected]
Contact RTI
Limited Warranty
RTI warrants new products for a period of three (3) years
from the date of purchase by the original purchaser (end
user) directly from RTI / Pro Control (herein referred to
as “RTI”), or an authorized RTI dealer.
Warranty claims may be initiated by an authorized RTI
dealer using the original dated sales receipt or other
proof of warranty coverage. In the absence of the receipt
of purchase from the original dealer, RTI will provide
warranty coverage extension of six (6) months from the
date code of the product. Note: RTI warranty is limited
to the provisions set forth in this policy and does not
preclude any other warranties oered by third parties
who are solely responsible for those other warranties.
Please visit rticorp.com for the complete warranty policy
and list of exclusions.
If you are encountering any problems or have a question
about your RTI product, please contact RTI Technical Support
for assistance.
Copyright © 2019 • Remote Technologies, Inc.
All rights reserved. 70-210217-20 V1.0
